Optex sensor User manual

5923704 DEC 2022
X-ZONE T
Read this operation manual carefully before use to ensure proper operation of this product.
Failure to read this operation manual may cause improper operation and may result in serious injury or death of a person.
The meanings of the symbols are as follows.
1. This product is a non-contact switch intended for header mount or wall mount for use on an automatic sliding door.
Do not use for any other applications.
2. When setting the sensor's detection area, make sure that there is no traffic around the installation site.
3. Before turning the power ON, check the wiring to prevent damage or malfunction of equipment connected to the product.
4. Only use the product as specified in the operation manual provided.
5. Be sure to install and adjust the sensor in accordance with the local laws and standards of the country in which the
product is installed.
6. Before leaving the installation site make sure that the product is operating properly and instruct the building
owner/operator on proper operation of the door and the product.
7. The product settings can only be changed by an installer or service engineer. When changed, the changed settings and
the date shall be registered in the maintenance logbook accompanying the door.
Detection area
The actual detection area may become smaller depending on the ambient light, the color/material of the
object or the floor as well as the entry speed of the object.
The sensor may not be activated when the entering speed of the object or a person is slower than
2"( 50 mm)/s or faster than 4'11"( 1500 mm)/s.
AIR
Mounting height : 7'3"(2.2 m)
Angle adjustment : +6°
Sensitivity : Middle
: Emitting spots
: Detection area
: Emitting spots
(can be eliminated)
Mounting height : 7'3"(2.2 m)
Vertical adjustment : +35°
Sensitivity : High
Area width : wide
Speed of detection object
: 2"( 50 mm)/s
: Detection area
A
C
B
G
H
I
0
3′3"
(1.0)
3′3"(1.0)
6′7"(2.0)
3′3"
(1.0)
6′7"
(2.0)
6′7"
(2.0)
BLUEZONE (1st row)
3rd row
DE
F
The chart shows the values at depth angle +6°.
AIR emitting area
[feet,inch(m)]
A
B
C
D
E
F
G
H
7' 3" (2.20)
3" (0.08)
10" (0.25)
1' 3" (0.39)
2' 2" (0.65)
4' 4" (1.33)
8'10" (2.70)
4" (0.10)
1' (0.31)
9'10" (3.00)
4" (0.11)
1' 1" (0.34)
1' 7" (0.48)
2' 7" (0.80)
1' 9" (0.53)
2'11" (0.89)
5' 4" (1.63) 5'11" (1.81)
8' 2" (2.50)
4" (0.09)
11" (0.28)
1' 5" (0.44)
2' 5" (0.74)
4'11" (1.51)
6' 7" (2.00)
3" (0.07)
2" (0.06) 3" (0.07) 3" (0.08)3" (0.07)2" (0.05)
9" (0.23)
1' 2" (0.35)
1'11" (0.59)
3'12" (1.21)
6' 9" (2.05) 8' 3" (2.51) 9' 2" (2.79)7' 7" (2.32)6' 1" (1.86)
I 9' 1" (2.78) 11'2" (3.40) 12'5" (3.79)
11'6" (3.50)
5" (0.12)
1' 3" (0.39)
2' (0.61)
3' 5" (1.03)
6'11" (2.11)
4" (0.09)
10'8" (3.25)
14'6" (4.42)10'4" (3.15)8' 3" (2.52)
[feet,inch(m)]
X
Mounting
surface
2nd row
Installation
a. Affix the mounting template at the desired mounting position.
(When setting the detection area close to the door, mount the sensor according to the chart below.)
b. Drill two mounting holes of ø1/8" (ø3.4 mm).
c. To pass the cable through the header, drill a wiring hole of ø5/16" (ø8 mm).
d. Remove the mounting template.
e. Remove the housing cover. Fix the sensor to the mounting surface with the two mounting screws.
X
H
Y
Sensor
Door
Header
Floor
Maximum mounting distance (Y)
X6' 7" (2.00) 7' 7" (2.30) 8' 2" (2.50 ) 9' 2" (2.80)
0 No limit
2" (0.05) 5" (0.13) 5" (0.13) 6" (0.14)
4" (0.10) 4" (0.11) 5" (0.12) 5" (0.12) 5" (0.12)
6" (0.15) 4" (0.10) 4" (0.10) 4" (0.11) 4" (0.11)
8" (0.20) -4" (0.09) 4" (0.10) 4" (0.10)
10" (0.25) 4" (0.09)
12" (0.30) - -
H
5" (0.13)
-
- -
- 4" (0.09)
[feet,inch (m)]
9'10" (3.00) 11'6" (3.50)
6" ( 0.14 )
5" ( 0.12 )
4" (
0.11 )
4" ( 0.10 )
4" ( 0.09 )
-
0
0
0
0
0
0
Make sure not to mount the sensor lower than the bottom of header.
Make sure to connect the cable correctly to the door controller before turning the power ON.
When turning the power ON or after adjusting the settings, do not enter the detection area for more
than 10 s in order to enable the presence detection.
Do not touch the dipswitches before turning the power ON, otherwise an error occurs.
1.Grey
2.Grey
3.White
4.Yellow
5.White stripe
6.Yellow stripe
7.Red (+)
8.Black (-)
Power
supply
Safety
output
Activation
output 2
1
3
4
Test
input
Wire the cable to the door controller as shown below.
12 to 24 VAC±10% / 12 to 30 VDC±10%
Opto coupler Voltage: 5 to 30 VDC
1
2
3
4
Form A relay 50 V 0.3 A Max.
Form A relay 50 V 0.3 A Max.
Manufacturer's statement
Failure to follow the instructions provided with this indication and improper handling may cause
death or serious injury.
WARNING
Failure to follow the instructions provided with this indication and improper handling may cause
injury and/or property damage.
CAUTION
Special attention is required to the section of this symbol.
NOTE
NOTE
NOTE
BLUEZONE area
When dipswitch 15 is set to " ON " , the BLUEZONE area, that provides extra safety over the threshold, is activated.
In case the BLUEZONE function is not required, set dipswitch 15 to " OFF " .
Do not set the 2nd row overlapping the threshold regardless of the setting of dipswitch 15.
BLUEZONE
(1st row)
2nd row
3rd row
BLUEZONE
(1st row)
2nd row
3rd row
Specifications
Model
Cover color
Mounting height
Detection area
Detection method
Power frequency
Power density
Depth angle adjustment
Power supply
Power consumption
Operation indicator
Output hold time
Response time
Operating temperature
Operating humidity
: X-ZONE T
: Black
: 6'7" to 11'6" (2.0 to 3.5 m)
: See Detection area
: Active infrared reflection (*1)
Microwave doppler effect
: 24.125 GHz
: < 20 dBm
: AIR area -6 to +6°
Microwave area +25 to +45°
: 12 to 24 VAC ±10% (50/60 Hz)
12 to 30 VDC ±10%
: < 2.5 W (< 4 VA at AC)
: See Operation indicator table
: Approx. 500 ms
: < 300 ms
: -31 to 131°F (-35 to +55°C)
: < 80%
Noise level
Activation output
Test input
Safety output
IP rate
Weight
Accessories
: < 70 dBA
: Form A relay
50 V 0.3 A Max.(Resistance load)
: Opto coupler
Voltage 5 to 30 VDC
Current 6 mA Max. (30 VDC)
: Form A relay
50 V 0.3 A Max.(Resistance load)
: IP54
: 9.5 oz (270 g)
: 1 Operation manual
2 Mounting screws
1 Mounting template
1 Area adjustment tool
1 Cable 9'10" (3 m)
1000 ms 1000 ms
Operation indicator table
Warm-up
Stand-by (Installation mode)
Status
Yellow blinking
Yellow
Operation indicator color
Signal saturation
Sensor failure
Slow Green blinking
Fast Green blinking
Stand-by (Operation mode)
2nd row detection
BLUEZONE (1st row) detection (*2)
3rd row detection
Microwave detection
Green
Orange
Red
Red blinking
Blue
Communication test output Turn off 500 ms (*3)
The specifications herein are subject to change without prior notice due to improvements.
*1 : Active infrared reflection has a presence detection function.
*2 : See BLUEZONE area
*3 : LED will be turned off approx. 500 ms when the sensor test output signal works well.
NOTE
1 1/2"(38)
2 3/8"(61 )
10 1/2"(267)
4 15/16"(125)
1 7/16"(36) 1 11/16"(43)
5/16"(7.5)
(1) Connector
(2) Mounting holes
(3) Operation indicator
(4) Width adjustment screws
(5) Depth angle adjustment screw
(6) Microwave sensitivity potentiometer
(7) Dipswitches
(8) Detection window
(9) Area adjustment tool
[inch (mm)]
(9)
(1)
(4) (5) (7)
(8)
(3)
(2)
(6)
Dimensions and part names
Motion/Presence detection
Microwave
Motion detection
NOTE
1. Mounting
H: Height from the floor to the bottom of the header
(The mounting height is "H+ Y".)
Y: Distance between the bottom of the header and the sensor
X: Distance between the door and the mounting surface
NOTE
CAUTION Risk of getting caught
Make sure to affix the mounting template as described in the above chart, otherwise it can be dangerous since there
may be no detection area around the threshold. Install the sensor as low as possible on the header.
Before starting the procedure, make sure that the power is turned OFF.
When passing the cable through the hole, do not tear the shield otherwise it may cause electric shock or breakdown of
the sensor.
2. Wiring
Danger of electric shock
WARNING
a. Plug the connector.
b. Supply power to the sensor. Adjust the detection area and set the dipswitches.
(See Adjustments 4. Dipswitch settings)
3. Turn ON the power
NOTE
Place the housing cover.
If wiring is to be exposed, break the knockout.
4. Mounting the housing cover
Do not use the sensor without the cover.
When using the cable knockout, install the sensor indoors or use the rain cover (separately available) otherwise electric
shock or breakdown of the sensor may occur.
WARNING Danger of electric shock
The following conditions are not suitable for sensor installation.
-Fog or exhaust emission around the door
-Wet floor
-Vibrating header or mounting surface
-Moving objects, steel plate, emergency lights or illumination in the detection area or in vicinity
-Highly reflecting floor or highly reflecting objects around the door
Do not wash, disassemble, rebuild or repair the sensor, otherwise it may cause electric shock or breakdown of the
equipment.
Danger of electric shock
WARNING

Select "N.O."/"N.C." for safety output.
The delay time between test input and
safety output is 10 ms.
Set this switch to snow if the sensor is used in
a region with snow or a lot of insects.
Test input
(
from door controller )
High
13
Low
13
65
Setting 1
65
Setting 2
65
Setting 3
65
Setting 4
2.0 to 3.0 m
21
Low
2.0 to 3.0 m
21
Middle
2.5 to 3.2 m
21
High
3.0 to 3.5 m
21
S-High
43
30 sec
43
60 sec
43
180 sec
43
600 sec
Select "N.O."/"N.C." for activation output.
Activation output
(to door controller)
Rain mode
Normal
7
Rain
7
Normal
8
Snow
8
Safety output
(to door controller)
N.O.
11
N.C.
11
OFF
10
ON
10
N.O.
12
N.C.
12
Bi
9
Uni
9
Snow mode
Direction
Immunity
Set this switch to rain if the sensor is used in
a region with a lot of rain.
When dipswitch 9 is set to "Uni", this setting
enables the door to close faster when a
person walks away from the door.
Set dipswitch 10 to "ON" when the sensor
operates by itself (Ghosting).
When dipswitch 10 is set to "ON" the actual
detection area may occur smaller.
Adjustments
When adjusting the 2nd row close to the door,
see Table 2 dipswitch 16 for the easier adjustment.
Make sure that the detection area
does not overlap with the door/header,
and there is no highly reflecting object
near the detection area otherwise
ghosting/signal saturation may occur.
Depth angle
adjustment
screw
Area adjustment tool
A
B
1. Area depth angle adjustment
NOTE
a. AIR adjustment b. Microwave adjustment
Depth angle adjustment screw for the AIR area. Depth angle adjustment screw for the microwave area.
Use the area adjustment tool (A) as shown above to
change the area depth angle.
For the easier adjustment, see Reference.
Use the area adjustment tool (B) as shown above to change
the area depth angle.
Shallow Deep
Red
Shallow Deep
Blue
ShallowDeep
ShallowDeep
[feet,inch(m)]
3′3"
(1.0)
3′3"
(1.0)
0-3′3"
(-1.0)
0
6′7" (2.0)
9′10" (3.0)
11′6" (3.5)
To adjust the AIR detection area width, use the
adjustment screws as shown in the picture below.
Width adjustment screws
Narrow
Wide
Eliminated
Eliminated
123 10 11 12
Please adjust
by using the tool (B).
a. AIR adjustment
2. Area width adjustment
Front view [feet,inch(m)]
4 9
1 12
~
~
:Wide
:Narrow
123 10 11 12
4 5 6 7 8 9
6′7"
(2.0)
0
9′10"
(3.0)
11′6"
(3.5)
0 6′7"
(2.0)
6′7"
(2.0)
3′3"
(1.0)
3′3"
(1.0)
NOTE When setting the detection area
width, make sure to turn the
adjustment screws until it clicks.
cannot be eliminated
separately, neither can .
123
10 1112
Table 2
4. Dipswitch settings
AIR settings Microwave settings Other setting
Comment
Set the sensitivity according to the mounting
height. Values below dipswitches are
reference only. Adjust the sensitivity
according to your risk assessment.
Setting
1
Function
Sensitivity
No.
2
To enable the presence detection, do not
enter the detection area for 10 s after setting
the timer.
Presence timer
3
4
When using more than one sensor close to
each other, set the frequency different for
each sensor.
Frequency
5
6
To adjust the microwave detection area width, use the narrow lens
as shown in the picture below.
b. Microwave adjustment
Adjust the microwave detection area with potentiometer.
3. Microwave sensitivity
H
L
Top view
H
L
[feet,inch(m)]
3′3"
(1.0)
6′7"
(2.0)
9′10"
(3.0)
0
9′10"
(3.0)
6′7"
(2.0)
3′3"
(1.0)
09′10"
(3.0)
6′7"
(2.0)
3′3"
(1.0)
Low High
Mounting height : 7'3" (2.2 m)
Vertical adjustment : +35°
Wide area
Narrow area
Narrow lens1. Remove screw
2. Open
2. Open
7
8
9
10
13
12
Simultaneous
output
BLUEZONE
(1st row)
OFF
15
ON
15
OFF
14
ON
14
When dipswitch 14 is set to "ON", both the
activation & safety relay outputs will operate
simultaneously regardless of detection area.
But only the safety output relay, will respond
back with a safety output when it receives a
test input.
When dipswitch 15 is set to "ON", the
BLUEZONE(1st row) is active and looks
through the threshold.
Installation mode
OFF
16
ON
16
Set dipswitch 16 to "ON" to adjust the 2nd
row. During the installation mode only the 2nd
row remains active and the operation indicator
shows Yellow. After setting the row set
dipswitch 16 "OFF".
14
15
16
11
Check the operation in the operation mode according to the chart below.
Checking
Entry
Outside of
detection area
Entry into
microwave area
Entry into
BLUEZONE(1st row)
Entry into
3rd row
Entry into
2nd row
Power
OFF
Activation
output
Safety
output
14
14
OFF
ON
OFF
ON
11
N.O.
N.C.
N.O.
N.C.
N.O.
N.C.
N.O.
N.C.
11
12
12
Status
Operation indicator
Stand-by
Green
Motion
detection
Orange
Motion/Presence
detection
Red Red blinking Blue
-
None
1. Do not wash the sensor with water.
2. Do not disassemble, rebuild or repair the sensor yourself,
otherwise electric shock may occur.
1. Always keep the detection window clean. If dirty, wipe the window with a damp cloth. (Do not use any cleaner/solvent.)
2. When the operation indicator blinks Green, contact your installer or service engineer.
3. Always contact your installer or service engineer when changing the settings.
4. When turning the power ON, always walk-test the detection area to ensure the proper operation.
5. Do not place any objects that move or emit light in the detection area. (e.g. plant, illumination, etc.)
1. Do not paint the detection window.
Inform building owner/operator of the following items
WARNING CAUTION
NOTE
Door operation Operation
indicator Possible cause Possible countermeasures
Troubleshooting
Door opens
when no one
is in the
detection area.
(Ghosting)
Unstable
Waterdrops on the detection window.
Use the rain-cover. (separately available)
Or wipe the detection window with a damp cloth.
Do not use any cleaner or solvent.
Or install in a place keeping the waterdrops off.
None Wrong power supply voltage. Set to the stated voltage.
Wrong wiring or connection failure. Check the wires and connector.
Door does not
open when a
person enters
the detection
area.
Unstable
Wrong detection area positioning. Check Adjustments 1, 2, 3.
Sensitivity is too low. Set the sensitivity higher.
Short presence timer. Set the presence timer longer.
Wrong wiring or settings. Check the wires and connector.Proper
Dirty detection window. Wipe the detection window with a damp cloth.
Do not use any cleaner or solvent.
The detection area overlaps with that
of another sensor. Check Table 2 dipswitch 5, 6.
Objects that move or emit light in the
detection area. Remove the objects.
Adjust the detection area to "Deep"(outside).
Or set dipswitch 10 to "ON".
The detection area overlaps with the
door/header.
Sensitivity is too high. Set the sensitivity lower.
Set dipswitch "7","8","9","10" to "Rain","Snow",
"Uni","ON".
Raining or snowing.
Others Set dipswitch 10 to "ON".
Wrong setting of dipswitches. Check Table 2 dipswitch 7, 8, 11. Proper
Sudden change in the detection area.
Check Table 2 dipswitch 1 to 4. If the problem
still persists, hard-reset the sensor.
(Turn the power OFF and ON again)
Proper
Door remains
open.
Wrong wiring or connection failure. Check the wires and connector.
Fast
Green
blinking
Sensitivity is too low. Set the sensitivity higher.
Dirty detection window. Wipe the detection window with a damp cloth.
Do not use any cleaner or solvent.
Contact your installer or service engineer.Sensitivity too low or sensor failure.
Installation mode is set to "ON". Set dipswitch 16 to "OFF".Yellow
Proper
operation. Slow
Green
blinking
Adjust the detection area to "Deep"(outside).
Or set dipswitch 10 to "ON".
The detection area overlaps with the
door/header.
Signal saturation.
Remove highly reflecting objects from the
detection area. Or lower the sensitivity.
Or change the area depth angle for AIR area.
INFRARED FINDER
Detection area
Detection area
1. Turn the depth angle adjustment screw to the right (Deep) to place the detection area most away from the door.
2. Set INFRARED FINDER sensitivity to "H" (High) and place it on the floor as shown below.
Area depth adjustment with INFRARED FINDER (Separately available)
3. Turn the depth angle adjustment screw to the left (Shallow) until the emitting area is placed at the position where
INFRARED FINDER is in the low detection status (Slow Red blinking).
Reference
