NSK Ti-Max Z Series User manual

1
ENGLISH
1. User and Intended Use
User: Qualified Professionals
Intended Use: Dental Treatment
2. Precautions for handling and operation
Please read these precautions carefully and use only as intended or instructed.
Safety instructions are intended to avoid potential hazards that could result in personal injury or damage to the device. Safety instructions are
classified as follows in accordance with the seriousness of the risk.
Class Degree of Risk
WARNING Hazard that could result in serious injury or damage to the device if the safety instructions are not correctly followed.
CAUTION Hazard that could result in light or moderate injury or damage to the device if the safety instructions are not correctly
followed.
NOTICE General product specification information highlighted to avoid product malfunction and performance reduction.

2
CAUTION
ŘRead this Operation Manual before use to fully understand the product functions and file for future reference.
ŘWhen operating the product always consider the safety of the patient.
ŘUsers are responsible for the operational control, maintenance and continual inspection of this product.
ŘDo not attempt to disassemble the product nor tamper with the mechanism except as recommended by NSK in this Operation Manual.
ŘDo not allow any impact on to the product. Do not drop the product.
ŘOperators and all others in the area must wear eye protection and a mask when operating this handpiece.
ŘShould the product function abnormally, cease operation immediately and contact your Authorized NSK Dealer.
ŘDo not use high acid water or sterilizing solutions to wipe, immerse or clean the product.
ŘThe following products are delivered in a non-sterile condition and must be autoclaved prior to use.
WARNING
ŘDepressing the Push Button while the handpiece is in operation may cause overheating, serious technical damage and possible premature
handpiece failure. During operation avoid contact with any oral tissue that may cause the Push Button to be depressed while the handpiece is
in operation.

3
EN DE FR ES IT PT
CAUTION
ŘPerform regular function and maintenance checks.
ŘIf the product is not used for a long period check it is functioning correctly before using on a patient.
ŘTo avoid clinical downtime it is recommended that a spare be kept on hand in case of a breakdown during surgery.
ŘAvoid continual eye contact with the LED light (Z800BL/Z800WL/Z900BL/Z900WL).
ŘThis handpiece is a LED product classified in the "Exempt Group" (no photobiological hazard) in accordance with IEC62471/EN62471 (Z800BL/
Z800WL/Z900BL/Z900WL).
ŘUse a power source which meets the following requirements (Z800BL/Z800WL/Z900BL/Z900WL).
1. The electricity supply of the power source is below 15W both under normal and single-failure conditions.
2. The power source uses a SELV circuit for electricity supply.
3. The output voltage of the power source is within the range recommended by the manufacturer of this product.
ŘU.S. Federal law restricts this device to sale by or on the order of a licensed physician.

4
3. Accessory List
No. Part Name Quantity Remarks
1 Spray Nozzle 1 -
2 Cleaning Wire 1 Brush and wire set
3 PTL O-ring Set 1 Included in the package for Z800L/Z800/Z900L/Z900

5
EN DE FR ES IT PT
WARNING
CAUTION
4. Setting of Air & Water Supply Pressure
Measure the supply pressure at the handpiece/hose connection point and set the pressure to the value
specified on the specification table (Fig. 1).
For NSK Multi Gauge information refer to Option Parts List.
ŘDo not exceed the optimum pressure specified on the specification table.
ŘDo not use air contaminated by dust, moisture or oil.
Fig. 1
Handpiece
Chip Air
Pressure
Exhaust Air
Pressure
Water
Pressure
Drive Air
Pressure

6
CAUTION
ŘDo not operate the Retention Lock Ring while under drive air pressure. The high pressure may cause sudden release of the handpiece from
the coupling.
5. Connection & Disconnection of the Handpiece
Refer to Operation Manuals of coupling and hose before connecting the handpiece.
Z800L/Z800/Z900L/Z900
5-1 Connection
1) Insert the handpiece into the Coupling (Fig. 2).
2) Make sure the handpiece is firmly connected to the coupling.
5-2 Disconnection
Pull back the Retention Lock Ring and remove the handpiece from the Coupling (Fig. 2). Fig. 2
Retention Lock Ring
Handpiece Coupling

7
EN DE FR ES IT PT
6. Insertion & Removal of the Bur
6-1 To Insert the Bur (Fig. 3)
1) Insert the bur into the chuck.
2) Depress the Push Button to open the chuck ( ).
3) Fully insert the bur into the chuck until it stops ( ) then release the Push Button.
4) Ensure that the bur is secure by gently pulling and pushing the bur WITHOUT depressing the Push Button.
6-2 To Remove the Bur (Fig. 4)
Depress the Push Button to open the chuck ( ) and remove the bur ( ).
1
2
Fig. 3
1
2
Fig. 4
Push Button
Push Button

8
CAUTION
NOTICE
ŘAlways insert the bur all the way into the chuck.
ŘRemove the bur only after the handpiece has completely stopped rotating.
ŘAlways keep the bur shank clean.
ŘEntry of debris into the chuck, via the bur shank, could cause bur rotation slip and also prevent the bur from being securely located in the
chuck.
ŘDo not exceed the bur speed recommended by the bur manufacturer.
ŘDo not exceed maximum bur length recommended by the handpiece manufacturer.
ŘDo not apply excess pressure to the bur as it may break or bend or become difficult to remove.
ŘDO NOT use burs with problems listed below as the bur may break, seize up or disengage from the chuck.
- Bent, deformed, anisomerous (worn), rusted, broken, deficient bur.
- Bur which is cracked on the edge or axis.
- Non-ISO standard, or tampered bur.
ŘGrip the handpiece while placing your thumb tip on the Push button which makes it easier to depress the button.

9
EN DE FR ES IT PT
7. Check before treatment
Check that the Head Cap is firmly tightened. Also check for handpiece vibration, noise and overheating outside the patient's oral cavity. If any
abnormalities are found do not use the handpiece and contact your Authorized NSK Dealer.

10
8. Maintenance
After each patient maintain the product as follows. Lack of maintenance could cause premature failure or
overheating of the handpiece.
8-1 Cleaning handpieces with the NSK Clean-Head System
After the treatment of each patient, clean the Clean Head.
1) Half fill a cup with clean water.
2) Remove dirt and debris from the Clean Head Holes with the cleaning wire and brush (supplied as an
accessory for the handpiece) (Fig. 5).
3) Rotate the handpiece and immerse half of the handpiece head in the cup of water (Fig. 6).
4) Rotate then stop intermittently the handpiece 3 times for 2 to 3 seconds each time.
5) Wipe the handpiece dry.
* If the dirt could not be removed from the hole, clean it by brush.
Fig. 5
Fig. 6
Clean Head Hole
Clean Head Hole

11
EN DE FR ES IT PT
CAUTION
ŘAfter washing with Thermo-Disinfector and prior to lubrication, dry the product until all internal moisture is thoroughly removed. Thermo-
Disinfector moisture remaining inside the product could reduce the effect of lubrication and could cause corrosion inside of the product.
ŘTo clean the product never use any solvent such as benzine or thinner.
8-2 Cleaning (Handpiece)
1) Remove debris from the product. Do NOT use a wire brush.
2) Wipe clean with alcohol-immersed cotton swab or cloth.
This icon denotes that the product can be washed via Thermo Disinfector.
Refer to the Thermo-Disinfector manual.

12
8-4 Cleaning (Spray Port)
When spray ports are clogged, or spray does not exit evenly from the ports, clean the ports (Fig. 8).
8-3 Cleaning (Optic)
Wipe clean the Glass Rod tip with an alcohol-immersed cotton swab. Remove all debris and oil (Fig. 7).
CAUTION
ŘDo NOT use a sharp tool to clean the Glass Rod. It could damage the glass and reduce the light
transmission.
CAUTION
ŘDo not forcibly insert the wire into the port. Resultant port damage could cause the spray to be
directed away from the bur, and the cooling efficiency reduces.
ŘDo not blow air into the Clean Head Hole.
Fig. 8
Fig. 7
Spray Port
Cotton Swab
Glass Rod
Spray Port
Wire

13
EN DE FR ES IT PT
CAUTION
8-5 Lubrication
NSK PANA SPRAY Plus/PANA SPRAY
Apply NSK PANA SPRAY Plus/PANA SPRAY every time after each use and/or before autoclaving.
1) Remove the bur from the handpiece.
2) Insert the Spray Nozzle into the Spray Port nozzle on the can.
3) Insert the Spray Nozzle into the rear of the handpiece. Hold the handpiece and spray for approximately
2-3 seconds. Apply lubricant until it expels from the handpiece head for at least 2 seconds (Fig. 9).
ŘWhen applying spray be sure to hold the handpiece firmly to prevent the handpiece from slipping out of the hand due to the spray pressure.
ŘHold the spray can upright.
Fig. 9
Spray Nozzle
Handpiece

14
CAUTION
Chuck cleaning
Clean the Push Button chuck once a week.
1) Mount the Tip Nozzle into the spray can port.
2) Lubricate the chuck directly through the bur insertion hole (Fig. 10).
3) Lubricate handpiece by using NSK PANA SPRAY Plus/PANA SPRAY (Fig. 9) or NSK automatic handpiece
cleaning and lubrication system.
NSK automatic handpiece cleaning and lubrication system
When using NSK automatic handpiece cleaning and lubrication system, refer to the system instructions.
ŘIf the chuck is not regularly cleaned the chuck grip may be weakened and the bur may be accidentally released while in operation.
Fig. 10
Bur Insertion Hole
Tip Nozzle

15
EN DE FR ES IT PT
CAUTION
8-6 Sterilization
Sterilize the product by autoclave sterilization. Remove the bur after each patient and sterilize as noted below.
1) Insert into an autoclave pouch. Seal the pouch.
2) Autoclavable under the conditions below.
Autoclave for more than 20 min. at 121°C, or 15 min. at 132°C, or 3 min. at 134°C.
3) The handpiece should remain in the autoclave pouch until required for use.
ŘDo not autoclave the product with other instruments even when it is in a pouch. This is to prevent possible discoloration and damage to the
product from chemical residue on other instruments.
ŘKeep the product in suitable atmospheric pressure, temperature, humidity, ventilation, and sunlight. The air should be free from dust, salt and
sulphur.
ŘImmediately after use, the product should be cleaned, lubricated and sterilized. If blood remains on the external or internal surfaces it can
become clotted and cause rust.
ŘDo not heat or cool the product too quickly. Rapid change in temperature could cause damage to the product.
ŘIf the sterilizer chamber temperature may exceed 135°C during the dry cycle then delete the dry cycle.

16
CAUTION
NOTICE
ŘAutoclave sterilization is recommended for the product. The validity of other sterilization methods is not confirmed.
ŘDo not touch the product immediately after autoclaving as it will be very hot and must remain in a sterile condition.
ŘNSK recommends Class B sterilizers as stated in EN13060.

17
EN DE FR ES IT PT
9. Replacing the O-rings (Z800L/Z800/Z900L/Z900)
Replace the O-rings if water is present in the exhaust air line. This is an indication of possible water leakage
within the coupling. ALWAYS change the complete set of O-rings.
1) Loosen and remove the taper ring at the rear of the handpiece (Fig. 11).
2) Gently remove each O-ring by hand (Fig. 12).
3) Insert the complete set of new O-rings in the correct grooves.
4) Firmly tighten the taper ring.
* Refer to Spare Parts List to identify the correct parts.
CAUTION
ŘDo not force the new replacement O-ring with excessive pressure.
ŘWhen inserting new O-rings, make sure they are inserted in the correct grooves.
ŘMake certain that the taper ring is firmly tightened. If the taper ring is loose water and air leakage
could occur.
Fig. 11
Fig. 12
Taper Ring
O-ring

18
10. Replacing the Non-Retraction Valve
A water Non-Retraction Valve is integrated in the Coupling Joint, which shuts off the water retraction directly at the handpiece head to prevent fluids
infiltrating the water line. If water is beginning to leak from the handpiece, replace the non-retraction valve.
NSK Coupling (Z800L/Z800/Z900L/Z900)
1) Remove the Coupling Joint from the hose.
2) Remove the back-end Gasket.
3) Pull and remove the water tube, and remove the Non-Retraction Valve.
4) Insert the new Non-Retraction Valve securely and remount the back-end Gasket.
* Refer to Spare Parts List to identify the correct parts.
Fig. 13
Back-end Gasket
Non-Retraction Valve

19
EN DE FR ES IT PT
11. Periodical Maintenance Checks
Perform periodical maintenance checks every three months, referring to the check sheet below. If any abnormalities are found, contact your Authorized
NSK Dealer.
Points to check Details
Head cap is loose Check that the Head Cap is firmly tightened.
Rotation Rotate the handpiece and check for abnormalities such as abnormal rotation, vibration, noise, and overheating.
Coolant Water Operate the handpiece and check that the coolant water is flowing through all spray ports.
12. Symbol
This product is Autoclavable up to Max.135ºC. This product can be washed via Thermo Disinfector.
Conforms to CE European Directive of "Medical device directive 93/42/EEC".
Manufacturer.
Authorized representative in the European community.
Caution: U.S. Federal law restricts this device to sale by or on the order of a licensed physician.
GS1 DataMatrix for Unique Device Identifier.
