MOTECK CB3T Operational manual

Features and Options
●Main applications: Furniture, Home care
●Standards features:
●Input: 120V AC 60Hz / 230V AC 50Hz (EI transformer) or 100 ~ 240V AC, 50/60Hz (SMPS)
●Output voltage: 24V DC (EI transformer), 29V DC (SMPS)
●Output rated current: 3.0A per channel for CB3T, 5.0A in total for CB3T-SY
●Max. number of actuators: 3 channels
●Max. number of controls: 1 channel
●Duty cycle: 10%, max. 2 min. continuous operation in 20 min.
●Over-current protection function
●Color: Black
●Electric shock protection level: Class II
●Power cord length: 3000mm
●Certified: CE Marking, EMC Directive 2014/30/EU, LVD Directive 2014/35/EU
Options:
●CB3T (standard version): Without synchronization
●CB3T-SY (synchronous version): Synchronous movement for 2 actuators
1
Control Box
CB3T
www.moteck.com
Product Data Sheet
CB3T is compact control box designed for home bed,
care bed, and other furniture applications. It is able to
drive up to 3 actuators, with the optional synchronization
function. There are two versions in this series as CB3T
and CB3T-SY.

23
Dimensions
I/O Introduction
Actuator #3
Actuator #2
Control #1 Actuator #1
AC power cord
203
111
190
100
71.5
216
Unit: mm

3
Compatibility
Actuator
Version Compatible requirement
Version
Hand control
Compatible requirement
Compatible models
Compatible models
Actuator port
Control port
Wireless option
Version Compatible models Compatible requirement
The feedback signal phase of dual Hall effect sensors from actuators must be “Type A” defined by
Moteck in order to be compatible with CB3T.
notice
Max. 3 channels with
max. 3A current per channel
• Without positioning sensor
• With Moteck F-type DIN plug
CB3T
• Dual Hall effect sensors
• With Moteck F-type DIN plug
• Motor speed ~6000rpm
CB3T-SY Max. 3 channels with
max. 3A current per channel
HI, HJ, HM, H2N, H2Z • Moteck P1 control category
• With Moteck F-type DIN plug
CB3T Max. 1 channel
HR, HDU, DKP4, DP05, DP11 • Moteck P2 control category
• With Moteck F-type DIN plug
HM6R (memory function) • Moteck P2 control category
• With Moteck F-type DIN plug
Max. 1 channel
CB3T-SY
TXA 2.4GHz RF adapter
TBA Bluetooth adapter
• Moteck P1 control category
• With Moteck F-type DIN plug
CB3T
BD61, BD62, FD20, FD40,
FD60, FD61, GD70, MD21,
MK33

4
Socket
F-type plug
8-pin socket 5-pin socket
Hand control socket for Moteck F-type DIN plug
●CB3T (standard version): Moteck control category P1
- 3 drives model - 1 drive model / 2 drives model
●CB3T-SY (synchronous version): Moteck control category P2
- With or without position memory function
Actuator socket for Moteck F-type DIN plug
●Without positioning feedback sensors ●With dual Hall effect sensors
M-
M+
4-pin socket 6-pin socket
GND
M-
M+
Hall 2
VCC
Hall 1
8-pin socket
Note: Connect M+ to “Vdc +” & M- to “Vdc -“ of DC power to extend the motor.
Switch the polarity of DC input to retract it.

5
Operating Guide
For CB3T-SY version (with example of HM 6-key hand control):
● System learning through HM6R hand control
Press button and at the same time until the actuators
start to move. The learning is done after both actuators
move to the fully retracted position.
● Function
①Extend both actuators synchronously.
②Retract both actuators synchronously.
③Press button until LED operating indicator flashes slowly,
and press button , or to store the needed position.
The LED will flash quickly to confirm the positions is stored.
④Drive both actuators toward the stored position
⑤Drive both actuators toward the stored position
⑥Drive both actuators toward the stored position
②
⑥④
①
③
⑤

6
www.moteck.com
Terms of Use
The user is responsible for application suitability of Moteck products. As ongoing improvement process continues, products listed on the Moteck website are subject to change without prior notice. Moteck
reserves the right to terminate the sales or remove any product displayed on the website, or listed in its catalogues.
©2022 Mar. MOTECK. MO-T-0060 Version: 2.2
Output voltage 24: 24V DC
Number of actuators
1: 1 channel
2: 2 channels
3: 3 channels
Input
CB3T -230-24 -2
120: 120V AC
230: 230V AC
CB3T -ISW1-29 -2-SY
Output voltage 29: 29V DC
Option SY: Synchronous version
Number of actuators 2: 2 channels
Input ISW1: Internal SMPS (100~240V AC)
Ordering Key
●CB3T (standard version)
●CB3T-SY (synchronous version)
For more information about operating guide, refer to the respective product data sheets of the control devices connected.
