MSA ALTAIR io 4 User manual

SStandards Compliance Certifications
ALTAIR io 4
Gas Detection Wearable
Order No.:
Print Spec:
CR:
MSAssafety.com

Contents
1 Device Cleaning 3
1.1 Routine Cleaning 3
1.2 Dust and Dirt Exposure 3
1.3 Chemical Exposure 3
1.4 Water Exposure 3
2 Notices 4
2.1 Bluetooth SIG Statement 4
2.2 Conditions for Safe Usage 4
2.3 Radio Information 4
2.4 Ingress Protection (IP) 5
2.5 Charging 5
3 Certifications and Markings 6
3.1 Certifications 6
3.2 Calibration Certification 7
3.3 Conformance Statement 7
3.4 Markings Contained on Label 7
ALTAIR io 4 2
US

1 Device Cleaning
Cleaning of the device is recommended following environmental exposure, to ensure optimal performance.
1.1 Routine Cleaning
Clean the exterior of the device regularly using only a damp cloth. Do not use cleaning agents, as many contain silicone or
alcohol, which can damage the sensors.
1.2 Dust and Dirt Exposure
Use a dry, soft bristled brush to remove any dust or dirt that has accumulated on the device, especially at the sensor
openings. If there is a buildup of dust or dirt particles remaining in the sensor area after brushing, use a vacuum to remove
remaining particles, but maintain at least a 1/2 inch (1.3 cm) distance from the gas detector.
1.3 Chemical Exposure
If the device is likely to come into contact with aggressive substances, for example acidic liquids or gases that may attack
metals or solvents that may affect polymeric materials, then it is the responsibility of the user to take suitable precautions
that prevent the device from being adversely affected thus ensuring that the type of protection is not compromised.
1.4 Water Exposure
If the device is exposed to water, turn the device sensor side down and gently shake water off the sensor area. Any
remaining water can be removed with a clean dry cloth. In the event that the device is immersed in water, allow the sensor
inlets time to dry before retesting and returning to service. Drying time is dependent upon humidity conditions and the
duration of immersion.
3 ALTAIR io 4
1 Device Cleaning US

2 Notices
WARNING!
Repair or alteration of the device beyond the procedures described in the user guide or by anyone other than a person
authorized by MSA, could cause the unit to fail to perform properly. Use only genuine MSA replacement parts when
performing any maintenance procedures described in the user guide. Substitution of components can seriously impair
performance of the unit, alter intrinsic safety characteristics or void agency approvals.
Failure to follow this warning can result in serious personal injury or death.
2.1 Bluetooth SIG Statement
The design is listed as “Industrial Portable Gas Monitoring Equipment”, Declaration ID D048399
https://launchstudio.bluetooth.com/ListingDetails/97535
2.2 Conditions for Safe Usage
WARNING!
• Combustible Gas Sensor Overrange: When the combustible gas sensors reading reaches its maximum range, to protect
the sensor the device enters a locked alarm state, the sensor shuts down and user-interface displays overrange in the
combustible sensor tile. This state can be reset by turning the device off and on in a fresh-air environment. Keep the
device in the fresh air environment until readings have stabilized and then zero sensors.
• The RF radiation power used to activate the RFID tag antenna shall not exceed 6 Watts for EPL Group I applications or 2
Watts for EPL Group IIC applications.
Failure to follow this warning can result in serious personal injury or death.
2.3 Radio Information
NOTICE
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
– Consult the dealer or an experienced radio/TV technician for help.
Canada: CAN ICES-003(B) / NMB-003(B)
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must accept any interference received, including interference that may
cause undesired operation.
ALTAIR io 4 4
US 2 Notices

You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void
the user's authority to operate the equipment.
English:
This device complies with RSS-210 of the Industry Canada Rules. Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
French:
Ce dispositif est conforme à la norme CNR-210 d'Industrie Canada applicable aux appareils radio exempts de licence. Son
fonctionnement est sujet aux deux conditions suivantes: (1) le dispositif ne doit pas produire de brouillage préjudiciable, et
(2) ce dispositif doit accepter tout brouillage reçu, y compris un brouillage susceptible de provoquer un fonctionnement
indésirable.
FCC ID: P9R-10214785
Contains Transmitter Module FCC ID: XPY2AGQN4NNN or XPYUBX18ZO01, QOQBT121
IC: 324C-10214785
Contains Transmitter Module IC: 8595A-2AGQN4NNN or 8595A-UBX18ZO01, 5123A-BGTBT121
Radio Power Frequency Range
Bluetooth ≤ 8.5 dBm 2.400 GHz - 2.4835 GHz
RFID ≤ 7 dBm 13.56 MHz
Cellular ≤ 23 dBm 699 MHz - 787 MHz
≤ 23 dBm 814 MHz - 862 MHz
≤ 33 dBm 824 MHz - 850 MHz
≤ 33 dBm 880 MHz - 915 MHz
≤ 30 dBm 1.710 GHz - 1.785 GHz
≤ 30 dBm 1.850 GHz - 1.980 GHz
To access the FCC and ISED on the ALTAIR io 4:
(1) Navigate to the Menu.
(2) Select the Device Info option.
(3) Select Regulatory and Legal Info.
2.4 Ingress Protection (IP)
IP ratings do not imply that the equipment will detect gas during and after exposure to those conditions.
Follow the recommendations as described in the ALTAIR io 4 User Guide (P/N 10225884) to determine appropriate
calibration interval and maintenance requirements if exposed to conditions representative of the IP Rating.
The IP rating is self-declared by MSA.
2.5 Charging
Do not charge the device in hazardous areas, as it may create a risk of explosion.
5 ALTAIR io 4
2 Notices US

3 Certifications and Markings
See device label on your specific device for applicable certification markings. Label examples included in this document are
for demonstration purposes only and may not accurately depict the current product certification status.
Information common to all labels:
Manufacturer MSA - The Safety Company
1000 Cranberry Woods Drive
Cranberry Township, PA 16066
USA
Product ALTAIR io 4
Gas Detection Wearable
Serial Number and
Date
On the ALTAIR io 4, refer to the Device Info menu, and select the "About" screen for the
instrument serial number and month/year of manufacture.
The date of manufacture is also encoded in the serial number found on the ALTAIR io 4 label.
3.1 Certifications
Location Certificate Applicable Standards Ambient Temperature
Range
North America
(USA and Canada)
UL Certificate Number: UL 913, 8th Edition
CAN/CSA C22.2 No 60079-0
CAN/CSA C22.2 No. 60079-1
CAN/CSA C22.2 No. 60079-11
CAN/CSA C22.2 No. 61010-1
UL 60079-0
UL 60079-1
UL 60079-11
UL 61010-1
-40°C ≤ Ta ≤ 60°C
ATEX and UK EC-Type Examination
Certificate: DEMKO 21 ATEX
2539
UK Examination Certificate: UL
EN 60079-0:XXXX
EN 60079-1:XXXX
EN 60079-11:XXXX
-40°C ≤ Ta ≤ 60°C
Temperature Code: T4
ALTAIR io 4 6
US 3 Certifications and Markings

Location Certificate Applicable Standards Ambient Temperature
Range
21 UKEx 2141
IEC Certificate Number: IECEx UL
21.0030
IEC 60079-0 X
IEC 60079-1 X
IEC 60079-11 X
-40°C ≤ Ta ≤ 60°C
Temperature Code: T4
3.2 Calibration Certification
All applicable inspections, testing, and calibrations were performed using NIST traceable equipment, where available, in
accordance with MSA’s ISO 9001 Certified Quality System.
3.3 Conformance Statement
MSA certifies that the materials, components, and/or instruments delivered in this shipment conform to all applicable
specifications. The items delivered have been processed through the appropriate approved document-controlled
procedures for receiving, manufacturing, and inspection. The materials, components and/or instruments were inspected,
tested, and calibrated, as applicable, per the associated drawings, standards requirements, and/or specifications, and were
deemed acceptable by appropriate authorized personnel.
3.4 Markings Contained on Label
NOTE: Labels may vary based on geographic location. The label below is an example, and the label on the device may
differ from the example based upon local requirements.
7 ALTAIR io 4
3 Certifications and Markings US

For local MSA contacts, please visit us at MSAsafety.com
