Oneida Air Systems 2005c3HP User manual

3HP
High Vacuum
Dust Collector
Oneida Air Systems, Inc. 1001 West Fayette St., Syracuse, N.Y. 13204
Phone [phone] 476 5151 Fax [phone] www.oneida air.com
Owners Manual

Thank You for Choosing an Oneida Air Systems Product!
OAS manufactures and sells dust collection equipment only. Our qualified technicians and
sales staff are available 7:30am - 6:00pm ST Mon. - Thur. and 7:30am - 5:00pm ST Fri. to
answer any questions concerning OAS products and dust collection. Call for ductwork design
and ductwork quotes, including system pricing and shipping cost.
Table of Contents
Page
Read the entire Owners Manual efore installing or operating system!
I.
II.
III.
IV.
V.
VI.
VII.
VIII.
IX.
X.
XI.
XII.
XIII.
XIV.
2
3
4
5
6
7 - 8
8
9
10
11
12
13
14
15
System Start-Up Information
Direct Drive Configurations
General Specifications & Fan Performance Curve
Dimensions
Stand Assembly
General Assembly Instructions
Fan / Blower Maintenance
Filter Maintenance
Wire Diagram
Accessories
Troubleshooting
Fire Hazards - Read Before Installing System
Terms and Conditions
Fan Motor Maintenance
1
Proudly
Made in
the U.S.A.
O.A.S. 2005
c
3HP High Vacuum Owners Manual

O.A.S. 2005
c
3HP High Vacuum Owners Manual
I. System Start-Up Information
1. Read the installation and maintenance instructions as well as the recommended
safety practices in this manual.
2. Install Ductwork completely:
A.) Seal ductwork with silicone sealant or duct tape.
B.) Have Dust Bin in place and sealed.
3. Have licensed electrician wire Fan / Blower according to wire diagram in this
owners manual.
4. Have licensed electrician check current draw on motor with all gates open. Current
draw should not exceed maximum motor amperage. (OAS is not responsible for
destroyed motors.)
Caution
The Dust Collector & Fan/Blower is heavy. Handling and
installation should always be performed by experienced and
trained personnel who have experience with rotary equipment.
In addition to the following instructional manual, care should
be taken to ensure compliance with specific safety
requirements mandated by federal, state and local codes.
arning
Do not operate Fan / Blower without connecting ductwork.
Never operate Fan/Blower without belt and shaft guard in
place. Keep clear of exhaust. Keep hands and objects clear
of inlet and outlet.
arning
Check amperage draw during operation with all blast gates
open. Make certain amperage is not outside operating limit
indicated on motor plate! If amperage is too high shut down
immediately! (See Troubleshooting section.)
2

II. 3hp High Vacuum Configuration
O.A.S. 2005
c
3HP High Vacuum Owners Manual
3
Pleated
Cartridge
Filters
(Do not remove
fabric straps
from cartridge.)
Removable
Dust
Container
Removable
55 Gal. Metal
Chip / Dust Bin
3hp Integral
Fan Blower
Angle Iron
Stand
Flex Hose
Outlet
Inlet
lbow
Square-to-Round
Cone
Cyclone

O.A.S. 2005
c
3HP High Vacuum Owners Manual
4
III. General Specifications & Fan Performance Curves
Physical and Electrical Data for 3 hp High Vacuum Unit.
3hp - 1342 cfm @ 3.5 SP
System Performance
Height w/ 55 Gal. Drum: 110 1/8
Footprint: 56 x 34
Fan Wheel diameter: 15 Backward Incline design
Cyclone Inlet: 6
System Dimensions
T FC 60 Hz Motor - Single Phase
Insulation Class: F4
Voltage: 230
Amperage: 14.5
Made in U.S.A.
Integral Fan Blower - 3hp
1 Pleated Cartridge - 130 sq. ft.
Spun-Bonded polyester BIA ZH1 / 487 test - Rated C
Captures 99.99% of test material over 20 microns
Captures 99.9% of test material between 0.2 - 2.0 microns @ 11fpm
External Cartridge Filter
55 Gal. Steel Drums
Large dust bins available
Dust Bin
Magnetic Motor Starter
Filter fficiency Gauge
Included
Static pressure and volume together determine a fans performance. Several factors, such as layout of
ductwork and diameter of openings, can affect a fans performance.
13
11
9
7
5
3
0
0 200 400 600 800 1000 1200 1400 1600
CFM
Static Pressure at Cyclone Inlet
System Performance Curve
12.5 10.9
9.1
6.8
3.5
1342
1045
842
618
0
3.5
6.8
9.1
10.9
12.5
CFM Static @
Cyclone Inlet

IV. Dimensions
O.A.S. 2005
c
3HP High Vacuum Owners Manual
5
22
6 1/8
4
28 1/2
7 1/4
36
75 3/4
111 7/8
12
62
30 7/8
10.031
I.D.
7.64
I.D.
1.25
Flange
For Minimum Mounting Heights
with 55 gal. drum
26 1/8 O.D. of
Mounting Ring
Bolt Holes
24 7/8
18
56
Outlet Size
56
7 3/4
14 1/8 18
74 1/8
17 3/16
12 1/8
5 1/16
For Twin 55 Gal. Barrel Measurements
See Page 9.

O.A.S. 2005
c
3HP High Vacuum Owners Manual
V. Angle Iron Stand
Bolt together the stand using the cross bars and 3/8 x 1 bolts. Note: the cross bar on
the cyclone stand goes in the back so that the dust bin can slide out.
55 Gal.
30 7/8
28 7/8
75 7/8
6

O.A.S. 2005
c
3HP High Vacuum Owners Manual
Cyclone
Barrel
Cyclone
Cone
2.
3.
2. Clamp the fan housing and cyclone barrel to
the cyclone cone with the clamp ring. Note: the
fan / blower and the cyclone barrel are very
heavy. The system will be top heavy. One method
is to lay the stand down, then bolt the cyclone
with the fan / blower to the stand. The iron ring
will slide into stand.
3. Tip the fan housing and cone upright. The
system is very top heavy.
4. Bolt the elbow-cartridge housing to the fan
housing outlet (rectangular). Clamp the cartridge
to the flat plate. Clamp the dust bins to the
bottom of the cartridge filters.
Continued on next page.
7
Pleated
Cartridge
Filters
(Do not remove
fabric straps
from cartridge.)
Removable
Dust
Container
5hp Integral
Fan Blower
Angle Iron
Stand
Outlet
Inlet
lbow
Square-to-Round
Cone
Cyclone
Clamp
Ring
VI. Assembly Instructions
Cyclone
Barrel
Air Inlet
Fan / Blower
1.
1. Orient the blower housing to match the stand
configuration and the desired angle for the cyclone inlet.
Bolt the fan / blower to the cyclone barrel using the
hardware taped on the motor.
Bolts are already welded on Fan/Blower unit. Put strip
of the neoprene gasket around the cyclone barrel behind
the bolt holes. Then put bolts through holes in barrel.
Put flat washer on bolt. then lock washer, then hex nut.
Cyclone Inlet and Fan / Blower are independent.
Filters can be to the right or left of the unit.
Air
Outlet
Neoprene
Gasket
Material
16 ea. 3/8 Flat Washers, Lock Washers and Hex Nuts
Fan / Blower is shipped strapped to Cyclone Barrel. It is
NOT attached to the unit. You must olt them together.
Follow the instructions elow.
One bolt hole
on each side.
Do NOT use
hook on motor
to lift unit.

VI. Assembly Instructions (Cont.)
O.A.S. 2005
c
3HP High Vacuum Owners Manual
5. Attach flex hose to bottom of collector and to lid of
dust bin. Securely fasten hose clamps. There must be
an air tight seal between the collector and dust bin.
6. Make sure the dust bin lid sits securely and the rubber
gasket on the bin lid is in place on the barrel. Maintain
an air tight seal between cyclone and dust bin to prevent
motor from overloading.
IMPORTANT:
Do not operate the collector until the dust bin is in place and
the connector is air tight or motor damage could result!
Stay clear of fan exhaust while collector is operating.
Collector
Hose Clamp
Hose Clamp
Flex Hose
Dust Bin
4.
7. Attach the ductwork from the woodworking machines to the inlet of the collector.
8. Bolt Angle Iron Stand to the floor. Unit is top heavy!
VII. Fan / Blower Maintenance
A high pressure blower requires a certain amount of resistance which will prevent motor
over amperage.
Make sure power source matches wire voltage configurations.
Check set screw and key in fan wheel, make sure fan wheel is secure. Fan blower should
not vibrate.
1. Electrical - Failure to follow instructions and safe electrical procedures could result in serious injury or death.
Disconnect all power and discharge all capacitors before servicing. Install and ground per local and national
codes. Consult a licensed electrician with questions or if repairs are required.
lectrical Connections -
A.) All wiring, fusing, and grounding must comply with National lectrical Codes and local codes.
B.) To determine proper rotation and voltage connections, refer to the Wire Diagram of this manual.
C.) Use the proper size of line current protection and motor controls as required by the National lectrical Code
and local codes. Recommended use is 125% of full load amps as shown on the nameplate for motors with
40 degrees Celsius ambient and a service factor over 1.0. Recommended use is 115% of full load amps as
shown on the nameplate for all other motors. Do not use protection with larger capacities than recommended.
Three phase motors must have all three phases protected.
2. Cleanliness - Keep both the interior and exterior of the motor free from dirt, water, oil, and grease.
3. Safety - Motors should be installed, protected and fused in accordance with latest issue of National lectrical
Code, N MA Standard Publication No. MG 2 and local codes. Rotating parts such as pulleys, coupling, external
fans, and unusual shaft extensions should be permanently guarded. Keep hands and clothing away from
moving parts. lectrical repairs should be made by trained, qualified personnel only.
4. Service - Notice - If lubrication instructions are shown on the motor nameplate, they will supercede this
general instruction.
Warning: Rotating Fan Blades. Keep Objects Clear of Inlet and Outlet.
8

VIII. Filter Maintenance
3HP High Pressure Owners Manual O.A.S. 2005
c
External Filter Cartridge Cleaning Intervals
Caution Fine dust collected in filter is hazardous
to your health! Do not breathe!
When unit is turned off, use compressed air to blow dust off from
exterior of filter. Hold nozzle at least 8 away from filter pleats*.
Do not remove bottom dust pan before or during the blow-off
process! Let dust settle into dust pan. Unclip and dump out dust.
Filter removal is not required. You can also run your fingers
around the filter pleats to knock material down.
* WARNING: A close, direct blast with the compressed air nozzle
too close to filter, may damage filter media. Always wear safety
glasses while blowing off filter.
Do not
remove
fabric
straps.
9
55 Gal. 55 Gal.
3hp High Vac Stand
(Twin 55 Gal. Barrels)
STZ050255
12
8
44
16
24
32 1/2
10
17 1/2
36
3 6 3
22
60
8
4
6 1/8
10 x 10 x 10
Splitter
22
