1. SPECIFICATIONS
POWER SUPPLY :- 220/240volts AC
MONITOR :- Hantarex 28" Polo Colour Monitor with auto degauss.
DIMENSIONS :- 780(w) x 900(d) x 2080(h)
WEIGHT :- 165kg.
ACCESSORIES :- Keys: (Cash Door) ..................... 2
(Coin Door)...................... 2
(Back Door) ..................... 2
Hex Tamper-Proof Wrench..................... 1
IEC Mains Lead...................................... 1
Operators Manual ................................... 1
Page 1

Page
2. PRECAUTIONS
2-1 Cautions When Installing.
This game is designed for indoor use only. The game must not be installed outdoors or
under the following conditions:-
a. In areas directly exposed to sunlight, high humidity, direct water contact, dust, high
heat or extreme cold.
b. In locations that would present an obstacle in the case of an emergency, i.e. near
fire equipment or emergency exits.
c. On an unstable surface or subject to floor vibration.
2-2 Caution when Handling.
a. AC power must always be turned OFF, and the game disconnected, before
replacing any parts or connecting/disconnecting connectors.
b. When unplugging the game from an electrical outlet, always grasp the plug, not the
mains lead.
c. The machine must be earthed with a securely connected earthed plug.
d. Care must be taken at all times to avoid electric shock when inspecting or
adjusting the game.
2-3 Cautions when Transporting.
a. Do not subject the game to physical shock when transporting or moving it.
b. Always return the levellers to the UP position before moving the machine.
c. Take care not to rope any moulded (plastic) parts when transporting.
2

Page
3. ADJUSTMENTS
3-1 Turning on the Power
After installing the product, turn on the power. The power switch is located above the
mains inlet on the rear of the cabinet.
3-2 Switches for Adjustments
Open the front door to find the switches for adjustments.
1. Service Switch
Press this switch to obtain game credits without incrementing the coin counter.
2. Test Switch
Slide this switch to "ON" to enter test mode.
Test mode allows game testing and the changing of game settings.
(See "3-4 Test Mode" on page 4)
3-3 Volume Adjust
There are two volume controls, one each for left and right player. Turn the control to
increase or decrease the volumes.
3
TEST SWITCH
VOLUME
CONTROLS
COIN COUNTER
SERVICE
SWITCH
SERVICE BRACKET

Page
3-4 Test Mode
1. Open the coin door for access to the service bracket, then slide the test switch
to "ON". The "Switch Test Screen" appears on the monitor display.
2. Pressing the service button steps through the test screens.
3. When testing is finished ensure that the test switch is returned to the "OFF"
position to return to Game Screen
The Test Switch must always be "OFF" during normal game mode.
3-4-1 Switch Test
1. Enter test by switching
the Test Switch ON. The
"Switch Test Screen"
appears.
2. The corresponding
writing on the test screen
will change to red while
the switch under test is
activated.
3-4-2 Gun and Lamp Test
1. Advance to the GOUT Test Screen
from the Switch Test Screen by
pressing the service button on the
service bracket.
2. Pressing the 1 Player Start Button
selects the test required. The
selected test will change to red.
3. Pressing the 2 Player Start Button
will activate the test.
1P/2P Blowback - Gun recoils each
time 2 player start switch is
pressed
Auto Blowback - Both guns recoil
constantly when 2 player start
button is pressed. Pressing start
button again turns the test off.
Flash - Not Used
SWITCH TEST
DIP SW 12 OH
COIN1 COUNT 0H
COIN2 COUNT 0H
1P SWITCH 2P SWITCH
TRIGGER TRIGGER
START START
GOUT TEST
1P BLOWBACK
OFF
2P BLOWBACK
OFF
1P START LAMP
NO
2P START LAMP
NO
FLASH
NO
AUTO BLOWBACK
NO
4

Page
GAME MENU
LIFE 3
MUSIC IN ATTRACT
YES
INITIALIZE HI SCORE
NO
COIN OPTIONS
GAME COST
1 COIN 1 CREDIT
DISCOUNT TO CONTINUE
NO
COIN 1 MECH VALUE
1 COIN COUNT AS 1 COIN
COIN 2 MECH VALUE
1 COIN COUNT AS 1 COIN
BONUS FOR QUANTITY BUY IN
NONE
FREE PLAY
NO
COIN BOX
1 WAY
5
3-4-3 Game Menu
1. Advance to the Game Menu Screen by
pressing the service button.
2. Pressing the 1 Player Start Button selects the
test required. The selected test will change
to red.
3. Pressing the 2 Player Start Button will
change the settings.
3-4-4 Coin Options
1. Advance to the Game
Menu Screen by pressing
the service button.
2. Pressing the 1 Player Start
Button selects the test
required. The selected test
will change to red.
3. Pressing the 2 Player Start
Button will change the
settings.
Note:- The price of play
adjustments are made on
the credit board and the
coin options must be set as
shown in the table.
3-4-5 Monitor Test
1. Advance to the Game Menu Screen by pressing the service button.
2. The monitor will display vertical colour bars.
3. Pressing the service button again will cause the monitor to display a
crosshatch pattern.

Page 6
SOUND TEST
REQUEST No
0H
LEFT/RIGHT CHECK=REQUEST No 1H
3-4-6 Sound Test
1. Advance to the Game Menu Screen
by pressing the service button.
2. Pressing the 1 Player Start Button
changes the request No.
3. Pressing the 1 Player gun trigger
will generate a sound. A different
sound will be produced each time
the request No. is changed.
3-4-7 Gun Sight Set-Up
1 To initialize gun sight set-up press and hold in the Service Button and slide
the Test Switch ON.
2 Test screen for player 1 gun will appear. To adjust player 2 gun press the
Service Button.
3 Follow the instructions on the screen.
4 When set-up is completed ensure Test Switch is returned to OFF.
4. PARTS
DESCRIPTION PART No.
Side Decal - LH 40000196
Side Decal - RH 40000197
Front Decal 40000198
Play Panel Overlay 33000022
Top Flash Vac-Form 45000196
Top Flash Acrylic 30000034
Play Instruction Card 42000003
DECALS & PLASTICS

Page
CABINET
7
DESCRIPTION PART No.
Front Glass - Toughened (748x580x6) 31000020
Mirror (735x660x3) 31000021
Monitor 28" Hantarex Polo 84000012
Speaker 4½" 20w (with shield can) 62000006
Switch Mode Power Supply 83000040
Schaffner Mains In Assy 66000016
Schaffner Boot 66000017
Fuse 5amp 20mm Slo-Blo 63500600
Interlock Switch 60000006
Interlock Cover 39000028
Transformer 67700015
Bridge Rectifier 71000040
Capicitor 22,000mfd 25v 70200043
Fuse 3amp 1¼" Slo-Blo 63500547
18" 15w Fluorescent Tube 64500000
Choke 15w 63300000
Starter 63000000
75mm Castor 59000005
M16 Adjustable Foot 88300079
100ohm 10w W/W Potentiometer 76000164
3.5-6v Panel Meter 65000002
Service Switch 60000059
Start Button Assy - Red 60200235
Start Button Assy - Blue 60200237
Test Switch 60000023
Gun Assy - Red XPB-GUNRED
Gun Assy - Blue XPB-GUNBLUE
Gun Chain 45000209
Chain Clip 45000211
Holster 45000199
