Distance settable Photoelectric Sensor F3C-AA42-1
F3C-AA42-3J
Product specifications subject to change without notice Datenblatt f3c-aa42-3j/ 01.12.98
1
/ 8
Stable Detection Background-Suppression-Type
• Background influences are eliminated by a unique optical system for setting the detection distance
• Small black-/white-error
• Independant against ambient light
• Sensing distance mechanically adjustable:
BGS setting distance: 150... 900 mm
Detecting distance: 0 -750 mm
• Small housing-case specially designed for conveyer-application (only 8
mm of thickness on the top of the housing)
• Nearly no blind-zone by using additional receiver
• Easy BGS-adjustment by 6-turn-knob
• Sensitivity adjustment for near side detector
• Stability function indication by blinking LED
• Integrated jamming control unit (Only F3C-AA42-3J)
• Confirms to relevant EN/IEC standards, CE
Example for sensing characteristics (detection
area) in conveyer application and description of
setting the minimum and maximum
Background Suppression (BGS) function

Distance settable Photoelectric Sensor F3C-AA42-1
F3C-AA42-3J
Product specifications subject to change without notice Datenblatt f3c-aa42-3j/ 01.12.98
2
/ 8
Specifications
Item F3C-AA42-1 / F3C-AA42-3J
LED for emitter Infrared LED (wavelength 880 nm)
Sensitivity adjustment for BGS 6-turn endless adjustor
Sensitivity adjustment for near side detector
Typical adjustment range 1-turn potentiometer
0 ... 200 mm (Kod.-Gry./90 % refl.)
Connecting method/cable length
(Only F3C-AA42-3J)
(Only F3C-AA42-3J)
Prewired
Power supply (M12 plug) / 30 cm (4 x 0,34 mm²)
Neighbg. sens. (M12 socket) / 150 cm (4 x 0,34 mm²)
Valve output (without socket) / 200 cm (2 x 0,35 mm²)
Output configuration PNP
Control output
(Only F3C-AA42-3J)
Dark-on
Jamming contol output/input via M12 moulded
plug/socket, prewired valve control output
Circuit protection Load short-circuit protection and mutual
interference suppression
LED stability-/function indication Permanent light = Object detected/stable function
Blinking light = Object detected/instable function
Materials Case: ABS plastic
Lenses: Acrylic, PMMA
Weight 60g (F3C-AA42-1) / 180 g (F3C-AA42-3J)
Attachment Screwdriver for adjustment, instruction manual
Ratings/Characteristics
Item F3C-AA42-1 / F3C-AA42-3J
Power supply voltage 10 to 30 VDC; ripple 10 % max.
Current consumption 40 mA max.
Settable distance for background suppression 150... 900 mm
(Kod. -Gray-Cd., 90 % refl., 200 x 200 mm)
Detecting distance (recommended) 0 ... 750 mm
(Kodak-Gray-Cd., 90 % refl., 200 x 200 mm)
Hysteresis BGS-receiver: Max. 2 % of adjusted distance
Energetic receiver: Max. 20 % of adjusted distance
Reflectivity (Black-/white-error) max. 10 % of detection distance (Smax. 750 mm)
Spot size 40 mm diameter at 750 mm detection distance
Response time max. 10 ms for both operation and release
Control/Valve output current (Only F3C-AA42-3J) 150 mA max. at 30 VDC (voltage drop max. 2,0V)
Jamming supply current (Only F3C-AA42-3J) 5 A max. at 30 VDC (max. 30 sensor may be
connected for jamming control)
Ambient illumination Incandescent lamp: Illumination on optical spot:
max.5.000 lx
Sunlight: Illumination on optical spot: max. 5.000 lx
Fluorescent lamps: max. 5.000 lx
Ambient temperature Operating: -5°C to +55°C (no icing)
Insulation resistance 20 MΩmin. (at 500 VDC)
Dielectric strength 1.000 VAC, 50/60 Hz for 1min.
Vibration resistance 10 ... 55 Hz, amplitude = +/-1,5 mm (or 300 m/s²) for
2 hrs. each in X, Y and Z-direction
Shock resistance Pulse shape: half-sine, peak acceleration:
300 m /s², duration of pulse: 18 ms
Enclosure rating IP 54

Distance settable Photoelectric Sensor F3C-AA42-1
F3C-AA42-3J
Product specifications subject to change without notice Datenblatt f3c-aa42-3j/ 01.12.98
3
/ 8
Engineering Data
Operating range ( Sn = 20 cm / 45 cm / 60 cm / 75 cm)
Reflecting object: Kodak-Gray-Card / 90 % reflectivity / 200 mm x 200 mm
F3C- Spotdiameter via detection distance
0
0,5
1
1,5
2
2,5
3
3,5
4
4,5
0 1020304050607080
Detection dist./cm
Spot-diameter/cm
F3C - Operating characteristics
-1,5
-1
-0,5
0
0,5
1
1,5
0 10203040506070
Sensing dist./cm
-Y / +Y (cm)
S
n = 20 cm
S
n = 45 cm
S
n = 60 cm Sn = 75 cm

Distance settable Photoelectric Sensor F3C-AA42-1
F3C-AA42-3J
Product specifications subject to change without notice Datenblatt f3c-aa42-3j/ 01.12.98
4
/ 8
Angle characteristics of F3C-BGS-Conveyor Sensor
1. Vertical detection
2. Horizontal detection
Reflecting object: Kodak-Gray-Card / 90 % reflectivity / 200 mm x 200 mm
Vertical
F
3C - Vertical detection angle
-2,0
-1,5
-1,0
-0,5
0,0
0,5
1,0
1,5
2,0
2,5
3,0
3,5
-40 -30 -20 -10
0
10
2
03040
Angle / °
%-ual change of sens. dist.
F3C - Horizontal detection angle
0,0
0,5
1,0
1,5
2,0
2,5
3,0
-40 -30 -20
-
10
0
10
2
03040
A
ngle/°
%-ual change of sens.-dist.

Distance settable Photoelectric Sensor F3C-AA42-1
F3C-AA42-3J
Product specifications subject to change without notice Datenblatt f3c-aa42-3j/ 01.12.98
5
/ 8
Black-/White-Error
Nomenclature
B/W-Error related to Kod.-Gray-Cd. 90 %
0
10
20
30
40
50
60
70
80
15cm 30cm 45cm 60cm 75cm
BGS Setting distance
Sensing distance / cm
18% 6% 3% 90%
Pos. Functional description
10 IR-emitting LED
20 Near-side detector
30 Optical module
40 Black coloured adjustment knob for setting distance (6-turns)
50 LED light-/stability indicator
60 Yellow knob for near-side adjustment (1-turn)
70 M12-plug for power supply
80 M12-socket for neighbouring sensor (Only 3J-type))
90 Valve cable (Only 3J-type)

Distance settable Photoelectric Sensor F3C-AA42-1
F3C-AA42-3J
Product specifications subject to change without notice Datenblatt f3c-aa42-3j/ 01.12.98
6
/ 8
Operation
Output
configura-
tion
Mode
switch Output transistor Output circuit
F3C-AA42-1 F3C-AA42-3J
PNP
Dark-
ON
ON when
light is not
received
F3C-AA42-1
Photoelectric
Sensor
1 / + Vcc
4 / ..... NC
2 / Output
3 / .... 0 V
bn
bk
wt
bl
bn
bk
wt
bl
1
4
2
3
F3C-AA42-3J
Photoelectric
Sensor
1 / ... + Vcc
4 / Release
2 / .. Output
3 / ....... 0 V
bn
bk
wt
bl
+ Vcc ...
Release
Input .....
0 V ........
0 V
+ Valve
bn (bk-ye)
bl (bk)
Timing chart
Light is not received
(red) OFF
OFF
Release
• Jamming control connections and principal circuit (Only F3C-AA42-3J)
F3C-AA42-3J Plug for power supply Socket for neighbouring sensor Cable for valve
No. 1/bn + Vcc (10 ... 30 V/DC) + Vcc (10 ... 30 V/DC) - / -
No. 2/wt Control output Control Input - / -
No. 3/bl 0 V 0 V - / -
No. 4/bk Release Input Release Ouput - / -
bn (bk) - / - - / - + Valve output
bl (bk-ye) - / - - / - 0V/Valve
0V
Release
+Valve/bn(bk)
-Valve/bl(bk-ye)
1
2
4
3
bn
bk
wt
bl
bn
bk
wt
bl
1
4
2
3
Sensor 1Sensor 2... Sensor 30
+ VCC
+Valve/bn(bk)
-Valve/bl(bk-ye)
1
2
4
3
bn
bk
wt
bl
bn
bk
wt
bl
1
4
2
3
+Valve/bn(bk)
-Valve/bl(bk-ye)
1
2
4
3
bn
bk
wt
bl
bn
bk
wt
bl
1
4
2
3
Control ->
0V
Release
+ VCC
Control ->
0V
+ VCC
Release
Output

Distance settable Photoelectric Sensor F3C-AA42-1
F3C-AA42-3J
Product specifications subject to change without notice Datenblatt f3c-aa42-3j/ 01.12.98
7
/ 8
• Installation and adjustment
1. Switch off power supply
2. Connect sensor 1 to the power supply station. Make sure that the correct voltage value is
adjusted. Max. 30 sensors can be connected together. The power supply is linked from one
switch to the other via M12-connector.
3. Fix sensor, by using an adequate mounting bracket, in the middle of between the conveyer rolls
and twist the case slighty backward (2-5°)
4. Turn black-coloured distance adjustment knob (Pos. 40) and yellow coloured screw (Pos. 60) for
near-side-detection carefully counterclockwise until minimum position is reached
5. Switch on power supply
6. At first adjust the sensing distance by turning the black knob, that at least 5 % of the switching
distance value can be guaranteed related to the reflecting background (check by using a Kodak
Gray Card with 90 % reflectivity)
7. Activate near-side detector by turning the yellow-coloured knob (Pos. 60) clockwise - the red LED
should not blink and should light permanently when the object is detected. Otherwise increase
sensitivity by turning the yellow knob clockwise
8. When object is removed, the red LED should not light or blink
Recommended adjustment
The adjusted sensing-distance of the near-side detector should not exceed the BGS-Setting-
distance.
Correct operation
The moving direction of the sensor or object should be
preferably along the optical axis of the light beam. Lateral
approach is also possible. Movement from the top to the
bottom or opposite can case malfunction and should be
avoided.
In case of installing two sensors facing each other, the
optical axis should be moved to prevent any mutual
interference.
Avoid influences of any strong ambient light sources that
can decrease the sensitivity of the sensor or cause instable working condition.
Connections and precautions
If the input/output lines of the photoelectric sensor are placed in the same conduit or duct as power
lines or high-voltage lines, the photoelectric sensor could be induced to malfunction, or even be
damaged by electrical noise. Either separate the wiring or use shielded lines as input/output lines to
the photoelectric sensor.
The cord connected to the Sensor can be extended up to 50 m provided that the diameter of each
wire is 0,3 mm²minimum.
Movement of object
Sensing distance
adjustor
LED (light received)
L
ight beam

Distance settable Photoelectric Sensor F3C-AA42-1
F3C-AA42-3J
Product specifications subject to change without notice Datenblatt f3c-aa42-3j/ 01.12.98
8
/ 8
Maintenance
Normally the F3C doesn’t need any maintenance. Only the optical surfaces should be cleaned from
time to time by using a soft cloth.
Startup Operation
A maximum of 300 ms is required from the time power is turned on until F3C is able to detect
objects. If power is supplied to the loads and the F3C from different sources, turn on power to the
F3C first.
Water resistivity
Do not use F3C in water, in rain or outdoors.
Accessories
Standard mounting bracket for easy installation.
Ordering number E39-L40
