MTS Sensors Temposonics E Series User manual

E-Series CANopen
Operation Manual
Temposonics®
Magnetostrictive Linear Position Sensors

Temposonics®E-Series CANopen
Operation Manual
Table of Contents
1. Introduction..................................................................................................................................................... 3
1.1 Purpose and use of this manual.................................................................................................................................................................. 3
1.2 Used symbols and warnings ....................................................................................................................................................................... 3
2. Safety instructions............................................................................................................................................. 4
2.1 Intended use................................................................................................................................................................................................ 4
2.2 Forseeable misuse....................................................................................................................................................................................... 4
2.3 Installation, commissioning and operation.................................................................................................................................................. 5
2.4 Safety instructions for use in explosion-hazardous areas ........................................................................................................................... 5
2.5 Warranty...................................................................................................................................................................................................... 5
2.6 Return ......................................................................................................................................................................................................... 5
3. Identification.................................................................................................................................................... 6
3.1 Order structure of E-Series EP .................................................................................................................................................................... 6
3.2 Order structure of E-Series EL..................................................................................................................................................................... 7
3.3 Order structure of E-Series EH .................................................................................................................................................................... 8
3.4 Nameplate ................................................................................................................................................................................................... 9
3.5 Approvals .................................................................................................................................................................................................... 9
3.6 Scope of delivery......................................................................................................................................................................................... 9
4. Product description and commissioning ..................................................................................................................10
4.1 Functionality and system design ............................................................................................................................................................... 10
4.2 Styles and installation of E-Series EP........................................................................................................................................................ 11
4.3 Styles and installation of E-Series EL ........................................................................................................................................................ 12
4.4 Styles and installation of E-Series EH........................................................................................................................................................ 13
4.5 Magnet installation.................................................................................................................................................................................... 14
4.6 Electrical connections................................................................................................................................................................................ 17
4.7 Frequently ordered accessories................................................................................................................................................................. 18
5. Operation.......................................................................................................................................................20
5.1 Encoder functionality system description.................................................................................................................................................. 20
5.2 Encoder installations configuration of node parameters............................................................................................................................ 21
5.3 Configuration of process parameters ........................................................................................................................................................ 21
5.4 CANopen Network Management (NMT) .................................................................................................................................................... 22
5.5 Configuration ............................................................................................................................................................................................ 24
5.5.1 Layer Setting Service (LSS) ............................................................................................................................................................. 24
5.5.2 Error control service ........................................................................................................................................................................ 27
5.6 Programming parameter ........................................................................................................................................................................... 28
5.6.1 SDO download ................................................................................................................................................................................. 28
5.6.2 SDO upload...................................................................................................................................................................................... 28
5.6.3 SDO abort ........................................................................................................................................................................................ 29
5.6.4 SDO recall user default parameters: Index 1011 subindex 1............................................................................................................ 29
5.6.5 SDO TPDO communication parameter: Index 1800 (PDO1) to index 1803 (PDO4) ......................................................................... 29
5.6.6 SDO PDO mapping: Index 1A00 to index 1A03................................................................................................................................ 30
5.6.7 SDO store parameter index 1010..................................................................................................................................................... 31
5.6.8 Sensor communication default parameter ....................................................................................................................................... 31
5.6.9 PDO mapping................................................................................................................................................................................... 32
5.6.10 Device properties according to CiA DS 406 ................................................................................................................................... 33
5.6.11 Cam Channels................................................................................................................................................................................ 34
5.7 Process data.............................................................................................................................................................................................. 36
5.7.1 Synchronous mode.......................................................................................................................................................................... 36
5.7.2 Asynchronous mode........................................................................................................................................................................ 36
5.7.3 PDO message format....................................................................................................................................................................... 36
5.7.4 PDO transmission time consideration.............................................................................................................................................. 37
5.7.5 Cam switch ...................................................................................................................................................................................... 37
6. Maintenance and troubleshooting .........................................................................................................................38
7. Removal from service / dismantling.......................................................................................................................39
8. Technical data.................................................................................................................................................40
9. Annex ...........................................................................................................................................................42

Temposonics®E-Series CANopen
Operation Manual
3
1.2 Used symbols and warnings
Warnings are intended for your personal safety and for avoidance
of damage to the described product or connected devices. In this
documentation, safety information and warnings to avoid danger
that might affect the life and health of operating or service personnel
or cause material damage are highlighted by the preceding pictogram,
which is defined below.
1. Introduction
1.1 Purpose and use of this manual
The content of this technical documentation and of its various annexes
is intended to provide information on mounting, installation and
commissioning by qualified automation personnel 1 or instructed
service technicians who are familiar with the project planning and
dealing with Temposonics®sensors.
Before starting the operation of Temposonics®sensors read this
documentation thoroughly and follow the safety information.
Keep the manual for future reference!
Symbol Meaning
NOTICE
This symbol is used to point to situations
that may lead to material damage, but not
to personal injury.
1/ The term qualified technical personnel characterizes persons who:
• are familiar with the safety concepts of automation technology applicable to the
particular project,
• are competent in the field of EMC,
• have received adequate training for commissioning and service operations
• are familiar with the operation of the device and know the information required for
correct operation provided in the product documentation.

Temposonics®E-Series CANopen
Operation Manual
4
2.1 Intended use
This product may be used only for the applications defined under
item 1 in conjunction with the third-party devices and components
recommended or approved by MTS Sensors. As a prerequsite of
proper and safe operation, the product requires correct transport,
storage, mounting and commissioning and must be operated with
utmost care.
1.The sensor systems of all Temposonics®series are intended
exclusively for measurement tasks encountered in industrial,
commercial and laboratory applications. The sensors are
considered as system accessories and must be connected to
suitable evaluation electronics, e.g. a PLC, IPC, indicator or other
electronic control unit.
2. Safety instructions
Forseeable misuse Consequence
Wrong sensor connection The sensor does not work
properly or will be destroyed
Operate the sensor out off the
operating temperature
No signal output
The sensor can be damaged
Power supply is out of the
defined range
Signal output is wrong /
no signal output /
the sensor will be damaged
Position measurement is
influenced by an external
magnetic field
Signal output is wrong
Cables are damaged
Short circuit – the sensor can
be destroyed / sensor does not
respond
Spacers are missing /
are installed in a wrong order Error in position measurement
Wrong connection
of ground / shield
Signal output is disturbed
The electronics can be damaged
Use of a magnet that is not
certified by MTS Sensors Error in position measurement
Do not reprocess the sensor afterwards.
 The sensor might be damaged.
Do not step on the sensor.
 The sensor might be damaged.
2.2 Forseeable misuse

Temposonics®E-Series CANopen
Operation Manual
5
2.3 Installation, commissioning and operation
The position sensors must be used only in technically safe condition.
To maintain this condition and to ensure safe operation, installation,
connection and service work may be performed only by qualified
technical personnel.
If danger of injury to persons or of damage to operating equipment
is caused by sensor failure or malfunction, additional safety measures
such as plausibility checks, limit switches, EMERGENCY STOP
systems, protective devices etc. are required. In the event of trouble,
shut down the sensor and protect it against accidental operation.
Safety instructions for commissioning
To maintain the sensor operability, it is mandatory to follow the
instructions given below.
1. Protect the sensor against mechanical damage during installation
and operation.
2. Do not open or dismantle the sensor.
3. Connect the sensor very carefully and pay attention to the polarity
of connections and power supply.
4. Use only approved power supplies.
5. It is indispensable to ensure that the specified permissible limit
values of the sensor for operating voltage, environmental
conditions, etc. are met.
6. Check the function of the sensor regularly and provide
documentation of the checks.
7. Before system switch-on, ensure that nobody’s safety is
jeopardized by starting machines.
2.4 Safety instructions for use in explosion-hazardous areas
The sensor is not suitable for operation in explosion-hazarded areas.
2.5 Warranty
MTS Sensors grants a warranty 2 period for the Temposonics®position
sensors and supplied accessories relating to material defects and
faults that occur despite correct use in accordance with the intended
application 2. The MTS Sensors obligation is limited to repair or
replacement of any defective part of the unit. No warranty can be taken
for defects that are due to improper use or above average stress of the
product, as well as for wear parts. Under no circumstances will MTS
Sensors accept liability in the event of offense against the warranty
rules, no matter if these have been assured or expected, even in case
of fault or negligence of the company.
MTS Sensors explicitly excludes any further warranties. Neither
the company’s representatives, agents, dealers nor employees are
authorized to increase or change the scope of warranty.
2.6 Return
For diagnostic purposes, the sensor can be returned to MTS Sensor
Technologie GmbH & Co. KG. Any shipment cost will be borne by
the sender 2. For a corresponding form, see chapter “9. Annex” on
page 42.
2/ See also applicable MTS Sensors sales and supply conditions, e.g. under www.mtssensors.com

Temposonics®E-Series CANopen
Operation Manual
6
3.1 Order structure of E-Series EP
Temposonics®order code
a Sensor model
E P Profile
b Design
0Without position magnet
d Connection type
D 3 4 5 pin M12
f Output
C 3 04CANopen
C 4 04CANopen (duo terminator)
e Operating voltage
1+24 VDC (−15 / +20 %)
Optional:
j Magnet number for multi position measurement
Z0 2 2 magnets
i Type
1Standard
h Resolution
410 µm
520 µm
g Baud rate
11000 kBit/s
2500 kBit/s
3250 kBit/s
4125 kBit/s
c Stroke length
X X X X M 0050…2540 mm
X X X X U002.0…100.0 in.
Standard stroke length (mm)*
Stroke length Ordering steps
50 … 500 mm 25 mm
500…2540 mm 50 mm
Standard stroke length (in.)*
Stroke length Ordering steps
2 … 20 in. 1.0 in.
20…100 in. 2.0 in.
.
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22
E P 0 D 3 4 1C1
a b c d e fg h i j
optional
3. Identification
*/ Non standard stroke lengths are available; must be encoded in 5 mm / 0.1 in. increments

Temposonics®E-Series CANopen
Operation Manual
7
3.2 Order structure of E-Series EL
Temposonics®order code
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22
E L 0 D 3 4 1C1
a b c d e fg h i j
optional
*/ Non standard stroke lengths are available; must be encoded in 5 mm / 0.1 in. increments
a Sensor model
E L Low profile
b Design
0Without position magnet
d Connection type
D 3 4 5 pin M12
f Output
C 3 04CANopen
C 4 04CANopen (duo terminator)
e Operating voltage
1+24 VDC (−15 / +20 %)
g Baud rate
11000 kBit/s
2500 kBit/s
3250 kBit/s
4125 kBit/s
c Stroke length
X X X X M 0050…2540 mm
X X X X U002.0…100.0 in.
Standard stroke length (mm)*
Stroke length Ordering steps
50 … 500 mm 25 mm
500…2540 mm 50 mm
Standard stroke length (in.)*
Stroke length Ordering steps
2 … 20 in. 1.0 in.
20…100 in. 2.0 in.
.
Optional:
j Magnet number for multi position measurement
Z022 magnets
i Type
1Standard
h Resolution
410 µm
520 µm

Temposonics®E-Series CANopen
Operation Manual
8
3.3 Order structure of E-Series EH
Temposonics®order code
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22
E H 1C1
a b c d e fg h i j
optional
a Sensor model
E H Rod
b Design
Model EH rod-style sensor with housing 1.4305 (AISI 303)
rod, material 1.4301 (AISI 304)
KFlange M18×1.5-6g / rod Ø 7 mm
LFlange ¾"-UNF-3A / rod Ø 7 mm
Model EH rod-style sensor with housing 1.4305 (AISI 303)
rod, material 1.4306 (AISI 304L)
MFlange M18×1.5-6g / rod Ø 10 mm
SFlange ¾"-UNF-3A / rod Ø 10 mm
Model EH rod-style sensor with housing 1.4404 (AISI 316L)
rod, material 1.4404 (AISI 316L)
FFlange ¾"-UNF-3A / rod Ø 10 mm
WFlange M18×1.5-6g / rod Ø 10 mm
f Output
C 3 04CANopen
C404CANopen (duo terminator)
e Operating voltage
1+24 VDC (−15 / +20 %)
g Baud rate
11000 kBit/s
2500 kBit/s
3250 kBit/s
4125 kBit/s
d Connection type
D 3 4 5 pin M12
E H 1 2 m PUR cable (Part no. 530 166)
E H 2 5 m PUR cable (Part no. 530 166)
E H 3 10 m PUR cable (Part no. 530 166)
E H 4 15 m PUR cable (Part no. 530 166)
E T 1 2 m Teflon®cable (Part no. 530 157)
E T 2 5 m Teflon®cable (Part no. 530 157)
E T 3 10 m Teflon®cable (Part no. 530 157)
E T 4 15 m Teflon®cable (Part no. 530 157)
c Stroke length
X X X X M 0050…2540 mm
X X X X U002.0…100.0 in.
Standard stroke length (mm)*
Stroke length Ordering steps
50 … 500 mm 5 mm
500 … 750 mm 10 mm
750…1000 mm 25 mm
1000…2540 mm 50 mm
Standard stroke length (in.)*
Stroke length Ordering steps
2… 20 in. 0.2 in.
20… 30 in. 0.4 in.
30… 40 in. 1.0 in.
40…100 in. 2.0 in.
Optional:
j Magnet number for multi position measurement
Z0 2 2 magnets
i Type
1Standard
h Resolution
410 µm
520 µm
*/ Non standard stroke lengths are available; must be encoded in 5 mm / 0.1 in. increments
.

Temposonics®E-Series CANopen
Operation Manual
9
3.4 Nameplate
EP00600MD341C304241Z02
FNr.: 1516071
Sensor model
Stroke length (e.g. 600 mm)
Connection type
Output
Baud rate
Resolution
Multi position measurement
Part No.
Serial number
3.5 Approvals
CE certification, UL/cUL certified*
3.6 Scope of delivery
E-Series EP (profile)
Sensor, 2 mounting clamps up to 1250 mm (49 in.) +
1 clamp for each 500 mm (20 in.)
E-Series EL (low profile)
Sensor, 2 mounting clamps up to 1250 mm (49 in.) +
1 clamp for each 500 mm (20 in.)
E-Series EH (rod)
Sensor and O-ring
Fig. 1: Example of nameplate
3/ Only sensors with connector outlets are UL/cUL certified

Temposonics®E-Series CANopen
Operation Manual
10
4.1 Functionality and system design
Product designation
• Position sensor Temposonics®E-Series
Construction serie
• Temposonics®E-Series EP/EL/EH
• Stroke length: EP 50…2540 mm (2…100 in.)
EL 50…2540 mm (2…100 in.)
EH 50…2540 mm (2…100 in.)
• Output signal: CANopen
Application
The Temposonics®sensor is used for measurement and conversion
of the length (position) variable in the fields of automated systems and
mechanical engineering.
Principle of operation and system construction
For position measurement, the absolute, linear Temposonics®position
sensors make use of the properties offered by the specially designed
magnetostrictive waveguide. Inside the sensor a torsional strain pulse
is induced in the waveguide by momentary interaction of two magnet-
ic fields. The interaction between these two magnetic fields produces
a strain pulse, which is detected by the converter at the sensor elec-
tronics housing. One field is produced by a moving position magnet,
which travels along the sensor rod with the waveguide inside. The oth-
er field is generated by a current pulse applied to the waveguide. The
position of the moving magnet is determined precisely by measuring
the time-of-flight between the application of the current pulse and the
arrival of the strain pulse at the sensor head. The result is a reliable
position measurement with high accuracy and repeatability.
4. Product description and commissioning
4
5
3
1
Measurement cycle
1Current pulse generates magnetic field
2Interaction with position magnet field
generates torsional strain pulse
3Torsional strain pulse propagates
4Strain pulse detected by converter
5Time-of-flight converted into position
Sensing element (Waveguide)
Position magnet (Magnetic field)
Torsional strain pulse converter
2
Fig. 2: Principle of operation: Time-of-flight based magnetostrictive position sensing principle
Modular mechanical and electronic construction
• The sensor housing (rod/profile) protects the sensor element.
• The sensor electronics housing, a rugged aluminum/stainless steel
construction, contains the complete electronic interface with
active signal conditioning.
• The external position magnet is a permanent magnet. Mounted
on the mobile machine part, it travels along the sensing element
and triggers the measurement through the housing wall.
• Depending on the type, the sensor is connected to the controller
via a plug.
• The sensor can be connected directly to a control system.
Its electronics generates a strictly position-proportional signal
output between zero and end position.

Temposonics®E-Series CANopen
Operation Manual
11
4.2 Styles and installation of E-Series EP
Magnet
50 (2)
68 (2.68)
Null zone
13
(0.52)
14.6
(0.57)
Stroke length
50…2540
(2…100)
Dead zone
68
(2.68)
31
(1.22)
43.4
(1.71)
35.6 (1.4)
Sensor electronics housing
48.8
(1.92)
35
(1.38)
Controlling design dimensions are in millimeters and measurements in ( ) are in inches
Unless otherwise stated, apply to the general tolerances according to DIN ISO 2768-m
Installation of EP
The position sensor can be installed in any position. Normally, the
sensor is firmly installed and the position magnet is fastened to
the mobile machine part. Thus it can travel along the sensor rod
contactlessly.
The sensor is fitted on a flat machine surface using mounting clamps
(Fig. 4). A length-dependent number of these clamps are delivered
with the sensor and must be distributed over the profile at regular
distances.
For fastening, we recommend using M5×20 screws according to
DIN 6912 that should be tightened with a maximum fastening torque
of 5 Nm.
Adjustable mounting clamps
M5×20
max. 5 Nm
Fig. 3: Temposonics®E-Series EP
NOTICE
Do not mount the sensors in the area of strong magnetic or electric
noise fields. Take care to mount the sensor in an axially parallel
position to avoid damaging the carriage, magnet and sensor rod.
The sensor is isolated from the machine ground. For this reason,
grouding via grounding lug on the sensor electronics housing is
indispensable (Fig. 5).
Fig. 4: Mounting clamps with cylinder screw M5×20, fastening torque ≤ 5 Nm
on a Temposonics®E-Series EP sensor with U-magnet
Fig. 5: Grounding profile sensor

Temposonics®E-Series CANopen
Operation Manual
12
4.3 Styles and installation of E-Series EL
Magnet
Stroke length
50…2540
(2…100)
Dead zone
68
(2.68)
12
(0.47)
13
(0.51)
27
(1.06)
2
(0.08 ) 14.6
(0.57)
35.6 (1.4)
68 (2.68)
50 (2)
17
(0.67)
Null zone
35
(1.38)
Sensor electronics housing
45
(1.77)
Controlling design dimensions are in millimeters and measurements in ( ) are in inches
Unless otherwise stated, apply to the general tolerances according to DIN ISO 2768-m
Installation of EL
The position sensor can be installed in any position. Normally, the
sensor is firmly installed and the position magnet is fastened to
the mobile machine part. Thus it can travel along the sensor rod
contactlessly.
The sensor is fitted on a flat machine surface using the mounting
clamps (Fig. 7). A length-dependent number of these clamps are
delivered with the sensor and must be distributed over the profile at
regular distances.
For fastening, we recommend using M5×20 screws according to
DIN 6912 that should be tightened with a maximum fastening torque
of 5 Nm.
Adjustable mounting clamps
M5×20
max. 5 Nm
Fig. 6: Temposonics®E-Series EL
NOTICE
Do not mount the sensors in the area of strong magnetic or electric
noise fields. Take care to mount the sensor in an axially parallel
position to avoid damaging the carriage, magnet and sensor rod.
The sensor is isolated from the machine ground. For this reason,
grounding via grounding lug on the sensor electronics housing is
indispensable (Fig. 5).
Fig. 7: Mounting clamps with cylinder screw M5×20, fastening torque ≤ 5 Nm
on a Temposonics®E-Series EL sensor with block magnet

Temposonics®E-Series CANopen
Operation Manual
13
4.4 Styles and installation of E-Series EH
Controlling design dimensions are in millimeters and measurements in ( ) are in inches
Unless otherwise stated, apply to the general tolerances according to DIN ISO 2768-m
Fig. 8: Temposonics®E-Series EH
Magnet
Ø 34
(Ø 1.34)
AF 34
Sensor electronics housing
48
(1.89)
13
(0.51)
Dead zone
63.5
(2.5)
Stroke length
50…2540
(2…100)
8
(0.31)
Sensor rod
Type: Ø 7 ± 0.10 (Ø 0.28 ± 0.01)
Type: Ø 10 ± 0.13 (Ø 0.39 ± 0.01)
Null zone
51
(2)
PUR cable: 24.3 (0.96)
Teflon®cable: 26 (1.02)
Cable length
60
(2.36)
14
(0.55)
Threaded flange
Type: M18×1.5−6g
or
Type: ¾"-16 UNF−3A
5 pin
Installation of EH
The rod-style version has been developed for direct stroke
measurement in a fluid cylinder.
Mounted on the bottom of the piston, the ring magnet travels over
the rod contactlessly and marks the position exactly through the
rod wall – independent of the hydraulic fluid.
Hydraulics sealing
The sealing via a 15.3 × 2.2 O-ring in the undercut is possible (Fig. 9).
A screw hole based on ISO 6149-1 (Fig. 10) must be provided.
• The flange contact surface must be seated completely on the
cylinder mounting surface.
• The cylinder manufacturer determines the pressure-resistant gasket
(copper gasket, O-ring, etc.).
• The position magnet should not grind on the rod.
• The plunger borehole (Ø 10 mm rod: ≥ Ø 13 mm (≥ Ø 0.52 in.) /
Ø 7 mm rod: ≥ Ø 10 mm (≥ Ø 0.4 in.)) depends on the pressure
and piston speed.
• The peak pressure should not be exceeded.
• Protect the sensor rod from wear using suitable constructive
measures.
With M12 connector
With cable outlet
Fig. 10: Notice for threaded flange M18×1.5-6g lean on DIN ISO 6149-1
Thread
(d1×P) d2d3d4d5L1L2L3L4Z°
M18×1.5 55 mm 13 mm /
10 mm 24.5 mm 19.8 mm 2.4 mm 28.5 mm 2 mm 26 mm 15°
This dimension applies
when tap drill cannot
pass through entire boss
Thread (d1×P)
(Reference size)
Applies at Ød4
A
R 0.4 max.
L3
L1
45° ±5°
Ra 3.2
Ød
5
Ra 3.2
Ød
2
Ra 0.2
Ra 0.1
Pitch diameter
Z°
L
2
L
4
A
0.2 A0.2 A
Ød
3
Fig. 9: Sealing via O-ring 15.3 × 2.2 in the flange undercut
max.
50 Nm
Sealing via O-ring
15.3 × 2.2
(0.6 × 0.09)
in the flange undercut

Temposonics®E-Series CANopen
Operation Manual
14
4.5 Magnet installation
Mounting the ring magnet
Install the magnet using non-magnetizable material for mounting
device, screws, spacers etc.
• Max. permissible surface pressure: 40 N/mm2
• Max. fastening torque for M4 screws: 1 Nm; use washers,
if necessary
• Minimum distance between position magnet and any magnetic
material have to be 15 mm (0.6 in.).
If no other option exists and magnetic material is used, observe the
specified dimensions (Fig. 11)
Fig. 11: Installation with magnetizable material
SW 46
Anziehmoment
≤ 50 Nm
> 30
Magnet
Empfohlene
Hydraulik-
abdichtung
Abb. 10
Einbau mit unmagnetischem Material
Magnet
nicht-magnetisbare
Distanzscheibe
> 15
min. 5
Abb. 11
Einbau mit magnetisierbarem Material
Abb. 12
Beispiel Sensorunterstützung
Alternative
Hydraulikdichtung
O-Ring 15,3 x 2,2
Sensor-Druckgehäuse
Stab mir Flansch
bleibt im Zylinder
Ringmagnet
Basissensor
Elektronikkopf mit Messeelement
austauschbar über zwei M4 Schrauben
mit 2,5 mm Innensechkant,
Anziehmoment max. 1,3 Nm
U-magnet
Sensor rod
Non-magnetic fixing clip (561 481)
3 ±1
(0.12 ±0.04)
M4
1
2
Fig. 12: Mounting device for U-magnet
Fig. 13: Example of sensor support
Mounting the U-magnet
Using a non-magnetizable mounting device is mandatory. The magnet
must not grind on the sensor rod. Alignment errors are compensated
via the air gap.
• Max. surface pressure: 40 N/mm2
• Max. fastening torque for M4 screws: 1 Nm; use washer,
if necessary
Large stroke lengths from 1 meter (39 in.)
Horizontally installed sensors should be supported mechanically
at the rod end. Longer rods require evenly distributed mechanical
support over the entire length. In this case (Fig. 13) the sensor rod
can be supported by fixing clips and an U-magnet can be used for
measurement.
NOTICE
A maximum permissible air gap of 3 mm (0.12 in.) must not be
exceeded.
Controlling design dimensions are in millimeters and measurements in ( ) are in inches
Null zone
≥ 5 (≥ 0.2)
Position
magnet
Non-magnetic
spacer
Magnetic
material
≥ 15 (≥ 0.6)
U-magnet
Non-magnetizable
entrainment device

Temposonics®E-Series CANopen
Operation Manual
15
NOTICE
On all sensors, the areas left and right of the active stroke length are provided for mounting and damping of the measuring signal.
They should not be used for measurement, but the active stroke length can be exceeded.
Active measuring range
The technical data of each sensor is checked as well as documented and the active stroke length (useful electrical stroke) with its start and end
position is adjusted during final inspection and testing.
Temposonics®E-Series EP with U-magnet Temposonics®E-Series EP with magnet slider
68
(2.68)
35
(1.38)
35
(1.38)
Stroke length
Start position
Reference edge of mounting
68
(2.68)
35
(1.38)
19
(0.75)
Stroke length
Start position
Reference edge of mounting
Temposonics®E-Series EP with block magnet Temposonics®E-Series EL with magnet slider
68
(2.68)
35
(1.38)
35
(1.38)
Stroke length
Start position
Reference edge of mounting
68
(2.68)
35
(1.38)
19
(0.75)
Stroke length
Start position
Reference edge of mounting
Temposonics®E-Series EL with block magnet Temposonics®E-Series EH with ring or U-magnet
68
(2.68)
35
(1.38)
35
(1.38)
Stroke length
Start position
Reference edge of mounting
63.5
(2.5)
51
(2.01)
51
(2.01)
Start position
Reference edge of mounting
Stroke length
Fig. 14: Active measuring range
Controlling design dimensions are in millimeters and measurements in ( ) are in inches

Temposonics®E-Series CANopen
Operation Manual
16
Multi position measurement
The minimum distance between the magnets is 75 mm (3 in.).
Temposonics®E-Series EP with U-magnet Temposonics®E-Series EP with block magnet
75
(3)
75
(3)
Temposonics®E-Series EP with magnet slider S & V Temposonics®E-Series EL with magnet slider S & V
75
(3) 75
(3)
Temposonics®E-Series EL with block magnet Temposonics®E-Series EH with ring or U-magnet
75
(3)
75
(3)
Fig. 15: Minimum distance for multi position measurement
Controlling design dimensions are in millimeters and measurements in ( ) are in inches

Temposonics®E-Series CANopen
Operation Manual
17
Controlling design dimensions are in millimeters and measurements in ( ) are in inches
4.6 Electrical connections
Placement of installation and cabling have vital influence on the sensor
EMC (electromagnetic compatibility). Hence correct installation of
this active electronic system and the EMC of the entire system must
be ensured by using suitable metal connectors, shielded cables
and grounding. Overvoltages or faulty connections can damage its
electronics despite protection against wrong polarity.
NOTICE
Never connect/disconnect the sensor when voltage is applied.
Instructions for connection
• Use low-resistance twisted pair and shielded cables and connect
the shield to ground externally via the controller equipment.
• Keep control and sign leads separate from power cables and
sufficiently far away from motor cables, frequency inverters,
valve lines, relays, etc.
• Use only connectors with metal housing and connect the shielding
to the connector housing.
• Keep the connection surface at both screening ends as large
as possible.
• Keep all non-shielded leads as short as possible.
• Keep the earth connection as short as possible with a large
cross section. Avoid ground loops.
• With potential differences between the ground connection of the
machine and the electronics, no compensating current flowing
over the shield is allowed. We recommend using an equipotential
bonding conductor with large cross-section or a cable with separate
dual shielding and connecting the shields only at one end.
• Use only stabilized power supplies and make sure that the specified
connecting values are met.
• Install potential compensating leads with large cross section, or use
cables with separate double shielding, and connect only one end of
the shield.
• Use only stabilized power supplies in compliance with the specified
connecting values.
NOTICE
The E-Series EP and EL sensors must be grounded via grounding
lug on the sensor electronics housing (Fig. 5).
Connection types
Connect the sensor directly to the control system, indicator or other
evaluating systems as follows:
D34
M12 A-coded Pin Function
1
2
3
4
5
1 Shield
2 +24 VDC (−15 / +20 %)
3 DC Ground (0 V)
4 CAN_H
5 CAN_L
Cable outlet (EH model only)
Cable color Function
GY CAN_L
PK CAN_H
YE –
GN –
BN +24 VDC (−15 / +20 %)
WH DC Ground (0 V)

Temposonics®E-Series CANopen
Operation Manual
18
Position magnets
M5
20
(0.79)
43
(1.69)
14
(0.55)
40 (1.58)
18°
25.3
(1)
M5
40 (1.58)
18°
57 (2.24) 14
(0.55)
25.3 (1)
49 (1.93)
Ø 32.8
(Ø 1.29)
Ø 23.8
(Ø 0.94)
Ø 13.5
(Ø 0.53)
Ø 4.3
(Ø 0.17)
60°
140°
3
(0.12)
7.9
(0.31)
19,5 (0.77)
1,5
(0.06)
33 (1.3)
14
(0.55)
20,5
(0.81)
14,9 (0.59)
8 ± 2 (0.31 ± 0.08)
Space sensor element
Ø 4.3
(Ø 0.17)
Magnet slider S
Part no. 252182
Magnet slider V
Part no. 252184
U-magnet OD33
Part no. 251416-2
Block magnet
Part no. 403448
For: EP and EL
Material: GFK, magnet hard ferrite
Weight: Ca. 35 g
Operating temperature: −40…+75 °C
(−40…+167 °F)
For: EP and EL
Material: GFK, magnet hard ferrite
Weight: Ca. 35 g
Operating temperature: −40…+75 °C
(−40…+167 °F)
For: EP and EH
Material: PA ferrite
Weight: Ca. 11 g
Surface pressure: max. 40 N/mm2
Fastening torque for M4 screws:
Max. 1 Nm
Operating temperature: −40…+105 °C
(−40…+221 °F)
For: EP, EL and EH
Material: hard ferrite
Weight: Ca. 20 g
Operating temperature: −40…+75 °C
(−40…+167 °F)
Fastening torque for M4 screws:
Max. 1 Nm
Position magnets
Ø 32.8
(Ø 1.29)
Ø 23.8
(Ø 0.94)
Ø 13.5
(Ø 0.53)
Ø 4.3
(Ø
0.17)
7.9
(0.31)
Ø 25.4
( Ø 1)
Ø 13.5
(
Ø 0.53) 7.9
(0.31)
Ring magnet OD33
Part no. 201542-2
Ring magnet OD25,4
Part no. 400533
For: EH
Material: PA ferrite GF20
Weight: Ca. 14 g
Surface pressure: max. 40 N/mm2
Fastening torque for M4 screws:
Max. 1 Nm
Operating temperature: −40…+105 °C
(−40…+221 °F)
For: EH
Material: PA ferrite
Weight: Ca. 10 g
Surface pressure: Max. 40 N/mm2
Operating temperature: −40…+105 °C
(−40…+221 °F)
Additional options available in our Accessories Guide 551444)
Controlling design dimensions are in millimeters and measurements in ( ) are in inches
4.7 Frequently ordered accessories – Additional options available in our Accessories Guide 551444

Temposonics®E-Series CANopen
Operation Manual
19
Cable connector Connection accessories
~53
(~ 2.09)
Ø 20
(Ø 0.79)
38
(1.5)
20
(0.79)
~ 57
(~2.25)
45
(1.77)
56
(2.2)
48.4
(1.91)
Ø 14.5
(Ø 0.57)
Female, straight, 5 pin
Part no. 370677
Female, angled, 5 pin
Part no. 370678
CANopen T-Connector, M12, 5 pin
Part no. 370691
CANopen bus terminator
Part no. 370700
Housing: GD-Zn, Ni / IP67
Termination: Screw; max. 0.75 mm²
Contact insert: CuZn
Cable Ø: 4…8 mm
Fastening torque: Max. 0.6 Nm
Housing: GD-Zn, Ni / IP67
Termination: Screw; max. 0.75 mm2
Contact insert: CuZn
Cable Ø: 5…8 mm
Fastening torque: Max. 0.6 Nm
Selfcuring coupling nut
2 × cable connector female
1 × cable connector male shielded
Housing: PUR
Contact insert: Au
Controlling design dimensions are in millimeters and measurements in ( ) are in inches

Temposonics®E-Series CANopen
Operation Manual
20
CANopen bus interface
CANbus (Controller Area Network) is designed for high-speed data
exchange at machine level. CAN is a vendor independent open fieldbus
system, based on standard ISO 11898. CAN specifies the functional
and technical parameters with which the intelligent digital automation
devices can be networked via a master-slave serial link by using a
communication profile. Protocol architecture of functional and
applications data is oriented to the OSI reference model (ISO 7498).
Bus technology is administrated and developed by the user
organisation CiA (CAN in Automation).
5.1 Encoder functionality system description
Temposonics®sensors are linear transducers and are suitable for a
CANopen protocol network. That is a CAN based higher layer protocol.
The sensor can be used as a CAN bus slave in networks with the
CANopen data protocol (CiA Standard DS 301 V4.02), the encoder
profile DS 406 V3.1 and the LSS Service DS 305 V2.1.1.
The sensor is performing Class C2 functionality.
Network Management (NMT) – Slave
The NMT state machine defines the communication behavior of the
CANopen device.
Layer Setting Services (LSS) DS 305
Layer Setting Services (LSS) are used in order to configure the sensor
in terms of node ID and / or the baud rate. The sensor can be switched
to LSS configuration mode either globally or selectively.
Service Data Object (SDO)
SDO messages are used for reading and writing access to all entries
of the object dictionary. SDOs are used for device configuration in the
first place.
Identity objects
Identity including vendor ID, product code, revision number and
serial number.
Variable Process Data Object (PDO) mapping
The real-time data transfer of position, velocity and limit switch states
is performed by PDO messages. Data is transmitted within four
TPDO’s (transmit PDO) and each with a maximum 8 byte wide data
block. Variable PDO mapping can be configured via SDO messages.
Special Function Object (SFO) sync object
The sync object is broadcasted periodically by the synchronisation
device to all application devices. Synchronous PDOs will be
transmitted to the controller after receiving the sync message.
Emergency object
Emergency messages are triggered by the occurrence of a device
internal fatal error situation and are transmitted from the application
device concerned to the other devices with highest priority.
This makes them suitable for interrupting type error alerts.
Nodeguard object
The nodeguard object is used to monitor the whole network state.
The nodeguard object is sent cyclically to detect the sensor that the
controller works well. On a missing nodeguard object (i.e. controller
stopped) the sensor automaticly can stop PDO data transmission to
reduce the busload.
Heartbeat function
Instead of the node-guarding the heartbeat-function can be used.
The Producer-Heartbeat-Time defines the time frame in which
a new heartbeat message is sent.
Event timer
The event timer defines the asynchronous transmission period
for PDOs.
Encoder profile DS 406
Up to four work areas with upper and lower limits and corresponding
status register. Up to four cam switches with upper or lower threshold
level and status register
CANbus connection
The CANopen encoders are equipped with a bus trunk line in various
lengths and can be terminated in the device.
The devices do not have an integrated T-coupler nor they are looped
internally. If possible, drop lines should be avoided, as in principle they
lead to signal reflections. As a rule the reflections caused by the drop
lines are not critical, if they have completely decayed before the point
in time when the scanning occurs.
5. Operation
