Oki C5150n User manual

© 2004 Oki Data Americas, Inc. 58368501
Install the Tray
1. Unpack the tray and remove the
shipping materials.
2. Turn off the printer and unplug the
power cord.
3. Remove the interface cable.
4. Note the location of the pins (1),
connector (2) and tray opening (3).
5. Lower the printer onto the auxiliary
tray, aligning the printer with the
tray and lowering the holes/plug in
the bottom of the printer onto the
pins/connector on the tray.
6. Reattach the interface cable.
7. Plug in the power cord and turn on
the printer.
8. Print out the Menu Map.
a. Press +one or more times until
INFORMATION MENU appears
on the display.
b. Press ENTER twice.
The MenuMap prints.
9. Look for TRAY2 in the
information at the top of the first
page of the MenuMap and under
the MEDIA MENU listing. If it
isn’t there, check to be sure that the
connection between the printer and
Tray 2 is secure, then reprint and
recheck the MenuMap.
10. Check the MEDIA MENU
settings shown on the MenuMap
and make any needed changes for
•TRAY2PAPERSIZE
• TRAY2 MEDIATYPE
• TRAY2 MEDIAWEIGHT
to match the print media you will
normally use in Tray 2. (If you need
help with this, see “How to Make
Changes in the Menus” in your
on-line User’s Guide, or refer to
“Changing Default Media Weight
Settings” in your Handy Reference
Guide.)
Load Paper
1. Pull out the tray.
2. Fan the paper
3. Position the paper guides in the
tray.
4. Load paper (up to 530 sheets,
20-lb. US Bond), keeping the stack
below the full line (1).
5. Push the tray back into the printer.
BACK ENTER
OLN INE
CANCEL
MENU
C5150/C5200/C5400/C5400n
2nd Paper Tray
Oki 42158511 Second Paper Tray
Installation Instructions
(continued on back)

Activate the Tray in
the Printer Driver
Windows®
PCL Driver (C5400, C5400n)
1. Click Start →Settings →Printers
[Printers and Faxes for XP].
The Printers (Printers and Faxes)
dialog box opens.
2. Right click the PCL printer icon,
then click Properties
3. Click the Device Option(s) tab.
4. For Available Tray, select 2.
5. Click OK, then close the Printers
(Printers and Faxes) dialog box.
Postscript Emulation Driver
(C5400n)
1. Click Start →Settings →Printers
[Printers and Faxes for XP].
The Printers (Printers and Faxes)
dialog box opens.
2. Right click the Postscript
emulation printer icon, then click
Properties.
3. Next:
–Windows XP, 2000 and NT 4.0:
click the Device Settings tab.
–Windows Me and 98: click the
Device Options tab.
4. Then:
–Windows XP, 2000, NT 4.0 and
Me: under Installable Options,
click Available Tray and select 2.
–Windows 98: under Change
setting for Available Tray, select
2 (1 Optional Tray).
5. Click OK, then close the Printers
(Printers and Faxes) dialog box.
Hiper-C Driver (C5150, C5200)
1. Click Start →Settings →Printers
[Printers and Faxes for XP].
The Printers (Printers and Faxes)
dialog box opens.
2. Right click the printer icon, then
click Properties.
3. Next:
–Windows XP, 2000 and NT 4.0:
click the Device Option(s) tab.
–Windows Me and 98: click the
Printer Properties tab, then click
the Device Option tab.
4. For Available Tray, select 2.
5. Click OK, then close the Printers
(Printers and Faxes) dialog box.
Macintosh®
OS 8.x and 9.x (C5400n)
1. Activate Chooser from the Apple
menu.
2. Select LaserWriter 8.
3. Click Printer →Setup.
4. Click Configure.
5. Change the Available Tray setting
to 2 (1 Optional Tray).
6. Click OK twice.
7. Close Chooser.
OS X to X.1 (C5400n)
No activation is required.
OS X.2 (C5400n)
1. Activate Print Center from Local
Hard Drive →Applications →
Utilities →Print Center.
2. Highlight the printer name and
select from the menu Printers →
Show Info.
3. Click the Available Tray
drop-down menu and select 2 (1
Optional Tray).
4. Click Apply Changes and exit to
the desktop.
