Ti-Max NL400 CDE
Installation Manual OM-E0260E
1. Packaging Contents 3. Attachment of The Connectors
Check to see that all of the following parts are included
and undamaged.
Thank you for purchasing the Ti-Max NL400 CDE. Read this installation manual carefully before use for safety and keep this
within user's reach.
2. Before Assembling the Tubing
Pass the handpiece side motor cords through the
appropriate openings of the control unit so that the
tubing is fixed securely in the arm and the motor
rests at the desired position for handpieces. (Fig.1)
After properly placing the handpiece side motor cords
in the arm, attach connectors as follows.
Control Box Side Motor Cord
Handpiece Side Motor Cord
Connector
Tube-retaining Ring
(3 pieces, Different Types)
Connector Pin Remover
Fig.1
Opening Parts
Arm
Handpiece Side
Motor Cord
Terminal Side
Control Box Side
Motor Cord
Insert the terminals of each handpiece side motor
cords securely to the ends of the holes of the
connectors, paying close attention to the positions of
the cord colors and numbers. (Fig.2)
■If it is necessary to remove a terminal from the
connector.
Insert an “Connector Pin Remover” securely into the
opposite side of the connector from the terminal to
be removed and pull out the cord while pressing on
the “Connector Pin Remover.” (Fig.3)
Fig.2
Fig.3
Fig.4
３
２
１
６
５
４
Brown
Connector CordTerminal
Insert them matching the cord
color and number.
Black
Red
Orange
Yellow
Caution
After inserting the terminals of the cords,
gently pull them to check that they are
securely fixed.
Caution
・After adjoining the connectors, gently pull
them to check that they are securely fixed.
・After adjoining the connectors, check that
the cord colors of the control box side and
the handpiece side match.
Connector
①Insert ②Pull Out
Cord
Connector Pin Remover
Handpiece Side
Motor Cord
1
1
2
Insert the connector of the handpiece side motor cord
assembled in to the connector of the control box
side motor cord securely until they lock. (Fig.4).
1
2

4. Attachment of The Tube
Attach an appropriate tube-retaining ring to the tubes
of the handpiece side motor cord, paying attention to
the following directions. (Fig.5)
Fig.5
Tube
Tube-retaining Ring
■Tube-retaining Ring
Attach to the tube with the inside chamfered
part facing outward.
Chamfered
Part
(Thick, with line)・・・・For Coolant Tube (Transparent)
(Thick)・・・・For Water Tube (Blue)
(Thin)・・・・For Chip Tube (Yellow)
Fig.6
Tube Barb
Securely push the tube-retaining ring over the barb
connection. (Fig.7)
Fig.7
Notice
If alcohol is applied to the tube, it makes it
easier to insert the barbs.
Barb Press In
Push the tube-retaining ring
to the end from the barb.
Tube-retaining Ring
Refer to the Operation Manual “Ti -Max NL400” for
other handling information.
'05.02.01 N
1
2
3
Attach each tube of the handpiece side motor cord
from step to match the identical colored tubing on
as the control box side motor cord. (Fig.6)
