NBB SR8304-F User manual

Assembly Instructions
Shelter type: SR8304-F
SR8304-F-01-221021-USA

1
7
3
14
15
4
4
8
11
11
1312
11
8
5
2
6
9
9
2
EXPLODED VIEW
ITEM
NO. PART NAME
DRG NUMBER LENGTH QTY.
1 S1C Frame S1C
Panel
outside
4
2 CB1 Bracket CB1
Default
8
3 JF1 Bracket JF1
Default
4
4 Post P1 P1
Default
2
5 ST3 Roof Tie ST3
Default
1
6 DR Bracket DR
Default
8
7 AR2R 2m Pitch Rafter AR2R-02
Default
3
8
AR2IS 2m Pitch Infill
Panel Shallow
AR2IS-02
Default
2
9
ARFS2 Apex Roof F
section 2m
ARFS2
Default
2
10
AR2CLT2 2m Apex
Roof centre lower trim
2m
AR2CLT2
Default
1
11
AR2POA AR2 Roof
Panel outer ALU
AR2POA
Default
4
12
AR2CUT2 2m Apex
Roof centre upper trim
2m
AR2CUT2
Default
1
13
AR2TS 2m Apex Roof
Trim strip
AR2TS-01
Default
2
14 FT1 Bracket FT1
Default
4
15 FT3 Bracket FT3
Default
3
16 40x40 Plastic End Cap EC40
40 x 40
4

3
PARTS LIST
ITEM
NO. PART NAME
DRG NUMBER Size (inch)
QTY.
1 S1C Frame S1C
78.74 x 40.74
4
2 CB1 Bracket CB1
4.3 x 4.3 x 1.57
8
3 JF1 Bracket JF1
4.33 x 1.57
4
4 Post P1 P1
78.75 x 40.5
2
5 ST3 Roof Tie ST3
81.1 x 1.57 x 1.57
1
6 DR Bracket DR
4.3 x 1.6 x 2
8
7 AR2R 2m Pitch Rafter AR2R-02
85.75 3
8
AR2IS 2m Pitch Infill
Panel Shallow
AR2IS-02
85 2
9
ARFS2 Apex Roof F
section 2m
ARFS2
83.1 x 2 x 2
2
10
AR2CLT2 2m Apex
Roof centre lower trim
2m
AR2CLT2
82.85 1
11
AR2POA AR2 Roof
Panel outer ALU
AR2POA
45.5 x 41.3
4
12
AR2CUT2 2m Apex
Roof centre upper trim
2m
AR2CUT2
83 1
13
AR2TS 2m Apex Roof
Trim strip
AR2TS-01
45.5 x 2.3
2
14 FT1 Bracket FT1
1.57 x 1.57 x 3.94
4
15 FT3 Bracket FT3
1.57 x 3.15 x 4.17
3
16 40x40 Plastic End Cap EC40
1.6 x 1.6
4

4
FIXINGS
Tools required:
Drill/Screwdriver
Mallet
17mm Wrench
T25 Torx bit
Fittings Bolt set M10 T25 T38 BTANCM12100
M10 x 60mm Nut Washer
1" Tech
screw
1.5"
Tech
screw
Black
Caps
M10/12 x 100 mm
Concrete Bolt
Pack A+B
33 33 66 136 40 66 11

40.75
83.07
42.32
MEASURE THE WIDTH AND DEPTH
OF THE SHELTER TO CHECK
CORRECT ALIGNMENT.
Please note:
1.5" Tec Screws
are for roof panels only
S1C
S1C
JF1
CB1
CB1
JF1
CB1
CB1
JF1
CB1
Step 1
Assemble S1C frames to make up the main structure using CB1
brackets for the corners and JF1 brackets for the straight joints.
5

ST3
CB1
P1
CB1
P1
JF1
JF1
CB1
CB1
A
B
P1
CB1
CB1
ST3
P1
ENSURE CORRECT
ALIGNMENT ON
CORNERS
CB1
CB1
DETAIL A
SCALE 1 : 5
DETAIL B
SCALE 1 : 5
6
Step 2
Attach P1 Posts to S1C frames using JF1 Brackets. Fix the ST3 Tie Bar to
the P1 Posts as shown below using CB1 Brackets.

AR2IS
AR2IS
AR2R AR2R
DR
DR
DR
DR
DR
AR2R
AR2IS
AR2IS
AR2R
AR2R
AR2R
DR
DR
DR
DR
DR
7
Step 3
Attach AR2R rafters using DR brackets. Secure the AR2IS to S1C frames using
tech screws. The end rafters should be placed in position at the same time as
the AR2IS .

A
ARFS2
ARFS2
AR2CLT2
AR2CLT2
ARFS2
ARFS2
DETAIL A
SCALE 1 : 2
8
Step 4
Attach the AR2CLT2 to the top of the rafters. The ARFS2 parts are to be
attached to the lower part of the rafters as shown below.

FT1
FT3
FT3
FT1
FT3
AR2POA
AR2POA
AR2POA
AR2POA
AR2CUT2
AR2TS
AR2TS
FT1
FT1
FT3
AR2POA
AR2POA
AR2POA
AR2POA
AR2CUT2
FT1
FT1
FT1
FT1
FT3
FT3
AR2TS
AR2TS
9
Step 5
Attach the AR2POA roof panels. Cap off the top using the AR2CUT2 trim as shown.
Use the AR2TS strips to cover the gaps between the panels.
Once the shelter is in its final position and square, it can be secured to
the ground with the FT3 and FT1 brackets using the concrete bolts.

81.50
83.07
40.75
42.32
PLAN VIEW
OVERALL DIMENSIONS AND GROUND FIXING POSITIONS
Suggested size for concrete base: 8" oversized on all 4 sides.
10

12
MAINTENANCE:
To ensure your products give you many years of use we recommend that you:
THANK YOU
FOR PURCHASING THIS PRODUCT
Clean panels regularly with soapy water •
Ensure all fittings are tight (for example after a big storm) •
Touch up any exposed metal should it get scratched •
CONTACT DETAILS:
Email : [email protected]
Web : www.nobutts.com
Tel : [phone]
No Butts Bin Company, Inc. 16 Birch Lane, Madison, CT 06443
All Parts and Fixings checked by:
Print Name: Signature:
