Oneida Air Systems Smart Dust Collector User manual

Appearance may vary.
9_11
ZBM000033
Powerful Economical MadeintheUSA
Oneida Air Systems, Inc. was founded in 1993 to bring cost effective, state-of-the-art
dust collection systems and material handling ductwork to woodworking shops. OAS
designsandmanufacturesindustrialgradedustcollectionsystemsthatcreateaprac-
tical, safe and healthy work place environment.
1.800.732.4065 www.oneida-air.com
1001 W. Fayette St., Syracuse, NY 13204
U.S. Patent #7,550,021 B2
U.S. Patent #D604,464 S
Smart System Pat. Pend.
Flame Guard Pat. Pend.
Dust Sentry Pat. Pend.
Awarded to our 2hp
Smart Dust Collector
American Woodworker
Dec. - Jan. 2011

1
Smart Dust Collector Owner’s Manual © O.A.S. 2010
Thank You for Choosing an Oneida Air Systems Product!
OAS manufactures and sells dust collection equipment only. Our qualified technicians and sales staff are available
8:30am - 5:00pm EST Mon. - Fri. to answer any questions concerning OAS products and dust collection. Call for duct-
work design and ductwork quotes, including system pricing and shipping cost.
Read the entire Owner’s Manual before installing or operating system!
Proudly Made
in the USA
I.
II.
III.
IV.
V.
VI.
VII.
VIII.
IX.
X.
2
3
4, 5
6
7 - 11
12
13
14
15
16
System Start-Up Information
System Specifications
Parts List
Dimensions
System Assembly
Cleaning External Filter
Fan Motor Maintenance
Troubleshooting
Fire Hazards - Read Before Installing System
Terms and Conditions
TableofContents Page

I.SystemStart-UpInformation
2
1. Read the installation and maintenance instructions as well as the recommended safety practices in this
manual
2. Install ductwork completely before operating collector:
A.) Seal ductwork with silicone sealant or duct tape.
B.) Have dust bin in place and sealed.
Caution
The Direct Drive Fan / Blower makes the system top heavy! Use extreme care when setting the unit
up! It is recommended that at least two people lift the system up.
Warning
Do not operate Fan / Blower unless Fan Housing is attached to Cyclone body and Dust Drum is in
place. Dust Drum and Cyclone must be in place and sealed or motor will overheat!
Warning
Check amperage draw on motor with all gates open. Current draw should not exceed maximum
motor amperage as stated on motor plate. (OAS is not responsible for damage to motors caused by
improper installation, wiring or failure to follow these directions.)
Smart Dust Collector Owner’s Manual © O.A.S. 2010

3
Smart Dust Collector Owner’s Manual © O.A.S. 2010
SmartDustCollector
New!
Smart Dust Collector - 2hp
Smart Dust Collector - 3hp
XXS020100
XXS030100
Part # Description
TM
System
Performance
Motor
Filter Media
Dust Bin
Included
35 Gallon Heavy Steel Drum with casters.
Drops down for easy removal and dumps in
seconds.
New Patent Pending Flame GuardArrestor
Bin Level Indicator
Remote Control
Silencer
Dust Bag Liner Hold-Down
Filter Grounding Wire
GE Certified (H-12) HEPAMedia. MERV 16+
rated. See specs on website.
*Oneida reserves the right to change or modify specs and system appearance without notice.
Actual system appearance may vary.
Max. Static Pressure - 24” (3hp) / 23” (2hp) .
2 to 3 times the suction of standard collectors.
2 or 3hp Motor / 220V Power Supply
Made in the USA
HEPA
Media and
Pat. Pend.
Flame Guard
Arrestor
The Oneida Smart Dust Collector™ is a unique breakthrough in portable dust
collection technology. The Smart System has an infinitely variable fan curve
which means that it can automatically adjust and maximize air volume and
suction to a wide range of tools, hose sizes, and even undersized suction
ports.
For 4 - 6” dust ports, it provides much more air volume and pressure (up to
26” of H2O), 2 to 3 times that of a standard dust collector. For woodworking
tools with 3” or smaller dust ports, you’ll get high suction similar to a shop
vacuum. The stunning result is a lot more air at the woodworking tool and
much less fugitive dust escaping to the shop air. 99% of the waste is pre-
separated with a high efficiency cyclone and clean air is returned to the shop
through GE® Certified (H-12) HEPAmedia (MERV 16+ rated).
The Smart Collector is equipped with patent pending Flame Guard arrestor
for fire safety. It also features the patent pending Dust Sentry, a drum overfill
sensor with a strobe light, so you know when it’s time to empty the drum.
Designed to overcome the friction in Flex Hose!
High suction for small diameter ports, similar to
a shop vacuum!
For New
Product
Innovation
Static Pressure
(Suction) (In.-H2O)
Static Pressure
(Suction) (In.-H2O)
CFM
CFM
Length
Length
Hose Dia.
Hose Dia.
6”
5”
4”
3”
2.5”
6”
5”
4”
3”
2.5”
10’
10’
10’
10’
10’
10’
10’
10’
10’
10’
3.0
9.5
14.0
17.5
23.0
3.0
9.5
13.5
17.0
20.0
1040
766
634
470
385
930
725
525
410
265
Actual 3hp System Performance w/ Flex Hose Connected
Actual 2hp System Performance w/ Flex Hose Connected
The first portable dust collector that automatically changes
its performance in real-time... constantly adapting to the
demands you put on it.
International
Woodworking
Fair
The Challengers Distinguished Achievement
Award® is internationally recognized as one
of the industry’s highest honors in recognizing
advancements in technology, process or signifi-
cant contributions to environmental improve-
ment in the woodworking industry. It challenges
IWF exhibiting companies to develop forward-
thinking technology in machinery, materials,
supplies, manufacturing techniques, services
and safety. www.iwfatlanta.com
Awarded to our 2hp
Smart Dust Collector
American Woodworker
Dec. - Jan. 2011
Appearance may vary.

4Smart Dust Collector Owner’s Manual © O.A.S. 2010
1. BHX001802 - Motor Cowling (1)
2. RMF000060 - Foam Filter Block (Installed at Factory)
3. BXI020118 / BXI030118 - 2 or 3hp Motor Assembly (1)
4. BHX001801 - Fan Housing (1)
6. SCX001801A - Cyclone (1)
7. AXB999110 - Drum Level Indicator (1)
8. SEX350600 - Drum Lid (1)
9. ARS990001 - Lid Clamp guards (4)
10. SES350000 - 35 Gal. Steel Drum (1)
11. AFL990001 - Drum Latches (4)
12. RHC000000 - Drum Casters (3)
13. RFG020000 - Leg Gusset (3)
14. VRM990425 - Foam Leg Grip (1)
15. VRT010049 - Front Leg (1)
16. FXX001801 - Front Drum Lid Bracket (1)
17. RHC000005 - Front Leg Caster (1)
18. BSS131000 - Silencer (1)
19. BSC130000 Drop In Foam Filter Silencer (1)
20. FCS133695HF - 13 x 36 HEPA Media Filter
21. AFJ051602 - J Hooks (4)
22. AFT000001 - Thumb Nuts (6)
23. FPZ000013 - 13” Plastic Dust Bin (1)
24. Plastic Axle Protector (1)
25. RSR330625 - Threaded Rear Axle (1)
26. YSS516185 - Threaded 18” Filter Rod (2)
26B. YSS516010 - Threaded 10” Filter Rod (1)
27. VRH051618 - Filter Rod Coupler (2)
28. RBX000000 - Filter Bottom Bracket (1)
29. VRT010047 - Rear Leg (2)
30. STP000003 - Handle (2)
30A. VRM425075 - Flat Handle Grip (2)
31. FXX001802 - Rear Drum Lid Bracket (2)
32. AFS125016 - Rear Leg Threaded Tube Connect (2)
33. AFB038001 - Eye Bolt (2)
34. VRW100200 - 10” Wheels (2)
35. RSP092069P - Drum Liner Holder (1)
36. FGA000000 - Filter Ground Wire (1)
37. WBP000000 - Control Box / Strobe Light (1)
IV.PartsList
OAFW180000 - Flat Washer USS 5/16” (28)
PRGZ025050 - Gasket 1/2” (25 ft.)
QRGZ516100 - Gasket 1” (7 ft.)
UAFT155175 - Whiz Lock Nut 5/16” (6)
RPBH000600 - Plastic Push Pin (6)
NAFW025000 - Flat Washer USS 1/4” (41)
MAFT901032 - Nylock Nut 10 - 32 (8)
LAFT900058 - Nylock Nut 5/8 - 11 (2)
JAFT010916 - U Spring Nut #10 x 9/16” (4)
IAFT000005 - Whiz Lock Nut 1/4” (31)
GAFS103238 - Screw 10 - 32 x 3/8” Pan Head (8)
FAFS015800 - Bolt 1/4” - 20 x 1/2” Hex Head (16)
EAFS015920 - Bolt 1/4” - 20 x 3/4” Hex Head (6)
DAFS010075 - #10 Sheet Metal Screw 3/4” (4)
B AFB025175 - Carriage Bolt 1/4”- 20 x 1.75” (9)
Hardware List
AASC000125 - Caulk Single (1)
HAFB155175 - Bolt 5/16”-18 x 3/4” (14)
S AFT058011 - Jam Nut - 5/8” 11 (2) - 1/4” high
TAFT050811 - Hex Nut - 5/8” 11 (2) - 1/2” high
C AFB155155 - Flange Bolt 5/16”- 18 x 1” H GR5 (8)

5
Smart Dust Collector Owner’s Manual © O.A.S. 2010
1
2
36
3
4
18
26B
26
26
29
29 30
31
32 32
33
34
* 35 - Drum Liner Hold Down (Not Shown)
33
30A
27
27
19
20
21
22
28
22
22
23 24
25
(4)
(4)
(4)
(4)
(6)
(6)
(12)
(8)
(7)
6
13
14
15
17
16
8
9
10
11
1212 12
11 11
9
9
7
37
13 13
M
G
M
G
M
G
H
C
C
O
O
O
B
I
B
F
II I
FF
EE
I
I
IN
N
N
NA
P
P
P
P
EE
BB
BB
A
I
I
Motor Plate
Gasket
Material
Gasket
Material
Fan
Housing
Washer
Bolt
All hardware may not be shown because of
perspective. Check parts list for complete
amounts.
Figure 1
II
NN
NN
H
UU
H
OO
30
30A

6Smart Dust Collector Owner’s Manual © O.A.S. 2010
III.Dimensions
77”
26”
55”
6” Dia. Inlet
35 Gal.
Steel
Drum
17”
35”
19”
48”
3”
6”
33”
Drum will lift off floor in use and
when unit is being moved. Fits through a 36” door.
SystemsElectricalData
200 to 240 volt single phase 20 amps. A 30 amp circuit breaker is recommended.
(Similar to a clothes dryer.)
Appearance
may vary.

7
Smart Dust Collector Owner’s Manual © O.A.S. 2010
V.SystemAssembly
It is always good to have a qualified helper to
assist you during assembly. Some parts are
heavy and awkward to deal with.
Drum Assembly
Drum Lid Assembly
1. Apply silicone sealant to each hole be-
fore attaching the casters to assure air tightness.
This is very important when using a collection
bag because even a tiny air leak will interfere
with the bag working.
4. Apply 1” gasket around rim of the under-
side of drum lid. [Figure 3]
Carefully align the ends so there is no gap be-
tween them and it makes a tight seal against
itself.
2. Attach the casters to the bottom of the
drum with included 1/4 - 20 hex head bolts,
making sure the bolt heads are on the inside of
the drum. [Figure 1]
3. Attach the dust drum latches with the in-
cluded 10 - 32 pan head screws with the screw
head on the outside of the drum and the nyloc
nuts on the inside of the dust drum. Apply
silicone sealant to each hole here also to pre-
vent air leaks. [Figure 2]
5. Apply a continuous line of silicone seal-
ant [Figure 4] to the cone flange before bolting
in place with (6)1/4-20 x 3/4” bolts,(12) washers
and (6)nuts.
[Figure 5] Make sure the 2 holes for the front
leg brace are lined up with the cone inlet and
tabs for the back leg braces will be pointed down
when cone is right-side up. [Figure 6}
Figure 1. Bottom of dust drum with caster wheels.
Figure 2. Dust drum latches and hardware.
Figure 4.
Apply silicone
to bottom of
flange.
FI
GM
EIN
Bolt
Washer
Cone
Lid
Washer
Nut
Fig. 3
Figure 6. Posi-
tion drum lid so
the two holes
that attach to
front leg brace
are below the
cyclone inlet.
Figure 6. Tabs
for the back leg
braces will be
pointed down.
Figure 5. Check lid alignment
(see Figure 6)

8Smart Dust Collector Owner’s Manual © O.A.S. 2010
7. Set Cone and lid on top of drum on a
smooth, level floor, apply (4) plastic lid clamp
guards. Do not clamp lid. [Figure 9A]
Fig. 8 Fig. 8A
Figure 9A
Dust Drum Lid
Clamp
Guard
6. Cut 3 wooden blocks from a 2 x 4 that are
2 1/2” high. [Figure 8]
Place blocks under drum so it lifts it and will not
roll. [Figure 8A]
Leg Assembly
8. Slide foam hand grip onto top of bent front
leg. You may need some lubricant such as a
little soapy water to help. [Figure 10]
11. Slide plastic cover on cord holder and
attach to front of gussett with 1.75” carriage
bolts on front leg and either back leg as shown.
You may have to carefully pull holder wider to
fit bolt in bottom hole.
[Figure 11]
10. Attach gusset
to front leg using 2”
carriage bolt / gusset
/ leg / 1/4” washer /
1/4” nut. Loosely bolt
front leg to the angle
ring on cyclone as
shown below.
7A - Insert
Black plastic
leg plugs in
top of legs
[Figure 10A]
Fig.10 Fig.10A
Fig.11
Fig.12
9. Attach front wheel and tighten nut on
caster assembly to secure. [Figures 12, 13]
Figure 12 -
Attach wheel
Figure 13 -
Tighten Nut on caster.
12. On the two straight, back legs, gently
insert the threaded inserts with a hammer in
bottom of leg, then screw in the two eyebolts all
the way in. [Figure 12]

9
Smart Dust Collector Owner’s Manual © O.A.S. 2010
15. Attach drum lid to the front and rear leg
bracket lid holders using 1/4” - 20 x 3/4” Hex
head bolts, washers and nuts. Tabs on rear leg
brackets should point up.
[Figures 13, 14]
Figure 13 - Front Figure 14 - Rear
EI N
13. Put wheel nuts between 4” - 5” from
each end of threaded axle. Next put axle
through rear leg eyebolts. Then loosely put jam
nuts on each end followed by the wheels with
hub on the inside. Finish with the 5/8” nylock
nuts flush to the ends of the axle. You will
tighten this assembly later.
14. Bolt rear leg gus-
sets loosely to cyclone as
shown.
Put on plastic axle cover after the final
tightening of the nuts
16. Tighten up all bolts on the gussets and
lid brackets while keeping the legs square.
When this is done, tighten up the wheel bolts
on the axle to their final positions.
17. Apply 1/2” gasket around outside of bolt
holes in cyclone top as shown, making sure
there is no gap where ends butt together.
Nylock
Nut Jam
Nut 5/8”
Nut Axle
Rear
Leg
Wheel
18. Place Blower housing in position so that
the filter outlet is pointed down, opposite the in-
let. Hand start eight 5/16” x 3/4” hex head bolts
with washers, then tighten securely. DO
NOT tighten to over 17 ft. lbs. of torque.
[Figure 15]
Figure 15 - Attach Blower housing
HO
Figure 17 - Apply gasket
19. Apply 1/2” wide PSA foam rubber strip
around the underside of motor plate on outside
of bolt holes. [Figures 17]
