NordicTrack RW200 User manual

Serial Number
Decal (under rail)
USER’S MANUAL
Model No. NTRW5914.0
Serial No.
Write the serial number in the space
above for reference.
www.nordictrack.com
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manual
for future reference.
To register your product and
activate your warranty today, go
to www.nordictrackservice.com/
registration.
For service at any time, go to
www.nordictrackservice.com.
Or call 1-800-TO-BE-FIT
(1-800-862-3348)
Mon.–Fri. 6 a.m.–6 p.m. MT
Sat. 8 a.m.–12 p.m. MT
Please do not contact the store.
ACTIVATE YOUR
WARRANTY
CUSTOMER CARE

2
NORDICTRACK is a registered trademark of ICON Health & Fitness, Inc.
WARNING DECAL PLACEMENT
TABLE OF CONTENTS
This drawing shows the location(s) of the warning
decal(s). If a decal is missing or illegible, see
the front cover of this manual and request a
free replacement decal. Apply the decal in the
location shown. Note: The decal(s) may not be
shown at actual size.
WARNING DECAL PLACEMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
IMPORTANT PRECAUTIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
BEFORE YOU BEGIN. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
HOW TO USE THE ROWER. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
FCC INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
MAINTENANCE AND TROUBLESHOOTING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
EXERCISE GUIDELINES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
PART LIST. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
EXPLODED DRAWING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
ORDERING REPLACEMENT PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Back Cover
LIMITED WARRANTY. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Back Cover

3
IMPORTANT PRECAUTIONS
WARNING: To reduce the risk of serious injury, read all important precautions and
instructions in this manual and all warnings on your rower before using your rower. ICON assumes
no responsibility for personal injury or property damage sustained by or through the use of this
product.
1. It is the responsibility of the owner to ensure
that all users of the rower are adequately
informed of all precautions.
2. Before beginning any exercise program,
consult your physician. This is especially
important for persons over age 35 or per-
sons with pre-existing health problems.
3. Use the rower only as described in this
manual.
4. The rower is intended for home use only. Do
not use the rower in a commercial, rental, or
institutional setting.
5. Keep the rower indoors, away from moisture
and dust. Do not put the rower in a garage or
covered patio, or near water.
6. Place the rower on a level surface, with a mat
beneath it to protect the floor or carpet. Make
sure that there is at least 2 ft. (0.6 m) of clear-
ance around the rower.
7. Inspect and properly tighten all parts regu-
larly. Replace any worn parts immediately.
8. Keep children under age 12 and pets away
from the rower at all times.
9. Wear appropriate clothes while exercising;
do not wear loose clothes that could become
caught on the rower. Always wear athletic
shoes for foot protection.
10. The rower should not be used by persons
weighing more than 250 lbs. (113 kg).
11. Always keep your back straight while using
the rower; do not arch your back.
12. Do not release the row bar while the cord is
extended.
13. Over exercising may result in serious injury
or death. If you feel faint, if you become short
of breath, or if you experience pain while
exercising, stop immediately and cool down.

UTS
4
all
STANDARD SERVICE PLANS

5
Thank you for selecting the new NORDICTRACK®
RW200 rower. Rowing is an effective exercise for
increasing cardiovascular fitness, building endurance,
and toning the body. The RW200 rower is designed to
let you enjoy this effective exercise in the convenience
and privacy of your home.
For your benefit, read this manual carefully before
you use the rower. If you have questions after reading
this manual, please see the front cover of this manual.
To help us assist you, note the product model number
and serial number before contacting us. The model
number and the location of the serial number decal are
shown on the front cover of this manual.
Before reading further, please review the drawing
below and familiarize yourself with the labeled parts.
Folding Clamp
Rail Handle
Frame Handle Wheel
Footrest
Seat
Resistance Handle
Rail
Row Bar
BEFORE YOU BEGIN
Length: 7 ft. 3 in. (220 cm)
Width: 1 ft. 10 in. (56 cm)
Strap
Knob
Console
Adjustable Neck

6
• Assembly requires two persons.
• Place all parts in a cleared area and remove the
packing materials. Do not dispose of the packing
materials until you finish all assembly steps.
• Assembly requires the following tool(s):
one Phillips screwdriver
one adjustable wrench
To avoid damaging parts, do not use power tools.
ASSEMBLY
2. If there are shipping tubes (not shown) attached
to the rower, remove and discard the shipping
tubes and the hardware attaching them.
With the help of a second person, pull the
Rail (2) outward and rotate the Stabilizer (3)
downward.
2
3
1. Go to www.nordictrackservice.com/
registration on your computer and register
your product.
• activates your warranty
• saves you time if you ever need to contact
Customer Care
• allows us to notify you of upgrades and offers
Note: If you do not have Internet access, call
Customer Care (see the front cover of this
manual) and register your product.
1
2

7
3. Have a second person hold the Rail (2) dur-
ing this step.
Attach the Stabilizer (3) to the Frame (1) with
two M10 x 20mm Screws (61).
Then, hold the Rail Handle (34), pull the Rail (2)
outward, and rest the Rail on the floor.
61
3
4. Orient the Seat (23) as shown, and slide the
Seat Carriage (5) onto the Rail (2). 4
23
2
2
5
34
3
1

8
5. Slide the Seat (23) to the front of the Rail (2).
Next, attach a Stop (32) to each side of the Rail
(2) with an M4 x 19mm Screw (69).
Then, attach the Rail Cap (38) to the Rail (2)
with two M4 x 19mm Screws (69).
6. While a second person holds the Console (75)
and the Upright (77) near the Frame (1), connect
the Upright Wire (84) to the Reed Switch Wire
(47). Insert the excess wire into the Frame.
Tip: Avoid pinching the wires. Attach
the Upright (77) to the Frame (1) with four
M8 x 35mm Screws (82); start all the Screws
before fully tightening them.
7. Identify the Right and Left Upright Covers (80,
81), and orient them as shown.
Press the Right and Left Upright Covers (80, 81)
together around the Upright (77) and attach them
to the Upright with two M4 x 19mm Screws (69).
Then, insert the Knob (78) into the Right Upright
Cover (80) and tighten it into the Upright (77).
2
5
6
7
38
69
69
32
32
23
69
82
77
81
80
77
69
69
78
1
84
75
47
69
Avoid pinching
the wires

9
9. Make sure that all parts are properly tightened before you use the rower. Extra parts may be included.
Place a mat under the rower to protect the floor.
8. The Console (75) can use four D batteries (not
included); alkaline batteries are recommended.
Do not use old and new batteries together or
alkaline, standard, and rechargeable batter-
ies together. IMPORTANT: If the Console has
been exposed to cold temperatures, allow
it to warm to room temperature before you
insert batteries. Otherwise, you may dam-
age the console displays or other electronic
components. Remove the screws and the
battery covers, insert batteries into the battery
compartments, and then reattach the battery
covers. Make sure to orient the batteries as
shown by the diagrams inside the battery
compartments.
To purchase an optional power adapter, call
the telephone number on the cover of this
manual. To avoid damaging the console,
use only a manufacturer-supplied regulated
power adapter. Plug one end of the power
adapter into the receptacle on the console; plug
the other end into an outlet installed in accor-
dance with all local codes and ordinances.
75
75
Screws
Screws
Battery
Covers
Battery
Covers
Receptacle
Receptacle
8

10
HOW TO ADJUST THE RESISTANCE
To vary the
intensity of your
exercise, you
can adjust the
resistance that
you feel when
you pull the row
bar. To increase
the resistance,
move the resis-
tance handle
toward the front
of the rower; to
decrease the
resistance, move the resistance handle toward the
rear of the rower.
HOW TO ADJUST THE FOOT PADS
First, sit on the seat and place your feet in the foot
pads.
Next, press the
footrest bracket,
slide the foot pad
to the desired
position, and
then release the
footrest bracket
so that the tab
engages a slot
in the foot pad.
Then, tighten the
strap over your foot.
Adjust the other foot pad in the same way. Make
sure to adjust both foot pads to the same position.
HOW TO ADJUST THE CONSOLE VIEWING ANGLE
To adjust the
console to the
desired viewing
angle, loosen
the knob in the
upright, move
the neck to the
desired angle,
and tighten the
knob; do not
hold or pull on
the console.
HOW TO FOLD AND STORE THE ROWER
The rower can be stored in a folded position to con-
serve space. Store the rower in a location where
children cannot tip it. Remove the batteries from the
console when storing the rower for extended periods of
time.
To store the rower, first slide the Seat (23) to the rear of
the Rail (2).
Next, hold and lift the Frame Handle (52) and the Rail
Handle (34), and tip the rower forward onto the Shields
(7, 8) and the Storage Feet (43).
Handle
Pad
Tab
Bracket
Knob
Neck
23
2
34
52
3
43
7, 8
HOW TO USE THE ROWER
