Newstripe EcoLiner II User manual

1700 Jasper St., Unit F, Aurora, CO 80011 T800.624.6706 F303.364.7796 •Newstripe.com
EcoLiner™ II Manual / 4620.0517
EcoLiner™ II
Product Manual

ECOLINER™ II
1700 Jasper St., Unit F, Aurora, CO 80011 T800.624.6706 F303.364.7796 •Newstripe.com
EcoLiner™ II Manual / 4620.0517
Page 1of 12
TABLE OF CONTENTS
Precautionary Warning................Page 1
Assembly .....................................Page 2
Operation....................................Page 3
Cleaning Procedure .....................Page 4
Cleaning Procedure .....................Page 4
(Winter Storage)
Maintenance ...............................Page 5
Parts List......................................Page 6
Spray Gun Assembly....................Page 7
Images..................................... Page 8-9
Troubleshooting Guide..............Page 10
Warranty ...................................Page 12
Thank you! For your purchase of the
Newstripe ECOLINER™II sprayer.
Please read over the instructions and make
sure you understand operating procedures
before using the unit.
Please check the serial number on your
unit. This Manual is for units with serial
number 1015236 and above only. For units
with serial numbers below 1015236, please
contact Newstripe for the correct manual.

ECOLINER™ II
ALWAYS wear safety goggles or protective eye-wear when operating the unit!
1700 Jasper St., Unit F, Aurora, CO 80011 T800.624.6706 F303.364.7796 •Newstripe.com
EcoLiner™ II Manual / 4620.0517
Page 1of 11
PRECAUTIONARY WARNING!
Please read and understand all operation instructions as detailed
in this manual. Failure to follow specified instructions may result in
equipment damage or serious injury to personnel up to and
including death!
DO NOT use oil, petroleum, primer or base coat paints in the
EcoLiner™™ II.
ALWAYS STRAIN THE PAINT. Field marking paint often has oversized
material, lumps, skin, etc., in it. If not strained, these contaminates
will be drawn into the pump, shut-off valve, lines, etc., and will cause
problems.
THIN THE PAINT BEFORE adding it to the pail for the ECOLINER™™.
Almost all field marking paints MUST BE THINNED before using them
with the ECOLINER™™. These paints are typically thinned at ratios of
1:1 (One-gallon of water to one-gallon of paint) up to 3:1.
NEVER perform maintenance on the machine while the system is
running.
The gas On/Off lever should always be OFF when the machine is not
being used.
DO NOT run the pump dry after cleaning.
Please note that modifying, changing or servicing any portion of the
machine, system or components outside of the procedures and parts
outlined in the owner’s manual will VOID the warranty.
Use only in well-ventilated area.
Always consult your Facility Safety and/or Personnel Department
for specified safety protocols prior to operating this equipment.

ECOLINER™ II
ALWAYS wear safety goggles or protective eye-wear when operating the unit!
1700 Jasper St., Unit F, Aurora, CO 80011 T800.624.6706 F303.364.7796 •Newstripe.com
EcoLiner™ II Manual / 4620.0517
Page 2of 11
ASSEMBLY
1. The EcoLiner™II is shipped mostly assembled. You are only required to attach the spray gun
assembly and paint hose.
2. Slide Support Arm with side plates through mounting tube on front of chassis.
3. Tighten down Star Knobs.
4. Mount Spray Gun Mounting Arm on Support Arm with spray hose connection facing rearward.
5. Tighten Star Knob.
6. Line width is adjusted by raising or lowering Spray Gun and selecting the appropriate Spray Nozzle.
7. Connect Paint Hose from Pressure Valve Cross to Spray Gun. Tighten lightly with wrench.
8. CHECK ENGINE OIL. FILL WITH HIGH QUALITY 10W30 DETERGENT MOTOR OIL. Use high quality
10W30 detergent motor oil. Fill level is between the cross hatched markings on the dipstick with
the dipstick pushed against the fill port. (Not screwed in.)
Your EcoLiner II box should include:
Support arm for spray gun with left & right
side spray shields
Gun mounting Bar
Spray gun assembly
Nozzles, 5002 (2”-3” lines) and 9005 (5”-6”
lines)
Pail paint strainer
Owner’s Manual
Pic 1

ECOLINER™ II
ALWAYS wear safety goggles or protective eye-wear when operating the unit!
1700 Jasper St., Unit F, Aurora, CO 80011 T800.624.6706 F303.364.7796 •Newstripe.com
EcoLiner™ II Manual / 4620.0517
Page 3of 11
OPERATION
1. Adjust spray shields to a 4” width. You may have to raise or lower the spray gun so that the machine
will produce a 4” line. To stripe narrower or wider lines, select the proper spray nozzle from the
selection guide and adjust the spray shields. Adjust the spray gun as needed to produce the required
line width.
2. Add water or pre-mixed paint to pail.
3. Move On/Off gas lever to ‘On’ position.
4. Move choke lever to the ‘choke’ position.
5. Move the throttle lever to about the ¾ position. Turn on/off switch to ‘On.’
6. Pull starter chord. Once the engine begins to run, move the choke lever to “run” position.
7. Adjust throttle to just over the ½ position where the engine is running smoothly.
8. Turn the Pump Prime Valve, located below the pressure valve, to the open position.
9. Lift the pail lid slightly and watch the paint flow from the hose. Once there is a continuous flow from
the hose, close the Pump Prime valve. The unit will now spray when the handle mounted trigger is
squeezed.
10. To use Spray Gun by hand, unscrew the star knob and remove gun from mounting bracket. Engage
pump lever and prime if needed.
OPERATIONAL NOTES!
Before using paint, fill the paint pail with water to familiarize
yourself with the machine.
Select the correct nozzle for the line width required.
Adjust side spray shields for line width and adjust spray gun height
up or down as needed to achieve the line width. (Note: water will
produce a wider line than paint.)
Fill bucket to about 2” from the top with PREMIXED paint. DO
NOT place Non-thinned paint in unit, as this will clog the pump.
Most athletic field marking paint is mixed at a ratio of 1:1, one
gallon of water to one gallon of paint. Some paints may be
thinned more. See paint manufacturer’s directions.
You will need to use the Pump Prime valve each time you run the
pail dry and when you switch to water for cleaning to remove air in
the system. The spray pressure valve is initially set at the factory
for maximum spray pressure. If you feel you are getting too much
paint flow from the nozzles, unscrew the Pressure Valve Cap until
the flow is where you would like it to be and then run the Locking
ring up against the cap to maintain the setting.

ECOLINER™ II
ALWAYS wear safety goggles or protective eye-wear when operating the unit!
1700 Jasper St., Unit F, Aurora, CO 80011 T800.624.6706 F303.364.7796 •Newstripe.com
EcoLiner™ II Manual / 4620.0517
Page 4of 11
CLEAN UP PROCEDURE
CLEAN AFTER EACH USE
1. When your Striping job is complete, pull the paint return hose & prime valve hose out of the lid and
point them towards the ground behind the machine or in a separate pail.
2. Remove the pail lid and set aside. Pull out suction hose and place to side of machine or in a separate
pail.
3. Empty pail of unused paint, or remove pail completely and cover for the next time you stripe.
4. Place another empty pail on machine.
5. Wipe off or rinse off suction hose, screen, return hose, pump prime hose and pail lid.
6. Remove nozzle cap, nozzle, and valve seat and put in container of water to soak.
7. Place 2-3 gallons of clean water in the pail. Place pick up tube back in pail. Leave return hose out of
pail. This allows you to flush all hoses of paint. Start engine. Use Pump Prime valve to prime pump and
activate control lever. CAREFUL: Return hose will ‘jump’ from paint pressure. Run until spray runs
clear.
8. Clean nozzle parts that have been soaking and reassemble on spray gun.
9. Clean and rinse exterior of machine. Use soapy water (dish washing detergent or Simple Green) once
each week to thoroughly clean pump. Add soap to 2-3 gallons of water, run machine and let it circulate
back to pail and then empty.
CLEANING PROCEDURE FOR WINTER (FREEZING) STORAGE
1. Clean as instructed in cleaning procedure and then place ½ bottle of pump protector in pail.
2. Place spray knob in prime position and run pump until pump protector is seen flowing from return
hose.
3. Turn spray knob to spray position and trigger gun until pump protector sprays from gun.
4. Turn spray control knob to prime position, turn off pump and trigger spray gun to release pressure.
5. Remove as much fuel from the engine gas tank as you can. Run engine until it runs out of gas.
6. Turn Spray knob to prime position.
7. Disconnect paint hose from pump and gun then, drain hose.
8. Unit may now be stored in freezing temperatures.
9. Drain and change engine oil in the spring.

ECOLINER™ II
ALWAYS wear safety goggles or protective eye-wear when operating the unit!
1700 Jasper St., Unit F, Aurora, CO 80011 T800.624.6706 F303.364.7796 •Newstripe.com
EcoLiner™ II Manual / 4620.0517
Page 5of 11
MAINTENANCE
ITEM
CHECK
MAINTENANCE ACTION
Engine oil level
Prior to every use
Change engine oil after first 20 hours of
operation and then every 100 hours
thereafter.
Paint Pail/Tank
After every use
Clean paint pail/tank hoses and nozzle
Hoses and pump
After every use
Run soapy water through pump and
hoses for additional cleaning
Wheels
Check air level before each use
Fill with air as needed. Grease weekly.
Handles
Monthly
Check handles for tightness to frame.
Engine air filter
Monthly
Clean monthly. Replace every 4
months
**For additional instructions please contact Newstripe, Inc. at 800-624-6706

ECOLINER™ II
ALWAYS wear safety goggles or protective eye-wear when operating the unit!
1700 Jasper St., Unit F, Aurora, CO 80011 T800.624.6706 F303.364.7796 •Newstripe.com
EcoLiner™ II Manual / 4620.0517
Page 6of 11
PARTS LIST
Item
Description
Part
Number
Item
Description
Part
Number
1
Chassis
10004610
23
Cable stop
10001577
2
Engine, Briggs & Stratton XR550
10004707
24
Pressure valve adjusting cap
N/A
3
Air filter element for engine (Not
Shown, Briggs & Stratton P/N)
796970
25
Locking ring
N/A
4
Wheel assembly (4 required)
10000012
26
Pressure limiter collar
N/A
5
Handle, weldment
10003469
27
Pressure Valve
10003478
6
Handle support braces (2)
10004612
28
Brass T fitting, ½”
10004111
7
Control cable
10000820
29
Reducer, ½” – ¼”
10002481
8
Control lever
10002951
30
Brass elbow
10004131
9
Hose, paint
10000695
31
Pump prime valve
10000233
10
Hose, pressure
10004468
32
Brass elbow
10000159
11
Hose, suction
10004467
33
Brass cross
10000235
12
Filter, suction hose (Not shown)
10002842
34
Plug
10000113
13
Hose, Re-circulating
10003692
35
Ball seat fitting
10000731
14
Hose, Pump prime valve return
10003692
36
Belt guard
10004617
15
Spray gun mounting arm
10004651
37
Drive Belt, 3L200 (Not
shown)
10003369
16
Spray gun assembly
10001949
38
Pump, diaphragm
10003367
*
See Spray Gun Assembly on Page 7 for breakdown
of part numbers
39
Pump elbow fittings
10004459
17
Spray gun support arm
10003550
40
Bearing, pump shaft (2) (Not
Shown)
10003131
18
Pivot, Right
10001229
41
Pump shaft (Not Shown)
10003365
19
Pivot, Left
10001228
42
Gun mount star knob
10004480
20
Spray shields (2)
10003562
43
Pail
10002838
21
Star knobs, common (5)
10000007
44
Lid EcoLiner™ II & SP
assembly, 5-gallon pail
10002827
22
Cable adjuster with nut
10000018

ECOLINER™ II
ALWAYS wear safety goggles or protective eye-wear when operating the unit!
1700 Jasper St., Unit F, Aurora, CO 80011 T800.624.6706 F303.364.7796 •Newstripe.com
EcoLiner™ II Manual / 4620.0517
Page 7of 11
SPRAY GUN ASSEMBLY
(Item 10001949)
Item
Description
Part Number
45
Valve Seat
10000136
46
Nozzle
Select nozzle below
47
Nozzle Cap
10001890
SELECT NOZZLE FOR APPLICATION
Item
Description
Part Number
5002
2” Line
10001891
8005
4” -5” Line (Heavy Turf)
10003493
8004
4”-5” Line (Turf/Asphalt)
10001893
9505
5”-6” Line
10001894
Nozzle Cap #47
Nozzle #46
Valve Seat #45
Spray Gun
#16

ECOLINER™ II
ALWAYS wear safety goggles or protective eye-wear when operating the unit!
1700 Jasper St., Unit F, Aurora, CO 80011 T800.624.6706 F303.364.7796 •Newstripe.com
EcoLiner™ II Manual / 4620.0517
Page 8of 11
#18 Right
Pivot
#17 Spray Gun
Support Arm
#11 Suction
Hose
#8 Control
Lever
#7 Control
Cable
#13 Recirculating
Hose
#21 Star Knobs
Pic 2
#15 Spray Gun
Mounting Arm
#14 Pump Prime
Valve Return
Hose
#9 Paint
Hose
#6 Handle
Support Braces
#22 Cable Adjuster
with Nut & #23
Cable Stop
#10 Pressure
Hose
Pic 3
#24 Pressure Valve
Adjusting Cap
#42 Gun Mount Star Knob
#16 Spray Gun
#20 Spray
Shield
#5 Handle
Weldment

ECOLINER™ II
ALWAYS wear safety goggles or protective eye-wear when operating the unit!
1700 Jasper St., Unit F, Aurora, CO 80011 T800.624.6706 F303.364.7796 •Newstripe.com
EcoLiner™ II Manual / 4620.0517
Page 9of 11
TROUBLESHOOTING GUIDE
PROBLEM
POSSIBLE CAUSE
REMEDY
#25 Locking
Ring
#26 Pressure
limiter collar
#27 Pressure Valve
#13 Recirculating
Hose
#10 Pressure Hose
#39 Pump Elbow
Fittings
#34 Plug
#9 Paint Hose
#35 Ball seat
fitting
#33 Brass
Cross
#30 Brass
Elbow
#29 Reducer, ½” – ¼”
#28 Brass T fitting, ½”
Pic 4
#32 Brass
Elbow
Pic 5
#14 Pump Prime Valve
Return Hose
#31 Pump
prime valve
#10 Pressure Hose
#38 Diaphragm
Pump
#36 Belt Guard
#11 Hose, suction
#39 Pump Elbow
Fittings

ECOLINER™ II
ALWAYS wear safety goggles or protective eye-wear when operating the unit!
1700 Jasper St., Unit F, Aurora, CO 80011 T800.624.6706 F303.364.7796 •Newstripe.com
EcoLiner™ II Manual / 4620.0517
Page 10 of 11
Pump will not prime
Air in pump system
Open pump valve and check flow from hose
into pail. When flow is continuous. Close
valve.
Pump will not prime after
relieving air in system
Pump is probably clogged
with paint
Disconnect supply and discharge hoses. Clean
out hoses. Pour hot water into opening of
pump and let soak. Reconnect hoses and start
pump again.
Pump won’t prime due to clog in
the system
Spray system not properly
cleared after previous use.
If hot water alone does not remove clog,
pour liquid dish soap or the “Simple Green”
product into the pump inlet. Jog the pump
by pulling the starter cord several times with
engine off to get the soap in to the pump
and let it soak 15-30 minutes, then try
pumping water. The pump does not need to
be rinsed of all the soap as the soap will mix
easily with the paint. If still not working call
factory. Disassembly of pump will VOID
the warranty.
Pump will not run
Loose or broken drive belt
Inspect, adjust or replace. Belt should
deflect approximately ½” between pulleys.
Paint leaving nozzle in stream, not
spraying
Paint too thick
Thin Paint
Pressure too low
See step #4 in operating instructions
Spray Inconsistent
Obstruction in nozzle
Obstruction on pick up
tube screen or clogged
Remove nozzle screen. Clean or replace.
Remove pick up tube and filter screen. Filter
paint before putting in pail. Clean screen to
remove clogs.
Spray pattern too narrow or
uneven
Wrong nozzle or spray
head height is incorrect
Paint is too thick
Adjust spray head height up or down.
Nozzle slot must be crosswise to the fun
body.
Thin Paint
Paint drips after being shut off
Control cable out of
adjustment
Clogged or worn spray
control valve
Check cable at shut-off valve. Adjust or
replace
Dissemble and clean, or replace
Paint drips after being shut off
Faulty control lever
Replace

ECOLINER™ II
ALWAYS wear safety goggles or protective eye-wear when operating the unit!
1700 Jasper St., Unit F, Aurora, CO 80011 T800.624.6706 F303.364.7796 •Newstripe.com
EcoLiner™ II Manual / 4620.0517
Page 11 of 11
WARRANTY – 18 MONTH
NEWSTRIPE, INC., WARRANTS TO THE ORIGINAL PURCHASER, FOR 18 (EIGHTEEN) MONTHS AFTER
DATE OF PURCHASE, THAT THE EQUIPMENT* HEREBY SOLD SHALL BE FREE OF DEFECTS IN MATERIALS
AND WORKMANSHIP. THIS WARRANTY DOES NOT EXTEND TO ANY DAMAGE OR MALFUNCTION
RESULTING FROM MISUSE, NEGLECT, ACCIDENT, IMPROPER OPERATION, OR NORMAL WEAR AND
TEAR.
Damage incurred in shipment from Newstripe, Inc. to the customer is the total responsibility of the
carrier. The CUSTOMER MUST NOTE DAMAGES on the Bill of Lading of Trucking Company or Railroad;
and Newstripe, Inc. will furnish to the customer the cost or parts and labor. The customer can then bill
the common carrier for the damages by placing his signature on the documents.
The Newstripe, Inc. obligation under this warranty and any implied warranties is limited to
replacement or repair of defective parts of its manufacture without charge for 18 (Eighteen) months
from date of purchase. For service under this warranty, buyer shall ship the defective part or parts of
the equipment, transportation prepaid, to Newstripe, Inc. together with a written description of any
claimed defect and proof of purchase date of the materials being returned. Prior to retuning any part
or machine, the CUSTOMER must obtain a Return Materials Authorization number. Call 1-800-624-
6706.
*Components not manufactured by Newstripe, Inc. such as engines, compressors, pumps, and
transaxles are furnished with their respective manufacturer’s warranties only. Where Newstripe
elects to extend manufacturers’ warranties, the warranty shall cover up to 100% of the cost to repair
or replace materials and parts for the first 12 months of ownership, excluding labor. Extension of any
manufacturers’ warranty for these components is at the sole discretion of Newstripe, Inc. and does
not include wearable parts and consumable components from normal wear and tear.
The responsibilities described above are the only responsibilities of Newstripe, Inc. under this written
warranty or any implied warranty, and may be exercised only within 18 (Eighteen) months from the
date of purchase. In no event shall Newstripe, Inc. be liable for incidental or consequential damages
and no person had any authority to bind it to any representation or warranty, not be responsible for
work done, materials furnished or repairs made by others without its' specific written authorization.
THIS WARRANTY SHALL BE IN LIEU OF ANY AND ALL OTHER WARRANTIES, EXPRESSED OR IMPLIED,
INCLUDING ANY WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, AND THERE
IS NO OTHER REPRESENTATION OR WARRANTY OF ANY KIND WITH RESPECT TO THE GOODS SOLD HEREBY
EXCEPT AS SET FORTH HEREIN. IT IS EXPRESSLY AGREED THAT THIS WARRANTY SHALL BE LIMITED TO THE
ADJUSTMENT, REPAIR OR REPLACEMENT OF PARTS AND THE LABOR AND SERVICES REQUIRED THEREBY.
IN NO EVENT, INCLUDING ANY CLAIM FOR NEGLIGENCE, SHALL NEWSTRIPE, INC. BE LIABLE FOR
INCIDENTAL OR CONSEQUENTIAL DAMAGES.
Sincerely,
Newstripe, Inc
