Introduction
Before use
Only qualied personnel of electrical and mechanical engineering should work with the
product.
Use the product correctly after thoroughly reading the "Safety precautions." In addition,
be sure to observe the contents described in warning, caution, and note in this manual.
The product described in this manual has been designed and manufactured to be
incorporated in general industrial equipment. Do not use for any other purpose. Oriental
Motor Co., Ltd. is not responsible for any damage caused through failure to observe this
warning.
Safety precautions
The precautions described below are intended to prevent danger or injury to the user
and other personnel through safe, correct use of the product. Use the product only after
carefully reading and fully understanding these instructions.
Description of signs
Handling the product without observing the instructions that
accompany a "Warning" symbol may result in serious injury
or death.
Handling the product without observing the instructions
that accompany a“Caution”symbol may result in injury or
property damage.
The items under this heading contain important handling
instructions that the user should observe to ensure safe use
of the product.
Description of graphic symbols
Indicates "prohibited" actions that must not be performed.
Indicates "compulsory" actions that must be performed.
yDo not use the product in explosive or corrosive environments, in the
presence of ammable gases, locations subjected to splashing water,
or near combustibles.
This may cause re or injury.
yDo not forcibly bend, pull or pinch the cable and connector.
This may cause re.
yDo not disassemble or modify the product.
This may cause injury.
yAssign qualied personnel the task of installing, wiring, operating/
controlling, inspecting and troubleshooting the product.
Failure to do so my result in re or injury.
yIf this product is used in a vertical application, be sure to provide a
measure for the position retention of moving parts.
Failure to do so may result in injury or damage to equipment.
yInstall the product in an enclosure.
Failure to do so may result in injury.
yConnect the cables securely according to the wiring diagram.
Failure to do so may result in re.
HM-60324-5
OPERATING MANUAL Thank you for purchasing an Oriental Motor product. This Operating Manual describes
product handling procedures and safety precautions.
yPlease read it thoroughly to ensure safe operation.
yAlways keep the manual where it is readily available.
2-Phase Stepping Motor
PKP Series Flat Type
yDo not use the product beyond its specications.
This may cause injury or damage to equipment.
yKeep your ngers and objects out of the openings in the product.
Failure to do so may result in re or injury.
yDo not touch the product during operation or immediately after
stopping.
This may cause a skin burn(s).
yDo not carry the motor by holding the motor output shaft or motor
cable.
Doing so may cause injury.
yKeep the area around the product free of combustible materials.
Failure to do so may result in re or a skin burn(s).
yLeave nothing around the product that would obstruct ventilation.
Failure to do so may result in damage to equipment.
yDo not touch the rotating part (output shaft) during operation.
Doing so may cause injury.
yProvide a cover over the rotating parts (output shaft) of the motor.
Failure to do so may result in injury.
yUse a motor and driver only in the specied combination.
Failure to do so may result in re.
yProvide an emergency stop device or emergency stop circuit external
to the equipment so that the entire equipment will operate safely in the
event of a system failure or malfunction.
Failure to do so may result in injury.
yWhen an abnormal condition has occurred, immediately stop
operation and turn o the driver power.
Failure to do so may result in re or injury.
yThe motor surface temperature may exceed 70 °C (158 °F)
even under normal operating conditions. If the operator is
allowed to approach the running motor, attach a warning
label as shown below in a conspicuous position.
Failure to do so may result in a skin burn(s).
Warning
label
Precautions for use
•When conducting the insulation resistance measurement and the
dielectric strength test, be sure to separate the connection between the
motor and the driver.
Conducting the insulation resistance test or dielectric strength test with the motor and
driver connected may result in damage to the product.
•Do not apply a radial load and axial load in excess of the specied
permissible limit
Operating the motor under an excessive radial load or axial load may damage the motor
bearings (ball bearings). Be sure to operate the motor within the specied permissible
limit of radial load and axial load.
•Motor surface temperature
The motor surface temperature may exceed 100 °C (212 °F) under certain conditions
(operating ambient temperature, operating speed, duty cycle, etc.). To prevent the
bearings (ball bearings) from reaching its usable life quickly, use the motor in a condition
where the surface temperature does not exceed 100 °C (212 °F).
Use the geared motor in a condition where the gear case temperature does not exceed
70 °C (158 °F), in order to prevent deterioration of grease and parts in the gear case.
•Rotation direction of output ange of Harmonic geared type
The output ange of the Harmonic geared type rotates in the opposite direction to the
rotation direction of the motor output shaft.

2
Preparation
Checking the product
Verify that the items listed below are included. Report any missing or damaged items to
the branch or sales oce from which you purchased the product.
yMotor .................................... 1 unit
yOPERATING MANUAL ...... 1 copy (this document)
Model list
Check the model number of the motor against the number shown on the nameplate.
Type Motor frame size
[mm (in.)] Gear ratio Motor model
Standard
42 (1.65) − PKP242D23A2
60 (2.36) − PKP262FD15AW
Harmonic
geared
51 (2.01) 50 PKP242D23A2-H50
51 (2.01) 100 PKP242D23A2-H100
ø72 (2.83) 50 PKP262FD15AW-H50
ø72 (2.83) 100 PKP262FD15AW-H100
Names of parts
The area indicated in gray color represents a rotating part.
zConnector type
The pin numbers as well as the colors of lead wires are shown in the gures.
Pilot
Output ange
Mounting
holes
(4 places)
Load mounting
holes (6 places)
Connector
Motor frame size
51 mm (2.01 in.)
Pin No.1
Pin No.5
Pilot
Output
shaft
Mounting
holes
(2 places)
Pin No.1
Pin No.5 Connector
Motor frame size

42 mm (1.65 in.)
Wiring connection diagram (Bipolar 4 lead wires)
The connection diagrams show the accessory
connection cable. (The pin No.3 is not used.)
1/Black
2/Green
4/Blue5/Red
B
A
A
B
Connection cable (accessory)
Connector
Connector locks
Motor lead wires
Pin No.5/Red
Pin No.1/Black
Applicable connector/lead wire
Type Model
Connector housing MDF97-5S-3.5C (HIROSE ELECTRIC CO., LTD.)
Contact MDF97-22SC (HIROSE ELECTRIC CO., LTD.)
Designated crimping tool HT801/MDF97-22S (HIROSE ELECTRIC CO., LTD.)
Applicable lead wire
− AWG22 (0.3 mm2)
− Outer sheath diameter:
ø1.2 to 1.5 mm (0.047 to 0.059 in.)
− Strip length of the insulation cover:
1.8 to 2.3 mm (0.071 to 0.091 in.)
zLead wire type
Motor frame size
ø72 mm (2.83 in.)
Pilot
Output ange
Mounting holes
(8 places)
Load mounting
holes (10 places)
Motor lead
wires
Motor frame size

60 mm (2.36 in.)
Pilot
Output shaft
Mounting holes
(4 places)
Motor lead wires
Wiring connection diagram
(Bipolar 4 lead wires)
Black
Green
BlueRed
B
A
A
B
Specications of drivers possible to combine
Use the 2-phase stepping motor at type in combination with drivers which
specications are described in the table.
Enter the gear ratio in the box () within the model name.
•Driver with mounting plate
Motor model Driver model Motor rated
current
Right angle
PKP242D23A2 CVD223FBR-K CVD223FB-K 2.3 A/phase
PKP242D23A2-HCVD223FBR-K CVD223FB-K
PKP262FD15AW CVD215BR-K CVD215B-K 1.5 A/phase
PKP262FD15AW-HCVD215BR-K CVD215B-K
•Driver without mounting plate
Motor model Driver model Motor rated current
PKP242D23A2 CVD223F-K 2.3 A/phase
PKP242D23A2-HCVD223F-K
PKP262FD15AW CVD215-K 1.5 A/phase
PKP262FD15AW-HCVD215-K
Connection
•When inserting the connector
Hold the connector main body, and insert it in straight
securely. Inserting the connector in an inclined state may
result in damage to connector or a connection failure.
•When pulling out the connector
Pull out the connector in straight while releasing the lock
part of the connector. Having the motor lead wires or
pulling out the connector in a state of being locked may
damage the connector.

3
Secure the lead wires at the connection part to prevent the connection
part from receiving stress due to the exing of the lead wires or the lead
wires’own mass. Also, do not excessively bend the lead wires near the
connection part of the connector. Applying stress on the motor lead wires
may cause poor contact or disconnection, leading to malfunction or heat
generation.
Bend excessively
Have length allowances
More than 4 times
of the diameter of
the lead wires.
Connection with the drivers of Oriental Motor
Refer to the following table when connecting with the drivers of Oriental Motor.
“Color” in the table shows the colors of lead wires of the connection cable (accessory).
•Connection with the CVD driver
Driver
CN2 Pin No.
Connector type Lead wire type
Pin No. Color Color
1 4 Blue Blue
2 5 Red Red
3 − −
4 2 Green Green
5 1 Black Black
Installation
Location for installation
The motor is designed and manufactured to be incorporated in equipment. Install it in a
well-ventilated location that provides easy access for inspection.
The location must also satisfy the following conditions:
yInside an enclosure that is installed indoors (provide vent holes)
yOperating ambient temperature
−10 to +50 °C (+14 to +122 °F) (non-freezing)
Harmonic geared type: 0 to +40 °C (+32 to +104 °F) (non-freezing)
yOperating ambient humidity 85% or less (non-condensing)
yArea that is free of explosive atmosphere or toxic gas (such as sulfuric gas) or liquid
yArea not exposed to direct sun
yArea free of excessive amount of dust, iron particles or the like
yArea not subject to splashing water (rain, water droplets), oil (oil droplets) or other
liquids
yArea free of excessive salt
yArea not subject to continuous vibration or excessive shocks
yArea free of excessive electromagnetic noise (from welders, power machinery, etc.)
yArea free of radioactive materials, magnetic elds or vacuum
y1,000 m (3,300 ft.) or lower above sea level
Installation method
The motor can be installed in any direction.
Install the motor onto an appropriate at metal plate having excellent vibration
resistance and heat conductivity.
When installing the motor, secure it with bolts (not supplied) so that there is no gap
between the motor and metal plate.
zStandard type
Metal plate
Mounting holes
Pilot holder
Metal plate
Mounting
holes
Motor frame size 42 mm (1.65 in.) Motor frame size 60 mm (2.36 in.)
Pilot holder
Motor frame size
[mm (in.)] Nominal size Tightening torque [N·m (oz-in)]
Eective depth of screw
thread [mm (in.)]
42 (1.65) M3 1 (142) 4.5 (0.18)
60 (2.36) M4 2 (280) −
zHarmonic geared type
Pilot holder
Metal plate
Mounting
holes
Pilot holder
Metal plate
Mounting
holes
Motor frame size 51 mm (2.01 in.) Motor frame size ø72 mm (2.83 in.)
Motor frame size
[mm (in.)] Nominal size Tightening torque [N·m (oz-in)]
Eective depth of screw
thread [mm (in.)]
51 (2.01) M3 1 (142) 7 (0.28)
ø72 (2.83) 5 (0.2)
Installing a load
When connecting a load to the motor, align the centers of the motor output shaft and
load shaft. Be careful not to damage the output shaft or bearings when installing a
coupling or pulley to the motor output shaft.
•Harmonic geared type
Install a load using the load mounting holes.
Motor frame size 51 mm (2.01 in.) Motor frame size ø72 mm (2.83 in.)
Load mounting
holes (6 places)
Load mounting
holes (10 places)
Load mounting hole
Motor frame size
[mm (in.)] Nominal size Tightening torque [N·m (oz-in)]
Eective depth of screw
thread [mm (in.)]
51 (2.01) M3 1 (142) 6 (0.24)
ø72 (2.83) M3 1 (142) 7 (0.28)
Permissible radial load, permissible axial load and
permissible moment load
The radial load, axial load and moment load on the motor output shaft must be kept
under the permissible values in the table below.
zStandard type
Motor frame
size
[mm (in.)]
Permissible radial load [N (lb.)] Permissible
axial load
[N (lb.)]
Distance from the tip of motor output shaft [mm (in.)]
0 (0) 5 (0.2) 10 (0.39)
42 (1.65)
60 (2.36) 20 (4.5) 25 (5.6) 34 (7.6) 5 (1.12)
zHarmonic geared type
Motor frame size
[mm (in.)]
Permissible axial load
[N (lb.)]
Permissible moment load
[N·m (oz-in)]
51 (2.01) 200 (45) 8.5 (1200)
ø72 (2.83) 450 (101) 5.0 (710)

4
yUnauthorized reproduction or copying of all or part of this manual is prohibited.
yOriental Motor shall not be liable whatsoever for any problems relating to industrial
property rights arising from use of any information, circuit, equipment or device
provided or referenced in this manual.
yCharacteristics, specications and dimensions are subject to change without notice.
yWhile we make every eort to oer accurate information in the manual, we welcome
your input. Should you nd unclear descriptions, errors or omissions, please contact the
nearest oce.
yis a registered trademark or trademark of Oriental Motor Co., Ltd.,
in Japan and other countries.
© Copyright ORIENTAL MOTOR CO., LTD. 2016
Published in February 2018
T
echnical Support Tel:[phone]
8:30
A.M. to 5:00 P.M., P.S.T. (M-F)
7:30
A.M. to 5:00 P.M., C.S.T. (M-F)
www
.orientalmotor.com
Schiessstraße 44, 40549 Düsseldor
f, Germany
T
echnical Support Tel:[phone]
www
.orientalmotor.de
T
el:01256-347090
www
.oriental-motor.co.uk
T
el:01 47 86 97 50
www
.orientalmotor.fr
T
el:02-93906346
www
.orientalmotor.it
T
el:[phone]
www
.orientalmotor.com.br
• Please contact your nearest Oriental Motor oce for further information.
4-8-1Higashiueno
,Taito-ku,Tokyo 110-8536
Japan
T
el:03-6744-0361
www
.orientalmotor.co.jp
Tel:[phone]
www.orientalmotor.com.tw
Singapore
Tel:[phone]
www.orientalmotor.com.sg
Tel:[phone]
www.orientalmotor.com.my
Korea
Tel:[phone]
www.inaom.co.kr
Tel:[phone]
www.orientalmotor.co.th
Tel:[phone]
www.orientalmotor.com.cn
Tel:[phone]
www.orientalmotor.co.in
Hong Kong Branch
Tel:[phone]
•How to calculate loads
Use the calculating formula below for the axial load and moment load.
Example 1; When an external force F is applied on the position of distance
L from the center of the output ange
Axial load: Fs [N] = F + mg (Load mass)
Moment load: ∆M [N·m] = F × L
F [N]
L [m]
Load mass m [kg]
mg
Fulcrum
Moment load ∆
M [N·m]
Example 2; When external forces F1 and F2 are applied on the position of
distance L from the mounting face of the output ange
Axial load: Fs [N] = F1 + mg (Load mass)
Moment load: ∆M [N·m] = F2 × (L + constant a) *
* Motor frame size 51 mm (2.01 in.): a = 0.0129
Motor frame size ø72 mm (2.83 in.): a = 0.0095
F2 [N] F1 [N]
L [m]
C
onstant a [m]
L
oad mass m [kg]
Fulcrum
Moment load ∆M [N·m]
mg
Maintenance/inspection
Inspection
It is recommended that periodic inspections would be conducted for the items listed
below after each operation of the motor. If an abnormal condition is noted, discontinue
any use and contact your nearest Oriental Motor sales oce.
During inspection
yAre any of motor mounting screws loose?
yAre there any abnormal noises in the motor bearings (ball bearings) or other moving
parts?
yAre there any scratches, signs of stress or loose driver connection in the motor lead
wire?
yAre there any loose connections on the connector or driver?
yAre the motor’s output shaft and load shaft out of alignment?
Warranty
Check on the Oriental Motor Website or General Catalog for the product warranty.
Disposal
Dispose the product correctly in accordance with laws and regulations, or instructions of
local governments.
Specications
Check on the Oriental Motor Website for the product specications.
General specications
Degree of protection IP20
Operation
environment
Ambient
temperature
−10 to +50 °C (+14 to +122 °F) (non-freezing)
Harmonic geared type: 0 to +40 °C (+32 to +104 °F)
(non-freezing)
Humidity 85% or less (non-condensing)
Altitude Up to 1,000 m (3,300 ft.) above sea level
Surrounding
atmosphere No corrosive gas, dust, water or oil
Storage
environment
Shipping
environment
Ambient
temperature −20 to +60 °C (−4 to +140 °F) (non-freezing)
Humidity 85% or less (non-condensing)
Altitude Up to 3,000 m (10,000 ft.) above sea level
Surrounding
atmosphere No corrosive gas, dust, water or oil
Insulation
resistance
100 MΩ or more when 500 VDC megger is applied between the
windings and the case.
Dielectric
strength
Sucient to withstand the following conditions applied between the
windings and the case for 1 minute.
y0.5 kVAC 50/60 Hz
Regulations and standards
RoHS Directive
The products do not contain the substances exceeding the restriction values of RoHS
Directive (2011/65/EU).
