Optex Boundary Gard BX-80N Manual

CONTENTS
1. Product concept ……………………………….P2-4
2. Features / Detection area ..……………..….…P5-8
3. Installation hints ……………………………...P9-15
The BX-80N Guidebook

Early warning boundary protection
Product Concept
1. Product Concept
BX-80N is an advanced PIR
detector which is designed to
protect the immediate
perimeter of the building. It is
developed for the purpose of
“early warning” i.e. before an
intruder breaks into the
premises.
This product can only be used
for the boundary of a building.
(NOTE)
2. Do not use BX-80N when
intruder may pass by (i.e.
entrance of a building).
Use VX for such application.
1. Do not use BX-80N for
perimeter region of a property
like photobeams.
2

Unique and reliable detection area
The BX-80N creates a unique multi-layered, horizontal barrier and just
one BX-80N unit can protect a long area, because it is installed in the
center of the detection area and protects both sides.
It provides four detection areas (upper and lower areas for both sides)
and generates an alarm condition only when both upper and lower
detection areas are blocked simultaneously.
The BX-80N provides highly accurate detection even under severe
environmental conditions.
Product Concept
3

Product Concept
Enhancement of protection capabilities
When a general-purpose mechanical security system is installed,
detectors are usually located inside a building. In order to increase the
effectiveness of such a security system, Optex recommends not only
securing the inside of the building but also adding protection to the
outside areas.
By adding BX-80N, it detects intruders before entry. This invisible barrier
offers the first line of defense to a property’s boundary.
4

2. Features - to reduce false alarms in severe outdoor environmental conditions -
Both upper and lower detection areas
have to be activated to generate an
alarm condition.
This reduces false alarms,
particularly those caused by
temperature changes, light reflection
and small animals.
Size-judging function
The size judging function virtually eliminates false alarms due to small
animals.
Features
Two double-layered detection patterns
No detection
When only the lower zone
detects a moving object,
the unit is not activated.
When only the upper zone
detects a moving objects,
the unit is not activated.
When both the upper and
lower zones detect a
moving object, the unit is
activated.
No detection Detection
5

Adjustable detection length for appropriate detection area
The appropriate detection area has to be set for each installation site to prevent
false alarms.
The lower detection areas of the BX-80N is four-step variable. By setting the
appropriate detection area, the BX-80N drastically reduces false alarms as it
generates an alarm only when both upper and lower detection areas are
blocked simultaneously.
Features
12m (detection area)
8m (detection area)
5m (detection area)
2m (detection area)
ExampleDetection area pattern A
There are moving objects
(i.e. tree, bushes, etc.）
Detects the shorter range
[16m (8m single side)]
There are reflective
objects (i.e. puddle, pool,
metal plate, etc.)
No obstacle
in detection area
6

Detection area pattern C
Features
The angle of all detection areas can be adjusted horizontally by 0 to 3
degrees. If there are objects such as bay windows, troughs and so on
that are obstructing the detection area, please make concessions by
adjusting its angle to attain the appropriate area.
Both the lower detection areas of BX-80N operate individually. By setting
appropriate detection areas for each application, the BX-80N expands its
capabilities.
Detection area pattern B
The angle of all detection
areas are adjustable
horizontally 0 or 3 degrees.
7

Double Shielding
Double conductive shielding
Patented Double Conductive
Shielding Technology utilizes a
special conductive filter to cover the
element window, allowing infrared
energy to pass through, while
blocking and grounding out
unwanted light and RFI sources.
This helps reduce false alarms
caused by car headlights and more
particularly reflected sunlight.
The BX-80N uses advanced
temperature compensation to
automatically increase the
detector’s sensitivity under
high temperature conditions,
especially where the
background temperature
ranges from 35 –37 degree
C, close to that of the human
body.
Audible alarm – area check mode -
Built-in buzzer sounds an alarm while an alarm is occurring. This buzzer
can also be used to annunciate detection during area check mode.
Features
Sensitivity
Temperature compensation
sensitivity of Optex detectors
Ambient
temperature
(Ԩ）
Human body
temperature (Ԩ)
Advanced temperature compensation
8

Installation hints
3. Installation hints
Please check each item below.
Please see the back pages for supplement information.
Before installation Page Yes
1. Did you install the BX-80N at a suitable height? 10
2. Did you install the BX-80N in the immediate perimeter of
the building? 10
3. Did you install the BX-80N to the surface of a wall
accurately? 11
4. Did you install the BX-80N parallel to the ground? 11
5. Did you set the appropriate detection range? 12
6. Did you install the BX-80N so that the unit does not
receive too much direct light (i.e. sun light, car head-light,
etc.) ?
13
7. Did you install the BX-80N by preventing the lower
detection area from aiming toward reflective objects (i.e.
puddle, pool, metal plate, etc.)?
13
8. Did you install the BX-80N by preventing obstacles from
blocking the detection area (i.e. bay window, trough, etc.)? 14
9. Did you install the BX-80N by preventing moving objects
within detection area (i.e. swaying tree, bushes, etc.) 15
9

1. Installation height
2. Install the BX-80N in the immediate perimeter(boundary)
of the building
Installation height is 0.8 – 1.2m.
BX-80N is designed to be wall-
mounted centrally on a building,
covering the building perimeter.
Be sure to install the BX-80N to
the immediate perimeter of the
building.
NOTE: Do not use BX-80N for
perimeter protection like
photobeams.
Installation hints
10

3. Install the BX-80N to the surface of a wall
For proper activation,
installation on the surface has
to be accurate otherwise
detection figures will not be
parallel to the installation
surface.
4. Install the BX-80N parallel to the ground
Install detector upright, with
upper detection areas parallel
to the ground. If detector is
installed at an angle towards
the ground, operational
reliability of the detector may
be decreased.
Installation hints
11

Installation hints
5. Set the appropriate detection range
BX-80N creates a narrow
24m long detection area.
If the protection area is
shorter than 24m, the lower
detection area has to be
adjusted to allow for the ideal
detection area otherwise the
BX-80N will detect object
outside of protection area.
For this application, please
refer to “detection area
pattern A & B” of page 6 & 7.
Both the lower detection
areas of the BX-80N operate
individually. Thus the unit
allows for an appropriate
detection area to be set for
each application.
If the left and right detection
areas of protection differ, the
lower detection area has to
be adjusted otherwise the
BX-80N detects the objects
outside of protection area.
12

Installation hints
Avoid aiming the lower
detection area toward
reflective objects (puddle, pool,
metal plate, etc.).
If the reflective objects are
unavoidable, please refer to
“detection area pattern A and
B” of page 6 & 7.
6. Avoid direct light BX-80N includes Double
Conductive Shielding to
prevent false alarms caused by
light disturbances.
It is recommended that you
avoid too much light being
directed or reflected into the
BX-80’s field of view as the
light (such as strong sunlight)
causes an unstable condition
within the sensor’s view.
7. Avoid reflective objects within detection area
13

Installation hints
8. Avoid obstacles which block detection area
1. Avoid obstacles
(i.e. bay window, trough, etc.)
The angle of the detection area
can be adjusted horizontally to 3
degrees.
Please adjust the detection angle
to avoid obstacles from being
included in the detection area.
(please refer to “detection area
pattern C” of page 7.)
If obstacle objects are
unavoidable, we recommend to
use options.
2. Avoid obstacles
(i.e. tables, flowerbeds, etc.)
The angle of the lower detection
area can be adjusted in four
steps. Please set appropriate
detection area to suit the
installation site.
(please refer to “detection area
pattern A and B” of page 6 & 7.)
The BX-80N should not be installed in area’s where obstacles in
the detection area are likely to affect the proper performance of
the unit. If the use of the BX-80N is unavoidable in such
circumstances, the appropriate detection area should be set by
following either of these 2 methods:
Adjustable horizontally
0 or 3 degrees
BX-80N with
options (SP-2
spacer unit and
BA-1 multi angle
wall mount
bracket)
[ top view ]
14

Installation hints
9. Avoid moving objects within detection area
Avoid pointing detector
towards moving objects (i.e.
swaying tree, bushes, flag,
etc.).
If moving objects are
unavoidable, please refer to
“detection area pattern A &
B” of of page 6 & 7.
15
