Numatic MV 570 User manual

Owner InstructionsOwner Instructions
Original InstructionsOriginal Instructions
CAUTION, Read instructions before using the machineCAUTION, Read instructions before using the machine
MV 570 / MVD 570 / MV 570A / MVD 570AMV 570 / MVD 570 / MV 570A / MVD 570A
MV 900 / MVD 900 / MV 900A / MVD 900AMV 900 / MVD 900 / MV 900A / MVD 900A
MV 900 (A)
MV 570
www.numatic.com

2
Optional Accessory - 607160 - Kit ND5
Kit BA5
Kit BB5
Kit BA28

3
X 4
X 4
900 Handle Assembly

4
I
0
=
=
Fitting the Hose, Fitting the Air Seperator

5
Moving the Machine

6
MV, MVD Warning Light
Cause Solution
 Remove the caps.
Blocked hose Unblock the hose.
Bag full Remove and replace
 
Hepa cartridge clogged Replace, seek advice from an instructed
person or manufacturer.
Low Flow Indicator
Slow Repeated Flash
Please change the bag.
If the fault persists check the following:-
Constant Red Light
This indicates a possible machine fault or that the auxiliary socket has become overloaded.
If the auxiliary socket is over loaded the machine will cut out.
󰀨
If the fault remains check the fuse.
MV (A), MVD (A) Warning Light

7
󰀨
The red operating switch controls the
vacuum motor.
Auto Switching
The auxiliary socket to the rear of the
machine is a power source for your
secondary appliance.
If the green operating switch is in the
ON position the vacuum will operate
only when the secondary appliance
has been turned on.
Fuse
MV 570, MV 900, MVD 570, MVD 900

UK Machine x 1 fuse
To examine or change the fuse, apply pressure to the top of the fuse holders and twist
to release the fuse carrier and fuse.
Simplex type uses 220179 6.3 amp Anti Surge Fuse.
Duplex type uses 208760 4.0 amp Anti Surge Fuse.
Warning 
MV 570A, MVD 570A, MV 900A , MVD 900A Auxiliary Power Socket
Simplex type 2000W Maximum Output Load (min 100W)
Duplex type 1000W Maximum Output Load (min 100W)

8
Changing the Bag, Cleaning the Filter
1
2

9
Changing the cable
1 2
3 4
56
78

10
About the Machine
WEEE Legislation ( Waste, Electrical and Electronic Equipment).
Vacuum cleaner, accessories and packaging should be sorted for environmental-friendly recycling.
Only for EU countries:
Do not dispose of Vacuum cleaner into household waste!
According to the European Directive 2012/19/EU on waste electrical and electronic equipment and its
incorporation into national law.
Vacuum cleaners that are no longer suitable for use must be separately collected and sent for recovery in an
environmentally - friendly manner.
Safety Critical Components
Mains Lead
HO5VV-F 10m x 3 Core x 1.5 mm²
PPE
(Personal Protective Equipment) that may be required for certain operations.
NOTE:
A risk assessment should be conducted to decide what PPE should be worn.
Caution FloorsignSafety Footwear Head Protection Safety Gloves Dust / Allergens Protection Eye Protection Protective Clothing
MV / MVD style machines:
This vacuum cleaner is intended for indoor use in the extraction and collection of dry materials.
Extraction from electric power tools can be controlled by an integral automatic electronic
󰀨
Not suitable for the collection of biological hazards, or explosive dusts.
Do not use in wet environments or to collect wet materials.
Ear Defenders must be worn when using this machine
Rating Label 1
2
3
4
5
6
7
8
9
1

3
4
5
6
7
8
9
Company Name & Address
Machine Description
Voltage Frequency
Power rating
Weight (ready to use)
IPX Rating
Dust Class
WEEE Logo
Approvals Mark
Machine yr/wk Serial number
10
10
901647
Simplex
Cartridge
Filter

machines
901652
Duplex
Cartridge
Filter

machines
