GENERAL DESCRIPTION MANUAL
INT-1024 (IPK)
Document Revision 4
(Release 4000/4500)

NEC Unified Solutions, Inc. reserves the right to change the specifications,
functions, or features at any time without notice.
NEC Unified Solutions, Inc. has prepared this document for use by its
employees and customers. The information contained herein is the property of
NEC Unified Solutions, Inc. and shall not be reproduced without prior written
approval of NEC Unified Solutions, Inc.
Dterm and NEAX are registered trademarks of NEC Corporation and Electra Elite
and EliteMail are registered trademarks of NEC America, Inc. TeLANophy is a
registered trademark of Active Voice, Inc. Microsoft and Windows are registered
trademarks of Microsoft Corporation. AT&T is a registered trademark of AT&T
Wireless Services, Inc. Q-Master is a trademark of Zeacom Limited.
Copyright 2005
NEC Infrontia, Inc.
6535 N. State Highway 161
Irving, TX 75039-2402
Technology Development

___________________________________________________________________________________
PREFACE
GENERAL
INFORMATION The Electra Elite IPK system is a feature-rich key system that provides over
200 features including Computer Telephony Integration, Least Cost Routing,
Uniform Call Distribution, ISDN-BRI Voice Trunks, ISDN-PRI Voice Trunks, IP
Telephony, Voice over Internet Protocol (VoIP) trunks and stations, and many
others.
The Electra Elite IPK system meets the customer needs today and, as
business expands, the system can be expanded to grow as well.
The Electra Elite IPK system has a set of manuals that provide all the
information necessary to install and support the system. The manuals are
described in this preface.
THIS MANUAL This manual provides general information about the system, its features,
system configuration, and standards. This manual provides an overview of
the Electra Elite IPK system and is useful when presenting information to
potential customers.
Chapter 1 – Introduction
This chapter provides an overview and a brief description of the system.
Chapter 2 – Features
This chapter provides a list of features that are available with the system.
Each feature is briefly described.
Chapter 3 – Equipment
This chapter provides a list and brief description of the equipment that is
available with the system.
Chapter 4 – Installation, Programming, and Maintenance Overview
This chapter briefly describes the installation, programming functions, and
maintenance of the system.

Chapter 5 – Hardware Specifications
This chapter provides requirements and specifications relating to the
system hardware. This chapter is helpful to those that install the system.
SUPPORTING
DOCUMENTS Electra Elite IPK Features and Specifications Manual
This manual provides detailed information concerning every feature
available in the system.
Electra Elite IPK System Hardware Manual
The System Hardware Manual is provided for the system installer. This
manual has detailed instructions for installing the Electra Elite IPK KSU,
ETUs, Multiline Terminals, and optional equipment.
Electra Elite IPK Programming Manual
This manual provides instructions for programming the Electra Elite IPK
system using a Multiline Terminal or PC.
Electra Elite IPK Least Cost Routing Manual
This manual provides instructions to the service technician for
programming the customer site for least cost routing.
Electra Elite IPK Job Specifications Manual
This manual is intended to help the technician with installing and
maintaining the Electra Elite IPK system. This manual contains the job
specification worksheets. When these worksheets are completed, they
provide all of the system programming values and configuration
information necessary to assist technicians in maintaining the system.
Electra Elite IPK Key-Common Channel Interoffice Signaling (K-CCIS)
Manual
This manual provides information for installing and programming the
Key-Common Channel Interoffice Signaling (K-CCIS) System.
Electra Elite IPK Wireless System Manual
This manual describes the system and provides hardware installation and
programming procedures for the Electra Elite IPK Wireless
Communication System (WCS).

Regulatory Information

General Description Manual i
___________________________________________________________________________________
___________________________________________________________________________________
REGULATORY
GENERAL
INFORMATION Established Federal Communications Commission (FCC) rules permit this
telephone system to be directly connected to the telephone network. A jack is
provided by the telephone company. Jacks for this type of customer provided
equipment are not provided on party lines or coin lines.
The telephone company may make changes in its technical operations and
procedures. When such changes affect the compatibility or use of the Electra
Elite IPK system, the telephone company is required to give adequate notice
of the changes.
COMPANY
NOTIFICATION Before connecting this telephone system to the telephone network, the
following information must be provided to the telephone company:
1. Your telephone number.
2. FCC registration number:
H When the system is to be installed as a Key Function system (no
dial access to Trunk Groups/Route Advance Blocks), use the
following number:
NIFMUL-43074-KF-E
H When the system is to be installed as a Multifunction system, use
the following number:
NIFMUL-43076-MF-E
H When the system is to be installed as a PBX Function system, use
the following number:
NIFMUL-43075-PF-E
H Ringer Equivalence Number (REN): 2.0B
H USOC jacks required: RJ21X and RJ2GX

Document Revision 4 Electra Elite IPK
___________________________________________________________________________________
ii Regulatory
___________________________________________________________________________________
The following table lists the Facility Interface Codes (FIC), Ringer
Equivalent Numbers (REN), Service Order Codes (SOC), and Jack Types
for the interface ETUs.
INCIDENCE OF HARM When the system is malfunctioning, it may also be causing harm to the
telephone network. The telephone system should be disconnected until
the source of the problem can be determined and until repair has been
made. When this is not done, the telephone company may temporarily
disconnect service.
Table 1 FIC, REN, SOC, and Jack Types for Electra Elite IPK System ETUs
Trunk/Station ETU Type FIC REN SOC Jack
BRT(4)-U( ) ETU 02IS5 N/A 6.0F N/A
CAMA Trunk 02RV-O 0.7A 9.0F RJ21X
COI(4)-U( ) ETU (Loop Start) 02LS2 0.7A 9.0F RJ21X
COI(8)-U( ) ETU (Loop Start) 02LS2 0.7A 9.0F RJ21X
COI(8)-U( ) ETU (Ground Start) 02GS2 0.7A 9.0F RJ21X
COIB(4)-U(10) ETU ETU for COI/
COID Mode (Loop Start) 02GS2 0.7A 9.0F RJ21X
COIB(4)-U(10) ETU ETU for COI
Mode (Ground Start) 02GS2 0.7A 9.0F RJ21X
COIB(4)-U(20) ETU ETU for
COID/COI Mode (Loop Start) 02LS2 0.7A 9.0F RJ21X
COIB(8)-U( ) ETU for COI/COID
Mode (Loop Start) 02LS2 0.7A 9.0F RJ21X
DID(4)-U( ) ETU 02RV2T N/A 9.0F RJ21X
DTI-U( ) ETU
04DU9-BN
04DU9-DN
04DU9-1KN
04DU9-1SN
N/A 6.0P N/A
OPX(2)-U( ) ETU 0L13C N/A 9.0F RJ21X
PRT(1)-U( ) ETU 04DU9-1SN N/A 6.0P N/A
TLI(2)-U( ) ETU TL31M N/A 9.0F RJ21X

Electra Elite IPK Document Revision 4
General Description Manual - iii
___________________________________________________________________________________
___________________________________________________________________________________
General Description Manual iii
___________________________________________________________________________________
RADIO FREQUENCY
INTERFERENCE In compliance with FCC Part 15 rules, the following statement is provided:
IMPORTANT NOTE
“This equipment generates, uses, and can radiate radio frequency
energy and if not installed and used in accordance with the System
Hardware Manual, may cause interference to radio communications.
This equipment has been tested and approved for compliance with the
limits for a Class B (except as noted below) computing device pursuant
to subpart J of Part 15 of FCC Rules, that are designed to provide
reasonable protection against such interference when operated in a
commercial environment. Operation of this telephone system in a
residential area is likely to cause interference, in which case, the user,
at his or her own expense, is required to take whatever measures may
be required to correct the interference.”
 When equipped with the B64-U30 KSU and P64-U20 PSU, the Electra Elite
IPK can be operated as a Class B device except when using one of the
ETUs in the following table. The system then becomes a Class A device
that may not be used in a residential area.
HEARING AID
COMPATIBILITY The NEC Multiline Terminals and NEC Single Line Telephones that are
provided for this system are hearing aid compatible. The manufacturer of
other Single Line Telephones for use with the system must provide notice
of hearing aid compatibility to comply with FCC rules that now prohibit the
use of non-hearing aid compatible telephones.
DIRECT INWARD
DIALING Operating this equipment without providing proper answer supervision is a
violation of Part 68 of the FCC rules.
Proper Answer Supervision occurs when:
H This equipment returns answer supervision to the Public Switched
Telephone Network (PSTN) when Direct Inward Dialing (DID) calls
are:
J Answered by the called station.
J Answered by the Attendant.
ACD(8)-U10 CMS(2)/(4)-U30 FMS(2)/(4)/(8)-U30 IPCA( )-U10
CCH(4)-U-10 EXPT(2)-U10 HUB(8)-U10 VMS(2)/(4)/(8)-U30
SPE(M)-U( )

Document Revision 4 Electra Elite IPK
___________________________________________________________________________________
iv Regulatory
___________________________________________________________________________________
J Routed to a recorded announcement that can be administered
by the Customer Premise Equipment (CPE) user.
J Routed to a dial prompt.
H This equipment returns answer supervision on all DID calls
forwarded to the Public Switched Telephone Network (PSTN).
Permissible exceptions are:
J A call is unanswered.
J A busy tone is received.
J A reorder tone is received.
VOICE
ANNOUNCEMENT/
MONITORING OVER
DID LINES CAUTION
Using the Voice Announcement feature to eavesdrop or record sound
activities at the other end of the telephone line may be illegal under
certain circumstances and laws. Consult a legal advisor before
implementing any practice to monitor or record a telephone
conversation. Some federal and state laws require a party monitoring
or recording a telephone to use a beep-tone(s), notify all parties to the
telephone conversation and/or obtain consent of all parties to the
telephone conversation. In monitoring or recording sound activities at
the other end of the telephone line using the Voice Announcement
feature, the sound of the alert tone at the beginning of the Voice
Announcement may or may not be considered sufficient under
applicable laws. Some of the applicable laws provide for strict
penalties for illegal monitoring or recording of telephone conversations.
MUSIC ON HOLD IMPORTANT NOTE
"In accordance with U.S. Copyright Law, a license may be required
from the American Society of Composers, Authors and Publishers, or
other similar organization, if radio or TV broadcasts are transmitted
through the Music On Hold feature of this telecommunication system.
NEC Unified Solutions, Inc., hereby disclaims any liability arising out of
the failure to obtain such a license."

Electra Elite IPK Document Revision 4
General Description Manual - v
___________________________________________________________________________________
___________________________________________________________________________________
General Description Manual v
___________________________________________________________________________________
SERVICE
REQUIREMENTS If equipment malfunctions, all repairs must be performed by an authorized
agent of NEC Unified Solutions, Inc. or by NEC Unified Solutions, Inc. The
user requiring service is responsible for reporting the need for service to
an NEC Unified Solutions, Inc. authorized agent or to NEC Unified
Solutions, Inc.
UL REGULATORY
INFORMATION This equipment has been listed by Underwriters Laboratories and found to
comply with all applicable requirements of the standard for telephone
equipment UL 1459.
INDUSTRY CANADA
REQUIREMENTS Industry Canada has established rules that permit this telephone system
to be directly connected to the telephone network. Prior to the connection
or disconnection of this telephone system to or from the telephone
network, the telephone company must be provided with the following
information.
1. Your telephone number.
2. IC registration number: 140 7942 A
3. Ringer Equivalence Number (REN) of the equipment: 2.1
The Industry Canada label identifies certified equipment. This certification
means that the equipment meets certain telecommunications network
protective, operational and safety requirements as prescribed in the
applicable TerminalEquipment Technical Requirements document(s). The
Department does not guarantee that equipment operates to the user
satisfaction.
Before installing this equipment, users should ensure that it is permissible
to be connected to the facilities of the local telecommunications company.
The equipment must also be installed using an acceptable method of
connection. The customer should be aware that compliance with the
above conditions may not prevent degradation of service in some
situations.
Repairs to certified equipment should be coordinated by a representative
designated by the supplier. Any repairs or alterations made by the user to
this equipment, or equipment malfunctions, may give the
telecommunications company cause to request the user to disconnect the
equipment.

Document Revision 4 Electra Elite IPK
___________________________________________________________________________________
vi Regulatory
___________________________________________________________________________________
Users should ensure for their own protection that the electrical ground
connections of the power utility, telephone lines and internal metallic water
pipe system, When present, are connected together. This precaution may
be particularly important in rural areas.
CAUTION
Users should not attempt to make such connections themselves, but
should contact the applicable electric inspection authority or electrician.
The Ringer Equivalence Number (REN) assigned to each terminal device
provides an indication of the maximum number of terminals allowed to be
connected to a telephone interface. The termination of an interface may
consist of any combination of devices subject only to the requirement that
the sum of the Ringer Equivalent Numbers of all the devices does not
exceed five.
This equipment has been listed by the Canadian Standards Association
and found to comply with all applicable requirements of the standard for
telephone equipment C 22.2 No. 225.
This equipment meets IC requirements CS03.
This digital apparatus does not exceed the Class A limits for radio noise
emissions from digital apparatus as set out in the radio interference
regulations of Industry Canada.
Le present appareil numerique n’emet pas de bruits radioelectriques
depassant les limites applicables aux appareils numeriques de Classe A
prescrites dans le reglement sur le brouillage radioelectrique edicte par
Industrie Canada.
BATTERY DISPOSAL The Electra Elite IPK system includes the batteries listed below. When
disposing of these batteries, KSUs, and/or ETUs, you must comply with
applicable federal and state regulations regarding proper disposal
procedures.
Table 2 Battery Types and Quantities for KSUs and ETUs
Unit Name Type of Battery Quantity
B64-U20 KSU Lead Acid 2
CPUI( )-U( ) ETU Nickel-Cadmium 1
CTI/VP(4)/(8)/(12)/(16)-U( ) ETU Lithium 1

Electra Elite IPK Document Revision 4
General Description Manual - vii
___________________________________________________________________________________
___________________________________________________________________________________
General Description Manual vii
___________________________________________________________________________________
The Electra Elite IPK CPUI( )-U( ) ETU provides memory backup for
approximately 21 days. The Ni-Cd battery should be replaced about every
two years.
IMPORTANT SAFEGUARDS FOR BATTERY DISPOSAL
DO NOT PLACE USED BATTERIES IN YOUR REGULAR TRASH! THE
PRODUCT YOU PURCHASED CONTAINS A NICKEL-CADMIUM OR
SEALED LEAD BATTERY. NICKEL-CADMIUM OR SEALED LEAD
BATTERIES MUST BE COLLECTED, RECYCLED, OR DISPOSED OF IN
AN ENVIRONMENTALLY SOUND MANNER.
The incineration, landfilling or mixing of nickel-cadmium or sealed lead
batteries with the municipal solid waste stream is PROHIBITED BY LAW in
most areas. Contact your local solid waste management officials for other
information regarding the environmentally sound collection, recycling, and
disposal of the battery.
Nickel-Cadmium (or sealed lead) batteries must be returned to a federal or
state approved nickel-cadmium (or sealed lead) battery recycler. This may
be where the batteries were originally sold or a local seller of automotive
batteries. Contact your local waste management officials for other
information regarding the environmentally sound collection, recycling and
disposal of the battery contained in this product. For Ni-Cd batteries, you
can also call 1-800-8-BATTERYSM when further information is required.
The packaging for the Electra Elite IPK system contains the following
labels regarding proper disposal.
DTP-1HM-1 TEL
DTP-1HM-2 TEL Lithium 1
DTP-16HC-1 TEL Nickel-Cadmium 1
DTR-1HM-1 TEL Lithium 1
DTR-4R-1 TEL Nickel-Cadmium 1
DTU-4R-1 TEL Lead Acid 1
FMS(2)/(4)/(8)-U( ) ETU Nickel-Cadmium 1
MIFA-U10 ETU Nickel-Cadmium 1
MIFM-U10 ETU Nickel-Cadmium 1
VMS(2)/(4)/(8)-U( ) ETU Lithium 1
Table 2 Battery Types and Quantities for KSUs and ETUs (Continued)
Unit Name Type of Battery Quantity

Document Revision 4 Electra Elite IPK
___________________________________________________________________________________
viii Regulatory
___________________________________________________________________________________
PRODUCT PACKAGE LABELING
CONTAINS NICKEL-CADMIUM BATTERY.
BATTERY MUST BE RECYCLED OR
DISPOSED OF PROPERLY. MUST NOT BE
DISPOSED OF IN MUNICIPAL WASTE.
CONTAINS SEALED LEAD BATTERY.
BATTERY MUST BE RECYCLED. MUST NOT
BE DISPOSED OF IN MUNICIPAL WASTE.
Pb
Ni-Cd
CONTAINS NICKEL-METAL HYDRIDE
BATTERY. BATTERY MUST BE RECYCLED
OR DISPOSED OF PROPERLY. MUST NOT
BE DISPOSED OF IN MUNICIPAL WASTE.
Ni-MH

General Description Manual i
___________________________________________________________________________________
___________________________________________________________________________________
TABLE OF CONTENTS
Chapter 1 Introduction
Section 1 System Overview ........................................................................1-1
Section 2 Multiline Telephones ..................................................................1-3
Section 3 System Description ....................................................................1-9
Chapter 2 Features
Section 1 Features List ...............................................................................2-1
Section 2 Features Descriptions ................................................................2-5
Chapter 3 Equipment
Section 1 Equipment List ............................................................................3-1
Section 2 KSU Power-Based ETU Quantity Limitations ........................3-19
Chapter 4 Installation, Programming, and Maintenance Overview
Section 1 Installation ...................................................................................4-1
Section 2 Programming ..............................................................................4-2
Section 3 Maintenance ................................................................................4-3
Chapter 5 Hardware Specifications
Section 1 System Capacity .........................................................................5-1

Document Revision 4 Electra Elite IPK
___________________________________________________________________________________
ii Table of Contents
___________________________________________________________________________________
Section 2 Traffic Capacity .......................................................................... 5-1
Section 3 Cabling Requirements and Specifications .............................. 5-2
Section 4 Power Requirements ................................................................. 5-6
4.1 Power Supply Inputs ...............................................................................5-6
4.2 Power Supply Consumption ....................................................................5-6
Section 5 Environmental Conditions ........................................................ 5-6
5.1 Temperature ............................................................................................5-6
5.2 Humidity ..................................................................................................5-6
5.3 Weights and Dimensions. .......................................................................5-7
Section 6 Audible and Visual Indication ................................................. 5-12
6.1 Tone Patterns ........................................................................................5-12
6.2 Multiline Terminal LED Flash Patterns ..................................................5-12
Section 7 Outside Line Types .................................................................. 5-15
Section 8 Network and Control ................................................................ 5-15
8.1 Transmission, Network, and Control Specifications ..............................5-15
8.1.1 Transmission ........................................................................................5-15
8.1.2 Network ................................................................................................5-15
8.1.3 Control ..................................................................................................5-16
8.1.4 Telephone .............................................................................................5-16
Section 9 Dialing Specifications .............................................................. 5-17
9.1 Dial Pulse Address Signaling ................................................................5-17
9.2 Dual-Tone Multifrequency (DTMF) Address Signaling ..........................5-17

Electra Elite IPK Document Revision 4
General Description Manual - iii
___________________________________________________________________________________
___________________________________________________________________________________
General Description Manual iii
___________________________________________________________________________________
Section 10 External Equipment Connection .............................................5-18
10.1 Music Sources for Music on Hold via KSU ............................................5-18
10.2 Music Source for Station Background Music via COI ETU ...................5-18
10.3 External Paging (Audio) ........................................................................5-18
10.4 External Tone Ringer/Night Chime Output ............................................5-19
10.5 SMDR Output ........................................................................................5-19
10.6 PC Connection ......................................................................................5-19
10.7 Relay Contact .......................................................................................5-19
Section 11 Battery Backup .........................................................................5-19
11.1 System Backup .....................................................................................5-19
11.2 Memory Backup ....................................................................................5-19

Document Revision 4 Electra Elite IPK
___________________________________________________________________________________
iv Table of Contents
___________________________________________________________________________________
THIS PAGE INTENTIONALLY LEFT BLANK
