ORiNG IGS-9844 User manual

Quick Installation Guide
Version 1.0
Quick Installation Guide
ORing Industrial Networking Corp.
Introduction
PRINTED ON RECYCLED PAPER
QIG IGS-9844/9848GPF Series
The are managed Ethernet switches with eight
10/100/1000Base-T(X) ports, four 100/1000Base-X SFP ports, and four
or eight 1000Base-X optical
fiber ports with SC connectors.
IGS-9844/9848GPF series
(IGS-9844 GPF series) (IGS-9848GPF series)
Preparation
Before you begin installing the switch, make sure you have all of the package
contents available and a PC with Microsoft Internet Explorer 6.0 or later, for
using web-based system management tools.
Elevated Operating Ambient:
Reduced Air Flow:
Mechanical Loading:
Circuit Overloading:
If installed in a closed or multi-unit rack
assembly, the operating ambient temperature of the rack environment may be
greater than room ambient. Therefore, consideration should be given to
installing the equipment in an environment compatible with the maximum
ambient temperature (Tma) specified by the manufacturer.
Installation of the equipment in a rack should be such
that the amount of air flow required for safe operation of the equipment is
not compromised.
Mounting of the equipment in the rack should be
such that a hazardous condition is not achieved due to uneven mechanical
loading.
Consideration should be given to the connection of the
equipment to the supply circuit and the effect that overloading of the circuits
might have on overcurrent protection and supply wiring. Appropriate
consideration of equipment nameplate ratings should be used when addressing
this concern.
Safety & Warnings
Dimension
Panel Layouts
1
1. SFP fiber ports
2. RJ45 ports
3. Power LED
4. PWR1 LED
5. PWR2 LED
6. R.M. status LED
7. Ring status LED
8. Faulty relay indicator
9. Console port
10. Fiber ports
Package Contents
Contents
DIN-rail Kit
CD
IGS-9848GPF
IGS-9844GPF
Pictures Number
X1
X1
X1
Front View
Top Panel
The are shipped with the following items. If any of
these items is missing or damaged, please contact your customer service
representative for assistance.
IGS-9844/9848GPF series
GIGABIT
INDUSTRIAL
SWITCH
IGS-9844/9848GPF Series
Industrial Managed Gigabit Switch
QIG
Console Cable
X2
X1
X1
Wall-mount Kit
Number
X1
X1
X1
X2
X1
X1
33.0
30.0
12.5
105.5
10.9
15.0
70.5
154.0
96.4
87.0
48.0
17.5
94.0
124.0
48.0
58.0
7.50
R2.5
R3.95
66.25
48.75
95.9
IGS-9848GPF
PWR
PWR1
PWR2
10/100/1000T
G8
G6
G4
G2
G12
G11
G10
G9
100/1000X
G7
G5
G3
G1
LNK/
ACT
G16
G15
G14
G13
1000X
LNK/
ACT
G20
G19
G18
G17
IGS-9848GPF
33.0
30.0
12.5
105.5
10.9
15.0
70.5
154.0
96.4
87.0
48.0
17.5
94.0
124.0
48.0
58.0
7.50
R2.5
R3.95
66.25
48.75
95.9
IGS-9844GPF
IGS-9844GPF
PWR
PWR1
PWR2
10/100/1000T
G8
G6
G4
G2
G12
G11
G10
G9
100/1000X
G7
G5
G3
G1
LNK/ACT
LNK/ACT
G16
G15
G14
G13
1000FX
IGS-9844GPF
2
IGS-9844GPF
PWR
PWR1
PWR2
10/100/1000T
G8
G6
G4
G2
G12
G11
G10
G9
100/1000X
G7
G5
G3
G1
LNK/ACT
LNK/ACT
G16
G15
G14
G13
1000X
10
9
3
4
5
6
7
8
IGS-9848GPF
PWR
PWR1
PWR2
10/100/1000T
G8
G6
G4
G2
G12
G11
G10
G9
100/1000X
G7
G5
G3
G1
LNK/
ACT
G16
G15
G14
G13
1000X
LNK/
ACT
G20
G19
G18
G17
1
2
10
9
3
4
5
6
7
8
IGS-9848GPF
Rear View
12
1. Wall-mount screw holes
2. Din-rail screw holes
PWR-1PWR-2
1A@24V
DC 48V
V2-V2+ V1-V1+
Fault
1
1. Wall-mount screw holes
2. Din-rail screw holes
2
1. Terminal blocks: PWR1, PWR2
(12-48V DC), Relay
2. Ground wire.
1
Installation
Step 1:
Step 2:
Slant the switch and screw the Din-rail kit onto the back of the switch, right in
the middle of the back panel.
Slide the switch onto a DIN-rail from the Din-rail kit and make sure the switch
clicks into the rail firmly.
Step 1:
Step 2:
Step 3:
Screw the two pieces of wall-mount kits onto both ends of the rear panel of the
switch. A total of six screws are required, as shown below.
Use the switch, with wall mount plates attached, as a guide to mark the
correct locations of the four screws.
Insert four screw heads through the large parts of the keyhole-shaped apertures,
and then slide the switch downwards. Tighten the four screws for added stability.
IGS-9844GPF
PWR
PWR1
PWR2
10/100/1000T
G8
G6
G4
G2
G12
G11
G10
G9
100/1000X
G7
G5
G3
G1
LNK/ACT
LNK/ACT
G16
G15
G14
G13
1000FX
ORing Industrial Networking Corp.
Copyright© 2013 ORing
All rights reserved.
TEL: [phone]
FAX: [phone]
Website: www.oring-networking.com
E-mail: [email protected]
1907-2-29-IGS984XGPF-1.0
DIN-rail Installation
Wall-mounting

QIG Quick Installation Guide
PRINTED ON RECYCLED PAPER
Version 1.0
Quick Installation Guide
ORing Industrial Networking Corp.
Resetting
To reboot the switch, press the button for 2-3 seconds.
To restore the switch configurations back to the factory defaults, press the button for 5 seconds.
Reset
Reset
Network Connection
The have standard Ethernet ports. According to the link type,
the switch uses CAT 3,4,5,5e UTP cables to connect to any other network devices
(PCs, servers, switches, routers, or hubs). Please refer to the following table for
cable specifications.
IGS-9844/9848GPF series
Specifications
IGS-9844/9848GPF Series
GIGABIT
INDUSTRIAL
SWITCH
IGS-9844/9848GPF Series
Industrial Managed Gigabit Switch
Cable Types and Specifications:
Cable Type Max. Length Connector
10BASE-T Cat. 3, 4, 5 100-ohm UTP 100 m (328 ft) RJ-45
100BASE-TX Cat. 5 100-ohm UTP UTP 100 m (328 ft) RJ-45
1000BASE-TX Cat. 5/Cat. 5e 100-ohm UTP UTP 100 m (328ft) RJ-45
For pin assignments for different types of cables, please refer to the following
tables.
10/100 Base-T(X) MDI/MDI-X
Pin Number MDI port MDI-X port
1TD+(transmit)RD+(receive)
2TD-(transmit)RD-(receive)
3 RD+(receive) TD+(transmit)
4NotusedNotused
5NotusedNotused
6 RD-(receive) TD-(transmit)
7NotusedNotused
8NotusedNotused
1000Base-T(X) MDI/MDI-X
Pin Number MDI port MDI-X port
1 BI_DA+ BI_DB+
2 BI_DA- BI_DB-
3 BI_DB+ BI_DA+
4BI_DC+BI_DD+
5 BI_DC- BI_DD-
6 BI_DB- BI_DA-
7 BI_DD+ BI_DC+
8 BI_DD- BI_DC-
Note: “+” and “-” signs represent the polarity of the wires that make up each
wire pair.
To connect the console port to an external management device, you need an RJ-45 to
DB-9 cable, which is also supplied in the package. Below is the console port pin
assignment information.
Console Port Pin Definition
PC (male) pin assignment RS-232 with DB9 (female) pin
assignment (RJ45-DB9 cable) RJ45 pin assignment
PIN#2 RxD PIN#2 RxD PIN#2 RxD
PIN#3TxD PIN#3TxD PIN#3TxD
PIN#5 GND PIN#5 GND PIN#5 GND
Wiring
The switch supports dual redundant power supplies, Power Supply1 (PWR1) and
Power Supply 2 (PWR2). The connections for PWR1, PWR2 and the RELAY are
located on the terminal block.
Insert the negative/positive wires into the V-/V+ terminals, respectively.
To keep the DC wires from pulling loose, use a small flat-blade
screwdriver to tighten the wire-clamp screws on the front of the terminal block
connector.
STEP 1:
STEP 2:
PWR-1PWR-2
1A@24V
V2-V2+ V1-V1+
Fault
Power inputs
The two sets of relay contacts of the 6-pin terminal block connector are used to detect user-configured
events. The two wires attached to the fault contacts form an open circuit when a user-configured when an
event is triggered. If a user-configured event does not occur, the fault circuit remains closed.
Relay contact
Grounding and wire routing help limit the effects of noise due to electromagnetic interference (EMI). Run
the ground connection from the ground screws to the grounding surface prior to connecting devices.
Grounding
Configurations
After installing the switch card, the green power LED should turn on. Please refer to the
following tablet for LED indication.
LED Color Status Description
PWR Green On DC power on
PW1 Green On DC power module 1 activated
PW2 Green On DC power module 2 activated
R.M Green On Ring Master
On Ring enabled
Ring Green
Blinking Ring structure is broken (i.e. part of the ring is disconnected)
Fault Amber On Faulty relay (power failure or port malfunctioning)
10/100/1000Base-T(X) Fast Ethernet ports
Green On Ethernet running at 1000Mbps
LNK/ACT
Amber On Ethernet running at 10/100Mbps
SFP
LNK Green On Port link up
ACT Green On Data transmitted
100Base-FX or 1000Base-X Fiber Port
LNK Green On Port link up
ACT Green On Data transmitted
1. Launch the Internet Explorer and type in IP address of the switch. The default static IP address is
192.168.10.1
2. Log in with default user name and password
(both are ). After logging in, you should
see the following screen. For more information
on configurations, please refer to the user
manual. For information on operating the switch
using ORing’s Open-Vision management utility,
please go to ORing website.
admin
Follow the steps to set up the card:
ORing Switch Model IGS-9844GPF-MM
Physical Ports
Fiber Ports Number
Technology
Ethernet Standards
IEEE 802.3 for 10Base-T
IEEE 802.3u for 100Base-TX and 100Base-FX
IEEE 802.3z for 1000Base-X
IEEE 802.3ab for 1000Base-T
IEEE 802.3ad for LACP (Link Aggregation Control Protocol)
IEEE 802.3x for Flow control, IEEE 802.1D for STP (Spanning Tree Protocol)
IEEE 802.1p for COS (Class of service)
IEEE 802.1Q for VLAN Tagging
IEEE 802.1w for RSTP (Rapid Spanning Tree Protocol
IEEE 802.1s for MSTP (Multiple Spanning Tree Protocol)
IEEE 802.1x for Authentication
Power
Redundant Input power
Power consumption(Typ.)
Triple DC inputs. 12-48VDC on 7-pin terminal block
15 Watts
Overload current protection
Reverse polarity protection
Present
Present
Physical Characteristic
Enclosure IP-30
Dimension(WxDxH) 96.4 (W) x 105.5(D) x 154(H) mm (3.8 x 4.15 x 6.06 inch)
10/100/1000Base-T(X) Ports
in RJ45 Auto MDI/MDIX
MAC Table 8K
RS-232 Serial Console Port
Priority Queues 8
Processing Store-and-Forward
Switch Properties
Switch latency: 7 us
Switch bandwidth: 40Gbps
Max. Number of Available VLANs: 256
IGMP multicast groups: 128 for each VLAN
Port rate limiting: User Define
Security Features
Device Binding security feature
Enable/disable ports, MAC based port security
Port based network access control (802.1x)
VLAN (802.1q) to segregate and secure network traffic
Radius centralized password management
SNMPv3 encrypted authentication and access security
Https / SSH enhance network security
Software Features
STP/RSTP/MSTP (IEEE 802.1D/w/s)
Redundant Ring (O-Ring) with recovery time less than 10ms over 250 units
TOS/Diffserv supported
Quality of Service (802.1p) for real-time traffic
VLAN (802.1Q) with VLAN tagging and GVRP supported
IGMP Snooping for multicast filtering
IP-based bandwidth management
Application-based QoS management
DOS/DDOS auto prevention
Port configuration, status, statistics, monitoring, security
DHCP Server / Client support
SMTP Client
Modbus TCP
Network Redundancy O-Ring, Open-Ring, O-chain, STP, RSTP, MSTP
RS-232 in RJ45 connector with console cable. Baud rate setting: 9600bps, 8, N, 1
Fiber Ports Specification
Fiber Ports Standard 1000Base-SX 1000Base-LX
Fiber Mode Multi-mode Single-mode
Fiber Diameter ( m)µ62.5/125 m
50/125 m
µ
µ
9/125 mµ
Fiber Optical Connector SC SC
Typical Distance (Km) 0.55 Km 10 Km
Wavelength (nm) 850 nm 1310 nm
Max. Output Optical Power
(dbm) -4 dbm -3 dbm
Min. Output Optical Power
(dbm) -9.5 dbm -9.5 dbm
Max. Input Optical Power
(Sensitivity) -3 dbm
-18 dbm -20 dbm
0dbm
Min. Input Optical Power
(Saturation)
Link Budget (db) 8.5db 10.5db
Weight (g ) 1100 g 1100 g 1250 g 1250 g
Warning / Monitoring System
Syslog server / client to record and view events
Include SMTP for event warning notification via email
Event selection support
8
1000Base-SX 1000Base-LX
Multi-mode Single-mode
62.5/125 m
50/125 m
µ
µ
9/125 mµ
SC SC
0.55 Km 10 Km
850 nm 1310 nm
-4 dbm -3 dbm
-9.5 dbm -9.5 dbm
-3 dbm
-18 dbm -20 dbm
0dbm
8.5 db 10.5 db
IGS-9844GPF-SS IGS-9848GPF-MM IGS-9848GPF-SS
100/1000Base-X with SFP port 4
1000Base-X Optical Fiber Port 4 8
4 8
Processing Up to 10K Bytes
Fault contact
Relay Relay output to carry capacity of 1A at 24VDC
Weight (g ) 710 g 740 g722 g 735 g 735 g 740 g
Environmental
-40to85C(-40to185 F)
oo
Storage Temperature
-40to70C(-40to158 F)
oo
Operating Temperature
5% to 95% Non-condensingOperating Humidity
Regulatory Approvals
FCC Part 15, CISPR (EN55022) class AEMI
EN61000-4-2 (ESD), EN61000-4-3 (RS), EN61000-4-4 (EFT), EN61000-4-5 (Surge),EN61000-4-6 (CS), EN61000-4-8, EN61000-4-11
EMS
IEC60068-2-27Shock
IEC60068-2-32
IEC60068-2-6Vibration
EN60950-1, UL508 (E331061), UL/cUL Class 1 Division 2 Group A/B/C/D, ATEX Class 1 Zone 2 Safety
Free Fall
Warranty
5 years
1000 Base-T(X) RJ-45
Pin Number Assignment
1BI_DA+
2BI_DA-
3BI_DB+
4BI_DC+
5BI_DC-
6BI_DB-
7BI_DD+
8BI_DD-
10/100 Base-T(X) RJ-45
Pin Number Assignment
1TD+
2TD-
3RD+
4Notused
5Notused
6RD-
7Notused
8Notused
