Oakley Holeshot 3 Hand User manual

®

TABLE OF CONTENTS
ENGLISH 02-13
ESPAÑOL 14-25
FRANCAIS 26-37
ITALIANO 38-49
PORTUGUÊS 50-61
MAGYAR 62-73
DEUTSCH 74-85
JAPANESE 86-95
©2007 Oakley, Inc. U.S. Patent D509444S

HOLESHOT 3-HAND
The technology of performance becomes the art of style with Oakley Holeshot, an
invention that brings sport into life. This true Swiss Made timepiece blends the
authenticity of Oakley design with the durability of 316L stainless steel and the
refinement of a pure sapphire crystal.
Aband of supple Unobtainium® offers all-day comfort. The date display can be
read at a glance, and luminous phosphors on the minute and hour hands improve
visibility in low light. Water resistance is 10 bar, equivalent to the pressure at a
depth of 330 feet (100 meters).
02 HOLESHOT 3-HAND INSTRUCTIONS MANUAL

SETTING THE TIME
The crown can be pulled out to two click positions for setting the date and time.
To set the date and time the first time (or to reset the date and time after the
battery is changed), do the following:
HOLESHOT 3-HAND INSTRUCTIONS MANUAL 03
TO SET THE TIME
1. Pull the crown out to the first click
position (a).
2. Turn the crown until yesterday’s date
appears.
3. Pull the crown out to the second click
position (b).
4. Turn the hands forward until today’s date
appears, then continue forward until the
current time is reached. If the current time
is in the afternoon or evening, move the
hour hand all the way around the dial to
pass 12 o’clock noon.
5. Push the crown back down.
Toset the exact second, wait until the
second-counting hand reaches “60” before
you pull out the crown. Set the time then
wait until the exact second is reached
before pushing the crown back down.
AB
Second Hand
Date
Crown

TO ADJUST THE TIME AND DATE FOR SUBSEQUENT SETTINGS, USE
THESE SHORT PROCEDURES
TO SET THE TIME
1. Pull the crown out to the second click position (b).
2. Turn the crown until you reach the correct time.
3. Push the crown back down.
TO SET THE DATE
1. Pull the crown out to the first click position (a).
2. Turn the crown until you reach the correct date.
If the current time is between 9 PM and
midnight, set the date to the following day.
(This is necessary to ensure the date
display will normally change at midnight
instead of 12 noon.)
3. Push the crown back down.
04 HOLESHOT 3-HAND INSTRUCTIONS MANUAL
AB
Second Hand
Date
Crown

POWER SAVING MODE
When the timepiece is not in use, the battery life can be prolonged by pulling the
crown out to the second click position (b). This will stop the hands and reduce
power consumption.
HOLESHOT 3-HAND INSTRUCTIONS MANUAL 05

06 HOLESHOT 3-HAND INSTRUCTIONS MANUAL
BATTERY REPLACEMENT
The miniature battery that powers the timepiece is designed to last approximately
46 months. However, because the battery is inserted at the factory for extensive
performance checks, its actual life, once in your possession, may be less.
Battery replacement may be performed only by an Authorized Oakley Service
Center. Any attempt to open the watch case by persons other than Authorized
Oakley Service Professionals will void the product warranty.
Within the United States, call Oakley global headquarters at 1-800-403-7449 to
find an Authorized Oakley Timepiece Dealer or Service Professional near you.
Customers outside the United States should contact their local Authorized Oakley
Timepiece Dealer or visit the Oakley website at www.oakley.com for the number
of the nearest Oakley distributor.

CLEANING
Failure to keep the case and band clean may result in a skin rash. Use a soft,
clean cloth to wipe off any moisture that adheres to the case or band.
HOLESHOT 3-HAND INSTRUCTIONS MANUAL 07

COMPOSITION
CASE BODY..............................................................................................Stainless steel
CASE BACK ..............................................................................................Stainless steel
MANUFACTURING..................................Impact forged, high-precision CNC machined
CRYSTAL ..............................................................Sapphire with anti-reflective coating
CROWN ......................................................................Double seal for water resistance
BRACELET COMPOSITION ..............................................Oakley Unobtainium® rubber
CLOSURE ......................................................................................Stainless steel buckle
08 HOLESHOT 3-HAND INSTRUCTIONS MANUAL

SPECIFICATIONS
MOVEMENT ................................................................................................Swiss Made
TYPE OF OSCILLATOR ........................................................................Quartz tuning fork
FREQUENCY OF OSCILLATOR ......................................................32,768 cycles per sec.
DRIVE SYSTEM ............................................................Two-pole step motor (180º/sec.)
ACCURACY....................................................................................-12 /+18 sec. per mo.
THERMAL OPERATING MIN ............................................................................0ºC (32ºF)
THERMAL OPERATING MAX. ......................................................................50ºC (122ºF)
WATER RESISTANCE ................................10 bar; equivalent to depth of 100m / 330ft
BATTERY....................................................................Silver oxide: No. 397, SR 726 SW
BATTERY ENDURANCE ....................................................................Approx. 46 months
HOLESHOT 3-HAND INSTRUCTIONS MANUAL 09

SAFEGUARDING
WATER EXPOSURE
Rated at 10-bar hydrophobic, the timepiece may be worn during bathing,
swimming and shallow diving. It is not designed for scuba or saturation diving.
Do not pull out the crown or use the buttons if the timepiece is wet. If used in
seawater, rinse the timepiece with fresh water and dry completely.
TEMPERATURE
For precision timekeeping, normal operating temperature is 0°C to 50°C (32°F
to 122°F).
MAGNETISM
Strong magnetic fields can have an adverse affect on the timepiece. Keep it away
from magnetic objects.
CHEMICALS
The timepiece may become discolored or damaged if exposed to cosmetic spray,
detergents, adhesives, solvents, or paints.
SHOCK WAVE
Although the timepiece resists shock damage, impact against a hard surface may
cause damage to the movement or crystal.
PERIODIC MAINTENANCE
Toensure that the case, crown, crystal seal, and gasket remain resistant to water
exposure, it is recommended that the timepiece be inspected once every 2 to 3
years by an Authorized Oakley Service Center.
10 HOLESHOT 3-HAND INSTRUCTIONS MANUAL

HOLESHOT 3-HAND INSTRUCTIONS MANUAL 11
OAKLEY WARRANTY POLICY
All authentic Oakley timekeeping instruments are warranted against manufacturer’s
defects for two full years from the date of purchase. Coverage is valid only with
proof of purchase from an Authorized Oakley Timepiece Dealer.
IMPORTANT
This limited warranty does not cover the crystal, strap/band/bracelet, or
attachments. The deterioration of leather components is not covered, nor are
scratches to the case caused by use, nor is moisture damage if the timepiece is
anon-hydrophobic model, nor is damage caused by natural disaster such as fire,
flood, or earthquake. We reserve the right to relinquish all responsibility under
this guarantee for repair of damage when misuse or abuse is evident, including
defects related to tampering or servicing done by agents other than Authorized
Oakley Service Facilities. This warranty does not affect specific legal rights of
the consumer.
To qualify for service under the above guarantee, valid proof of purchase —
which clearly shows the purchase date and the name of the Authorized Oakley
Timepiece Dealer — must be presented if a repair claim is made during the
warranty period.

OAKLEY WARRANTY POLICY
REGISTRATION
The cutting-edge technology within each Oakley timepiece serves as validation of
its authenticity. By registering your timepiece via mail or online at
www.oakley.com, you provide further credentials by allowing us to document
your purchase.
HOW TO MAKE A WARRANTY CLAIM
Within the United States, telephone our global headquarters at 1 [phone]
with your purchase information. Customers outside the United States should
contact their local Authorized Oakley Timepiece Dealer or visit the Oakley
website at www.oakley.com for the number of the nearest Oakley distributor.
Swiss Movement
Swiss Made
12 HOLESHOT 3-HAND INSTRUCTIONS MANUAL

HOLESHOT 3-HAND INSTRUCTIONS MANUAL 13
HOW TO MAKE A WARRANTY CLAIM
Oakley Global Headquarters, USA: 1 [phone]
Oakley Africa: [phone]
Oakley Brasil Ltda.: 0800-770-7822 ou 0xx11-4197-9999 (Grande São Paulo e celular)
Oakley Canada: 1-877-625-5396
Oakley Europe: Belgium: 0800 10 464 • Danmark: 800 10 631 • España: 900 993 385
•Finland: 0 800 11 33 80 • France: 0 800 037 619 • Nederland: 0800 022 9086
•Island: 800 83 82 • Italia: 800 343 467 • Luxemburg: 800 22 957
•Norge: 800 11 268 • Portugal: 800 833 011 • Sverige: 020 795 467
Oakley GMBH: Germany,Austria and Poland: [phone]
Oakley Japan: 0120 009 146
Oakley México: 52) 55 59503643
Oakley South Pacific (Australia): 1 800 637 001
Oakley South Pacific (New Zealand): 0800 696 255
Oakley UK: 01462 475400 Eire customers: 00 353 4439557

HOLESHOT 3-HAND
La innovación tecnológica se convierte en arte con Oakley Holeshot, un invento que
introduce el deporte en nuestras vidas. Este verdadero reloj suizo combina la
autenticidad del diseño Oakley con la durabilidad del acero inoxidable 316L y el
refinamiento de un cristal de zafiro puro.
La correa de Unobtainium® flexible es cómoda de llevar todo el día. La pantalla con
la fecha se puede ver de un vistazo y el fósforo luminoso del minutero y del horario
mejora la visibilidad cuando hay poca luz. Tiene una resistencia al agua de 10 bar,
equivalente a la presión a una profundidad de 100 m.
14 HOLESHOT 3-HAND INSTRUCTIONS MANUAL

AJUSTE DE FECHA Y HORA
La corona se puede extraer hasta dos posiciones indicadas por un click para
ajustar la fecha y la hora.
Para ajustar la fecha y la hora por primera vez (o para reajustar la fecha y la hora
después de cambiar la pila), haga lo siguiente:
PARA AJUSTAR LA HORA
1. Tire de la corona hasta la posición del primer
click (a).
2. Gire la corona hasta que aparezca la fecha
del día de ayer.
3. Tire de la corona hasta la posición del
segundo click (b).
4. Gire las manecillas hacia delante hasta
que aparezca la fecha de hoy, luego
continúe hacia delate hasta situarlas en la
fecha actual. Si la hora actual es por la
tarde o tarde / noche, mueva la manecilla
horaria alrededor de la esfera hasta pasar
las 12:00 del mediodía.
5. Presione la corona de nuevo hacia dentro.
Para ajustar al segundo exacto, espere
hasta que el segundero alcance “60” antes
de tirar de la corona hacia fuera. Ajuste la
hora y luego espere hasta alcanzar el
segundo exacto antes de volver a
presionar la corona hacia dentro.
HOLESHOT 3-HAND MANUAL DE INSTRUCCIONES 15
AB
Segundero
Fecha
Corona

16 HOLESHOT 3-HAND MANUAL DE INSTRUCCIONES
PARA AJUSTAR LA FECHA Y HORA EN OCASIONES POSTERIORES, UTILICE
LOS SIGUIENTES PROCEDIMIENTOS ABREVIADOS
PARA AJUSTAR LA HORA
1. Tire de la corona hasta la posición del segundo click (b).
2. Gire la corona hasta alcanzar la hora correcta.
3. Presione la corona de nuevo hacia dentro.
PARA AJUSTAR LA FECHA
1. Tire de la corona hasta la posición del
primer click (a).
2. Gire la corona hasta alcanzar la fecha
correcta. Si la hora actual está entre las
21:00 y la medianoche, ajuste la fecha al
día siguiente. (Esto es necesario para
asegurarse de que la pantalla de la fecha
cambia normalmente a medianoche en vez
de hacerlo a las 12:00 del mediodía.)
3. Presione la corona de nuevo hacia dentro.
AB
Fecha
Corona

HOLESHOT 3-HAND MANUAL DE INSTRUCCIONES 17
MODO DE AHORRO DE ENERGÍA
Cuando no esté utilizando el reloj, podrá prolongar la duración de la pila tirando
de la corona hasta alcanzar la posición del segundo click. Esto detendrá las
manecillas y reducirá el consumo de energía.

18 HOLESHOT 3-HAND MANUAL DE INSTRUCCIONES
SUSTITUCIÓN DE LA PILA
La pila miniatura que alimenta el reloj está diseñada para durar
aproximadamente 46 meses. No obstante, debido a que la pila es insertada en
fábrica para pruebas exhaustivas de funcionamiento, su duración real, una vez en
posesión del usuario, podría ser menor.
La sustitución de la pila sólo puede ser llevada a cabo por un distribuidor
autorizado de relojes Oakley. Cualquier intento de abrir la caja del reloj por
personas ajenas a los profesionales de un Servicio Técnico autorizado de Oakley
invalidará la garantía del producto.
Desde dentro de los Estados Unidos, llame a la Sede Central de Oakley para todo
el mundo al 1-800-403-7449 para encontrar un distribuidor autorizado de relojes
Oakley o el servicio Técnico más cercano. Los clientes de fuera de Estados Unidos
deberán dirigirse a su distribuidor local autorizado de relojes Oakley o visitar el
sitio web de Oakley en www.oakley.com para averiguar el número del distribuidor
de Oakley más cercano.

LIMPIEZA
La falta de limpieza de la caja y la correa podría causar lesiones cutáneas. Utilice
un paño suave y limpio para la humedad adherida a la caja o a la correa.
HOLESHOT 3-HAND MANUAL DE INSTRUCCIONES 19
