Ops-Core MOTO VISOR User manual

CLEANING & CARE
•Spot-clean the Moto Visor with a mild detergent and water.
•Visually check the entire Moto Visor for signs of breakage.
•Clean dust and dirt by using air pressure.
Check that the Cam-Loc Handles work properly.
NOTE: IF ANY DEFECTS ARE FOUND, THE DAMAGED COMPONENTS SHOULD BE REPLACED BEFORE USE.
FOR SENTRY HELMETS
© OPS-CORE 2016 UM-1001 REV. C
MOTO VISOR
OPERATOR’S MANUAL
FASTEN CAM-LOC HANDLES
Fasten both the left and right Cam-Loc Handles to
secure the Moto Visor in place.
4
INSTALLATION PROCEDURE

ABOUT YOUR VISOR:
This manual covers the installation and basic operating
instructions for the Ops-Core Moto Visor. The Ops-Core
Moto Visor provides additional eye and face protection
from ballistic threats for the Ops-Core Sentry helmet.
With easy one-handed operation it opens and closes
with indexing increments to allow for multiple vented
positions. Installation and removal is tool-less. The
Moto Visor is designed for use in conjunction with the
Authorized Protective Eyewear List (APEL).
INTRODUCTION INSTALLATION PROCEDURE
MOTO VISOR KIT INCLUDES:
(1) Moto Visor
The Moto Visor quickly attaches to the Sentry Helmet without the use of tools.
RELOCATE NVG BUNGEES
Before the Sentry Visor can be properly installed,
any existing NVG Bungees cannot be anchored to
the bottom of the shroud. If your helmet has NVG
Bungees, relocate them to a point at the top of the
shroud as shown.
OPEN CAM-LOC HANDLES
INSERT CONNECTOR SHOES
Rotate both Cam-Loc Handles to the open position
as shown.
Align and insert the visor’s ARC Rail Connector Shoes
into the ARC Rails of your Sentry Helmet until the
visor is ush with the front edge of the helmet.
3
Cam-Loc Handle
Ballistic Lens
ARC Rail
Connector Shoe
NOTE: Be sure that the protrusion on the
ARC Rail Connector Shoes engages with the
desired rail slot. Be sure to align with the
same slot on both sides.
CONTINUE INSTRUCTIONS ON BACK
Multiple Vented Positions
