MP-Man TS 302 User manual

EN MP3 & Video Player with Touchscreen Control
Instruction Manual
Please read this instruction carefully before the operation
For Model No.
TS302

Page 2 Table Of Contents
English
ÂTable of Contents
THANK YOU.....................................................................................................................................5
Package Contents ..........................................................................................................................5
Features............................................................................................................................................5
CONTROLS AT A GLANCE..............................................................................................................6
GETTING STARTED...........................................................................................................................8
Charging the Battery......................................................................................................................8
Charging with a Computer ...........................................................................................................8
Turning the Player On/Off ..............................................................................................................8
Resetting the Player ........................................................................................................................9
Using the Touchscreen Controls ....................................................................................................9
Installing a microSD Memory Card...............................................................................................9
MAIN MENU.................................................................................................................................. 10
Main Menu Controls .....................................................................................................................10
MUSIC MODE................................................................................................................................ 11
Music Browser Controls................................................................................................................. 11
Now Playing Controls (Music Playback).....................................................................................12
Quick Option Menu ...........................................................................................................13

Page 3 Table Of Contents
English
VIDEO MODE ................................................................................................................................ 15
Movie Browser Controls ................................................................................................................15
Movie Playback Controls .............................................................................................................16
PHOTO MODE ............................................................................................................................... 17
Photo Browser Controls.................................................................................................................17
Photo Viewer Controls .................................................................................................................. 17
Quick Option Menu ...........................................................................................................18
RADIO MODE................................................................................................................................ 19
Radio Tuning Controls...................................................................................................................19
Quick Option Menu ...........................................................................................................20
TEXT MODE ...................................................................................................................................22
Text Browser Controls ....................................................................................................................22
Text Reader Controls.....................................................................................................................22
Quick Option Menu ...........................................................................................................23
EXPLORER MODE ..........................................................................................................................25
Explorer Controls ...........................................................................................................................25
Quick Option Menu ...........................................................................................................25
SETTING MODE ............................................................................................................................. 27

Page 4 Table Of Contents
English
DV MODE ...................................................................................................................................... 29
CAMERA MODE ...........................................................................................................................30
CALENDAR MODE ........................................................................................................................ 31
CLOCK MODE...............................................................................................................................32
MPMANAGER ...............................................................................................................................33
SPECIFICATIONS...........................................................................................................................34
TROUBLESHOOTING & SUPPORT...................................................................................................35

Page 5 Thank You
English
ÂThank You
Congratulations on your purchase of the Video & MP player. This manual is designed to help you easily
set up and begin using your new player right away. Please read this manual carefully and retain it for
future reference.
Package Contents
Please make sure that the items shown below are
included in the package. Should an item be miss-
ing, please contact the local retailer from which you
purchased this product.
Video & MP player
USB Cable
Instruction Manual & Documentation
Professional Stereo Earphones
Protective Pouch
Thispackagemaycontainplasticbagsorothermate-
rials that pose a hazard to children. Be sure to safely
disposeofallpackingmaterialsafteropening.
Features
Integrated flash memory
Intuitive touchscreen control
.” TFT Display
Plays music, video, photos and text
ID and LRC support for song and synchronized
lyric information display
microSD card slot for easy memory capacity
upgrades (microSD card not included)
Integrated FM Radio
Integrated . Mega Pixel Camera
USB . Hi-speed for fast file transfers

Page 6 Controls At A Glance
English
ÂControls at a Glance
Left View
1. Volume Up button <UP>
2. Volume Down button <DOWN>
3. microSD Card slot
Load a microSD memory card here to upgrade
the memory capacity of the player.
Front View
4. Speaker
5. LCD touchscreen
Tap the display with your nger to activate the
on-screen control.
6. Power/Enter button
Press and hold the button to
power the palyer on or off.
<ENTER>
7. LED indicator
8. Menu button <MENU>
Rear View
9. Camera LENS
10. Reset button <RESET>
Bottom View
11. USB Port/Charge
Connect to a computer to transfer media les to
the player.
12. 3.5mm Headphone Jack

Page 7 Controls At A Glance
English
1
2
3
4
5
6
7
8
9
10
12
11

Page 8 Getting Started
English
ÂGetting Started
Charging the Battery
Your player has an integrated rechargeable battery.
Upon initial use, the battery should be charged fully
to ensure optimal performance and battery life.
If the player has not been used in a while, the
battery may need to be recharged overnight (about
 hours).
The battery used in this device may present
a fire or chemical burn if mistreated. Do not
disassemble, incinerate, or heat the battery.
Do not leave the battery in a place subject
to direct sunlight, or in a car with its win-
dows closed.
Do not connect the player to a power source
other than that which is indicated here or on
the label as this may result in the risk of fire
or electric shock.
Charging with a Computer
Your player can be charged through a USB com-
puter connection. Use the supplied USB cable to
connect the player to a high-power USB port of a
computer. The computer must be powered on and
not in sleep mode.
When the player is connected and charg-
ing, a USB symbol will be displayed on the
player’s screen.
Turning the Player On/Off
To turn the player on, press and hold the
<ENTER> button until the screen turns on.
To turn the player off, press and hold the
<ENTER> button until the screen turns off.

Page 9 Getting Started
English
Resetting the Player
Reset the player if it should freeze and not respond
or otherwise malfunction.
1. Disconnect your player if it is connected to a
computer.
2. Use a paper clip to gently press the <RESET>
button located on the rear of the player.
Using the Touchscreen Controls
Your video MP player comes equipped with an
easy-to-use touchscreen which allows access to the
player’s functions. Use your finger tip or the stylus
to tap the area of the screen where a control icon is
displayed. If you tap and hold an icon, it will register
as a continuous button press.
To avoid damaging the screen, do not
touch it with excessive force or with
any object other than your nger or the
stylus. For best response, make sure
your hands are clean before using the
touchscreen controls.
Installing a microSD Memory
Card (optional)
You can upgrade the memory capacity of your
player by adding microSD memory card.
Insert microSD card into the slot as shown in the
illustration below.
This player supports memory cards up
to 2GB in size.

Page 10 Main Menu
English
ÂMain Menu
When you turn on the player, you will see the Main
menu.
From the Main menu, you can access each of your
MP player’s function modes. These modes are:
Music Browse and play music
Video Browse and play movies
Photo Browse and view pictures
Radio Listen to FM radio broadcasts
Text Browse and read text files
Explorer Browse all files
Setting Adjust the player’s options
DV Record video clips
Camera Capture still images
Calendar Launch the calendar program
Clock Set the internal clock display
Main Menu Controls
Each function mode is represented by an icon on
the Main Menu screen. To enter a mode, tap the
icon with your finger.
You may also use the player’s standard controls to
access each mode:
Press the <UP> or <DOWN> button to move the
selection.
Press <ENTER> to confirm.
