NAMCO CASINO WINNER User manual

OPERATORS MANUAL
ITIS THE RESPONSIBILITY OF THE OPERATOR TO MAINTAIN CUSTOMER SAFETY
AT ALL TIMES, AND IT IS IMPERATIVE THAT THE DETAILS SET OUT IN THIS MANUAL
ARE FOLLOWED PRECISELY
Part No. XCW-716-900 Issue 1
CASINO WINNER

Page 2

Page 3
Thank you for purchasing the CASINO WINNER game machine (hereafter referred to as the
“machine”).
This operation manual describes:
How to install, operate, relocate, transport, maintain and discard the machine safely and
properly
How to operate the machine correctly and make full use of its features
How to ensure safety of players and bystanders
Inquiries concerning the machine and repairs
For further information about the machine and repairs (including replacement of
consumable parts), please contact your distributor.
The machine uses clip arts from the “Master Clip” image collection sold by H2 Soft Art
(Tel.: [phone], Fax: [phone]).
The images used herein were obtained from IMSI’s MasterClips®and MasterPhotos
Premium Image Collection (75 Rowland Way, Movato, CA 94545, U.S.A.).
The machine uses original Ryobi fonts. ©Ryobi Limited
