Remote I/O Chassis
This kit provides a Remote I/O Chassis for the NCR CX7 All-in-One POS (7772) or
NCRCX5 All-in-One POS(7773).
•7772-K038 – Remote USBCentric I/O (Retail) Chassis
•7772-K039 – Remote SerialCentric I/O (Hospitality) Chassis

2 Remote I/O Chassis
Kit Contents
7772-K038 Remote USBCentric I/O(Retail) Chassis
Item Part Number Description
1Remote USBCentric I/O(Retail) Chassis Assembly
497-0526508 Bottom Plate, Remote I/O, CX7
497-0526509 Casing,Remote I/O, CX7
497-0526511 Remote I/OPlate and Shield, Retail, CX7
497-0467780 Foot, Rubber, 7600
497-0525283 PCBAssembly – CX7 I/OBoard, Retail
006-8617798 Screw, M3 x 8mm Machine, Phillips, Flat, Black
006-8613167 Screw, M3 x 6mm, SEMS, Pan Head, Phillips, Machine
Screw External Tooth Washer, Zinc Plate
497-0527120 Label, CX7 Remote I/O, Retail
2 497-0526512 L-Shaped Bracket, CX7
3 006-8617798 M3 x 8mm Machine, Phillips, Flat, Black
4 497-0527274 Label, Vesa Flame Retardant, Black

Remote I/O Chassis 3
7772-K039 Remote Serial Centric I/O(Hospitality) Chassis
Item Part Number Description
1Remote Serial Centric I/O(Hospitality) Chassis Assembly
497-0526508 Bottom Plate, Remote I/O, CX7
497-0526509 Casing,Remote I/O, CX7
497-0526510 Remote I/OPlate and Shield, HSR, CX7
497-0467780 Foot, Rubber, 7600
497-0525263 PCBAssembly – CX7 I/OBoard, HSR
006-8617798 Screw, M3 x 8mm Machine, Phillips, Flat, Black
006-8613167 Screw, M3 x 6mm, SEMS, Pan Head, Phillips, Machine
Screw External Tooth Washer, Zinc Plate
497-0527119 Label, CX7 Remote I/O, Hospitality
2 497-0526512 L-Shaped Bracket, CX7
3 006-8617798 M3 x 8mm Machine, Phillips, Flat, Black
4 497-0527274 Label, Vesa Flame Retardant, Black

4 Remote I/O Chassis
Installation Procedure
Warning: Disconnect the AC power cord from the AC outlet and wait 30 seconds
before servicing the terminal.
1. Install the Brackets on each side of the Remote I/O Chassis (2 screws per bracket) in
the orientation shown below.
Note: The Brackets may also be mounted 180° from the position shown below.
Illustration below shows the Remote SerialCentric I/O(Hospitality) Chassis (7772-
K039).

Remote I/O Chassis 5
2. Mount the assembly on the wall as desired. The Remote I/OChassis can be mounted
in four (4)ways:
I/O Facing Up
I/O Facing Down

6 Remote I/O Chassis
I/O Facing Right

Remote I/O Chassis 7
I/O Facing Left
3. Connect the cables to the appropriate I/Oport. For information on the ports
available for each kit, refer to the I/OPorts section:
•7772-K038 Remote USBCentric I/O(Retail) Chassis on the next page
•7772-K039 Remote Serial Centric I/O(Hospitality) Chassis on page9
4. Mount the Vesa Flame Retardant Label on the Back Cover as shown.
Note: The Label is needed when mounting on a third-party arm.

8 Remote I/O Chassis
I/OPorts
7772-K038 Remote USBCentric I/O(Retail) Chassis
Callout Port Name
1 RJ50 Serial (Enhanced UART)
2 Dual USB 3.0
3 DisplayPort
4 DB9 Serial (Standard UART)
5 LAN In
6 LANOut
7 USB-C
8 LED
9 24VPower In
10 USB12V
11 USB24V
12 Cash Drawer

Remote I/O Chassis 9
7772-K039 Remote Serial Centric I/O(Hospitality) Chassis
Callout Port Name
1 RJ12 Serial
• COM1 (Enhanced UART)
• COM2 (Standard UART)
• COM3 (Enhanced UART)
• COM4 (Standard UART)
2 Cash Drawer A
3 Cash Drawer B
4 DisplayPort
5 LANIn
6 LAN Out
7 USB-C
8 LED
9 24VPower In
10 USB24V
11 USB12V
12 Dual USB 3.0
13 RJ45 Serial
• COM5 (Enhanced UART)
• COM6 (Standard UART)
