6 Standard Photoelectric Sensors
Specifications
Item Through-beam Retroreflective Diffuse reflective
E3FZ-T / E3FR-T E3FZ-R / E3FR-R E3FZ-D / E3FR-D
Sensing distance 15 m 4 m [100 mm] 1 m (white paper 300x300 mm)
Spot diameter –
Standard sensing object Opaque: 12 mm dia .min Opaque: 75 mm dia. min –
Differential travel – 20% max. of sensing distance
max.
Black/white error –
Directional angle Emitter and Reciever: 3° to 15° Sensor: 3° to 10°, Reflector: 30° –
Light source (wave length) Infrared LED (870 nm) Red LED (660 nm) Infrared LED (860 nm)
Power supply voltage 10 to 30 VDC, including 10% ripple(p-p)
Current consumption 45mA max.
(Emitter: 25mA max.,
Receiver; 20 mA max. )
25 mA max.
Control output Load power supply voltage; 30 VDC max., Load current; 100 mA max.(Residual voltage; 2 V max.),
Light-on/Dark-on selectable by wire,
E3F@-6@: NPN open-collector output
E3F@-8@: PNP open-collector output
Protective circuits Power supply reverse polarity
protection, output short-circuit
protection, and reversed output
polarity protection
Power supply reverse polarity protection,
output short-circuit protection, mutual interference prevention and
reversed output polarity protection
Response time Operate and reset; 1 ms max.
Sensitivity adjustment – One-turn adjuster
Ambient illumination
(receiver side)
Incandescent lamp; 3000 lx max., Sunlight 10000 lx max.
Ambient temperature Operating; -25 to +55°C, Storage; -40 to +70°C (with no icing or condensation)
Ambient humidity Operating; 35 to 85% RH, Storage; 35 to 95% RH (with no condensation)
Insulation resistance 20MΩmin. at 500 VDC
Dielectric resistance 1000 VAC at 50/60 Hz for 1 min
Vibration resistance Destruction; 10 to 55 Hz, 1.5 mm double amplitude for 2 hours, each in X, Y and Z directions
Shock resistance Destruction; 500 m/s2, 3times, each in X, Y and Z directions
Degree of protection *1
*1. The IP69k test according to DIN 40 050 part 9 is intended to simulate high pressure/steam cleaning. During the test 14-16 l/min water
at 80°C is sprayed onto the sensor from different angles with 8000-10000 kPa. The sensor may not suffer any damaging effects from
high pressure water in appearance and functionality.
IEC 60529 IP67, IP69K after DIN 40050-9
Connection method Pre-wired cable (standard length 2 m), Standard M12 connector
Indicator Operation indicator: yellow, stability indicator: green
(Emitter has only power supply indicator; green)
Weight
(packed state)
Pre-wired approx. 120 g approx. 60 g
Standard
connector
approx. 40 g approx. 20 g
Material Case ABS
Cover lens
Plate window
PMMA
Accessories Instruction sheet, 2x M18 nuts, snap mounting tool (E3FZ only).
