Norac UC4+ User manual

Case IH 4420, 3320 Prop ML &
Enhanced Stability Installation Manual
Spray Hei ht Controller
Improvin the competitiveness of Industry and
A riculture throu h Precision Measurement

Printed in Canada
Copyright 2005-08 by NORAC Systems International Inc.
Reorder P/N: UC4+BC+CS5-INST Rev C (Case International 4420, 3320 PROP ML
& ENHANCED STABILITY)
NOTICE
NORAC Systems International Inc. reserves the right to improve products and their specifications without notice and
without the requirement to update products sold previously. Every effort has been made to ensure the accuracy of the
information contained in this manual. The technical information in this manual was reviewed at the time of approval for
publication.

TABLE OF CONTENTS
1 INTRODUCTION..................................................................................................................................1
2 GENERAL SYSTEM DESCRIPTION ..................................................................................................2
3 PARTS LISTS ......................................................................................................................................4
4 INSTALLATION PROCEDURE...........................................................................................................9
4.1 EXISTING SYSTEM CHECK ...............................................................................................................9
4.2 BOOM SPEED TEST........................................................................................................................9
4.3 WING SENSOR INSTALLATION.......................................................................................................11
4.4 MAIN LIFT SENSOR INSTALLATION..................................................................................................14
4.5 ROLL SENSOR INSTALLATION.......................................................................................................15
4.5.1 Intermediate Frame Roll Sensor Mounting.......................................................................16
4.5.2 Reference Frame Roll Sensor ............................................................................................17
4.5.3 Boom Frame Roll Sensor Mounting..................................................................................18
4.6 HYDRAULIC INSTALLATION ...........................................................................................................19
4.6.1 Valve Assembly...................................................................................................................19
4.6.2 Valve Mounting....................................................................................................................21
4.6.3 Hydraulic Plumbing.............................................................................................................22
4.6.4 120’ Boom Orifice Installation............................................................................................24
4.7 ELECTRICAL INSTALLATION..........................................................................................................25
4.8 COMPLETING THE INSTALLATION ..................................................................................................29
5 ELECTRICAL REFERENCE – CABLE DRAWINGS........................................................................30
5.1 ITEM C01: 44674 –CABLE UC3 SENSOR ROLL BIAS ...................................................................30
5.2 ITEM C02: 44668 –SENSOR BRANCH CABLE...............................................................................30
5.3 ITEM C02B: 44664 –CABLE UC4 CAN NODE .............................................................................31
5.4 ITEM C03: 44656 –CABLE VALVE VARIABLE RATE......................................................................31
5.5 ITEM C04: 44658-62 –CABLE VALVE CS4 INTERFACE.................................................................32
5.6 ITEM C05: 44658-46D –CABLE VALVE DT ROLL WITH PIGTAIL...................................................33
5.7 ITEM C10: 44650-39 –CABLE POWER GENERIC SELF-PROPELLED..............................................34
5.8 ITEM C11: 44651-03 –CABLE EXTENSION CABLE VALVE GENERIC..............................................35
5.9 ITEM C12: 44658-24 –CABLE INTERFACE UC4 C12 DT06-2X GND2..........................................36
5.10 ITEM C13: 44658-47 –CABLE INTERFACE UC4 BC C13 DT2 MAIN EXTENSION ...........................37
5.11 ITEM C14: 44658-28 –CABLE INTERFACE UC4 BC C14 POWER PIGTAIL.....................................38
6 APPENDIX A – VALVE CONNECTOR CHANGE.............................................................................39

1
1 INTRODUCTION
Congratulations on your purchase of the NORAC UC4+ Spray Height Controller. This
system is manufactured with top quality components and is engineered using the latest
technology to provide operating features and reliability unmatched for years to come.
When properly used the system can provide protection from sprayer boom damage,
improve sprayer efficiency, and ensure chemicals are applied correctly.
Please take the time to read this manual completely before attempting to install the system.
A thorough understanding of this manual will ensure that you receive the maximum
benefit from the system.
YOUR INPUT CAN HELP MAKE US BETTER! If you find issues or have suggestions
regarding the parts list or the installation procedure, please don’t hesitate to contact us via
the information given below:
Phone: [phone] Canada (Toll Free)
1-866-306-6722 United States (Toll Free)
0-800-404-8389 United Kingdom (Toll Free)
1-306-664-6711 all other regions
E-mail: [email protected]
Website: www.norac.ca

2
2 GENERAL SYSTEM DESCRIPTION
Figure 1 depicts the general system layout of the UC4+ Spray Height Control system.
Figure 1 – System Components and General Location
NOTICE:
Every effort has been made to ensure the
accuracy of the information contained in
this manual. All parts supplied are
selected specially to fit the sprayer to
facilitate a complete installation.
However, NORAC cannot guarantee all
parts fit as intended due to the variations
of the sprayer by the manufacturer.
Please read this manual in its entirety
before attempting installation.
ATTENTION:
When installing the UC4+ Spray Height
Control system please be aware that at a
point in the installation your sprayer
booms will be inoperative until the
installation is complete. Any installation
procedure requiring boom movement will
need to be done first. Once the hydraulics
have been disconnected you must
complete the electrical installation before
the booms become operative.

4
3 PARTS LISTS
The parts that come with your UC4+ Sprayer Boom System are listed in Table 1. The item
number on the left side of this table references each part. Please ensure that all parts in
your kit are present before proceeding with your installation.
Table 1 – Case 4420/3320 Sprayer Boom Control System Parts
Item Part Number Name Quantity
B05 44706-01 KIT CABLE TIE BLACK 10 PCS 21 IN 150 PCS 7 5 IN 1
B11 44743 MOUNTING BRACKET MAIN LIFT SENSOR UC4 PLUS 1
B13 44728 MOUNTING BRACKET COMPLETE UC4 BREAKAWAY EXTENDED 2
C01 44674 CABLE UC3 SENSOR ROLL BIAS 1
C02 44668 CABLE UC3 SENSOR BRANCH 1 AMP RECEPT 3 AMP PLUG BC 1
C02B 44664 CABLE UC4 CAN NODE DUAL 1
C03 44656D CABLE VALVE VARIABLE RATE DT 1
C04 44658-62 CABLE VALVE CS4 INTERFACE 1
C05 44658-46D CABLE VALVE DT ROLL WITH PIGTAIL 1
C10 44650-39 CABLE POWER GENERIC SELF-PROPELLED 1
C11 44651-03 CABLE EXTENSION VALVE GENERIC 1
C12 44658-24 CABLE INTERFACE UC4 C12 DT06-2X GND2 1
C13 44658-47 CABLE INTERFACE UC4 BC C13 DT2 MAIN EXTENSION 1
C14 44658-28 CABLE INTERFACE UC4 BC C14 POWER PIGTAIL 1
E01 4461BC+ UC4 PLUS BOOM CONTROL PANEL 1
E02 44631 UC4 ULTRASOUND SENSOR 3
E03 44641 UC4 PLUS ROLL SENSOR W TEMPERATURE PROBE 1
E04 44642 UC4 PLUS ROLL SENSOR 2
H02 44863-38 HOSE ASSEMBLY 122R2-06 156 IN L 6FORX 6FORX90 2
H04 44862-08 HOSE ASSEMBLY 122R2-04 36 IN L 6FORX 6FORX 2
H05 44863-10 HOSE ASSEMBLY 122R2-06 60 IN L 6FJX 8FORX 2
H07 44863-25 HOSE ASSEMBLY 122R2-06 136 IN L 6FORX 6FORX 1
H08 44863-31 HOSE ASSEMBLY 122R2-06 106 IN L 6FORX 6FORX 1
H20 44865-06 HYDRAULICS FITTING KIT - CS3 1
H21 44865-48 HYDRAULICS FITTING KIT - CS4 1
M01 446BC+MAN7 OPERATOR MANUAL UC4+ SPRAY HEIGHT CONTROL 1
M10 UC4+BC+CS5+INST MANUAL INSTALLATION CASE 4420, 3320 PROP ML & ENHANCED STABILITY 1
V01 44933D VALVE BLOCK ASSEM UC5-BC 2-STATION CC/LS VARIABLE RATE DT 1
V70 44952D VALVE ASSEMBLY EXPANSION DPC PROP DT 1

5
Table 2 - 44865-06 - Hydraulics Fittings Kit Details
Item Part Number Name Quantity
F02 103312 MALE ADAPTER - 6MB 6MJ 2
F03 104586 TEE ADAPTER - 6FORXR 6MORT 2
F04 104886 MALE ADAPTER - 8MOR 8MB 2
F05 44917 MALE ADAPTER - 6MB-6MOR MACHINED ORB 6
F06 104885 TEE ADAPTER - 8FORXR 8MORT 2
F07 104590 90 DEG ADAPTER - 6MOR 6FORX90 4
F08 104369 PLUG - 6MBP 2
F09 44928 ONE WAY ORIFICE INSERT - 0 047 4
F10 104592 O-RING HYD 3 8 IN FLAT FACE 2
F11 105184 ORIFICE INLINE 6 FLAT FACE 2

6
Table 3 - 44865-48 - Hydraulics Fittings Kit Details
The following fittings are used for connecting the main lift hydraulics.
Item Part Number Name Quantity
*F03 104586 TEE ADAPTER - 6FORXR 6MORT 2
*F04 44917 MALE ADAPTER - 6MB 6MOR 2
6 M B - 6 M OR X 90
SIZE IN
1/16TH'S
GENDER: MALE
OR FEMALE
90 ° ANGLE
SWIVEL
TYPE
GENDER
SIZE
TYPE:
B - ORB
J - JIC
OR - FLAT
FACE
P - PIPE
Fitting Name
Example:

7
The parts that come with your UC4 System are shown below in their general installation
configuration.
Figure 2 – UC4+ Spray Height Control system Components
If your valves or cables appear different than shown, refer to Appendix A for more
details.

8
Figure 3 – Hydraulic Plumbing Schematic
IMPORTANT:
The factory CASE main lift accumulators must be charged to their recommended setting
for proper operation of the UC4+ Spray Height Control system.
Even on new sprayers, the charge pressure should be checked before proceeding with the
installation.

9
4 INSTALLATION PROCEDURE
4.1 E XISTING SYSTEM CHECK
It is necessary to check the existing
system’s functionality before installing
the UC4+ Spray Height Control system.
1. Drive your sprayer onto a flat piece of
land, with unobstructed boom
movement (e.g. no power lines).
2. Test that all boom functions operate
correctly. As you test each function
check it off in Table 4.
It is necessary to test the boom
functions in all directions
Table 4 – Hydraulic System Function
Check Sheet
BOOM
FOLD
IN
FOLD
OUT UP DOWN
LEFT
MAIN
RIGHT
* Some sprayers may not have this
function.
4.2 B OOM S PEED T EST
IMPORTANT:
Raise/lower all boom sections several
times to warm up the hydraulic system.
Grease all moving parts for consistent
results.
1. Lower each boom and main section as
close to the ground as possible.
2. Set your sprayer at field working
RPM on the throttle and mark this
value in Table 5.
You will need a stopwatch or a
watch that displays “seconds” for
the next step.
3. Raise the LEFT boom from its
extreme LOW position to the very
TOP of its travel. Record the time
this takes in Table 5, “Trial #1” for
“Left UP”.
4. Lower the LEFT boom from its
extreme HIGH position to the
BOTTOM of its travel. Record this
time in Table 5, Trial #1, for “Left
DOWN”.
Be careful when lowering the
booms so they don’t hit the
ground.
5. Similarly, record two more time trials
(Trial #2 & #3) for the LEFT boom
and record in Table 5
6. Repeat Steps 1 through 5 for the
RIGHT, MAIN and ROLL functions.
Your sprayer may not have a roll
feature.
7. Average the three trials recorded for
each boom movement and record this
calculation in the “Average Time” slot
in Table 5.
8. These “Average Times” now represent
how quickly your system can react to
manual control. In Section 1.1, this
procedure is repeated with the UC4+
Spray Height Control system installed
for comparison and troubleshooting
purposes.

10
Table 5 – Boom Test Record (WITHOUT UC4+ Spray Height Control system)
Working RPM:
Boom Trial #1
[Sec] Trial #2 [Sec] Trial #3 [Sec] Avg Time [Sec]
Left UP
Left DOWN
Right UP
Right Down
Main UP
Main DOWN
Roll CW
Roll CCW
Table 6 – Boom Test Record (WITH UC4+ Spray Height Control system)
Working RPM:
Boom Trial #1
[Sec] Trial #2 [Sec] Trial #3 [Sec] Avg Time [Sec]
Left UP
Left DOWN
Right UP
Right Down
Main UP
Main DOWN
Roll CW
Roll CCW

11
4.3 W ING S ENSOR I NSTALLATION
1. Assemble the Breakaway Sensor
Mounting Brackets (B11) as show in
Figure 4 and Figure 5.
Figure 4 – Breakaway Sensor Bracket
Exploded View
Figure 5 – Breakaway Sensor Mounting
Bracket Assembly
To assemble the breakaway sensor
bracket:
a) Assemble the bolt and nut into the
collar.
b) Grease the bottom edge of the
collar and the angled tube of the
base.
c) Place the collar onto the angled
tube of the mounting base.
d) Install the spring between the
collar and the upper ring of the
base.
e) Insert tube through assembly and
tighten the collar
2. Mount the sensor bracket onto the
boom.
If possible, mount the sensor
brackets while the booms are in
their folded position to ensure that
they will not interfere with
anything when the boom is folded
for transport.
3. The sensor mounting brackets can be
installed with the mounting base
behind (Figure 8) or in front of the
tube (Figure 6).
It is advised to avoid mounting the
sensor bracket to a breakaway
portion of the boom because a
breakaway action can cause the
UC4+ Spray Height Control
system to force a boom close to the
ground.
Please refer to the UC4+ Spray Height
Control system warranty at the end of
the UC4+ Sprayer Boom Control
Operator’s Manual (M01) for
implications.
4. Mount the NORAC UC4+ ultrasonic
sensor (E02) into the sensor brackets.
The sensors should be oriented
forward (ahead) of the boom (see
Figure 6 and Figure 8).
When installing the UC4+ sensors
(E02), start with the smallest serial
number on the left hand side
proceeding to the largest serial

12
number on the right hand side
(Figure 10).
5. Sensor cables should run through the
mounting bracket tube and then
behind the member the bracket is
mounted onto. Cable-tie the
connector in place. The cable must
not be allowed to hang below the
boom (Figure 6).
Figure 6 – Another Acceptable Mounting
Avoid mounting sensors in
locations where they may read
from parts of the boom as shown
in Figure 7.
Figure 7 – Poor Mounting (Sensor
Reading off Boom)
General mounting rules for UC4+
ultrasonic wing sensors:
a) In its lowest position, the sensor
mouth must be 9 inches or more from
the ground.
b) The bottom of the sensor must be at
least 9 inches in front of the spray
nozzles.
c) The bottom of the sensor must be at
least 9 inches above the spray nozzles.
d) Ensure that there are no obstructions
within a 12-inch diameter circle
projected directly below the center of
the sensor.
e) The sensor should be approximately
vertical at normal operating heights.
Figure 8 – Sensor Mounting Guidelines
A
B
B
D
C
Ultrasonic
Acoustic Cone

13
Figure 9 - Wing sensor mounting location on 120' boom
Figure 10 – Sensor Serial Number Installation Location
3 SENSOR SYSTEM
5 SENSOR SYSTEM

14
4.4 MAIN LIFT SENSOR INSTALLATION
1. Assemble the main lift sensor bracket
(B11) as shown in Figure 11.
Figure 11 – Main Lift Sensor Bracket
2. The bracket can then be mounted to
the lowest frame member on the
center section of the sprayer. The
bracket should be mounted so the
sensor mounting collar is in
approximately the center of the
sprayer and ahead of the boom
(Figure 12 and Figure 13).
The sensor mounting collar must
not be behind the sprayer’s wheel.
The General Mounting Rules for
UC4+ Ultrasonic Sensors, from the
previous section, must be followed.
Figure 12 – Main Lift Sensor Bracket
Mounting Position
3. Mount the sensor onto the sensor
mounting collar (Figure 12).
Figure 13 – Main Lift Sensor Mounted in
the Correct Location
Bracket Tube
Sensor
Mounting
Tab
Sensor Mounting
Collar
Bracket Base

15
4.5 R OLL S ENSOR I NSTALLATION
Mount the roll sensors to the included
roll sensor brackets using the machine
screws and nylon lock nuts, as
illustrated in Figure 14.
The roll sensors must be mounted
tightly to the brackets.
The chassis roll sensor bracket
requires the tabs to be cut off. See
Figure 19.
Figure 14 – Mounting the Roll Sensor to
the Roll Sensor Mounting Bracket
When mounting the roll sensors, use the
following guidelines and refer to Figure
15.
a) The intermediate frame roll
sensor must have the lowest serial
number and the chassis roll
sensor must have the highest
serial number.
b) The smaller the distance between
A and B in Figure 15, the better
the performance will be.
c) Ensure the roll sensors are sitting
relatively level when the sprayer
chassis and boom are level.
d) The roll sensors must be mounted
with the circular AMP connector
facing towards the Right-Hand
Wing (when looking from the rear
of the sprayer).
Connectors
towards Right-
hand Wing


16
Figure 15 – General Roll Sensor Mounting Location on a Trapeze Style Boom
4.5.1 Intermediate Frame Roll
Sensor Mounting
The intermediate frame roll sensor
has the temperature probe on it.
1. It is often best to cable tie the
intermediate frame roll sensor in
place. When mounting the
intermediate frame roll sensor follow
the guidelines and refer to Figure 16.
The intermediate frame roll sensor
must be mounted on a portion of
the sprayer that does not pivot and
is as close to the boom frame roll
sensor as possible (Figure 15).
a) Make sure you are using the roll
sensor with the temperature probe
(E03).
b) Ensure the roll sensor is level with
respect to the chassis.
c) The AMP (circular) connector
MUST exit towards the right hand
wing.
d) Make sure the temperature probe is
able to reach the side of the valve
block.
Figure 16 – Intermediate Roll Sensor
Mounting
2. Fasten the temperature probe to the
UC4+ valve block, using the supplied
3/8”x1/2” bolt as shown in Figure 17.
3. Cable-tie the temperature probe cable
and AMP (circular) connector
securely to a frame member.
Check that the roll sensors and
cables will not interfere with, or
come into contact with any parts of
the sprayer.
Figure 17 – Temperature Probe Attached
to the UC4+ Valve Block

17
4.5.2 Reference Frame Roll Sensor
The reference frame roll sensor
should be the highest serial
number.
1. The reference frame (chassis) roll
sensor mounts directly beneath the top
parallel lift arm, as shown in Figure 18.
Figure 18 - Reference Frame Roll Sensor Mounting Location
2. To mount the reference frame roll
sensor it may be necessary to modify
the roll sensor mounting bracket, as
shown in Figure 19.
3. Ensure the sensor is mounted
adequately and that the cable provides
enough slack.
Figure 19 - Roll Sensor Mount
Modification
Reference Frame
Roll sensor location

18
4.5.3 Boom Frame Roll Sensor
Mounting
The remaining roll sensor after
installing the Intermediate and
Chassis Roll sensors is the Boom
Frame Roll sensor
1. Use the supplied hardware to mount
the boom frame roll sensor (E04) as
shown in Figure 20.
When mounting the boom frame roll
sensor follow these guidelines:
a) To prevent bending the bracket,
ensure bolts are placed as close
together as possible (minimize C in
Figure 20).
b) Be sure to use the roll sensor
without the temperature probe
(E04).
c) When the boom is centered (not
rolled over) the roll sensor should
be level with respect to the sprayer
chassis.
d) It is best to mount the roll sensor
to the left hand trapeze link (when
looking from the rear of the
sprayer).
e) The roll sensor AMP (circular)
connector MUST exit towards the
right had wing (when looking from
the rear of the sprayer).
Figure 20 – Boom Frame Roll Sensor
Mounted to a Trapeze Link
2. Cable-tie the sensor connector to the
frame with enough slack to allow the
link to rotate.
Make sure the bracket does not
collide with any parts of the
sprayer when the boom rotates.
Also ensure there is enough slack
to allow the roll sensor to rotate.
