MP-Man MPF405 User manual

MPF405
User Manual
MP3 PLAYER

2
List
Character--------------------------------------------------------3
Precaution-------------------------------------------------------4
Charge for the player------------------------------------------5
Format player---------------------------------------------------5
Connect to PC--------------------------------------------------6
Key sketch map-------------------------------------------------7
Screen display--------------------------------------------------8
Music mode------------------------------------------------------9
Music mode----------------------------------------------------10
Record mode--------------------------------------------------11
Voice mode---------------------------------------------------12
Setup------------------------------------------------------------13
Setup------------------------------------------------------------14
Tele book-------------------------------------------------------15
Text---------------------------------------------------------------16
Conversion--------------------------------------------------17

3
Character and parameter
SNR: >95dB
Output power: 5mW +5mW(32OHM)
Frequency response: 20Hz~20KHz
Support compacted rate:65Kbps~320Kbps
USB connector: 2.0
Recording format: WAV
Music format: MP3, WAV

4
Precaution
Please check for missing accessories.
The player is without waterproof function, so please
don't place player
near water source environment. or in the condition of
high temperature
place, And don't put liquid bottles on the player or put
the player on a heat
object.
Unexpected disconnection during formatting,
downloading or uploading
process may cause data loss or damage the
player.(Our company don't
have an duty on you data of player. we suggest you
have a copy on other
memory machine if there is important file.)
If there is any matter with the player, please send to
our service center
to repair. Don't disassemble by yourself, avoid
damaging by human.

5
Charge for the player
Please charge player with the adapter which comes
with this player. The charger with not standard voltage
is forbidden to use with the player.
For the quality of the battery, when charging for the
first time, please charge it after battery has been
exhausted.(12 hours for the first charge time will be
better) After the first charge, it will only take 4 hours
to charge it full.
When the player is connected to computer through
USB cable, it will be charged automatically. But we
don't suggest charge in that way for long
time.
Format the player
Please select “FAT” to format the player.
When the player is under formalization or transmitting
files, removed directly is prohibitive.

6
Connect to PC
Use USB cable to connect to computer. After
connected correctly, the screen will display connecting
icon. At this time, you could download or upload data
files and music from the computer
Don't take off the USB cable when your player
connecting with computer
and transmitting data. When removing the player from
the computer, please click the “Safety Remove
Hardware” sign. When the menu appears and the
player show “remove safely”, then you could remove
it.

7
Key sketch map
The functions of each key:
</> Press < to play the previous music file and > to
play the next music file, or press and hold < to
fast backward and > to fast forward play.
+/- To adjust volume when playing state
M Choose confirm, perss and hold to go back to
previous menu
Make sure the ON/OFF switch is in ON position,
press and hold button to boot up the player.
Press and hold the button to poweroff the
player. Then push the ON/OFF switch to OFF
position.

8
Screen display
Play mode
EQ

9
Music mode
The player supports MP3/WMA format and wav file.
After booting up, press </> to select Music, press M to
enter into music playback interface, press button
to start playing music, press button again to pause the
music, press and hold button to stop.
Press < to play the previous music file and > to play
the next music file.
Press and hold < button to fastbackward and > to fast
forward play.
Press + to increase the volume and – to decrease the
volume.
In the state of music play, press M to enter to play
menu, setup in play menu: repeat/equalizer/replay/exit.
In the state of pause music play, press M enter to stop
menu: local folder/delete file/detele all/exit. Press and
hold M to enter to main menu.
A-B repeat
On the state of playing, press M enter into menu,
press M to choose(repeat mode). Press> button to

10
set up the start point , then screen display A-,
press >once again to set up the end point
when displaying icon, it will repeat playing
from A to B when screen is displaying A-B
On the state of repeat, press M to go back to repeat
state.

11
Record mode
Choose record mode in main menu, press M to enter
to state of prepare recording
Press the button to start recording, press it again
to pause, press and hold it to stop and save the
recording file, press and hold M button to exit, or press
and hold M button while recording or pause to save
the recording file and exit to main menu.
Saved recording file can play from Voice mode.

12
Voice Mode
Select Voice menu and press M button to enter. Press
button to start playing sound files, press button
again to pause, press and hold button to stop.
Press < to play the previous file and > to play the next
file.
Press + to increase the volume and – to decrease the
volume.
Press M to enter to playing menu in the state of
playing, it can be setup in playing menu: repeat
mode/exit, short press M in the state of stop playing
and enter to stop menu: root/delete file/delete all/exit,
press and hold M to enter to menu mode.

13
System setup
Choose system setup, press M to enter to
system setup interface.
you can setup parameter of the player in
system setup menu
Time settings
Backlight
Language
Power off
Contrast
Start logo
Power off logo
Memory info.
Default
F/W version
Exit
Time settings:Display/Set system time.
Backlight: light on and user adjust is optional.
Language: English, German, French, Italian,
Spanish, Dutch optional.

14
Power off :Off time and sleep time are optional
Contrast: : Brightness can be adjusted
Start logo: There are two kinds of start logo for your
choice
Power off logo: There are two kinds of start logo for
your choice
Memory info: Check the capacity of player.
Default: It can be renewed to default procedure
F/W version: Check version of the player.
Exit:Return to main menu.

15
Tele book
Choose Tele Book, press M to enter to telebook
interface.
In the telebook interface: browse tel/import tel/export
tel/exit
Browse tel: check the telebook file which browsed to
player, include name, e-mail, telephone, QQ, phone
and fax information, etc. (it can enter to this function
only has telebook file browsed in. System will note: no
file, press and hold M to exit when it can not read
any telefile.)
Import tel: use this function to browse telebook from
computer to player. (There is “Telbook-Ch”tool in the
CD, it can edit telebook.)
Export tel: use this function to export telebook from
player and create to file. User can edit it on computer
using tool.
.

16
Text
After choosingText menu, press M to enter to text
interface.
Player supports TXT format.
M Prees and hold M to return to menu
interface/ short press M to confirm
< Previous page/upwards
> Next page/downwards

17
Conversion
For music conversion, please use MPMANAGER
software supplied in the CD ROM.
This software can be used also for UPDATE of your
player
MPMANAGER manual is included in your CDROM
