NEC Xen Topaz User manual

NEC Business Solutions Ltd.
Document No.:8802
Release 2.0
April, 2005
Features and
Specifications Manual

April 2005 NEC Business Solutions Ltd
ii
Doc. No. 8802 - Release 2.0 April 2005
THIS PAGE INTENTIONALLY LEFT BLANK

Features and Specifications Manual Chapter 1 - iii
Doc. No. 8846 - Release 2.0 April 2005
Table of Contents
Chapter 1 Regulatory Information ..................................... 1
Section 1 Electromagnetic Interference (EMI). . . . . . . . . . . . . . . . . . . . . . . . . . 1
Section 2 Incidence of Harm. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Section 3 Hearing Aid Compatibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Section 4 Service Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Section 5 Compliance Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Section 6 Connection Requirements for Earthing the Topaz KSU . . . . . . . . . 2
Section 7 Voice Announcement/Monitoring . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Section 8 Music on Hold . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Section 9 Battery Disposal and Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Chapter 2 About This Manual ........................................... 5
Section 1 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Chapter 3 Charts and Illustrations ..................................... 7
Section 1 Charts And Illustrations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Chapter 4 Features ...................................................... 43
Abbreviated Dialling ................................................................ 43
Account Codes ....................................................................... 49
Alarm ................................................................................. 54
Alphanumeric Display .............................................................. 56
Attendant Call Queuing ............................................................ 57
Automatic Route Selection (F-Route) ............................................ 58
Background Music ................................................................... 65
Barge In ............................................................................... 67
Call Forwarding ..................................................................... 70
Call Forwarding, Fixed ............................................................. 74
Call Forwarding, Off-Premise ..................................................... 76
Call Forwarding to Abbreviated Dial ............................................. 80
Call Forwarding with Follow Me .................................................. 83
Call Forwarding/Do Not Disturb Override ....................................... 85
Call Redirect ......................................................................... 86

April 2005 NEC Business Solutions Ltd
iv Table of Contents
Doc. No.: 8846 - Release 1.1 April 2005
Call Timer ............................................................................ 88
Call Waiting / Camp On ............................................................ 89
Callback .............................................................................. 91
Caller ID .............................................................................. 93
Caller ID Sending .................................................................... 99
Central Office Calls, Answering ..................................................100
Central Office Calls, Placing .....................................................104
Class of Service .....................................................................108
Conference ..........................................................................120
Conference, Voice Call/Privacy Release .......................................124
Continued Dialling .................................................................126
Cost Centre Codes .................................................................128
Department Calling ................................................................129
Department Group - Call Forward ...............................................135
Department Step Calling ..........................................................138
Dial Number Preview ..............................................................139
Dial Pad Confirmation Tone ......................................................140
Direct Inward Dialling (DID) ......................................................141
Direct Inward Line (DIL) ...........................................................147
Direct Inward System Access (DISA) .............................................152
Direct Station Selection (DSS) Console .........................................159
Directed Call Pickup ...............................................................163
Do Not Disturb ......................................................................165
Doorphone ...........................................................................167
Fax Machine Compatibility .......................................................169
Flash .................................................................................171
Flexible System Numbering .......................................................173
Forced Trunk Disconnect .........................................................175
Group Call Pickup ..................................................................177
Handsfree and Monitor ............................................................180
Handsfree Answerback/Forced Intercom Ringing .............................182
Headset Operation .................................................................184
Hold ..................................................................................186
Hotline ...............................................................................190

Features and Specifications Manual v
Doc. No.: 8846 - Release 1.1 April 2005
Xen IPK Features and Specifications Manual
Intercom .............................................................................192
ISDN Compatibility .................................................................195
Last Number Redial ................................................................201
LCR – Least Cost Routing ..........................................................203
Line Preference ....................................................................210
Long Conversation Cutoff .........................................................213
Loop keys ............................................................................215
Meet Me Conference ...............................................................218
Meet Me Paging .....................................................................221
Meet Me Paging Transfer ..........................................................223
Memo Dial ...........................................................................225
Message Waiting ....................................................................227
Microphone Mute ...................................................................231
Multiple Directory Numbers / Call Coverage ..................................233
Music on Hold .......................................................................237
Name Storing .......................................................................240
Night Service ........................................................................242
Off Hook Signalling ................................................................247
Paging, External ....................................................................250
Paging, Internal ....................................................................253
Park ..................................................................................256
PBX Compatibility ..................................................................259
Prime Line Selection ..............................................................262
Private Line .........................................................................264
Programmable Function Keys ....................................................266
Reason of Transfer Display .......................................................273
Repeat Redial .......................................................................274
Ring Groups .........................................................................276
Ringdown Extension, Internal / External .......................................278
Room Monitor .......................................................................280
Save Number Dialled ..............................................................283
Secretary Call Buzzer ..............................................................285
Secretary Call Pickup ..............................................................287
Selectable Display Messaging ....................................................289

April 2005 NEC Business Solutions Ltd
vi Table of Contents
Doc. No.: 8846 - Release 1.1 April 2005
Serial Call ...........................................................................292
Single Line Telephones, Analogue Sets .........................................293
Station Message Detail Recording ...............................................295
Tandem Trunking (Unsupervised Conference) .................................307
Time and Date ......................................................................311
Toll Restriction .....................................................................313
Toll Restriction-Dial Block ........................................................317
Toll Restriction Override ..........................................................320
Transfer .............................................................................322
Trunk Group Routing ..............................................................326
Trunk Groups .......................................................................329
Trunk Queuing/Camp On .........................................................331
Trunk to Trunk Forwarding .......................................................333
Trunk to Trunk Transfer ..........................................................335
Voice Mail ...........................................................................338
Voice Mail Integration .............................................................356
Voice Response System (VRS) ....................................................365
Volume Controls ....................................................................379
Warning Tone For Long Conversation ...........................................380

Features and Specifications Manual Disclaimer - vii
Doc. No. 8802 - Release 2.0 April 2005
Disclaimer
NEC shall not be liable for any direct, indirect, consequential or incidental
damages about the use of this equipment, manual or any related materials.
The information in this technical manual is advisory in nature and is subject to
change. NEC may make improvements and changes in the products described
in this manual without notice.
Changes will be periodically made to the information in the new editions. Efforts
have been made to ensure that the contents of this manual are correct. Should
you find any error, NEC welcomes your comments to improve our
communications. Please contact NEC on 1800 036 136.
Contents of this manual are subject to change without prior notice at the
discretion of NEC Business Solutions Ltd.
This document has been prepared for the use of employees and customers of
NEC Business Solutions Ltd and may not be reproduced without prior written
approval of NEC Business Solutions Ltd.
Copyright © 2005
NEC Business Solutions Ltd
633 - 647 Springvale Road
Mulgrave Vic 3170

April 2005 NEC Business Solutions Ltd
viii - Disclaimer Features and Specifications Manual
Doc. No. 8802 - Release 2.0 April 2005
THIS PAGE INTENTIONALLY LEFT BLANK

Features and Specifications Manual Chapter 1 - 1
Doc. No. 8802 - Release 2.0 April 2005
Regulatory
Information
SECTION 1ELECTROMAGNETIC INTERFERENCE (EMI)
WARNING
This is a Class A product. In a domestic environment this product may cause radio
interference in which case the user may be required to take adequate measures.
SECTION 2INCIDENCE OF HARM
If the System is malfunctioning, it may also be causing harm to the telephone network.
The Telephone system should be disconnected until the source of the problem can be
determined and until repair has been made. If this is not done, the Network Provider
may temporarily disconnect the service.
SECTION 3HEARING AID COMPATIBILITY
The NEC Multiline Terminals that are provided for this system are hearing aid
compatible. The manufacturer of Single Line Telephones for use with the system must
provide notice of hearing aid compatibility to comply with ACA Technical Standards.
SECTION 4SERVICE REQUIREMENTS
WARNING
This equipment must only be installed and maintained by service personnel.
In the event of equipment malfunction, all repairs must be performed by an authorised
dealer of NEC Business Solutions Ltd or by NEC Business Solutions Ltd. It is the
responsibility of users requiring service to report the need for service to one of NEC
Business Solutions Ltd authorised agents or to NEC Business Solutions Ltd.
SECTION 5COMPLIANCE INFORMATION
This equipment has been tested to comply with all relevant ACA Technical Standards.
The Xen Topaz KSU must be permanently connected to protective earth, via the earth
terminal inside the KSU.
Chapter 1

Chapter 1 - 2 Regulatory Information
NEC Business Solutions Ltd XEN Topaz
Doc. No. 8802 - Release 2.0 April 2005
SECTION 6 CONNECTION REQUIREMENTS FOR EARTHING THE TOPAZ KSU
Because this Topaz KSU has been ACA approved as an Earthed-SELV Customer
Switching System for connection to a telecommunications network, the KSU Earth
terminal E(on the 308M System Mainboard) MUST be permanently connected to
Earth by connecting a minimum of 2.5mm2 green/yellow conductor cable.
This cable MUST be connected between a Multiple Earth Neutral (MEN) Bonding Bar
at the nearest convenient mains Switch Board to the KSU. This cable must serve no
other purpose than installing the KSU.
CAUTION: If this cable is not installed or requires disconnection, then the
telecommunication network connection(s), namely CO and/or ISDN, must be
disconnected first from the KSU.
Liability for this installation rests solely with the licensed installer/dealer. It is
recommended that the installer provide their label and it is to be placed in the Main
Switch Board, certifying that the installation complies with the safety earthing
installation manual instructions for the Topaz KSU Section 3.1.
(Technical References: AS/NZS 60950:2000, ACIF S009:2001. See Protective
Earthing Conductor requirements.)
SECTION 7 VOICE ANNOUNCEMENT/MONITORING
CAUTION
The use of monitoring, recording or listening devices to eavesdrop, monitor, retrieve or
record telephone conversations or other sound activities, whether or not
contemporaneous with its transmission may be illegal in certain circumstances under
federal or state laws. Legal advise should be sought prior to implementing any practice
that monitors or records any telephone conversation. The telecommunications
(Interception) Act 1979 (Cth), The telecommunications Act 1997, The Privacy Act 1988
and State and Territory Listening Devices Legislation are all relevant. Some federal and
state laws require some form of notification to all parties to the telephone conversation,
such as using a beep tone or other notification methods, or require the consent of all
parties to the telephone conversation, prior to monitoring or recording a telephone
conversation. Some of these laws incorporate strict penalties. Section 6 of the Industry
Guidelines recommend pre-recorded messages or verbal notification to alert callers
that the calls may be monitored:
For example: “Your call may be listened to and recorded for quality and coaching
purposes. Please tell the consultant if you don’t want this to happen.”
Section 6 of the Industry Guidelines also make recommendations in relation to
notifications in writing.

XEN Topaz NEC Business Solutions Ltd
Features and Specifications Manual Chapter 1 - 3
Doc. No. 8802 - Release 2.0 April 2005
SECTION 8MUSIC ON HOLD
IMPORTANT NOTE
In accordance with Australian Copyright Law, a license may be required from The
Australian Performing Right Association Limited (APRA), or other similar organisation,
when radio or TV broadcasts are transmitted through the Music On Hold feature of this
telecommunication system. NEC Business Solutions Ltd hereby disclaims any liability
arising out of the failure to obtain such a license.
SECTION 9BATTERY DISPOSAL AND SAFETY
This system includes the batteries listed below. When disposing of these batteries,
KSUs and/or cards, you must comply with applicable Federal and State regulations
regarding proper disposal procedures.
IMPORTANT SAFEGUARDS FOR BATTERY DISPOSAL
The incineration, landfilling or mixing of nickel-cadmium or sealed lead batteries with
the municipal solid waste stream is PROHIBITED BY LAW in most areas. Contact your
local solid waste management officials for other information regarding the
environmentally sound collection, recycling and disposal of the battery.
Nickel-Cadmium or sealed lead batteries must be returned to a Federal or State
approved nickel-cadmium or sealed lead battery recycler. This may be where the
batteries were originally sold or a local seller of automotive batteries. Contact your local
waste management officials for other information regarding the environmentally sound
collection, recycling and disposal of the battery contained in this product.
CAUTION
Danger of explosion if batteries are incorrectly installed. Replace only with the same or
equivalant type of battery as indicated throughout this manual.
Table 1-1
Unit Name Type of Battery Quantity
IP2AT-924M KSU Lithium 1
DX2E-32i/NXE Battery Box Lead Acid
(User supplied)
2/4

Chapter 1 - 4 Regulatory Information
NEC Business Solutions Ltd XEN Topaz
Doc. No. 8802 - Release 2.0 April 2005
THIS PAGE INTENTIONALLY LEFT BLANK

System Hardware Manual Chapter 2 - 5
Doc. No. 8846 - Release 2.0 April 2005
About This Manual
SECTION 1FEATURES
Before Reading This Section
This section provides detailed information on the system's features. If you don't know
what the various features are, review the Table of Contents for this section and the
manual's Index. After reviewing, turn back to this section for the specifics.
Using This Section
The features in this section are in alphabetical order, like a dictionary. This section
subdivides each feature definition into headings as follows:
The Compatibility Chart at the top of each feature shows you if the feature is
available for each system and what system software is required.
Description tells what the feature is and describes its benefits. Along with the
Description are the Conditions and Default Setting. Conditions provides the feature's
operational limits (if any). Default Setting outlines how the feature works with the
default programming. When initially installed, the system uses the default setting. For
specific default settings on each program, refer to the chart at the end of this book.
Programming explains the system programming that lets you customize the feature.
Some features require programming; other's don't. If you decide to customize a
feature, use Section 2 to enter the change into the system.
Related Features presents the feature interaction.
Operation consists of instructions on how to use each feature.
Read These Notes
Simplifying System Phone Operation with One-Touch Keys
A system phone user can access many features through Service Codes (e.g., Service
Code 841 answers a Message Waiting indication from a co-worker). To streamline the
operation of their phone, a system phone user can store these codes under One-Touch
Keys. This provides one-button operation for almost any feature. To find out more, turn
to the One-Touch Calling and One-Touch Serial Operation features.
Programmable Keys
When reading an instruction using programmable keys, you will see a notation similar
to (PGM 15-07 or SC nnn). This means that the key requires function code nnn, and
you can program this code through Program 15-07 or by dialling Service Code 851 or
852. Refer to the Programmable Function Keys feature for more information.
Chapter 2

Chapter 2 - 6 About This Manual
NEC Business Solutions Ltd XEN Topaz
Doc. No. 8846 - Release 2.0 April 2005
Using Handsfree
The manual assumes each extension has Automatic Handsfree. This lets a user just
press a line key or CALL key to answer or place a call. For extensions without
Automatic Handsfree, the user must:
Lift the handset or press SPK for Intercom dial tone
Lift the handset or press SPK, then press a line key for trunk dial tone

System Hardware Manual Chapter 3 - 7
Doc. No. 8846 - Release 2.0 April 2005
Charts and Illustrations
SECTION 1CHARTS AND ILLUSTRATIONS
Table 3-1 Post Dialling Service Codes
Dial This... For this feature... When you are...
1Handsfree Answerback /
Forced intercom Ringing
Changing the signalling
mode of your outgoing
Intercom call
2Step Call Calling a busy station
*Intercom Off-Hook Signalling Calling a busy station
0Camp On/Callback Calling a busy station
Chapter 3

Chapter 3 - 8 Charts and Illustrations
NEC Business Solutions Ltd XEN Topaz
Doc. No. 8846 - Release 2.0 April 2005
Table 2: Service Codes by Number
Dial this Service Code…1When you are... For this feature... Also see
Function Key...
1Except where indicated, dial Service Code from Intercom dial tone (e.g., press idle CALL key first).
* + Enter Account Code + * Entering an Account Code Account Codes -
715 + Extension No. Picking up a call ringing or
waiting at another extension
Directed Call Pickup
Voice Response
System (VRS)
-
867
Picking up a call ringing an
extension in your own pickup
group (including Ring Group
calls)
Group Call Pickup 24
841 Answer a Message Waiting
Indication Message Waiting 38
833 Setting the Automatic
Transfer for each trunk line Transfer -
834 Cancelling the Automatic
Transfer for each trunk line Transfer -
835 Setting the Destination for
Automatic Trunk Transfer Transfer -
751 Making a Combined Page Paging -
888 + 0 Cancelling Call Forwarding Call Forwarding 16
888 + 1 + Type (2-4)
Activating Personal
Answering Machine
Emulation
Voice Mail (Personal
Answering Machine
Emulation)
16
888 + 2 + Destination + Type (2-4) Activating Call Forwarding
when Busy/Not Answered Call Forwarding 16
888 + 3 + Destination + Type (2-4)
Activating Call Forward
Follow Me at the destination
extension
Call Forwarding with
Follow Me 16
888 + 4 + Destination + Type (2-4) Activating Call Forwarding
Immediate Call Forwarding 16
888 + 6 + Destination + Type (2-4) Activating Call Forwarding
when Unanswered (delayed) Call Forwarding 16
888 + 7 + Destination + Type (2-4) Activating Call Forwarding
(Both Ringing) Call Forwarding 16
724 (After #9 805 + 01-51 + busy) Disconnecting a call in
progress on a trunk
Forced Trunk
Disconnect -
713 + 3 + Message (01-20), or *4
713 + 3 + Hang up to cancel
Activating and cancelling
Selectable Display
Messaging
Selectable Display
Messaging 17
713 + 6 + Trunk access code +
Outside number, or 713 + 6 + Hold
+ Hang up to cancel
Forwarding your calls to an
off-premise telephone
number
Call Forwarding Off-
Premise 17

XEN Topaz NEC Business Solutions Ltd
System Hardware Manual Chapter 3 - 9
Doc. No. 8846 - Release 2.0 April 2005
713 + 7 + Record message + # +
Condition (2, 4, 6 or 7) +
Destination + Type (2 or 3) or *4
713 + 7 + 3 to cancel
Recording, listening to or
erasing a Personal Greeting
or Park and Page
Voice Response
System (VRS)
(Personal Greeting)
17
861 + Orbit (01-64) Picking up a call parked in a
system Park orbit (01-64) Park *04 + orbit
894 Splitting (switching) between
calls on an SLT Call Waiting / Camp On -
884 Calling your mailbox Voice Mail Integration 67
6321 Entering the system
programming mode
System Programming
Password Protection -
6322 Backing up system data Maintenance -
Hookflash + ## 891 + Enter
Account Code + Hookflash
Entering an Account Code at
an SLT Account Codes -
872
Using Universal Answer
Code to pick up a call ringing
over the paging system
Central Office Calls,
Answering -
Hookflash + #1 826 + extension +
hookflash twice
Activating Conference from a
Single Line set Conference -
* + bin Dialling a Common Personal
Abbreviated Dialling number Abbreviated Dialling 27
806 Flashing a trunk from an SLT Flash -
814 + bin Dialling a group Abbreviated
Dialling number Abbreviated Dialling 28
# Using Last Number Redial Last Number Redial -
831 + orbit (01-64)
Parking a call in a system
Park orbit (1-8, 01-32 or 01-
64)
Park *04 + orbit (1-64)
753 Setting up an Unsupervised
Conference
Tandem Trunking
(Unsupervised
Conference)
-
805 + 01 -51 Placing a call over a specific
trunk
Central Office Calls,
Placing *01 + trunk (001-51)
1 (Off-hook) Changing the signalling mode
of your outgoing Intercom call
Handsfree
Answerback/Forced
Intercom Ringing
-
4 (On-hook) Listening to the General
Message
Voice Response
System (VRS) -
6 (On-hook) Checking an extension's
number
Voice Response
System (VRS) -
8 (On-hook) Listening for the time Voice Response
System (VRS) -
Table 2: Service Codes by Number
Dial this Service Code…1When you are... For this feature... Also see
Function Key...
1Except where indicated, dial Service Code from Intercom dial tone (e.g., press idle CALL key first).

Chapter 3 - 10 Charts and Illustrations
NEC Business Solutions Ltd XEN Topaz
Doc. No. 8846 - Release 2.0 April 2005
0Placing a call using ARS or
Trunk Group Routing
Automatic Route
Selection Trunk Group
Routing
*02
700 + code + 0 Using Dial Block Toll Restriction, Dial
Block -
701 + code + 0 A supervisor using Dial Block Toll Restriction, Dial
Block -
702 + Group number (01-32)
Setting Automatic Transfer
Setup for each extension
group
Transfer -
703 + Group number (01-32) Cancelling Automatic
Transfer Setup Transfer -
704 + Group number (01-32) +
mode + extension
Setting the destination for
Automatic Transfer Setup for
each extension group
Transfer -
705 + Group number (01-32)
Setting Delayed Transfer for
each extension group (on no
answer)
Transfer -
706 + Group number (01-32) Cancelling Delayed Transfer Transfer -
707 + Group number (01-32) Setting up DND for each
extension group Transfer -
708 + Group number (01-32) Cancelling DND for each
extension group Transfer -
711 SLT Listening to the General
Message
Voice Response
System (VRS) -
712 + 3 to erase, 5 to listen or 7 to
record
Recording, listening to or
erasing the General Message
Voice Response
System (VRS) -
716 + 3 to erase, 5 to listen or 7 to
record
Recording, listening to or
erasing a VRS Message
Voice Response
System (VRS) -
718 Night Mode Switching for
other group Night Answer -
720 Common Cancelling Service
Code
721 Print the SMDR Extension
Accumulated printout
Station Message Detail
Recording (SMDR) -
722 Print the SMDR Group
Accumulated printout
Station Message Detail
Recording (SMDR) -
723 Print the SMDR Account
Code Accumulated printout
Station Message Detail
Recording (SMDR) -
726
Leaving a message at an
extension, without first calling
that extension
Message Waiting -
Table 2: Service Codes by Number
Dial this Service Code…1When you are... For this feature... Also see
Function Key...
1Except where indicated, dial Service Code from Intercom dial tone (e.g., press idle CALL key first).

XEN Topaz NEC Business Solutions Ltd
System Hardware Manual Chapter 3 - 11
Doc. No. 8846 - Release 2.0 April 2005
745 + Trunk No.
(01~51)
Trunk Port Disable (1)
Disable (0) Enable -
750 + 0 (install) or 1 (remove)
Logging in (0) or logging out
(1) for your Department
Calling Group
Department Calling -
754 Enabling Conversation
Record at an SLT set Voice Mail -
763 + 6-digit code + line + phone
number Overriding Toll Restriction Toll Restriction -
777
Changing the COS of another
extension. Must be allowed in
Program 20-13-28.
Class of Service -
778 Displaying the language of
the system. Maintenance -
725 Live MonitoringVoice Mail Voice Mail -
771 Charge Cost Display by the
supervisor.
Station Message Detail
Recording -
774 Entry Credit for Toll
Restriction Toll Restriction -
780 Change to Station Group All
Ring Ring Groups -
800 + extension # + enter name +
HOLD
Programming extension
names Name Storing 55
801 + zone (1-9 or 01-32) 801 +
zone (0 or 00)
Making an Internal Zone
Page
Making an All Call Internal
Page
Paging, Internal 21 + zone
22
802 + Doorphone (1-6) Placing a call to a Doorphone Doorphone -
803 + zone (1-6)
803 + zone (0)
Making an External Zone
page
Making an External
Zone page
Making an External All
Call page
19 + zone
20
804 + trunk group (1-9 or 01-51) Placing an outside call over a
trunk group
Central Office Calls,
Placing *02 + group
807 Overriding Do Not Disturb or
Call Forwarding
Call Forwarding Do Not
Disturb 37
808 Stepping through a
Department Group
Department Step
Calling 36
809 Sending a Call Waiting
indication to a busy extension Call Waiting 33
Table 2: Service Codes by Number
Dial this Service Code…1When you are... For this feature... Also see
Function Key...
1Except where indicated, dial Service Code from Intercom dial tone (e.g., press idle CALL key first).

Chapter 3 - 12 Charts and Illustrations
NEC Business Solutions Ltd XEN Topaz
Doc. No. 8846 - Release 2.0 April 2005
810 Breaking into another
extension's call Barge In -
812 Changing the signal type for
calling an extension Intercom -
815 Saving a number (from SLT)
or dialling a saved number Save Number Dialled 30
818 + 1
818 + 2
818 + 3
818 + 4
818 + 5
818 + 6
818 + 7
818 + 8
Activating Day 1 Mode
Activating Night 1 Mode
Activating Midnight 1 Mode
Activating Rest 1 Mode
Activating Day 2 Mode
Activating Night 2 Mode
Activating Midnight 2 Mode
Activating Rest 2 Mode
Night Service
09+0 (Toggle Day 1/
Night1)
09 + 1
09 + 2
09 + 3
09 + 4
09 + 5
09 + 6
09 + 7
09 + 8
821
Enabling Handsfree
Answerback for incoming
Intercom calls
Handsfree
Answerback/Forced
Intercom Ringing
-
822 Calling off-premise with a
Doorphone
Call Forwarding, Off-
Premise
Doorphone
54
823 Enabling Forced Ringing for
incoming Intercom calls
Handsfree
Answerback/ Forced
Intercom ringing
-
824 Enabling/disabling Dial Pad
Confirmation Tone
Dialling Pad
Confirmation tone -
825 Turning Background Music on
and off Background Music 04
827 + 1 or 2 + time, or 827 + 1 or 2
+ 9999 to cancel
Checking, setting or
cancelling an alarm Alarm -
828 + hour + minutes Setting the system Time Time and Date -
829 Checking or changing ring
volume Volume Control -
830 Remote maintenance - -
832 Placing a call on Group Hold Hold -
836 Text Message Setting Select Display
Messaging -
Table 2: Service Codes by Number
Dial this Service Code…1When you are... For this feature... Also see
Function Key...
1Except where indicated, dial Service Code from Intercom dial tone (e.g., press idle CALL key first).
