ASSEMBLY INSTRUCTION FOR—C06….PRT 1 & 2
PARTS IDENTIFICATION LIST
TOP of UNIT
NO MODEL DESCRIPTION QTY
1CONFIRMAT SCREWS 50mm x 5mm 14
2CAPS 14
3BACKING NAILS 50
NO MODEL DESCRIPTION QTY
516mm PAN HEAD SCREWS 1
625mm PAN HEAD SCREWS 1
7“L” SAFETY BRACKET 1
When aaching unit to wall put safety bracket in
middle of unit with 16mm pan head screw then
25mm pan head screw into wall.
For plasterboard without a stud it is recommended
to use a plug with screw (not provided).
F

INFILL STEP
YOU WILL NEED TO RETRIEVE THE INFILL AND
3 X 60mm SCREW FROM PART 2, USING YOU
SCREWS PROVIDED, ATTACH THE INFILL TO
THE UNDER-SIDE OF THE TOP FIXED SHELF.
FIRST STEP:- UNPACKED YOUR CARTON PART 1 OF 2, LAY A,B,C,D,E ON FLOOR & RETRIEVE THE INFILL &
SCREWS FROM PART 2. ATTACH THE INFILL TO THE UNDERNEATH OF THE FRONT EDGED TOP FIXED SHELF AS
DEMONSTRATED DOWN BELOW IN INFILL STEP.
STAND LEFT-HAND GABLE FACING DOWN ON THE EDGED FRONT, USING THE 30mm 8 GAUGE CONFIRMAT
SCREWS PROVIDED YOU CAN NOW SCREW YOUR KICK FIRST, BOTTOM SHELF NEXT AND THEN TOP SHELF WITH
INFILL ALLREADY ATTACHED FACING DOWN INTO THE LEFT-HAND GABLE.
WHEN FINISHED DO THE SAME TO THE RIGHT-HAND GABLE.
LEAVE YOUR CARCASS FACING DOWN AND GO TO ..STEP 3.
YOU ARE NOW READY TO MOVE TO
PART 2 TO ASSEMBLE YOUR DRAWERS
TO GO INTO YOUR FINISHED CARCASS.
STEP 1 STEP 2
STEP 3 FINISHED

HOW TO ASSEMBLE YOUR 5—DRAWER
STEP 1.
LAYOUT YOUR DRAWER PIECES FLAT AS PER DESIGN WITH PRE-DRILLED HOLES FACING UP.
START WITH THE BACK OF THE FRONT DRAWER AND PLACE YOUR DOWELS & CAM PIN IN THE
PRE-DRILLED HOLES ON EITHER SIDE AS INSTRUCTED BELOW.
NO MODEL DESCRIPTION QTY
1CONFIRMAT SCREWS 20
2DOWELS 20
3BACKING NAILS 100
45/8 X 6 WOOD SCREWS 30
5 HANDLES 5
NO MODEL DESCRIPTION QTY
6CAMS 10
7CAM PINS 10
860mm 8 GAUGE INFILL SCREW 3
9EURO SCREWS 20
10 INFILL 55mm 1
PART 2 OF 2

PICTURE OF YOUR FINISHED DRAWER
STEP 3.
USING THE HANDLE SCREW ATTACHED THE HANDLE TO THE BACK OF THE DRAWER FRONT
INTO THE PREDRILLED HOLES ALLREADY PROVIDED.
DRAWER ASSEMBLY
STEP 4.
PLACE YOUR DRAWER RUNNER ON THE BOTTOM OF THE
DRAWER MAKING SURE THE WHEEL IS TO THE BACK OF THE
DRAWER SIDE, USING 2 OF THE 5/8 SCREWS, FIX INTO
YOUR DRAWER FRONT AND BACK OF THE RUNNER, NOW
REPEAT FOR THE
