NSK TiMax Z10L User manual

OM- C0442E
Contra Angle Handpiece
’11.11.05 S
The EU directive 93/42/EEC was applied in the design and production of this medical device.

1
ENGLISH
CAUTION
Intended to use
· When operating the Handpice always consider the safety of the patient.
· Check for vibration, noise and overheating outside the patient's oral cavity before use. If any abnormalities are found, stop using the Handpice
immediately and contact dealer.
· Should the Handpice function abnormally, cease operation immediately and return the Handpice to dealer for repair.
· Depressing the push-button while the handpiece is rotating will result in OVERHEATING of the handpiece head. Special caution must be
exercised during use to keep cheek tissue AWAY from the push-button of the handpiece. Contact with cheek tissue may cause the push-button
to depress and burn injury to the patient may occur.
· Do not attempt to disassemble the handpice or tamper with the mechanism.
· Do not allow any impact on to the Handpice. Do not drop the Handpice.
· Do not connect or disconnect the Handpice or bur until the drive motor has completely stopped.
· Do not use bent, deformed or damaged bur. If these burs are used, it bends suddenly, or it breaks during rotation. Bur may become difficult to
remove because latch groove is worn or it has swollen.
This handpice is intended only for dental clinic/dental office use.

2 3
ENGLISH GERMAN FRENCH SPANISH ITALIAN
2. Connecting/Disconnecting handpiece and Motor
2-1 Connecting
1)Align the handpiece and motor alignment pin.
2)Then push the handpiece directly into the motor in alignment with the pin.
1. Specification
· Always keep bur shanks clean. Dirt or debris in a chuck could cause poor bur concentricity or low chuck retention force.
· Do not exceed the drive motor speed recommended the bur manufacturers.
· Before use always confirm that the bur is correctly seated and locked into place.
· Always use with adequate water supply and coolant air or damage to the tooth structure may occur and overheating.
· Use eye protectors, dust mask, for safety and health during treatment.
· Perform periodical maintenance checks.
· If the handpiece has not been used for a long period, check for noise, vibration, and overheating before use.
· Do not wipe nor immerse the handpiece acidic water or acidic solutions.
· User is responsible for operation, maintenance and safety.
Z85,Z85L
Use short shank FG Bur for a mini head. If long bur has used, it may cause of the omission of early wear of a bearing, Bur will bend, and
breakage.
Z95,Z95L
· Do not use long surgical burs. Do not use burs longer than 26mm.
· If a foreign material enter to the gear and inside of handpiece, it may become a cause of burn injuries.
ISO 1797-1 Type3 Ø1.60mm FG Bur
Model
Max. Rotation Speed
Gear Ratio
Bur
Optic
Bur applied Length
Max Bur Length
Max Bur diameter
Z10L
16:1
12.5mm
22.5mm
ISO 1797-1 Type1 Ø2.35mm Contra Bur
Ø4.0mm
4:1 1:1
9.8mm 10.5mm
16.5mm 25mm
1:5
40,000min-1
Z10 Z15L Z15 Z25L Z25 Z85L Z85 Z95L
ISO 1797-1 Type3 Short Shank FG Bur
Ø2.0mm
Z95
OPTIC
NON-OPTIC OPTIC NON-OPTIC OPTIC NON-OPTIC OPTIC NON-OPTIC OPTIC NON-OPTIC

Push Button
4
ENGLISH GERMAN FRENCH SPANISH ITALIAN
5
2-2 Disconnecting
Hold the motor and the handpiece, and pull it out.
4. Mounting/ Removing the Bur
4-1 Mounting the Bur
4-1-1 Mounting the Bur (Contra Bur)to Z10,Z10L,Z15,Z15L,Z25,Z25L
1)Connect handpiece and motor.
2)Insert and llightly turn the bur until it engages with the latch mechanism. (Fig. 1)
3)Push the bur further inwards until it clicks into place.
4-1-2 Mounting the Bur (FG Bur)to Z85,Z85L,Z95,Z95L
1) Connect handpiece and motor.
2) Depressing the push button and insert the bur into the chuck. (Fig. 2)
CAUTION
Connect ONLY E type motor (ISO3964)and do not exceed maximum motor speed such as shown on the specification.
CAUTION
· After the Bur is locked in place, lightly pull out the Bur to make sure the Bur is locked.
· If the Bur is not correctly secured it may release during operation and can cause injury.
3. Check before treatment
Follow the check below, before use. If any abnormalities are found, stop using the handpiece immediately and contact the authorized NSK dealer
1)Insert the Bur. (Do not exceed maximum rotation speed for any item.)
2)Check that there is no abnormal rotation, vibration, noise and overheating.
3)If there are no immediate apparent abnormalities, continue to rotate the handpiece for about 1 minute. Then check that there is no abnormal
heating on the outer surface.
4)Operate it if there are not abnormalities above.
Fig. 2
Fig. 1
D-shape

6
ENGLISH GERMAN FRENCH SPANISH ITALIAN
7
CAUTION
Do not use a pointed tool or sharp edged to clean the Cellular Glass Optic Rod. They may damage
the mirror finish and reduce the light transmission efficiency. If Cellular Glass Optic Rod end has
become damaged, return it to dealer for repair.
4-2 Removing the Bur (Fig.3)
1)Push the push button with a thumb.()
2)Pull out the bur.()
5. Maintenance
After the treatment, be sure to perform the maintenance below.
5-1 Cleaning(Handpiece)
This handpiece can be washed via Thermo Disinfector.
Scrub dirt and debris from the handpiece, and wipe clean with alcohol-immersed cotton swab or cloth. Do not use a wire brush.
Refer the manual of Thermo-Disinfector for performing it.
5-2 Cleaning(Z10L,Z15L,Z25L,Z85L,Z95L)
Wipe clean the Cellular Glass Optic Rod entry point and exit point with an alcohol-immersed cotton
swab. Remove all debris and oil.(Fig.4)
5-3 Lubirication and Sterilization
Refer to the Maintenance Guide OM-Z0135E.
Push Button Cotton Swab
Glass Rod
Fig. 4
Fig. 3

8
6. Warranty
NSK warrants the handpiece against production errors and material defects. NSK reserves the right to analyze and determine the cause of any
problem. Warranty is voided should the handpiece be not used correctly. Replacement parts are available for seven years beyond discontinuation of the
model.
