NEC Univerge SV8100 User manual

NEC SV8100 Telephone System
Quick Reference Guide
512-977-0505

2

3
SoftKeys (button function display on bottom line of the display)
•Each display telephone provides interactive softkeys for intuitive feature access. It is no longer
necessary to remember feature codes to access the telephone advanced features because the
function of the Softkeys change as the user processes calls.
Programmable Keys (See page 10 for programming instructions)
•Usually programmed for you e tension number, CO lines, Direct Station Select (DSS), Park, Page
and Record buttons.
Non Programmable Keys
•Message Waiting Lamp (Blinks with new voice mail message(s)
•E it (Cancel and return to main screen)
•Help (Press help then a programmable key to display the current key programming)
•Recall (Used to disconnect calls and get dial tone for the ne t call)
•Feature (Used in programming)
•Answer (Used to answer a second call)
•MIC (Turns the phone’s microphone on/off. Usually left on.)
•Menu (Access to call history, directory and settings)
•Hold (Place callers on Hold)
•Transfer (Transfer calls to stations)
•Speaker (Press to answer or place call hands free)
Volume/Contrast Adjustments
To Adjust Ring Volume (see page 12 to adjust the ring tone)
•While the phone is ringing (internal or e ternal)
•Press the up or down Cursor key to adjust the ring volume.
•OR
•Press the Menu key
•Select Option 3 “Settings”
•Select Option 1 “Ring Volume”
•Adjust the volume with the p or Down cursor key
•Save with the OK softkey
To Adjust Handset or Speakerphone Volume
•While on a call using either the Handset or Speakerphone press the up or down cursor key to
adjust the caller’s volume.
To Adjust the Display Contrast Levels
•With the phone idle (not in use) Press the up or down cursor key to adjust the LCD display
contrast from light to dark.

4
Making Calls
To Place Internal Calls
•Press the DSS* button of the person you wish to call and you can talk handsfree after the tone
or lift the handset.
•Or, Lift the handset or press Speaker and dial the 3-Digit Extension Number
•Softkeys allow options to Ring/Voice (Toggles from Handsfree to Ringing) MW (turn callback
message waiting lamp on) or VMsg (leave a voicemail message)
To Place External Calls
•Lift the Handset or press Speaker
•Dial 9 and the Telephone number
•Lift the handset or talk handsfree
*DSS button (Direct Station Select) is one of the programmable buttons to call another e tension and
see a busy status.
Answering Calls
To Answer Internal Calls
•When phone beeps, answer hands free or, if the phone rings lift the handset or press speaker.
•The MIC lamp must be on for caller to hear you hands free. (Press the button to toggle on/off)
To Answer External Calls
•When the phone rings lift the handset or press the Speaker button to answer hands free.
•The MIC lamp must be on for caller to hear you hands free. (Press the button to toggle on/off)
Call Park (a parked call may be retrieved from any phone)
To Park or Retrieve Parked callers
•To place a caller in park use the Park Keys.
•To retrieve a parked caller press the lit Park key.
•E ample: While talking to a caller place them on Park 1. Page and instruct the recipient of the
call on which park key the call is located. You can also pick the Park 1 caller back up and transfer
them to the intended recipient’s e tension number.

5
Transferring Calls
To Transfer a call to another extension
•With the call in progress press the DSS button and hang up (Blind Transfer) or wait for the user
to answer and announce the caller, then hand up (announced transfer)
•If no DSS button is available press the Trf Softkey or Transfer button then dial the 3-digit
e tension number and hang up (blind transfer) or wait for the user to answer and announce the
caller, then hang up (announced transfer)
•If there is no answer and you want to get the caller back press the blicking green outside line
button or the Conf key. Or, the caller will go to voicemail if transferred.
To transfer directly to Voicemail
•With the call in progress press the Hold button
•Press the VMsg Softkey
•Press the DSS button for the intended recipient. (If no DSS button then dial the 3-digit extension
number.)
•Hang up the handset to complete the transfer to voicemail
Placing Callers on Hold
To Place a caller on Hold
•With the call in progress press Hold
•To return to the call at your e tension press the blinking green button on your phone. The call
can be retrieved at other e tensions by pressing the blinking red button.
•Calls will recall to your e tension if not answered within the programmed recall time limit.
To Place a caller on Exclusive Hold
•With the call in progress press Feature + Hold
•To return the call at your extension only press the blinking green button on your phone. (It will
show as a steady red on all others)
•Calls will recall to your e tension if not answered within the programmed recall time limit.
Mute (mic key)
•The MIC button will disable the Handset, Headset or Speakerphone mic. While in use the MIC
button is on to indicate your Handset, Headset or Speakerphone mic is enabled. Press the
button to toggle on/off. This button is usually left on.

6
Paging (page only, no talk back)
Paging to Phone or External Paging Speakers
Lift the handset press the Page Key or:
To page the internal phones (Digital phones only)
•Lift the Handset, press the InPg Softkey, Dial 1 (the group number for all phones)
•After the Beep-Beep speak into the handset
•Hang up the handset
To page External Phones/Speakers
•Lift the Handset, press the ExPg Softkey to page the e ternal speakers. Dial 0 (the zone number
for the all page zone)
•After the Beep-Beep speak into the handset
•Hang up the handset
Conference Calls
To make a conference call
•With the first call in progress (internal or e ternal) press the Conf Softkey
•Press the DSS key or Dial (9 plus the area code and number) the second party (internal or
e ternal)
•Press the Add Softkey (after they answer)
•Press the Begin Softkey to connect all parties together
•You may add more parties (internal or e ternal) by pressing the Conf Softkey again
DND
To set DND
•Press the down arrow then the Prog Softkey
•Press the DND Softkey
•Press the Set Softkey
•Select the Ext Softkey for E ternal calls, Icm for internal calls or All for both e ternal and internal
calls
•With DND set, the selected calls will be answered by voicemail
To Cancel DND
•Press the down arrow then the Prog Softkey
•Press the DND Softkey
•Press the Cncl Softkey to cancel DND

7
Call Forward
To set Call Forwarding
•Press the down arrow, then the Prog Softkey
•Press the Cfwd Softkey
•Select All, Both, Busy, NA (no answer), B/NA (Busy/ No Answer) or Flw (Follow Me) Softkey
•Select the Set Softkey
•Dial the Extension or 9+off Premise number to forward to and press Speaker
To Cancel Call Forwarding
•Press the down arrow, then the Prog Softkey
•Press the Cfwd Softkey
•Select All, Both, Busy NA, B/NA or Flw Softkey then select the CNCL Softkey to cancel
Directed Call Pickup
To answer a ringing co-workers phone
•Lift the handset or press Speaker
•Dial * *
•Dial the 3-digit extension number of the co-workers phone you want to answer
Missed Calls
(Icon will be located in the upper left of the display)
To see a list of callers to your phone
•Select the Enter Cursor Key (Center Key)
•Select Option 1 Missed Calls
•Use the p or Down Cursor key to scroll through the missed call list
•The icon will turn off once all missed calls have been viewed
Call Waiting
(While on a call)
To answer a second caller (you hear camp on tones)
•Press Answer and talk to the 2
nd
caller (first caller placed on hold, press the Conf key to return)
•If not answered 2
nd
caller goes to voicemail

8
Redial/Caller ID Buffer
Last number redial
•Press the Redial Cursor key, last number dialed is displayed (use the scroll key to see
more).
•Press the # key, life the Handset, or press Speaker to dial the number.
List of the last 10 Dialed Numbers or Caller ID Numbers to your phone (Phone must ring to
store the caller ID info)
•Press the List Softkey.
•Select the Redial or CID (Caller ID) Softkey.
•Use the up or down arrow Softkey or cursor p or down key to scroll through the
stored numbers.
•From the Dialed list, Press the # key, life the Handset, or press Speaker to dial the
displayed number.
To Store/Dial System Speed Dial Numbers
(Available to all phones)
To Store System Speed Dial Numbers
•Press the Prog Softkey.
•Press the down arrow Softkey.
•Press the SPD Softkey.
•Dial the bin number (001-999) to program.
•Dial the Phone Number.
•Press the Hold button.
•Enter the Name using the keypad. *
•Press the Hold button to save (hear beep/beep/beep tone).
•Press the Speaker button to quit.
To dial the System Speed Dial Numbers
•Press the Dir Softkey.
•Press the SPD Softkey.
•Use the up or down arrow Softkeys to scroll through the numbers.
•Or enter the first letters for the name and use the up or down arrow Softkeys to scroll
through the numbers.
•Press the Dial Softkey to dial the displayed number.
*# = Space, <> = Move Cursor, Feature Key = Delete

9
To Store/Dial the Station Speed Dial Numbers
(Available at the individual station only)
To Store Station Speed Dial Numbers
•Press the Prog Softkey
•Press the STA Softkey.
•Dial the bin number (0-9) to program.
•Dial the Phone Number
•Press the Hold button.
•Enter the Name using the keypad.*
•Press the Hold button to save (hear beep/beep/beep tone)
•Press the Speaker button to quit
To dial the Station Speed Dial Numbers
•Press the Dir Softkey
•Press the STA Softkey.
•Use the up or down arrow Softkeys to scroll through the numbers.
•Or enter the first letters of the name and use the up or down arrow Softkeys to scroll
through the numbers.
•Press the Dial Softkey to dial the displayed number.
Setting the Clock (From the Administrators Phone only)
To set the Clock (for Daylight Saving Time Changes)
•Press the Speaker button
•Dial 728 + Time (4-Digits in 24hr. format, 0830 = 8:30 AM, 1645 = 4:45PM)
•Press the Speaker button to quit.
•Call Telco Data 512-977-0505 to change the date.
Program Station Names
To change the phone users name
•Press the Speaker button.
•Dial 700.
•Dial the 3-digit Extension Number to change.
•Enter the Name using the keypad *
•Press the Hold button to save. (Hear the beep/beep/beep tone)
•Press the Speaker button to quit.
*# = Space, <> = Move Cursor, Feature Key = Delete

10
To Program DSS/ One Touch Keys
DSS (Direct Station Select) or One Touch Dial Keys
•Press the Speaker button
•Dial 751
•Press the Key to be programmed (shows current programming. If already programmed for a
different function dial 00 to erase and press the Key again.)
•Dial 01 plus the 3-Digital Extension number or 9 + the outside number and press Hold to save
•You will hear confirmation tones
•Press another Key to program or Speaker to quit
One Touch Extension Ring/Voice Call Toggle
To set your extension to ring
•Press Speaker
•Dial 723
•Press Speaker to quit
To set your extension for voice call
•Press Speaker
•Dial 721
•Press Speaker to quit
Callback Request Notification*
If you call a busy or unanswered e tension and press 0 or the MW Softkey it will turn on (Blinks)
the message waiting lamps on both e tensions requesting a callback.
To Call Back and Reset the Callback Message Notification
•The called e tension can press the MW Softkey and select Call to return your call or CNCL to
cancel the call and turn the lamps off.
To Cancel this feature from your phone
•Press Exit (left of the Softkeys)
•Press the MW Softkey
•Press the All Softkey
*This usually gets turned on by mistake causing users to think they have a new voicemail
message. If you have no new messages you can cancel this feature from your phone.

11
TELBK, Telephone Book:
(Available at the individual station only)
Name Groups 1-4 (Optional):
•Press Menu key
•Select option 2 “Directory” by using the cursor key
•Selection option 3 “Setting” by using the cursor key
•Select the GrpName Softkey
•Select the group 1-4 to change the name
•Enter a Name for the Group using the keypad*
•Press Hold
•Select another group to name or e it.
To Program Phone Numbers in the Telephone Book
•Press Menu key
•Select option 2 “Directory” by using the cursor key
•Select option 1 “Regist” by using the cursor key
•Enter a Name for the number using the keypad*
•Press Hold
•Select the Group (1-4) to save in
•Dial the Phone number to call (9+number)
•Press Hold
•Enter the memory location 0-299
•Press Hold to save and add another number
To Dial Phone Numbers from the Telephone Book
•Select the Telephone Book icon, on the right cursor key
•Use the up or down keys to scroll through all of the names
•OR
•Enter the first few letter of the name
•Press the up or down cursor key
•Use the up or down key to scroll through the names and select the correct one
•Press the desired Softkey, CHG (Change), DEL (Delete) or Dial to dial the number.
•You may also press the Menu key and search by Name (Stored Name), GRP (Group), N M
(Number) or MEM (Memory location 0-299)
*# = Space, <> = Move Cursor, Feature Key = Delete

12
911 Emergency Calls
Emergency calls requiring outside assistance
•Lift the handset or press Speaker
•Dial 911. Describe the nature and location of the emergency. (It is very important to give the
correct address, Building number, etc., as the phone lines may have a different address listed.)
•The Attendant will be notified by an audible alarm displaying the e tension name number that
placed the emergency call.
To Turn Background Music On or Off:
To Hear Music from Your Phone (if equipped)
•Press the Speaker button
•Dial 725 (toggles on or off)
•Press the Speaker button to quit.
Changing Station Ring Tones
To Change the Internal/ External Ring Tone
•Press the Speaker button
•Dial 720
•Dial 1 for internal or 2 for e ternal ring tones
•Dial 1-8 to select the desired tone
•Press the Speaker button to e it and set
Headset*
To use a headset you need a Headset button programmed, or lift the Handset instead of
pressing the Headset button
•Plug the headset into the bottom of the phone. (The jack with the headset icon located ne t to
the handset jack)
•Press the Headset button to use the Headset. (You will hear dial tone and make your call or you
can answer a ringing phone.)
*Not all headsets are guaranteed to work. Most of the latest models of the Plantronics brand
are recommended. Please call Telco Data for more information.

13
Voice Mail and Auto Attendant
(Requires the optional InMail)
Automated Attendant: Automatically answers the incoming outside caller. After listening to a
customized message (Day, Night or Holiday) an outside caller can dial directly to an e tension or
department.
Voice Mail: Answers your phone and gives the caller the option to leave you a message or dial
another e tension.
Voice Mail Setup
1. Record your Greeting
•Press the VMsg Softkey
•Press the Greet Softkey
•Press the Gr1 (greeting 1) Softkey. (You may record other greetings later.)
•Press the Rec Softkey
•Follow the prompts to record your greeting
•Press LSTN (listen), REC (Record over), DEL (Delete), BACK (previous menu) or # to e it
2. Record your Name
•Press the VMsg Softkey
•Press R N (76) to Record your Name
•Press the Rec Softkey
•Follow the prompts to record your name
•Press LSTN (listen), REC (Record over), DEL (Delete), BACK (previous menu) or # to e it
3. Enter your Password* (Security Code)
•Press the VMsg Softkey
•Press O P (67) for Mail Bo Options
•Press the Code Softkey
•Follow the prompts; enter your 4-digit password. (You must use this each time you access your
mail bo . There is no way to retrieve the password – it can only be reset.)
•Press OK to save or Clear to start over
*Without a password callers may be able to listen and delete your voice mail messages.

14
To Check Voice Mail Messages
From your Phone:
•When the Message Waiting Lamp blinks, the display will indicate the number of message. Press
the VMsg Softkey, when prompted enter your security code.
•Follow prompts to listen to messages, or press the softkeys to Lstn then you can select Next,
Rplay, Del, or More. List, Rew, FFwd or More. Reply, Redir, Call or More. CID and Back.
From outside the System:
•Dial a Line answered by the Auto Attendant or dial the main number and ask the attendant to
transfer you to e t 300.
•When Auto Attendant answers, Dial # + your Mail Bo Number (usually your 3-digit e tension)
and when prompted enter your security code.
•Follow the prompts to listen to messages. Save, Erase and E it the same as if you were in the
office.
Voice Mail Options
While listening to messages dial:
•TI (84) to head the Time and Data the message was left
•SA (72) to Save the message
•MF (63) to have the Message Forwarded to another user
•E (3) to Erase the message
•L (5) to Listen to the ne t message
•B (2) to Back up a few seconds
•BB (22) to Backup to the Beginning
•G (4) to Go ahead a few seconds
•* to Pause/ Resume listening
•# to E it the listen mode
Conversation Recording*
Recording your conversation
•Press the “Record” button
•“Recording” will be in the display
•Press the “Record” button to stop or hang-up
•The recording will be saved as a voicemail message
*Before recording any conversation you should seek the advice of a local attorney to ensure you are
complying with State and Federal Law.

15
Auto Attendant Greetings
(All recordings or mode change must be from the System Administrators phone)
Recording the Day/Night/Override Greeting*
•Press the VMsg Softkey, when prompted enter your security code.
•Press 72 (SA) for the System Administrator menu.
•Press the Instr Softkey for the Instruction Menu Messages.
•Enter mailbo number 001 for the Day Greeting, 002 for the Night Greeting, 003 for the
Override Greeting
•Follow the prompts to Lstn (listen, Rec (Record) or Erase the greeting.
•To record or change the greeting press the Rec Softkey
•Press the Done Softkey or the # Key when finished recording.
•Press the Lstn Softkey to review.
•Press Rec Softkey to re-record, or press the Exit Softkey, Hang Up.
Activating the Override Greeting
(Used for holidays or une pected weather closings)
•Press the VMsg Softkey, when prompted enter your security code.
•Press 726 (SAO) for the System Administrator Override menu.
•Enter the Table Number 1.
•The Display/Prompts give the information about the Answering Schedule Override. You may
turn the mailbo On/Off or change the Mailbo number (MBOX, usually 003).
•To turn On, press the On Softkey. (Be sure the greeting for the override mailbo is recorded.)
•Press the Exit Softkey and Hang Up.
•This Override greeting will answer until you re-enter the System Administrator Override menu
and press the Off Softkey.
*When recording the Day/ Night greeting, it will be easier to change the greetings if you use
e tension numbers (Press 102 for Sales) instead of menu numbers (Press 1 for Sales). Any valid
e tension number, Mailbo number or Group number can be used, see your installer for a list
of numbers.
