NAMCO GODZILLA WARS Jnr. User manual

Operators Manual
GODZILLA WARS Jnr.

Page
1. SPECIFICATIONS
POWER SUPPLY :- 220/240 Volts AC
CAPSULE SIZE :- 50mm DIAMETER
or
C2000 TICKET DISPENSER
DIMENSIONS :- 645(w) x 745(d) x 1665(h) (with header)
WEIGHT:- 77kg.
ACCESSORIES:- Keys: (Cash Door) .................................................... 2
(Coin Door) ....................................................2
(Back Door) .................................................... 2
(Hopper Door) or (Dispenser Door) ...............2
Operators Manual .............................................................. 1
2

Page
2. PRECAUTIONS
2-1 Cautions When Installing.
This game is designed for indoor use only. The game must not be installed outdoors or
under the following conditions:-
a. In areas directly exposed to sunlight, high humidity, direct water contact, dust,
high heat or extreme cold.
b. In locations that would present an obstacle in the case of an emergency, i.e. near
fire equipment or emergency exits.
c. On an unstable surface or subject to floor vibration.
2-2 Caution When Handling.
a. AC power must always be turned OFF, and the game disconnected, before
replacing any parts or connecting/disconnecting connectors.
b. When unplugging the game from an electrical outlet, always grasp the plug, not the
mains lead.
c. The machine must be earthed with a securely connected earthed plug.
d. Care must be taken at all times to avoid electric shock when inspecting or
adjusting the game.
2-3 When Transporting.
a. Do not subject the game to physical shock when transporting or moving it.
b. Take care not to rope any plastic parts when transporting.
3. INSTALLATION
1. Ensure that five ping-pong balls have been placed on the playfield, and the hopper
filled with capsules or the ticket dispenser loaded with tickets.
3

Page
4. HOW TO PLAY
1. Insert coin/s to establish credit, shown on the credit display, then press the
dispense button once. Godzilla will begin to move and the background sounds will
begin.
2. Pressing the bomb pushbutton when lit will fire a ping-pong ball at Godzilla. If the
timing is right the ball will go into Godzilla's mouth.
3. If six balls are shot into Godzilla's mouth in the given time, Godzilla is defeated
and a prize or tickets will be dispensed.
4. The game is over if the player fails to shoot six balls into Godzilla's mouth in the
given time.
5. ADJUSTMENTS
5-1. DIP Switch Settings
The DIP switches on the game PCB alter the price of play, game difficulty and ticket/
prize mode.
Note;- This machine is fitted with a credit dispense board, and the game PCB switches
should always be set for 1 coin 1 play and game pricing set using the credit
dispense board switches.
Always turn the machine OFF when adjusting DIP switches.
Function 1 2 3 4 5 6 7 8
Coin
1 coin - 1 play ON ON ON
1 coin - 2 plays off on on
1 coin - 3 plays on off on
2 coins - 1 play off off on
2 coins - 3 plays on on off
3 coins - 1 play off on off
3 coins - 2 plays on off off
Free play off off off
Number of
tickets
issued
2 tickets for each point ON
+10 tickets for 6 points
3 tickets for each point off
+10 tickets for 6 points
Difficulty
Hard on on
Medium OFF ON
Easy on off
Very Easy off off
Off = hopper mode / On= ticket mode OFF
Sound in attract mode Yes ON
No off
4

Page
Hopper Fuse (750ma)
Dispense Counter
Coin Counter
5
Service LEDs
Volume Control
Hopper Switch
Service switch
Test
Switch
12345
5-2. Volume Control
The volume control is fitted to the service bracket located inside the coin door.
5-3. Service Switch
Pressing the service switch establishes a game credit without operating the coin
counter.
5-4. Hopper Switch
If the hopper switch is pressed while the machine is in stand-by, the hopper will
turn and a capsule dispensed.
5-5. Test Switch
There are seven test steps. The steps are advanced each time the test switch is pressed.
Test 1 Mouth Motor Test
The mouth motor runs and count lamps 2 or 5 light when Optos 1 or 2 are
interrupted, and ping pong balls can be fired by pressing the bomb button.
Test 2 Godzilla Motor Test
Godzilla motor operates and count lamp 4 lights when Opto 3 is interrupted
Service Bracket

Page
Test 3 Ball Shooting Test
The mouth opens and balls are automatically shot. The height to which balls are
shot can be adjusted during this test. (see 5-6 below)
Test 4 Sound Test
All the game sounds are produced one after another.
Test 5 Lamp and LED test
The count lamps light one after another. The game over and hit lamps flicker
alternately. The bomb button lamp and service LEDs light every other second.
Test 6 Switch Test
A bleep will sound each time the bomb button, hopper switch, service switch,
Godzilla's mouth microswitch or hopper outlet microswitch is pressed.
Pressing the test switch again will put the machine back to stand-by mode.
5-6. Ball Height Adjustment
The height to which the balls are fired can be adjusted by loosening (do not
remove) the two screws fixing the spring retaining plate on the side of the ball
shooter assy and moving the plate up or down. Ensure that the two screws are
fully tightened when adjustment is completed.
Ball Higher
Ball Lower
Ball Height Adjust
6

Page
Service LED Indication Fault Indicated
Credit dispense pulse remains on
Service switch remains on
Mouth micro switch remains on
Hopper test switch remains on
Hopper microswitch remains on
Hopper not dispensed
Tickets run out
Ticket count switch remains on
Test switch remains on
Opto 3 remains on
Opto 2 remains on
Opto 1 remains on
Mouth motor not working
Count Lamp Indication Fault Indicated
Mouth does not return to start position at
power-up
Godzilla does not return to start position
at power-up
6. TROUBLESHOOTING
The game constantly monitors certain functions and if there is a failure certain LEDs
or count lamps light as an indication.
The following table indicates these conditions.
Lamp OFF Lamp ON
7

Page
7. PARTS
9
14,15 (behind
header)
13
1
10
2
3
6
8
9
4
7
11
12
16
17
5

Page 10
Item Description Part No
1Building Vac-Form 88300850
2Island Vac-Form 88300851
3Field Guard Vac-Form 88300852
4Rear Guard Acrylic 88300848
5Play Panel ------------
6Credit Display Panel 88300870
7Side Acrylic L&R 88300846
8Main Dome 88300845
9Dome Stay LH 88300865
10 Dome Stay RH 88300866
11 Playfield Acrylic 88300847
12 Credit Display 81000112
13 Display Lamps 24v 3w Wedge Lamp 64000034
14 Speaker 4 1/2" 62000006
15 Speaker Grille 87800011
16 Credit Dispense Button 60200233
17 Bomb Button 60200257

Page
3, 22
12
5
11
8
9
10, 11
12
13
1
16
17
15
14 18, 19, 20
10, 11
4 (x2)
6
721, 23

Page
Item Description Part No
1Opto Interrupter 88300893
2Opto Interrupt Plate 88300901
3Link Arm Stand-Off - Lower 88300896
4Washer Link Arm Stand-Off 88300899
5Mouth Motor 12v DC 40rpm 88300892
6Crank Arm 88300900
7Mouth Link Arm 88300894
8Main Shaft & Mntg Assy 88300871
9External Circlip 12mm 88300875
10 Delrin Bush 88300877
11 Nylon Washer 88300876
12 Retaining Clip 88300874
13 Main Motor 12v Step 88300885
14 Spring Bracket Upper 88300880
15 Step Motor Stabilising Spring 88300882
16 Spring Retainer 88300878
17 Spring Retainer Spacer 88300879
18 Roller Arm 88300885
19 Roller 88300886
20 Roller Bush 88300886
21 Link Arm Stand-Off - Upper 88300885
22 Spacing Bush - Lower 88300897
23 Spacing Bush - Upper 88300898
12

Page
12
3
4
5
6
7
8
Item Description Part No
1 Flip Arm 88300903
2Spacer 88300917
3Rod - Short 88300907
4Rod - Long 88300906
5Spring 88300909
6Solenoid 88300908
7Ball Shooter Main Bracket 88300902
8Solenoid Link Plate 88300904
13

Page 14
8. SCHEMATIC - Power supply
POWER SUPPLY BOARD

AC3 1 1
AC4 2 2
EARTH 3 3
AC24V1 4 4
AC24V2 5 5
AC12V1 6 6
AC12V2 7 7
AC9V1 8 8
AC9V2 9 9
1 +12V
2 +12V
3 METER V-
4 METER V+
5 MOTOR V+
6 AGND
7 AGND
PS
+24V 1 1
BGND 2 2
+12V 3 3
AGND 4 4
+7V 5 5
GND 6 6
PS
COM_A 1 1
STMA 2 2
STMA 3 3
COM_B 4 4
STMB 5 5
STMB 6 6
A1 A1 +12V
B1 B1 LED 1
A2 A2 LED 2
B2 B2 LED 3
A3 A3 LED 4
B3 B3 LED 5
A4 A4 LED 6
B4 B4 LED 7
A5 A5 +24V
B5 B5 LP1
A6 A6 LP2
B6 B6 LP3
A7 A7 LP4
B7 B7 LP5
A8 A8 LP6
B8 B8 LP7
A9 A9 +12V
B9 B9 LP8
A10 A10 +24V
B10 B10 LP9
A11 A11 +12V
B11 B11 LP10
A12 A12 LP11
B12 B12 +12V
A13 A13 L/OUT-A
B13 B13 L/OUT-B
A14 A14 +12V
B14 B14 PAY-C
A15 A15 +12V
B15 B15 COIN-100
A16 A16 +12V
B16 B16 COIN-10
A17 A17 +24V
B17 B17 SOLENOID
A18 A18 HOP MOT
B18 B18 AGND
A19 A19 DCM+
B19 B19 DCM-
A20 A20 SPKR+
B20 B20 SPKR-
+5V A1 A1
+5V B1 B1
+5V A2 A2
+5V B2 B2
CHAR SW A3 A3
GND B3 B3
CLOSE SW A4 A4
OPEN SW B4 B4
GND A5 A5
PHOTO SW1 B5 B5
GND A6 A6
GND B6 B6
B SHOT SW A7 A7
AGND B7 B7
B SHOC SW A8 A8
AGND B8 B8
COIN 1 SW A9 A9
COIN 2 SW B9 B9
AGND A10 A10
TEST SW B10 B10
PAY SW A11 A11
SERV SW B11 B11
AGND A12 A12
HOPP SW B12 B12
AGND A13 A13
SW1 SPARE B13 B13
SW2 SPARE A14 A14
SW3 SPAREB14 B14
AGND A15 A15
AGND A15 A15
1 1 DC24V
2 2 BGND
3 3 DC12V
4 4 AGND
5 5 DC7V
6 6 GND
11
22
33
44
55
66
11
22
33
44
55
66
77
88
99
1010
1111
1212
11
22 M
M2
11
22
33
44
55
66
77
88
99
SW6
MM3
HOPPER SW
SW7
+5V
SIG
GND
+5V
SIG
GND
+5V
SIG
GND PHOTO 2
PHOTO 1
PHOTO 3
LP12
12V 6W
MOUTH
11
22
33
44
55
66
77
88
99
1010
1111
1212
11
22
33
44
55
66
77
88
99
11
22
33
44
CC1
CC2
11
22
33
44
55
66
77
88
99
LP7
LP8
LP1
LP2
LP3
LP4
LP5
LP6
LP9
LP10
24V 0.15A
LED1
LED2
LED3
LED4
LED5
SERVICE LED's
11
22
33
44
55
66
11
22
33
44
11
22
SOL 3
11
22
33
44
55
66
77
88
99
1010
CREDIT
DISPLAY
MM1
24V
STEPPER
MOTOR
PCB ASSY
GND 2
MOUTH MOTOR
GND 1
GND 2
GND 3
GND 3
F1 5A
SCHAFFNER MAINS
ASSY
7.4VAC
11.6VAC
21.5VAC 220VAC
240VAC
EARTH
OVAC
ORANGE
BLACK
YELLOW
BLACK
RED
BLACK
YELLOW
BLACK
GREEN
WHITE
RED
BLACK
WHITE
RED
BROWN
ORANGE
BLU/RED
BLU/WHI
BLU/YEL
PINK
PURPLE
WHI/BLK
WHI/GREY
WHI/PUR
WHI/BRN
WHI/RED
WHI/ORG
WHI/GRN
WHI/YEL
WHI/BLU
WHI/BRN
BLACK
BROWN
RED
YELLOW
ORANGE
GRN/WHI
GRY/WHI
BLUE
RED/GRN
BLU/WHI
RED/WHI
BLU/BLK
WHI/YEL
WHI/ORG
WHI/GRN
WHI/ORG
BLUE
PURPLE
YELLOW
RED/BLK
BROWN
WHITE
WHI/BRN
WHI/GRY
GRY
WHI/RED
WHI/PUR
PURPLE
YELLOW
BLACK
YELLOW
BLUE
YELLOW
BLUE
WHITE
ORG/BLK
BLACK
CREDIT
DISPENSE
BOARD
0.8A
F1
LP1
12V
SW8
S10 MECHS ONLY
DISPENSE SW
DISPENSE LAMP
GND 1 11
22
33
+
BLACK
VOLUME
CONTROL
SW5 TEST
SW4 PAY
SW3 SERVICE
GODZILLA JNR
J2-40P
J1-30P
220-240V
MAINS
IN
GND 3
DISPENSE
COUNTER
SERVICE BRACKET
POWER
SUPPLY
BOARD
BOMB BUTTON
C220
COIN
MECH
METER
HOPPER
ASSY
TICKET
DISPENSER
CONNECTIONS
METER V-
MOTOR V+
GROUND
+12V
METER V+
