Niigata seiki DITG-30PJ User manual

Hold here when measuring.
Touch the point of the probe on the point
you want to measure.
Tension can be measured by hooking an
object in the hole at the point.
Indicates the measured value.
Can be used to indicate the maximum value
in any set of measurements. The Max.
Value needle stops at the maximum
attained value when the Indicator needle
returns to the zero position, enabling you to
read the maximum value easily.
To return the Max. Value needle to its
initial position.
Indicates the measurement value.
(1) Body
(2) Probe
(3)
Indicator needle
(4) Max.Value needle
(5) Screw to adjust
Max. Value needle
(6) Dial
Thank you for your purchasing our “Dial Tension Gauge”.
This product measures tension and compressive strength, e.g. the pressing force of a button or tension of a spring.
●To ensure optimum and safe use of this product, please read this
manual carefully before use. Keep this manual in a safe place for
handy reference.
●Always include this manual if you transfer or lend this product to
any third party.
●Contact your sales store or our company for any questions about
this product.
SAFETY NOTICE
■Part Names and Functions
(1) Body
(2) Probe
(5) Screw to adjust
Max. Value needle
(4) Max. Value needle
* The model is DITG-50PJ.
(3) Indicator needle
(6) Dial
Safety Precautions
In this manual, the following symbols indicate:
Any action that can cause damage.
Any prohibited action.
Any compulsory instructions.
please observe
This section explains the procedures you must follow in order to avoid any damage to the user, other persons or property.
Any misuse may cause injury or damage to property.
Caution
Movable
direction Do not twist
Do not apply strength in
any other direction than
the movable directions
Dial Tension Gauge
Measurement Instrument for Tension and Compressive Strength DITG-**PJ
Model No.
User Manual
For Operational Use
Read and follow all the instructions in this manual.
・Any use exceeding the scope described in this manual
may cause an accident.
Use this product only for taking measurements.
・Any use other than for the specified purpose may
cause damage or wear of this product, or an accident.
Use this product in the following environment:
●Dry conditions. No rain, water or oil
●Not in direct sunlight
●Keep away from children or any other person.
Only the user should be near the product.
・Any use in any place that does not meet the above
conditions may result in inaccurate measurement,
damage to this product, accident or injury.
Handle this product with care
・Avoid any physical shock or dropping the product. Do
not place weight on this product. These may result in
inaccurate measurement or damage.
Use within the range of measurement.
・Do not apply any force in excess of the measurement
range given in the specifications, this may result in
inaccurate measurement or damage to this product.
Do not disassemble or convert this product.
・ This may cause inaccurate measurement or damage to this
product. Contact the sales store or the seller for repair.
Avoid applying any force to the probe in any
other direction than the movable directions.
・Any twisting or pushing of the probe in any unmovable
direction may cause inaccurate measurement or damage
to this product.

Product Specification
Object
Right angle
I320-K 1612
●Materials: Body…ABS Probe…Steel ●Weight: 55g
Proper Contact How to Use
In order to obtain accurate values, ensure the probe
instructions are followed.
(1)Place the Max. Value needle to the initial position
Turn the screw to adjust Max. Value needle to align with
the Indicator needle.
(2)Contact the probe with the object
Contact the probe with the object so as to apply force at a
right angle to the object.
* See “Proper Contact”
on the left.
(3)Apply force while the angle of the probe remains
at a right angle
When applying force to the probe, always
maintain a right angle
to the object.
(4)Release the probe from the object and read the
Max. Value needle
* When measuring tension, make sure to apply force to
the probe at a right angle.
As the force reaches the maximum, release the probe from
the object and read the value indicated by the Max. Value
needle.
Align
DITG-30PJ
30〜300mN
10mN
DITG-50PJ
0.06〜0.5N
0.02N
DITG-100PJ
0.1〜1N
0.05N
DITG-150PJ
0.15～1.5N
0.05N
±0.5 units of scale
DITG-300PJ
0.3～3N
0.1N
DITG-500PJ
0.6～5N
0.2N
Model No.
Measurement Range
Resolution
Accuracy
●Ensure the probe contact is at right angles to the object
●Contact the point of the probe
Right angle
Force applied
to the probe not
at a right angle
Keep applying force
to the probe
at a right angle
Apply force to
the probe
at a right angle
The root of the probe
is contacted
Wipe away any dust or marks with a dry cloth.
Any foreign particles between the body and the probe may obstruct the
smooth movement of the units.
Keep this product in the attached case and store in a dry,
cool and dark place.
Avoid direct sunlight and moisture. Keep in a safe place away from
unauthorized users.
Maintenance and Storage
Niigata seiki Co., Ltd.
6-15-22, Tsukanome, Sanjo, Niigata, Japan, 955-0055
Tel. : [phone] Fax. : [phone]
MAIL:[email protected]

Max. Value needle Indicator needle
Screw to adjust
Max. Value needle
Right angle
Probe
Turn
Right angle
Max. Value needle
*Align it with the
direction in which
the Indicator
needle moves.
Object
Align
Read the measurement value (0.4N in this figure)
