Olimpia splendid DOLCECLIMA AIR PRO Specification sheet

DOLCECLIMA
AIR PRO
EN
INSTRUCTION FOR USE AND MAINTENANCE
IT
ISTRUZIONI PER USO E MANUTENZIONE
ES
INSTRUCCIONES PARA EL USO Y EL MANTENIMIENTO

WARNINGS
1. The appliance contains R410 gas.
2. Thisappliancecanbeusedby children aged from8 years and aboveand person with reducedphysical, sensory
or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play
with the appliance. Cleaning and user maintenance shall not be made by children without supervision. (be
applicable for the European Countries).
3. This appliance is not intended for use by persons (including childern) with reduced physical, sensory or mental
capabilities or lack of experience and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety. (be applicable for other countries
except the European Countries).
4. If the power cable is damaged, it must be replaced by the manufacturer or by its technical support service or
by similarly qualied personnel, to prevent any risk to the user.
5. To prevent any electrocution risk, it is essential to disconnect the plug from the power socket before performing
any maintenance operation on the appliance.
6. For the correct operation of the appliance, observe the minimum distances and the indications written in this
manual (see gure 1).
7. For the correct electrical connection of the appliance, follow the indications in paragraph 2.5.
EN
ADVERTENCIAS
1. El aparato contiene gas R410.
2. El aparato puede utilizarse por niños con una edad no inferior a los 8 años y por personas con reducidas
capacidades físicas, sensoriales o mentales, o sin experiencia ni el necesario conocimiento, siempre y cuando
bajo supervisión o después de que las mismas hayan recibido instrucciones relativas al uso seguro del
aparato y a la comprensión de los peligros inherentes. Los niños no deben jugar con el aparato. La limpieza
y el mantenimiento que deben efectuarse por el usuario no deben efectuarse por niños sin supervisión
(aplicable para los países de la Unión Europea).
3. El aparato puede utilizarse por personas (incluso niños) con reducidas capacidades físicas, sensoriales o
mentales, o sin experiencia ni el necesario conocimiento, siempre y cuando bajo supervisión o después de
que las mismas hayan recibido instrucciones relativas al uso seguro del aparato por una persona responsable
de su seguridad (sólo aplicable para los países fuera de la Unión Europea).
4 En caso de deterioro del cable de alimentación, debe ser sustituido por el fabricante, por el servicio de
asistencia técnica o por una persona con cualicación similar, para prevenir cualquier riesgo.
5. Para prevenir cualquier riesgo de electrocución, es indispensable desconectar el enchufe de la toma de
corriente antes de que se efectúe cualquiera operación de mantenimiento en el aparato.
6. Para el correcto funcionamiento del aparato, respete las distancias mínimas y las indicaciones indicadas en
este manual (vea gura 1).
7. Para la correcta conexión eléctrica del aparato, siga las indicaciones en el párrafo 2.5.
ES

AVVERTENZE
1. L’apparecchio contiene gas R410.
2. L’apparecchio può essere utilizzato da bambini di età non inferiore a 8 anni e da persone con ridotte capacità
siche, sensoriali o mentali, o prive di esperienza o della necessaria conoscenza, purché sotto sorveglianza
oppure dopoche lestesseabbiano ricevutoistruzioni relativeall’uso sicurodell’apparecchioe allacomprensione
dei pericoli ad esso inerenti. I bambini non devono giocare con l’apparecchio. La pulizia e la manutenzione
destinata ad essere effettuata dall’utilizzatore non deve essere effettuata da bambini senza sorveglianza
(applicabile per i paesi dell’Unione Europea).
3. L’apparecchio può essere utilizzato da persone (inclusi i bambini) con ridotte capacità siche, sensoriali o
mentali, o prive di esperienza o della necessaria conoscenza, purché sotto sorveglianza oppure dopo che le
stesse abbiano ricevuto istruzioni relative all’uso sicuro dell’apparecchio da una persona responsabile per
la loro sicurezza (applicabile solo per i paesi fuori dall’Unione Europea).
4. Se il cavo di alimentazione è danneggiato, esso deve essere sostituito dal costruttore o dal suo servizio
assistenza tecnica o comunque da una persona con qualica similare, in modo da prevenire ogni rischio.
5. Per prevenire ogni rischio di folgorazione è indispensabile scollegare la spina dalla presa di corrente prima
di effettuare ogni operazione di manutenzione sull’apparecchio.
6. Per il corretto funzionamento dell’apparecchio, rispettare le distanze minime e le indicazioni riportate nel
presente manuale (vedere gura 1)
7. Per il corretto collegamento elettrico dell’apparecchio, seguire le indicazioni riportate nel paragrafo 2.5.
IT

14
4
3
6
1
2
7
8
5
9
12
13
10
11
min.
30cm
min.
30cm
20
20
min.
70cm
1
3
5
2
4

min. 2m
min. 2m
2
1
3
3
2
36
4
4
6
8
10
7
9
11

4
88
9
4
8
9
5
5
ø127mm
min 300 mm
max 1200 mm
min 300 mm
max 1200 mm
ø127mm
12 13
ø6mm
1
a b d
c
h
g
f
e
i
7
7
7
10
10
7a
7
1
7
7a
14
15

27
27a
27
27
27 27a
27
27a
27
18
20
22
23
19
21

30
~8m
32
32a
30
32
28
28
32
32a
24
28
26
25
29
27

32
35
35
30 31
15
27
27
27a
32

DOLCECLIMA AIR PRO
ENGLISH
EN - 1
MAIN INDEX
0 -WARNINGS ................................................................................................................................ 3
0.1 - GENERAL INFORMATION .............................................................................................................3
0.2 - SYMBOLS.......................................................................................................................................3
0.2.1 - Editorial pictograms.........................................................................................................................3
0.3 - GENERAL WARNINGS...................................................................................................................5
0.4 - PROPER USE.................................................................................................................................9
0.5 - HAZARDOUS ZONES ....................................................................................................................9
1 -DESCRIPTION OF THE APPLIANCE ..................................................................................... 10
1.1 - LIST OF THE COMPONENTS SUPPLIED (FIG.5).......................................................................10
1.2 - IDENTIFICATION OF THE MAIN COMPONENTS (FIG.A) ..........................................................10
INFORMATION RESERVED FOR THE “INSTALLATION TECHNICIAN”
2 - INSTALLATION ....................................................................................................................... 11
2.1 - HOW TO TRANSPORT THE CONDITIONER .............................................................................. 11
2.2 - WARNINGS................................................................................................................................... 11
2.3 - MOBILE INSTALLATION...............................................................................................................12
2.4 - FIXED INSTALLATION..................................................................................................................12
2.5 - ELECTRICAL CONNECTION .......................................................................................................12
2.6 - DRAINAGE....................................................................................................................................13
  2.6.a-Useasdehumidier.......................................................................................................................13
2.6.b - Use as heat pump .........................................................................................................................13
(only for the suitable version) ........................................................................................................13
SECTION FOR THE TECHNICIAN AND USER
3 - USE OF THE APPLIANCE...................................................................................................... 14
3.1 - CONTROL PANEL SYMBOLS AND KEYS (Fig.B) .......................................................................14
3.2 - REMOTE CONTROL KEYS (Fig. C)............................................................................................15
3.3 - USE OF THE REMOTE CONTROL..............................................................................................16
3.3.a - Insertion of batteries......................................................................................................................16
3.3.b - Replacement of batteries ..............................................................................................................16
3.3.c - Location of the remote control.......................................................................................................17
3.4 - USE OF THE APPLIANCE............................................................................................................17
3.4.a Preliminary operations...................................................................................................................17
3.4.b Appliance switching on/off .............................................................................................................18
3.5 - AUTO MODE (Automatic) .............................................................................................................18
3.6 - COOLING MODE (COOL) ............................................................................................................18
3.7 - TURBO COOLING MODE ............................................................................................................18
3.8 - DEHUMIDIFICATION MODE (DRY) .............................................................................................19
3.9 - VENTILATION MODE (FAN).........................................................................................................19
3.10 - HEATING MODE (HEAT) ..............................................................................................................19
(only for version with heat pump) .................................................................................................19
3.11 - TIMER MODE ...............................................................................................................................20
3.11.a Programmed switching on .............................................................................................................20
3.11.b Programmed switching off .............................................................................................................20
3.12 - OTHER FUNCTIONS....................................................................................................................21
3.12.a SILENT function ...........................................................................................................................21
3.12.b SLEEP function ............................................................................................................................21

ENGLISH
EN - 2
DISPOSAL
This symbol on the product or its packaging indicates that the appliance cannot be
treated as normal domestic trash, but must be handed in at a collection point for
recycling electric and electronic appliances.
Your contribution to the correct disposal of this product protects the environment
and the health of your fellow men. Health and the environment are endangered by
incorrect disposal.
Further information about the recycling of this product can be obtained from your
local town hall, your refuse collection service, or in the store at which you bought the
product.
This regulation is valid only in EU member states.
3.12.c FOLLOW ME function ..................................................................................................................21
3.12.d Setting the unit of measurement of temperature..........................................................................22
3.12.eDirectingtheairow.....................................................................................................................22
3.12.f Short Cut function.........................................................................................................................22
3.12.g Auto-Restart .................................................................................................................................22
4 - MAINTENANCE AND CLEANING .......................................................................................... 22
4.1 - CLEANING....................................................................................................................................23
4.1.a - Cleaning the appliance and the remote control.............................................................................23
4.1.b-Airltersmaintenance...................................................................................................................23
4.1.c-Cleaningtheairlter .....................................................................................................................23
4.1.d-Cleaningthesuctionlter..............................................................................................................23
4.1.e - Recommendations for energy saving............................................................................................24
4.2 - MAINTENANCE ............................................................................................................................24
4.2.a - Discharging condensation.............................................................................................................24
4.2.b - Error codes....................................................................................................................................25
5 - TECHNICAL DATA .................................................................................................................. 25
6 - LIMITED WARRANTY USA..................................................................................................... 25
7 - WIRING DIAGRAM.................................................................................................................. 26
8 - INCONVENIENCES AND POSSIBLE REMEDIES ................................................................. 27

DOLCECLIMA AIR PRO
ENGLISH
EN - 3
0 - WARNINGS
0.1 - GENERAL INFORMATION
First of all, we would like to thank you for choosing our appliance.
0.2 - SYMBOLS
The pictograms in the next chapter provide the necessary information for correct, safe
use of the machine in a rapid, unmistakable way.
0.2.1 - Editorial pictograms
Service
Refersto situations inwhich you should inform theSERVICE departmentin the company:
CUSTOMER TECHNICAL SERVICE.
Index
Paragraphs marked with this symbol contain very important information and
recommendations, particularly as regards safety.
Failure to comply with them may result in:
- danger of injury to the operators
- loss of the warranty
- refusal of liability by the manufacturer.
Raised hand
Refers to actions that absolutely must not be performed.
DANGER OF HIGH VOLTAGE
Signals to the personnel that the operation described could cause electrocution if not
performed according to the safety rules.
Index
MAIN INDEX
The main index of this manual
is given on page “EN-1”
ILLUSTRATIONS
The illustrations are grouped on the initial pages of the manual

ENGLISH
EN - 4
GENERIC DANGER
It informs the personnel concerned that if the operation is not carried out in
compliance with the safety regulations, it presents the risk of suffering physical
damage.
DANGER DUE TO HEAT
It informs the personnel concerned that if the operation is not carried out in
compliance with the safety regulations, it presents the risk of burns due to contact
with components at very high temperatures.
DO NOT COVER
Indicates to the personnel concerned, that it is prohibited to cover the appliance,
to prevent over-heating.
ATTENTION
 • Indicates that this document must be read carefully before installing and/or
using the appliance.
 • Indicatesthattheassistancepersonnelmusthandletheappliancefollowing
the installation manual.
ATTENTION
 • Indicatesthattheremaybeadditionalinformationinattachedmanuals.
 • Indicatesthatinformationisavailableintheusermanualorintheinstallation
manual.
ATTENTION
Indicates that the assistance personnel must handle the appliance following the
installation manual.

DOLCECLIMA AIR PRO
ENGLISH
EN - 5
0.3 - GENERAL WARNINGS
WHEN USING ELECTRICAL EQUIPMENT,
BASIC SAFETY PRECAUTIONS MUST ALWAYS BE FOLLOWED IN ORDER
TO REDUCE RISKS OF FIRE, ELECTRIC SHOCKS
AND INJURY, INCLUDING THE FOLLOWING:
To prevent possible damages to the compressor, each start is delayed by 3
minutes with respect to the last switching off.
1. This document is restricted in use to the terms of the law and may not be
copied or transferred to third parties without the express authorization of
the manufacturer, OLIMPIA SPLENDID.
Our machines are subject to change and some parts may appear different
from the ones shown here, without this affecting the text of the manual in
any way.
2. Read this manual carefully before performing any operation (installation,
maintenance, use) and follow the instructions contained in each chapter.
3. Keep the manual carefully for future reference.
4. After removing the packaging, check that the appliance is in perfect
condition. The packaging materials must not be left within reach of children
as they can be dangerous.
5. THE MANUFACTURER IS NOT RESPONSIBLE FOR DAMAGES TO PERSONS
OR PROPERTY CAUSED BY FAILURE TO FOLLOW THE INSTRUCTIONS IN
THIS MANUAL.
6. The manufacturer reserves the right to make any changes it deems
advisable to its models, although the essential features described in this
manual remain the same.
7. The maintenance of equipment for conditioning such as this one may result
dangerous since inside this appliance a refrigerant gas under pressure and
live electrical components are present.
For this reason, possible maintenance interventions (with the exception of
lters cleaning) must be performed exclusively by authorized and qualied
personnel.
8. Failing to comply with the instructions contained in this manual, and using
the unit with temperatures exceeding the permissible temperature range
will invalidate the warranty.
9. Routine maintenance of the lters and general external cleaning can be
done by the user as these operations are not difcult or dangerous.

ENGLISH
EN - 6
10. During assembly and at each maintenance operation, it is necessary to
respect the precautions indicated in this manual and on the labels located
inside or on the appliance, as well as to take all the precautions suggested
by common sense and by the Safety Regulations in force in the country of
installation.
11. In case of replacement of parts, use only original OLIMPIA SPLENDID parts.
12. If the unit is unused for a long period, or no-one uses the climate-controlled
room, it is recommended to disconnect the electric power supply in order
to prevent accidents.
13. Do not use liquid or corrosive detergents to clean the unit, do not spray
water or other liquids onto the unit, since they could damage the plastic
components or even cause electric shocks.
14. Do not wet the indoor unit and the remote control.
Short circuits or res may occur.
15. In case of functioning anomalies (for example: abnormal noise, bad smell,
smoke, abnormal increase in temperature, electrical dispersions, etc.),
immediately switch off the appliance and disconnect the plug from the
power socket.
For repair work contact solely the technical service centres authorised by
the manufacturer and ask for original spare parts to be used. Failure to do
this can affect the safety of the appliance.
16. Do not let the air conditioner run for a long time when the humidity is very
high and a door or a windows is left open.
Moisture may condense and wet or damage furniture.
17. Do not disconnect the power plug during functioning.
Fire or electrical shocks hazard.
18. Do not place heavy or hot objects on top of the appliance.
19. Before electrically connecting the appliance, make sure the plate data
correspond to those of the distribution network. The power socket must
be equipped with a Ground System. The plate is located on the sides of the
appliance.
20. Install the appliance according to the manufacturer’s instructions. An
incorrect installation can cause damage to people, animals or property for
which the manufacturer accepts no responsibility.
21. If the appliance’s plug is incompatible with the socket, have the socket
replaced with a suitable one by a qualied technician, who must ascertain
that the section of the socket cables is compatible with the power absorbed
by the appliance. We do not recommend using adaptors and/or extension
cables. If they cannot be avoided, however, they must comply with current
safety regulations and their ampacity (A) must not be below the maximum
ampacity of the appliance.

DOLCECLIMA AIR PRO
ENGLISH
EN - 7
22. This appliance is not intended to be run via an external timer or with a
separate remote control system.
23. Always and only use the appliance in a vertical position.
24. Do not obstruct the air inlet and outlet grids in any manner.
25. Do not insert extraneous items in the air inlet and outlet grids as this will
create the risk of electrical shocks, re or damages to the appliance.
26. Do not use the appliance:
- with wet or damp hands;
- barefoot.
27. Do not pull the power cable or the appliance itself to remove the plug from
the socket.
28. Do not use this product under direct sunlight or near a heat source such as
a stove, heater or radiator (Fig.3).
29. Do not use the appliance near gas equipment (Fig.3).
30. Always place the appliance on a stable, plane and levelled surface.
31. Leave at least 30cm of free space on both sides and behind the appliance
and leave at least 30cm of free space above it (Fig.1).
32. Do not place the appliance near a power socket (Fig.4).
33. The socket must be easily accessible so that the plug can be removed
easily in an emergency.
34. Do not handle the plug with wet hands.
35. Do not excessively bend, twist, pull or damage the power cord.
36. Do not run the cord under carpeting, throw rugs or runners etc. Arrange
cord away from trafc areas so that it will not be tripped over.
37. Unplug the cord when unit is not in use for an extended period of time and/
or when no one is home.
38. Do not use the appliance in particularly moist environments (bathroom,
kitchen, etc.).
39. Do not use the appliance outdoors or on wet surfaces. Avoid dropping
liquids on the appliance. Do not use the appliance near sinks and taps.
40. Do not immerse the appliance in water or in other liquids.

ENGLISH
EN - 8
41. Clean the appliance with a damp cloth; do not use abrasive products or
materials. See the appropriate paragraph for the lters cleaning.
42. The most common cause of overheating is dust or lint deposit in the
appliance. Regularly remove these accumulations by disconnecting the
appliance from the power socket and vacuuming the grids.
43. Do not use the appliance in environments subject to signicant temperature
changes as condensation could form inside the appliance itself.
44. Install the appliance at at least 2 meters from other electronic devices (TV,
radio, computer, dvd player, etc.) in order to avoid disturbances (Fig.6).
45. Do not use the appliance if insecticide gas has just been sprayed in the
room or in the presence of burning incenses, chemical vapours or oily
residues.
46. Do not use the appliance if the lters are not positioned correctly.
47. Disassembly, repair or reconversion performed by an unauthorized person
could cause heavy damages and will cancel the manufacturer warranty.
48. Do not use the appliance in case of malfunctioning or faults, if the cord or
plug are damaged, or if it has been dropped or damaged in any manner.
Turn the appliance off, disconnect the plug from the socket and let it be
checked by professionally qualied personnel.
49. Neither disassemble nor modify the appliance.
50. Repairing the appliance by yourself is extremely dangerous.
51. If you no longer wish to use this appliance, it must be made inoperative
by cutting the power supply cable after removing the plug from the power
socket. Hazardous parts of the appliance must be rendered harmless,
especially as there is a risk of children playing with it.
52. Do not use tools different from those recommended by the manufacturer
for the defrosting process and for the appliance cleaning.
53. The appliance is equipped with a thermal protector which preserves the
circuit board in case of over-temperature. If this safety device intervenes,
disconnect the plug from the power socket and wait for the appliance to
completely cool down (at least 20÷30 minutes) and then reconnect the plug
to the power socket and restart the appliance.
If the appliance doesn’t restart, disconnect the plug from the power socket
and contact an Assistance Centre.
54. Do not vent R-410A into atmosphere: R-410A is a uorinated greenhouse
gas, covered by Kyoto Protocol, with a Global Warming Potential (GWP) =
2088.
55. This product contains R-410A refrigerant with O.D.P. = 0 (Ozone Depletion
Potential).

DOLCECLIMA AIR PRO
ENGLISH
EN - 9
0.4 - PROPER USE
• The air conditioner must be used exclusively to produce warm* or cold air or
to dehumidify air (upon choice) with the only purpose to make the environment
temperature comfortable.
• This appliance is only intended for a domestic use or similar.
• An improper use of the appliance with possible damages caused to people,
things or animals releases OLIMPIA SPLENDID from any responsibility.
0.5 - HAZARDOUS ZONES
• The climate controllers must not be installed in environments with the
presence of inammable gases, explosive gases, in very humid environments
(laundries, greenhouses, etc.), or in places with other machines that generate
a strong heat source, in proximity of a sources of salt water or sulphurous
water.
• DO NOT use gas, gasoline or other inammable liquids near to the climate
controller.
• Only use supplied components (see paragraph 1.1). The use of non-standard
parts may cause water leaks, electric shocks, res and injuries or damages
to things.
This product must be used exclusively according to the specications
indicated in this manual. Use different to that specied, could cause serious
injuries.
THE MANUFACTURER IS NOT LIABLE FOR INJURY/DAMAGE TO
PERSONS/OBJECTS DERIVING FROM FAILURE TO COMPLY WITH THE
REGULATIONS CONTAINED IN THIS MANUAL.
* Only for version with heat pump

212223
24
25
26
26
27
28
29
30
31
32
33
34
35
36
A
ENGLISH
EN - 10
1 - DESCRIPTION OF THE APPLIANCE
1.1 - LIST OF THE COMPONENTS SUPPLIED (Fig.5)
The appliance is packaged singularly in a cardboard packaging.
The packaging can be transported by hand by two operators or loaded on a forklift.
Store the packaging singularly; do not stack it.
1. Flexible hose for air expulsion (cooling and
automatic mode)
2. Terminalforexiblehosemachineside
3. Terminalforexiblehoseforxed/slider
installation
4. SLIDERfor installationon sliding/ rollerwindow
5. Locking bracket + screws for window locking
6. Terminal for slider / window installation
7. Flangeforxedinstallation
8. Seal for SLIDER installation
9. Seal for SLIDER installation
10. Plugsforfixedinstallationflange
11. Remote control
12. Condensation discharge pipe
(dehumidificationmodeonly)
13. Terminal adapter for condensation discharge pipe
14. Manual
1.2 - IDENTIFICATION OF THE MAIN COMPONENTS (Fig.A)
21. Control panel
22. Air outlet grille
23. Flap
24. IR remote control receiver
25. Wheels
26. Handel
27. Airltergrille
27a.Airlter
28. Condensation drain cap (for use as
dehumidier)
29. Air inlet grille
30. Extractableairlter
31. Hole for plug housing
32. Cap for condensation emptying (in case of
transport, maintenance or excessive accu-
mulation of water)
33. Cable winder
34. Power supply cable
35. Condensation drain cap (only for version
with heat pump)
36. Air outlet grille
