Quick guide
✁
Quick guide
■Actions
Press
Press a key briefly and release it.
Press and hold
Press a key, hold it for two to three seconds, and release it.
Make a call
Enter a phone number, and press Call.
Answer a call
Press Call, or select Options > Answer.
Answer call during call
Press Call.
End a call
Press End or select Options > End call.
Reject a call
Press End to send the call to voice mail.
Mute a call
Select Options > Mute during a call.
Redial
Press Call twice.
Adjust call volume
Move the Five-way joystick to the left or right during a call.
Use in-call menu
Select Options during a call.
Save name and number
Enter a number. Select Save. Enter a name. Select OK.
Use speed dials

Quick guide
✁
Press and hold a key [2–8]. You must assign a key to a number in the
phone book.
Look up a name
Select Names > Search.
Check voice mail
Press and hold the 1key [contact your service provider for details].
Write text messages
Select Menu > Messages > Text messages > Create message or move
the Five-way joystick to the left. Write the message.
Send text messages
In the message entry screen, select Send. Enter the recipient’s phone
number or search for it in contacts, and select OK. The message
service is dependent on the service provider.
Read new message
If Messages received appears on the display, select Show; then select
the message you want to read.
Reply to a message
Select Reply. Write a reply. Select Send.

Contents
5
Contents
For your safety 6
1. Phone at a glance ........................................................................................ 11
2. SIM card and battery .................................................................................. 12
3. About your phone ........................................................................................ 15
4. Basic operations........................................................................................... 23
5. Phone menu................................................................................................... 25
6. Phone security .............................................................................................. 27
7. Writing text................................................................................................... 29
8. Messages........................................................................................................ 33
9. Instant messages (Chat)............................................................................. 46
10.Call register ................................................................................................... 51
11.Names............................................................................................................. 52
12.Settings .......................................................................................................... 61
13.Gallery............................................................................................................. 68
14.Camera............................................................................................................ 69
15.Organiser........................................................................................................ 71
16.Applications .................................................................................................. 77
17.Web ................................................................................................................. 82
18.Connectivity.................................................................................................. 91
19.PC connectivity............................................................................................. 97
20.Reference information ............................................................................... 99

For your safety
6
For your safety
Read these simple guidelines. Not following them may be dangerous or illegal.
Read the complete user guide for further information.
SWITCH ON SAFELY
Do not switch the phone on when wireless phone use is prohibited or
when it may cause interference or danger.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free to operate the
vehicle while driving. Your first consideration while driving should be
road safety.
INTERFERENCE
All wireless phones may be susceptible to interference, which could
affect performance.
SWITCH OFF IN HOSPITALS
Follow any restrictions. Switch the phone off near medical
equipment.
SWITCH OFF IN AIRCRAFT
Follow any restrictions. Wireless devices can cause interference
in aircraft.
SWITCH OFF WHEN REFUELLING
Don't use the phone at a refuelling point. Don't use near fuel
or chemicals.
SWITCH OFF NEAR BLASTING
Follow any restrictions. Don't use the phone where blasting is
in progress.
USE SENSIBLY
Use only in the normal position as explained in the product
documentation. Don't touch the antenna unnecessarily.
QUALIFIED SERVICE
Only qualified personnel may install or repair this product.
ENHANCEMENTS AND BATTERIES
Use only approved enhancements and batteries. Do not connect
incompatible products.

For your safety
7
WATER-RESISTANCE
Your phone is not water-resistant. Keep it dry.
BACKUP COPIES
Remember to make backup copies or keep a written record of all
important information stored in your phone.
CONNECTING TO OTHER DEVICES
When connecting to any other device, read its user guide for detailed
safety instructions. Do not connect incompatible products.
EMERGENCY CALLS
Ensure the phone is switched on and in service. Press End as many
times as needed to clear the display and return to the start screen.
Enter the emergency number, then press Call. Give your location.
Do not end the call until given permission to do so.
■About your device
The wireless device described in this guide is approved for use on the EGSM 900
and GSM 1800 and 1900 networks. See ”Phone information” on page 10, to
identify your specific device model. Contact your service provider for more
information about networks.
When using the features in this device, obey all laws and respect privacy and
legitimate rights of others.
Warning: To use any features in this device, other than the alarm clock,
the device must be switched on. Do not switch the device on when
wireless device use may cause interference or danger.
■Network Services
To use the device you must have service from a wireless service provider. Many of
the features in this device depend on features in the wireless network to
function. These Network Services may not be available on all networks or you
may have to make specific arrangements with your service provider before you
can utilize Network Services. Your service provider may need to give you
additional instructions for their use and explain what charges will apply. Some
networks may have limitations that affect how you can use Network Services. For
instance, some networks may not support all language-dependent characters
and services.

For your safety
8
Your service provider may have requested that certain features be disabled or not
activated in your device. If so, they will not appear on your device menu. Contact
your service provider for more information.
This wireless device is a 3GPP GSM Release 99 terminal supporting GPRS service,
and is designed to support Release 4 GPRS networks. However, there may be
some compatibility issues when used in some Release 97 GPRS networks. For
more information contact your service provider.
This device supports WAP 2.0 protocols [HTTP and SSL] that run TCP/IP protocols.
Some features of this device require network support for these technologies.
■Shared memory
The device has three different memories. Names, text messages, SMS e-mail,
voice tags, calendar, and notes may share the first memory. The second shared
memory is used by multimedia messages, files stored in Gallery, and
configuration settings. The third shared memory is used by the e-mail application
and Java games and applications. Using one or more of these features may
reduce the memory available for the remaining features sharing the same
memory. For example, saving many Gallery items may use all of the available
memory in the second memory. Your device may display a message that the
memory is full when you try to use a shared memory feature. In this case, delete
some of the information or entries stored in the corresponding shared memory
before continuing.

Welcome
9
Welcome
Congratulations on your purchase of the Nokia 6822 mobile device.
Your device provides many functions that are practical for daily use,
such as a calendar, a clock, an alarm clock, and a built-in camera. The
camera can be used for recording video clips and taking pictures that
you can attach as wallpaper in the standby mode or as thumbnail
pictures in Names. For more information, see ”Camera” on page 69.
Other features on your device are:
• Multimedia messaging, see ”Multimedia messages [MMS] [network
service]” on page 37.
• Instant messages, see ”Instant messages (Chat)” on page 46.
• Presence-enhanced contacts, see ”My presence” on page 54.
• E-mail application, see ”E-mail [network service]” on page 40.
• EDGE [enhanced data rates for GSM evolution], see ”GPRS” on page
95.
• J2ME™ Java 2 Micro Edition, see ”Applications” on page 77.
• XHTML browser, see ”Web” on page 82.
• Bluetooth connectivity, see ”Set up a Bluetooth connection” on page
91.
■Copyright protection
Copyright protections may prevent some images, ringing tones, and
other content from being copied, modified, transferred, or forwarded.
■Contact Nokia
If you ever need to call Nokia Customer Care or your service provider,
you must provide specific information about your device [see ”Phone
information” on page 10].
Whether you call about your device or an enhancement, have the
equipment with you when you call. If a Nokia representative asks a

Welcome
10
specific question about the enhancement, you will have it available for
quick reference.
Nokia support on the web
Check www.nokia.com/support or your local Nokia web site for the
latest version of this user guide, additional information, downloads, and
services related to your Nokia product.
Phone information
Information about your device is
provided on the phone label on the
back of the device under the battery
[see ”Remove the back cover” on
page 12]. The label contains the
model and serial numbers, as well as
the following:
• Phone type [RM-69]
• Phone model [such as Nokia 6822]
• International Mobile Equipment Identity [IMEI]

Phone at a glance
11
1. Phone at a glance
Power key
[1]
Right
selection
key [2]
End key
[3]
Keypad
[4]
Microphone
[5]
Pop-Port
connector
[6]
Charger
port [7]
Call key
[8]
Left
selection
key [9]
Five-way joystick [10]
Display screen [11]
Loudspeaker [12]
Left selection key [keyboard open] [13]
Earpiece [14]
Infrared port [15]
Camera lens [16]

SIM card and battery
12
2. SIM card and battery
The SIM card and its contacts can easily be damaged by scratches or
bending, so be careful when handling, inserting, or removing the card.
Your device and its enhancements may contain small parts. Keep them
out of the reach of small children.
For availability and information on using SIM card services, contact your
SIM card vendor. This may be the service provider or another vendor.
Always switch the device off and disconnect the charger before
removing the battery.
■Remove the back cover
Push the back cover release button toward
the bottom of the device [1] and at the
same time, lift the back cover away from
the device [2].
■Insert the SIM card and battery
Important: Insert the battery exactly as shown in the diagram.
The contacts on the battery must be aligned with the contacts
on the device for the device to operate.

SIM card and battery
13
To release the SIM card holder, slide the card holder to the right [4], and
open it by lifting it up [5].
Insert the SIM card into the SIM card holder [6].
Make sure that the SIM card is properly inserted and that the golden
contact area on the card is facing downward. Close the SIM card holder
[7], and slide it back into place [8].
Direct the back cover toward the locking catches on the front cover [9],
and slide the back cover until it locks into place [10].

SIM card and battery
14
■Charge the battery
Warning: Use only batteries, chargers, and enhancements
approved by Nokia for use with this particular model. The use of
any other types may invalidate any approval or warranty, and
may be dangerous.
Your device is powered by a
rechargeable battery. To charge the
battery:
1. Plug the charger transformer
into a standard ac outlet.
2. Insert the charger output plug
into the round connector at the
bottom end of the device.
After a few seconds, the battery indicator in the display starts to
scroll from bottom to top. If the battery is completely discharged, it
may take a few minutes before the charging indicator appears on the
display or any calls can be made.
You can use the device while the charger is connected.
The BL-5C battery provides up to 3.5 hours of talk time and up to 14
days of standby time. Operation times are estimates and may vary
depending on network conditions, charging, and device use. Charging
the battery with the ACP-12 charger takes approximately 1 hour and 30
minutes while the device is in the standby mode.
For availability of approved enhancements, please check with your
dealer. When you disconnect the power cord of any enhancement, grasp
and pull the plug, not the cord.

About your phone
15
3. About your phone
■In-phone help
Many features have brief descriptions [help text] which can be viewed
on the display. To view the help text, scroll to a feature and wait for
about 15 seconds. Select More to view all of the description [if
necessary] or select Back to exit.
For instructions on how to turn the help text feature on and off, see
”Phone settings” on page 64.
■Start screen [standby mode]
The start screen is home base and indicates that the device is in the
standby mode.
[1] The name of your service provider may appear here.
[2] Audible signal bar—A higher bar indicates a stronger network signal.
[3] Audible battery bar—A higher bar indicates more power in the
battery.
[4] Left selection key—The Left selection key in the standby mode opens
the Go to menu. For more information, see ”Go to options” on page 62.
[5] Menu—Press the Five-way joystick to select the item displayed in
the bottom center [middle selection area] of the display screen. In the
standby mode, press the joystick to open the Menu.

About your phone
16
[6] Right selection key—The Right selection key in the standby mode
opens either the Names menu [default], a service provider’s home page,
or a user-specified function. For more information, see ”Personal
shortcuts” on page 62.
■Antenna
Your device has an internal antenna. Hold the device as shown with the
antenna area pointing up.
Note: As with any other radio transmitting
device, do not touch the antenna unnecessarily
when the device is switched on. Contact with
the antenna affects call quality and may cause
the device to operate at a higher power level
than otherwise needed. Avoiding contact with
the antenna area when operating the device
optimizes the antenna performance and the
battery life.
■Phone basics
Your device can be used with the keyboard open or closed.
To open the keyboard, do the following:

About your phone
17
1. Hold the device with both hands, and open the keyboard as
shown.
2. Extend the keyboard until you hear it click into place.

About your phone
18
3. Turn the device to a horizontal position and hold it as shown.

About your phone
19
■Key functions [keyboard closed]
Power key [1] switches the
device on and off. When the
keypad is locked, it turns the
device display lights on for
about 15 seconds.
Selection key [2] has no
function when the keyboard
is closed.
Left selection key [3] and
Right selection key [3]
provide a variety of functions
depending on the display text
above the keys.
Five-way joystick [4] moves
in four directions and selects
the active menu option when
pressed. For details, see ”The
five-way joystick” on page
21.
Call key [5] dials a device
number and answers a call. In the standby mode it accesses the list of
most recently called numbers.
End key [6] ends an active call or exits from the current function.
Keypad [7] enters numbers and characters.
Note: Some devices may not display the mobile Internet symbol
on the 0key.

About your phone
20
■Key functions [keyboard open]
When the keyboard is opened, the display graphics rotate 90 degrees
and the Left and Right selection keys change positions. The guiding text
near the Left and Right selection keys does not change.
Keyboard light key [1] switches the keyboard light on or off.
Power key [2] switches the device on and off.
Five-way joystick [3] moves in four
directions and selects the displayed
menu option when pressed.
Backspace key [4] deletes characters.
Character key [5] opens a set of
characters and symbols during text
writing.
Shift keys [6] enters upper case letters and symbols. You can press the
Shift key first, then the desired key; or press both keys at the same time.
Space bar keys [7] enters a space.
Call key [8] dials a device number and answers a call. In the standby
mode it accesses the list of most recently called numbers.
Left selection key [9] and Right selection key [9] selects the menu
option shown by the text displayed above the key.
End key [10] ends an active call or exits from a function.
