NordicTrack FUSION CST STUDIO User manual

USER’S MANUAL
CAUTION
Read all precautions and
instructions in this manual before
using this equipment. Keep this
manual for future reference.
Model No. NTSY24921.0
Serial No.
Write the serial number in the space
above for reference.
nordictrack.com
To register your product and
activate your warranty today,
go to my.nordictrack.com.
For service at any time, go to
support.nordictrack.com.
Or call 1-800-TO-BE-FIT
(1-800-862-3348)
Mon.–Fri. 6 a.m.–6 p.m. MT
Sat. 8 a.m.–12 p.m. MT
Please do not contact the store.
REGISTER YOUR
PRODUCT
CUSTOMER CARE
Serial
Number
Decal

2
This drawing shows the location(s) of the warning
decal(s). If a decal is missing or illegible, see the front
cover of this manual and request a free replacement
decal. Apply the decal in the location shown. Note: The
decal(s) may not be shown at actual size.
WARNING DECAL PLACEMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
IMPORTANT PRECAUTIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
BEFORE YOU BEGIN. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
HOW TO USE THE STRENGTH SYSTEM. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
HOW TO USE THE CONSOLE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
FCC INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
MAINTENANCE AND TROUBLESHOOTING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
CARDIO EXERCISE GUIDELINES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
STRENGTH EXERCISE GUIDELINES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
PART LIST. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
EXPLODED DRAWING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
ORDERING REPLACEMENT PARTS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Back Cover
LIMITED WARRANTY. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Back Cover
WARNING DECAL PLACEMENT
TABLE OF CONTENTS
NORDICTRACK is a registered trademark of ICON Health & Fitness, Inc. Android is a trademark of Google LLC.
The Bluetooth®word mark and logos are registered trademarks of Bluetooth SIG, Inc. and are used under license.
1
3
1
1
2
3
1
2
2

3
IMPORTANT PRECAUTIONS
WARNING: To reduce the risk of serious injury, read all important precautions and
instructions in this manual and all warnings on your strength system before using your strength
system. ICON assumes no responsibility for personal injury or property damage sustained by or
through the use of this product.
1. It is the responsibility of the owner to ensure
that all users of the strength system are
adequately informed of all precautions.
2. Before beginning any exercise program,
consult your physician. This is especially
important for persons over age 35 or per-
sons with pre-existing health problems.
3. The strength system is not intended for use
by persons with reduced physical, sensory,
or mental capabilities or lack of experi-
ence and knowledge, unless they are given
supervision or instruction about use of the
strength system by someone responsible for
their safety.
4. Use the strength system only as described in
this manual.
5. The strength system is intended for home
use only. Do not use the strength system in a
commercial, rental, or institutional setting.
6. Keep the strength system indoors, away
from moisture and dust. Do not put the
strength system in a garage or covered
patio, or near water.
7. Place the strength system on a level surface
with at least 6 ft. (1.8 m) of clearance around
the strength system. To protect the floor or
carpet from damage, place a mat under the
strength system.
8. Inspect and properly tighten all parts each
time the strength system is used. Replace
any worn parts immediately. Use only manu-
facturer-supplied parts.
9. Do not climb on any part of the strength
system.
10. Always hold the tablet holder in the horizon-
tal position when attaching it to the mirror.
Do not attach the tablet holder to any other
part of the strength system except the mirror.
11. Always plug the power adapter into the
strength system before you plug it into an
outlet.
12. Keep children under age 16 and pets away
from the strength system at all times.
13. Wear appropriate clothes while exercising;
do not wear loose clothes that could become
caught on the strength system. Always wear
athletic shoes for foot protection.
14. Keep hands and feet away from moving
parts.
15. Pull and release the handles and ankle straps
in a controlled manner.
16. Make sure not to hit the mirror with the
handles, ankle straps, or any other objects.
17. Make sure that the ropes remain on the pul-
leys at all times. If the ropes bind while you
are exercising, stop immediately and make
sure that the ropes are on the pulleys.
18. Over exercising may result in serious injury
or death. If you feel faint, if you become short
of breath, or if you experience pain while
exercising, stop immediately and cool down.

4
all
STANDARD SERVICE PLANS

5
Congratulations for selecting the revolutionary
NORDICTRACK®FUSION CST STUDIO strength
system. The FUSION CST STUDIO strength system
is unlike any ordinary strength system. Whether your
goal is to tone your body, build dramatic muscle size
and strength, or improve your cardiovascular system,
the strength system has an array of innovative features
that will help you to achieve the specific results you
want.
For your benefit, read this manual carefully before
you use the strength system. If you have questions
after reading this manual, please see the front cover
of this manual. To help us assist you, note the product
model number and serial number before contacting us.
The model number and the location of the serial num-
ber decal are shown on the front cover of this manual.
Before reading further, please familiarize yourself with
the parts that are labeled in the drawing below.
Handle
USB Charging Port
Handle
Clip
Resistance Disc
Tablet Stand
Ankle Strap
Squat Pulley
Squat Pulley
Leg
Console
Tablet Holder
Mirror
Tablet
Power Receptacle
Length: 3 ft. 6 in. (107 cm)
Width: 5 ft. 2 in. (157 cm)
Height: 6 ft. 2 in. (188 cm)
BEFORE YOU BEGIN
Clip

6
ASSEMBLY
• Due to the size and weight of the strength system,
assembly requires two or three persons.
• Place all parts in a cleared area and remove the
packing materials. Do not dispose of the packing
materials until you finish all assembly steps.
• Left parts are marked “L” or “Left” and right parts
are marked “R” or “Right.”
• In addition to the included tool(s), assembly
requires the following tools:
one adjustable wrench
Assembly may be easier if you have your own set
of wrenches. To avoid damaging parts, do not use
power tools.
1. To use the assembly steps in this manual, first see the helpful tips below.

7
2
2. Tip: To protect the floor or carpet from
damage, place a mat under the strength
system.
Attach the Right Leg (44) to the right side of the
Frame (1) with four M10 x 25mm Hex Screws
(101); start all the Hex Screws, and then
tighten them.
Attach the Left Leg (66) in the same way.
44
1
66
101

8
3
1
109
102
4
4. Tip: Avoid pinching the Rope (not shown).
With the help of another person, pivot the right
Tower Arm (19) upward and secure it to the
Frame (1) with an M10 x 30mm Screw (100).
Repeat this step for the left Tower Arm (19).
19
19
100
3. Press the Rear Bottom Cover (67) onto the
Frame (1).
Then, press the Front Bottom Cover (109) onto
the Frame (1), slide it upward, and attach it with
an M4 x 16mm Self-tapping Screw (102).
Note: For future reference, note that the large
serial number decal (A) is attached to the Frame
(1) beneath the Front Bottom Cover (109).
1A
67

9
5
5. Attach a Handle (37) to a Rope End (35) with a
Clip (36).
Attach the other Handles (37) in the same
way.
35
36
37
37
37
37
37

10
7
7. Plug the Power Adapter (126) into the receptacle
on the rear of the strength system.
Note: To plug the Power Adapter (126) into an
outlet, see HOW TO PLUG IN THE POWER
ADAPTER on page 11.
8. Make sure that all parts have been properly tightened. The use of the remaining parts will be explained in
HOW TO USE THE STRENGTH SYSTEM on page 11.
Before using the strength system, pull each handle a few times to make sure that the ropes move smoothly
around the pulleys. If one of the ropes does not move smoothly, find and correct the problem.
To register your product and activate your warranty today, go to my.nordictrack.com.
126
6
6. The magnetic Tablet Holder (68) can be attached
at any height on the Mirror (59).
Orient the Tablet Holder (68) so that the slot
(B) is facing upward and the padded side (C) is
facing the Mirror (59).
IMPORTANT: Always hold the Tablet Holder
(68) in the horizontal position when attaching
it to the Mirror (59).
Attach the Tablet Holder (68) to the Mirror (59)
at the desired height. Make sure that the Tablet
Holder is level and centered on the Mirror.
Set the Tablet (40) in the Tablet Holder (68). 68
B
C
40
59
