NBB SR8306-F User manual

Assembly Instructions
Shelter type: SR8306-F
SR8306F-01-22102021-USA

1
1414
13
13
6
20 4
4
21
10
15
19
9
8
10
9
13
14
15
16
11
12 17
18
15
19
8
2
17
18
11
7
5
5
3
2
EXPLODED VIEW
ITEM
NO.
PART
NO.
DESCRIPTION
DIMENSION IMAGE
QTY.
1
S1C
S1 - Full Frame - SRC
109 x 100 x
40 6
2
P1
Post Frame - P1
2000 x 1030
2
3
CB1
Corner Bracket - CB1
110 x 110 x
40 8
4
JF1
Joint Flat - JF1
110 x 40
8
5
DR
Rafter Bracket
110 x 40 x 52
16
6
FT1
FT1 BRACKET
40X40X100
5
7
FT3
FT3 Bracket
40 x 80 x 106
5
8
ST3
Roof Tie
2060 2
9
JFT
Bracket
220 x 150
1
10
P5
P5 POST
1960x40x40
1
11
AR2R-
02
2m Pitch Rafter
Assembly
2178 5
12
AR2CL
TO-03
2m Apex Roof Centre
Lower Trim Outer
1052 2
13
AR2CL
TI-02
2m Apex Roof Centre
Lower Trim Inner
1035 2
14
AR2IS-
02
2m Pitch Infill Panel
shallow
2180 2
15
ARFSO
F - section outer
1055 4
16
ARFSI
F - section inner
1035 4
17
AR2PO
A
AR2 Roof Panel Outer
1155x1050
4
18
AR2PI
A
AR2 Roof Panel Inner
1155 x 1030
4
19
AR2CU
TO-02
2m Apex Roof Centre
Upper Trim Outer
1055 2
20
AR2CU
TI
2m Apex Roof Centre
Upper Trim Inner
1035 2
21
AR2TS-
01
2m Pitch Roof Trim
Strips
1155 x 60
6
22
EC40
Plastic end cap
STD. STOCK
ITEM
6

3
PARTS LIST
ITEM
NO. PART NAME
DRG NUMBER Size (inch)
QTY.
1 S1C Frame S1C
78.74 x 40.74
6
2 CB1 Bracket CB1
4.3 x 4.3 x
1.57 8
3 JF1 Bracket JF1
4.33 x 1.57
8
4 P1 Post P1
78.74 x 40.74
2
5 ST3 Roof Tie ST3
81.1 x 1.57 x
1.57 2
6 JFT JFT
8.66 x 5.9
1
7 Post P5 P5
77.15 x 1.57
x 1.57
1
8 DR Bracket DR
4.3 x 1.6 x 2
16
9 AR2R 2m Pitch Rafter AR2R-02
85.75 5
10
AR2IS 2m Pitch Infill Panel
Shallow
AR2IS-02
85 2
11 Roof centre lower trim outer AR2CLTO-03
41.4 2
12 Roof centre lower trim inner AR2CLTI-02
40.74 2
13 Roof F Section Outer ARFSO
41.5 4
14
ARFSI Apex Roof F Section
Inner
ARFSI
40.75 4
15
AR2POA AR2 Roof Panel
outer ALU
AR2POA
45.5 x 41.3
4
16
AR2PIA AR2 Roof Panel inner
ALU
AR2PIA
45.5 x 40.5
4
17 Roof centre upper trim outer AR2CUTO-02
41.5 2
18 Roof centre upper trim inner AR2CUTI
40.75 2
19
AR2TS 2m Apex Roof Trim
strip
AR2TS-01
45.5 x 2.3
6
20 FT1 Bracket FT1
1.57 x 1.57 x
3.94 5
21 FT3 Bracket FT3
1.57 x 3.15 x
4.17 5
22 40x40 Plastic End Cap EC40
1.6 x 1.6
6

4
FIXINGS / TOOLS
Fittings Bolt set M10
Nut Washer
Black
Cap
T25 T50 AB1210
M10 x 60 mm
25mm
Tech
screw
50mm
Tech
screw
M10 x 100mm
Concrete Bolt
Pack A+B
40 40 80 80 136 66 13

83.07
83.07
164.57
CB1
JF1
JF1
S1C
Please note 1.5"
Tec Screws are for
roof panels only
CHECK
DIMENSIONS
TO ENSURE
CORRECT
ALIGNMENT
CB1
CB1
CB1
CB1
CB1
JF1 JF1
JF1
S1C
S1
CB1
JF1
JF1
JFT
ST3
ST3
P5
P1
P1
DETAIL B
SCALE 1 : 8
DETAIL C
SCALE 1 : 8
DETAIL D
SCALE 1 : 8
DETAIL E
SCALE 1 : 8
Step 1
Assemble S1C frames to make up the main structure using CB1 brackets
for the corners and JF1 brackets for the straight joints. Attach the P1 posts
to the ST3 Roof Ties, and fix these to the P5 post using the JFT Bracket as
shown below
5

AR2R
AR2R
AR2R
AR2R
AR2R
DR Bracket
AR2IS
AR2IS
Step 2
Attach the AR2R Rafters using the DR Brackets. Screw the AR2IS End
Panels into the top of the frames, ensuring they are put in place at the same
time as the end rafters.
6

AR2CLTO
AR2CLTO
AR2CLTI
AR2CLTI
ARFSO
ARFSO
ARFSO
ARFSO
ARFSI
ARFSI
ARFSI
ARFSI
Step 3
Attach the AR2CLTO and ARCLTI trims to the top of the rafters, with the
AR2CLTO on the edges, and the AR2CLTI spaced evenly in the middle.
Attach the ARFSO and ARFSI to the bottom of the rafters with the ARFSO
on the edges and the ARFSI spaced in the middile.
7

AR2POA
AR2POA
AR2POA
AR2POA
AR2PIA
AR2PIA
AR2PIA
AR2PIA
AR2TS
AR2TS
AR2TS
AR2TS
AR2TS
AR2TS
AR2CUTO
AR2CUTO
AR2CUTI
AR2CUTI
Step 4
Align the AR2POA roof panels with the outside of the shelter and space
the AR2PIA panels central. Attach the AR2TS Strips, screwing through the
roof panels. Fix the AR2CUTO and AR2CUTI to the top of the shelter as shown
below.
8

FT1
FT1
FT1
FT1
FT1
FT3
FT3
FT3
FT3
FT3
Step 5
Move the shelter to it's final position, and attach the FT1 and FT3
foot brackets. Fix the shelter to the ground using the anchor bolts.
9

40.75 39.17
87.07 75.87
40.75
81.87
10
PLAN VIEW
OVERALL DIMENSIONS AND GROUND FIXING POSITIONS
Suggested size for concrete base: 8" oversized on all four sides.

11
CONTACT DETAILS:
Email : [email protected]
Web : www.nobutts.com
Tel : [phone]
No Butts Bin Company, Inc. 16 Birch Lane, Madison, CT 06443
MAINTENANCE:
To ensure your products give you many years of use we recommend that you:
THANK YOU
FOR PURCHASING THIS PRODUCT
Clean panels regularly with soapy water •
Ensure all fittings are tight (for example after a big storm) •
Touch up any exposed metal should it get scratched •
All Parts and Fixings checked by:
Print Name: Signature:
