Onespace Basics 50-LD02OK User manual

7
OneSpace Basics Desk with Drawer and USB Charging, Oak
ASSEMBLY INSTRUCTIONS
MODEL 50-LD02OK
SUPPLIER CODE: LDCZ
For fastest service on claims, requests for replacement parts,
www.comfortproducts.net/support
e-mail: [e-mail]
Keep your sales receipt as documentation of your ownership.
CUSTOMER SERVICE
or questions, please visit our website at:
OneSpace is a Trademark of Comfort Products, Inc.
™

mumixamDesktop
weight capacity
= 165 lbs.
Drawer maximum
weight capacity
= 11 lbs.
ASSEMBLYOVERVIEW
2

ITEMS ARE NOT SHOWN TO SCALE.
PARTSLIST1OF2 # DESCRIPTION SIDE 1 SIDE 2 STOCK # QTY.
#
DESCRIPTION
STOCK #
QTY.
1 Desktop 51-LD02OKDT 1
2Leg 51-LD02OKLG 2
3 Support Board 51-LD02OKSB 1
4Drawer Left 51-LD02OKDL 1
5Drawer Right 51-LD02OKDR 1
6Drawer Front 51-LD02OKDF 1
7 Drawer Bottom 51-LD02OKDBM 1
8 Drawer Back 51-LD02OKDB 1
3
9Outer Rollers
51-LD02OKDS 1 set
of 4
10 Inner Rollers
Left Right
Left Right

ITEMS ARE NOT SHOWN TO SCALE.
PARTSLIST2OF2 # DESCRIPTION SIDE 1 SIDE 2 STOCK # QTY.
#
DESCRIPTION
STOCK #
QTY.
11 Frame Board
Right 51-LD02OKFR 1
12 Frame Board
Left 51-LD02OKFL 1
13 Frame Board
Middle 51-LD02OKFM 2
4

5
EXTRA HARDWARE INCLUDED FOR YOUR CONVENIENCE. ITEMS ARE NOT SHOWN TO SCALE.
HARDWARE LIST
PART DESCRIPTION QT Y.
A Bolt 16
GM4 X 18MM 2
KScrew Driver 1
C 4
- READ THE INSTRUCTION MANUAL BEFORE ASSEMBLING.
- REMOVE ALL PIECES BEFORE BEGINNING INSTALLATION.
- OPEN THE HARDWARE AS NEEDED .
- ASSEMBLE IN AN AREA WITH PLENTY OF SPACE.
- READ EACH STEP BEFORE BEGINNING CONSTRUCTION.
- NEVER FORCE THE SCREWS OR FITTINGS.
- KEEP THIS MANUAL FOR FUTURE REFERENCE.
- TIGHTEN ALL THE SCREWS EVERY 6 MONTHS.
CLEANING AND CARE
- CLEAN SURFACES WITH A DRY OR DAMP CLOTH.
- DO NOT USE ABRASIVE CLEANERS.
- DO NOT USE A POWER DRILL.
HARDWARE KIT
STOCK # 51-LD02OKHA
D M5 x 70mm 4
B Cam
M6 x 50mm
16
E M4 x 40MM 4
F M4 x 14MM 8
H Drawer Handle 1
I USB Port 1
J Allen Wrench 1
Extra Hardware (A - G) 1 set
IF YOU ARE MISSING ANY OF THESE PARTS, OR IF
YOU HAVE A DAMAGED PART, PLEASE VISIT
WWW.COMFORTPRODUCTS.NET/SUPPORT AND
REFERENCE THE MODEL # ON THE FRONT OF
THIS MANUAL. SIMPLY COMPLETE THE INFOR-
MATION, INCLUDING THE PART YOU NEED. THE
PART WILL NORMALLY BE SHIPPED WITHIN 48
HOURS.

ASSEMBLY INSTRUCTIONS
6
STEP 1
Attach the Support Board (3) to the two Legs (2) using four M4x70mm screws (D)
STEP 2
Attach the Drawer Back (8) between the Drawer Left (4) and Drawer Right (5) boards using four M4x40mm screws (E),
and insert the Drawer Bottom (7).
E
D
2
3
6
4
5
7

ASSEMBLY INSTRUCTIONS
7
STEP 3
STEP 4
CAUTION:
Do not overtighten
cams.
C
D
Screw in four Bolts (A) into the Drawer Front (6).
6
A
B
G
H
Insert four Cams (B) into the holes provided in the Drawer Left and Right pieces. Fit the Drawer Front onto the rest of the
drawer and secure by turning the cames 180 degrees with a screwdriver. Attach the Drawer Handle (H) to the
Drawer Front using two M4x14mm screws (G).

ASSEMBLY INSTRUCTIONS
8
STEP 5
STEP 6
Attach two Right Outer Rollers (9) to the Frame Board Right (11) and Frame Board Left (12) using four screws (8).
Refer to the drawing below to properly orient the rollers.
CAUTION:
Do not overtighten
cams.
C
D
Attach the Inner Rollers (10) to the underside of the drawer using four M4x14mm screws (8).
8
8
9

ASSEMBLY INSTRUCTIONS
9
STEP 7
STEP 8
Screw in four bolts each into Frame Board Right and Frame Board Left.
A
Assemble the Right and Left Frame Boards with the two Middle Frame Boards using the cams and bolts as in Step 4.
B
13
13
12
11

ASSEMBLY INSTRUCTIONS
10
STEP 9
Place the Desktop upside down on the oor, and screw in four Bolts into the sockets provided, as shown.
Mount the now-assembled Drawer Frame from Step 8 to the Desktop, using four cams to lock it into place.
STEP 10
A
B
1

ASSEMBLY INSTRUCTIONS (50-JN1301)
11
STEP 11
Attach the Leg assembly to the desktop using four 6x50mm Screws (C).
STEP 12
C
Turn the desk right-side up, and insert the drawer.

ASSEMBLY INSTRUCTIONS
STEP 14
12
Finally, insert the USB Port into the hole provided in the Desktop.

Insert the right and left drawers into the corresponding sides of the desk by aligning the inner and outer rollers.
drawers are hitting one another, they need to be switched.
STEP 16
ASSEMBLY INSTRUCTIONS (50-JN1301)
13

•
•
•
•
13
DO NOT stand on the desk. Do not use the desk as a stepladder.
ed.
Every 6 months, check all bolts and screws to ensure they are tight.
This product is California 93120 Compliant for Formaldehyde.
Comfort Products, Inc.
122 Gayoso Avenue
Memphis, TN 38103
Comfort Products warrants this product to be free from defects in material and workmanship for one (1) year. This warranty is made by
Comfort Products only to the original end-user customer acquiring the product directly from Comfort Products’ authorized dealers
as shown by the original sales receipt. The end-user customer remedy pursuant to this warranty is limited to repair or replacement of
parts at Comfort Products’ option within a reasonable amount of time. Comfort Products reserves the right to require damaged parts
to be returned to Comfort Products upon request. Consent from Comfort Products must be obtained before any warranty work is
performed. This warranty applies under conditions of normal use and is not subject to defects caused by improper assembly or
disassembly; defects occurring after purchase due to product mo sure
to the elements; labor or assembly cost. This warranty does not cover the cost of transportation or labor. In no event shall Comfort
Products be liable in either tort or contract for any loss or direct, special, incidental, consequential or exemplary damages. This Limited
Warranty is NOT applicable to end-user customers who use Comfort Products for rental purposes. This warranty applies only to end-user
customers in the United States. All warranties are limited to the original purchaser for normal use. The weight capacity of the desktop is
165 pounds and the weight capacity of the drawers is 11 lbs. For claims or questions concerning this warranty, please visit:
www.comfortproducts.net or email us at: [email protected]
