NBB SR8303 User manual

Assembly Instructions
Shelter type: SR8303
SR8303-01-27102021-USA

17
19
18
16
16
17
20
20
16
15
18
5
8
3
4
21 22
6
2
6
14
14
15
10
11
2
22
21
9
17
19
1
5
7
2
EXPLODED VIEW
ITEM
NO. PART NAME
DRG NUMBER LENGTH QTY.
1 S1 Frame S1
Panel
outside
4
2 ST3 Roof Tie ST3
Default
2
3 CB1 Bracket CB1
Default
8
4 JF1 Bracket JF1
Default
6
5 ST15 Tie Bar ST15
New Tie
Bar
2
6 S3 Frame 20 & 43 (M1) S3
Default
2
7 Post P5 P5
Default
1
8 JFT JFT
T shaped
Bracket
1
9 DR Bracket DR
Default
16
10 AR1R 1m Pitch Rafter AR1R
Default
5
11
AR1IS 1m Pitch Infill
Panel Shallow
AR1IS
Default
2
12
AR1CLTO 1m Apex
Roof Centre Lower
Trim Outer
AR1CLTO
Default
2
13
AR1CLTI 1m Apex
Roof centre lower trim
inner
AR1CLTI
Default
2
14
ARFSI Apex Roof F
Section Inner
ARFSI
Default
4
15 Roof F Section Outer ARFSO
Default
4
16
AR1POA Roof Panel
outer alu
AR1POA
Default
4
17
AR1PIA Roof Panel
inner ALU
AR1PIA
Default
4
18
AR1CUTO 1m Apex
Roof centre upper trim
outer
AR1CUTO
Default
2
19
AR1CUTI 1m Apex
Roof centre upper trim
inner
AR1CUTI
Default
2
20
AR1TS 1m Apex Roof
Trim strips
AR1TS
Default
6
21 FT1 Bracket FT1
Default
3
22 FT3 Bracket FT3
Default
5
23 40x40 Plastic End Cap EC40
40 x 40
12

3
PARTS LIST
ITEM
NO. PART NAME
DRG
NUMBER
Size (inch)
QTY.
1 S1 Frame S1
78.74 x 40.74
4
2 S3 Frame 20 & 43 (M1) S3
78.74 x 20.3
2
3 CB1 Bracket CB1
4.3 x 4.3 x 1.57
8
4 JF1 Bracket JF1
4.33 x 1.57
6
5 ST15 Tie Bar ST15
20.15 x 1.57 x
1.57 2
6 ST3 Roof Tie ST3
81.1 x 1.57 x
1.57 2
7 Post P5 P5
77.15 x 1.57 x
1.57 1
8 JFT JFT
8.66 x 5.9
1
9 DR Bracket DR
4.3 x 1.6 x 2
16
10 AR1R 1m Pitch Rafter AR1R
45 x 11.8 OA
5
11
AR1IS 1m Pitch Infill Panel
Shallow
AR1IS
45.2 x 13.5
2
12
AR1CLTO 1m Apex Roof
Centre Lower Trim Outer
AR1CLTO
41.4 2
13
AR1CLTI 1m Apex Roof
centre lower trim inner
AR1CLTI 40.74 2
14
ARFSI Apex Roof F Section
Inner
ARFSI
40.75 4
15 Roof F Section Outer ARFSO
41.5 4
16
AR1POA Roof Panel outer
alu
AR1POA
41.5 x 24.4
4
17
AR1PIA Roof Panel inner
ALU
AR1PIA
40.75 x 24.4
4
18
AR1CUTO 1m Apex Roof
centre upper trim outer
AR1CUTO
41.5 2
19
AR1CUTI 1m Apex Roof
centre upper trim inner
AR1CUTI
40.75 2
20
AR1TS 1m Apex Roof Trim
strips
AR1TS
24.8 x 2.3
6
21 FT1 Bracket FT1
1.57 x 1.57 x
3.94 3
22 FT3 Bracket FT3
1.57 x 3.15 x
4.17 5
23 40x40 Plastic End Cap EC40
1.6 x 1.6
12

4
FIXINGS
Tools required:
Drill/Screwdriver
Mallet
17mm Wrench
T25 Torx bit
Fittings Bolt set M10 T25 T38 BTANCM12100
M10 x 60mm Nut Washer
1" Tech
screw
1.5"
Tech
screw
Black
Caps
M10/12 x 100 mm
Concrete Bolt
Pack A+B
33 33 66 136 40 66 11

20.35
164.57
21.93
MEASURE THE WIDTH AND DEPTH
OF THE SHELTER TO CHECK
CORRECT ALIGNMENT.
Please note 1.5" Tec Screws
are for roof panels only
S1
CB1CB1
JF1
JF1
JF1
JF1
CB1
S3
ENSURE CORRECT
ALIGNMENT ON
CORNERS
CB1
CB1
JF1 JF1
DETAIL C
SCALE 1 : 6
DETAIL D
SCALE 1 : 6
Step 1
Assemble S1 and S3 frames to make up the main structure using CB1
brackets for the corners and JF1 brackets for the straight joints.
5

ST15
ST15
CB1
CB1 JFT
ST3
P5
CB1
CB1
ST3
A
B
P5
ST15
ST15
CB1
CB1
CB1
CB1
JFT
ST3
ENSURE CORRECT
ALIGNMENT ON
CORNERS
ST3
DETAIL A
SCALE 1 : 10
DETAIL B
SCALE 1 : 10
6
Step 2
Attach ST15 Tie bars to SC frames using CB1 Brackets. Fix the ST3 Tie
bars to the ST15 bars using CB1 Brackets and attach to the P5 Post using the
JFT bracket.

AR1IS
AR1IS
AR1R
AR1R
DR
DR
DR
DR DR
DR
DR
AR1R
AR1IS
AR1IS
AR1R
AR1R AR1R
DR
DR
DR DR
DR
AR1R
7
Step 3
Attach AR1R rafters using DR brackets. Secure the AR1IS End Panels to S1
frames using 1" tech screws. The end rafters need to be placed in position at
the same time as the AR1IS End Panels.

ARFSO
AR1CLTO
ARFSO
ARFSO
ARFSO
ARFSI
ARFSI
AR1CLTO
AR1LTI
ARFSI
AR1CLTI
ARFSI
ARFSO
ARFSI
AR1CLTO
AR1CTLI
ARFSI
AR1CLTO
ARFSO
ARFSO
ARFSO
ARFSI
8
Step 4
Attach the AR1CLTO and the AR1CLTI to the top of the rafters with the
AR1CLTO on the outside and the AR1CLTO on the inside. The ARFSO and
ARFSI parts are to be attached to the lower part of the rafters as shown
below.

AR1TS
AR1POA
AR1CUTI
FT1
FT3
FT3
FT3
FT1
FT1
FT3
AR1CUTO
AR1TS
AR1TS
AR1TS
AR1POA
AR1POAAR1POA
AR1CUTO
AR1PIA
AR1PIA
AR1PIAAR1PIA
FT3
AR1CUTO
AR1PIA
AR1TS
AR1TS
FT1
FT1
FT1
FT3
FT3
FT3
FT3
AR1TS
AR1TS
AR1POA
AR1POAAR1POA
AR1PIA
FT3
AR1POA
9
Step 5
Attach the AR1POA and AR1PIA roof panels to the top of the rafters.
Cap off the top using AR1CUTO and AR1CUTI trim as shown.
Use the AR1TS strips to cover the gaps between the panels.
Once the shelter is in its final position and square, it can be secured to
the ground using the concrete bolts and FT3/FT1 brackets.

41.26
20.35
164.86
PLAN VIEW
OVERALL DIMENSIONS AND GROUND FIXING POSITIONS
Suggested size for concrete base: 8" oversized on all 4 sides.
10

11
MAINTENANCE:
To ensure your products give you many years of use we recommend that you:
THANK YOU
FOR PURCHASING THIS PRODUCT
Clean panels regularly with soapy water •
Ensure all fittings are tight (for example after a big storm) •
Touch up any exposed metal should it get scratched •
CONTACT DETAILS:
Email : [email protected]
Web : www.nobutts.com
Tel : [phone]
No Butts Bin Company, Inc. 16 Birch Lane, Madison, CT 06443
All Parts and Fixings checked by:
Print Name: Signature:
