SPECIFICATIONS SHEET
NUMERIC
INTELLIPAD®CI KEYPAD
• Includes white, bone, and almond Decora®snap-in color inserts
• Compatible with Niles ZR4630 and ZR8630AV multizone receivers
Numeric™ Accessory Keypad

MULTIZONE PRODUCTS
FEATURES
■Must be used with Solo®, Solo®IR, Select®or Select®IR Master Keypads
■Numeric keys provide direct access to discs, tracks, stations, and/or DSS/TV channels
■Random, Group, Disc, and Favorite keys provide advanced system control
■Available in three designer colors - almond, bone, and white (inserts included with keypad)
SPECIFICATIONS:
■Dimensions: 1-3/4" wide x 4" high x 1-5/8" deep
Warranty: Two-year limited
IntelliPad®Ci Keypad
Numeric™
Stock Number
FG00809
NILES AUDIO CORPORATION 12331 S.W. 130 Street, Miami, FL 33186 Tel: [phone] – www.nilesaudio.com NANUMERICPDF
©2004 Niles Audio Corporation. All Rights Reserved. Niles and the Niles logo are registered trademarks of Niles Audio Corporation.
Product Detail
1 2 3
456
78 9
0
– +
RANDOM GROUP
DISC FAV
P
E
STOP
PAUSE
MC
*
PLAY
REW FF
+
_
TUNER DAT
CO DSS
CO2 DSS2
VCR SAT
OFF
MUTE VOLUME
Back View: Numeric
(b) Input: RJ-45 connector for
connection to additional
Accessory Keypad Modules.
(c) Output: RJ-45 connector for
connection to Master Keypad
Modules.
Front View: Numeric
(a) Function Keys for individual
component control.
Solo Master Keypadand
Numeric AccessoryKeypad
Select Master Keypad, Transport
andNumeric AccessoryKeypad
a
b
c
