ORiNG IPS-1080-24V User manual

P1 P2 Fau lt
IPS-1080-24V
3
4
10/1 00T X
1
2
7
8
5
6
Quick Installation Guide
Version 1.5
Quick Installation Guide
Introduction
PRINTED ON RECYCLED PAPER
Preparation
Before you begin installing the switch, make sure you have all of the package
contents available and a PC with Microsoft Internet Explorer 6.0 or later, for
using web-based system management tools.
Elevated Operating Ambient: If installed in a closed or multi-unit rack
assembly, the operating ambient temperature of the rack environment may be
greater than room ambient. Therefore, consideration should be given to
installing the equipment in an environment compatible with the maximum
ambient temperature (Tma) specified by the manufacturer.
Safety & Warnings
Dimension
Panel Layouts
1. PWR indicators
2. Faulty relay indicator
3. Link/Act LED for LAN ports
4. PoE LED for LAN ports
5. PoE LAN ports
Package Contents
Front View
The device is shipped with the following items. If any of these items is
missing or damaged, please contact your customer service representative for
assistance.
Installation
Step 1: Slant the switch and screw the Din-rail kit onto the back of the switch, right in
the middle of the back panel.
Step 2: Slide the switch onto a DIN-rail from the Din-rail kit and make sure the switch
clicks into the rail firmly.
DIN-rail Installation
Step 1: Screw the wall-mount kit onto the rear panel of the switch. A total of six
screws are required, as shown below.
Step 2: Use the switch, with wall mount plates attached, as a guide to mark the
correct locations of the four screws.
Step 3: Insert a screw head through the large parts of the keyhole-shaped apertures,
and then slide the switch downwards. Tighten the screws for added stability.
Wall-mounting
Q I G IPS-1080-24V 1907-200-XX
Reduced Air Flow: Installation of the equipment in a rack should be such that the
amount of air flow required for safe operation of the equipment is not compromised.
Mechanical Loading: Mounting of the equipment in the rack should be such that a
hazardous condition is not achieved due to uneven mechanical loading.
Circuit Overloading: Consideration should be given to the connection of the equipment to
the supply circuit and the effect that overloading of the circuits might have on overcurrent
protection and supply wiring. Appropriate consideration of equipment nameplate ratings
should be used when addressing this concern.
Network Connection
The switch provides standard Ethernet ports. According to the link type, the switch uses
CAT 3,4,5,5e UTP cables to connect to any other network devices (PCs, servers,
switches, routers, or hubs). Please refer to the following table for cable
specifications.
Cable Types and Specifications:
Cable
Type
Max. Length
Connector
10BASE-T Cat. 3, 4, 5 100-ohm UTP 100 m (328 ft) RJ-45
100BASE-TX Cat. 5 100-ohm UTP UTP 100 m (328 ft) RJ-45
1
Unit =mm (Tolerance ±0.5mm)
Features
Contents
Wall-mount Kit
DIN-rail Kit
IPS-1080-24V
Pictures Number
X 2
X 1
QIG X 1
X 1
6-pin terminal block X 1
68.1 5
8.0
14.0 1 3. 5
40.0
50.0
25.3
41
144. 3
41
24.7
94.9
29.0
13.1
Ø3.0
Ø5.9
Ø4.0
P1 P2 Faul t
IPS-1080-24V
3
4
10/1 00TX
1
2
7
8
5
6
2
3
4
5
Rear View
1
1. Din-rail screw holes
PWR -1PWR -2
V2- V 2+ V1- V 1+
1A@ 24V
Chec k Polar ity Fir st.
！
Wa rni ng !!!
Top Panel
1. Wall-mount screw holes
2. Terminal blocks: PWR1, PWR2
, Relay
3. DIP Switch
4. Ground wire.
2 3
4
1
1
IPS-1080-24V Industrial Unmanaged PoE Switch
S W I T C H
I N D U S T R I A L
P o E
IPS-1080-24V IPS-1080-is unmanaged PoE Ethernet switch with P.S.E. function.
24V supports Power over Ethernet, a system to transmit electrical power, along with
data, to remote devices over standard twisted-pair cable in an network. IPS-1080-24V
switch h s 8X10/100Base-T(X) P.S.E. (Power Sourcing Equipment) ports. P.S.E. is aa
device (switch or hub for instance that will provide power in a PoE setup. The
wide operating temperature range from -40 C to 75 C can satisfy most of operating
o o
environment. Therefore, the switch is one of the most reliable choices for PoE Ethernet
application.
Provide 8x10/100Base-T(X) PoE (P.S.E.) ports
Supports IEEE 802.3at compliant PoE and total power budget is 120Watts with
maximum 30Watts per port
Advanced PoE power boost technology to support dual 24VDC power inputs
Support auto-negotiation and auto-MDI/MDI-X
Support store and forward transmission
Support flow control
Warning system by relay output
Slim type rigid IP-30 housing design
DIN-Rail and wall mounting enabled
P1 P2 F ault
IPS-1080-24V
3
4
10/1 00TX
1
2
7
8
5
6

Q I G Quick Installation Guide
PRINTED ON RECYCLED PAPER
Quick Installation Guide
Q I G
G I G A B I T
I N D U S T R I A L
S W I T C H
P o E
DIP Switch Setting
Wiring
The switch supports dual redundant power supplies, Power Supply1
(PWR1) and Power Supply 2 (PWR2). The connections for PWR1,
PWR2 and the RELAY are located on the terminal block.
STEP 1: Insert the negative/positive wires into the V-/V+ terminals,
respectively.
STEP 2: To keep the DC wires from pulling loose, use a small flat-
blade screwdriver to tighten the wire-clamp screws on the front of the
terminal block connector.
PWR-1PWR-2 1A@24V
V2- V2+ V1- V1+
Power inputs
The two sets of relay contacts of the 6-pin terminal block connector are used to detect user-
configured events. The two wires attached to the fault contacts form an close circuit when a
user-configured event is triggered. If a user-configured event does not occur, the fault
circuit remains opened.
Relay contact
Grounding and wire routing help limit the effects of noise due to electromagnetic
interference (EMI). Run the ground connection from the ground screws to the grounding
surface prior to connecting devices.
Grounding
Configurations
After installing the switch, the green power LED should turn on. Please refer
to the following tablet for LED indication.
Specifications
LED
Color
Status
Description
P1 Green On DC power 1 activated
P2 Green On DC power 2 activated
Fault Amber On Faulty relay (power failure or port disconnected)
10/100/1000Base-T(X) Gigabit PoE Ethernet ports
LNK/ACT Green On Port link at 10/100Mbps
PoE Green On Power supplied over Ethernet
10/100Base-T(X) P.S.E. RJ-45 port
Pin No.
Description
#1
TD+ with PoE Power Input +
#2
TD- with PoE Power Input +
#3
RD+ with PoE Power Input -
#4
N.C.
#5
N.C.
#6
RD- with PoE Power Input -
#7
N.C.
#8
N.C.
For pin assignments for different types of cables, please refer to the following
tables.
Note: “+” and “-” signs represent the polarity of the wires that make up each
wire pair.
ORing Industrial Networking Corp.
Copyright© 2011 ORing
All rights reserved.
TEL: [phone]
FAX: [phone]
Website: www.oringnet.com
E-mail: [e-mail]
Version 1.5
DIP-2
OFF
OFF
ON
DIP-1
Power failure relay alarm disabled
PWR-1 failure, relay alarm enabled
PWR-2 failure, relay alarm enabled
OFF
ON
OFF
Description
ON PWR-1 or PWR-2 failure,
relay alarm enabled
ON
ORing Switch Model
Physical Ports
Technology
Ethe r net Standards
LED Indicators
Gree n : Power LED x 2Power indicato r
10/100 Ba s e -T(X) Ports in RJ45
Auto MD I / MDIX with P.S.E. 8
IEEE 802.3 fo r 1 0 Base-T
IEEE 802.3u f o r 1 0 0Base-TX
IEEE 802.3x f o r F low control
IEEE 802.3a t PoE specification (total power bud g e t i s 120Watts wi t h m a x imum 30Wat t s
per port)
MAC Table 1K MA C a ddresses
Environmental
-40 to 8 5 C (-40 to 185 F )
o o
Storage Tem perature
Operating Temperatu r e
5% to 95 % Non-condensi n gOperating Humid i ty
Regulatory Approvals
-40 to 7 5 C (-40 to 158 F )
o o
Ambe r: Indicate PWR1 o r PWR2 failure
Fault indi c ator
Fault Contact
Relay Rel ay output to car r y capacity of 1A at 2 4 VDC
Power
Redundant Inpu t p ower
Power consumpt i on(Typ. ) 3 Watts (PoE output not in c luded)
Ove rload current p r otection
Reverse pola r ity protectio n
Pres e nt
Pres e nt
Physical Characteristic
Encl o sure IP-30, Met a l
Dim e nsion (W x D x H)
Weight (g) 634g
Dual D C inputs 12~57V D C on 6-pin termin a l block
41 (W ) x 9 4.9 (D) x 144.3 (H) m m ( 1.03 x 3.74 x 5.68 i n ches)
10/1 00Base-T(X)R J 45 Port
Indi c ator
Gree n for port Link/A c t.
Gree n for PoE powe r i njected.
Proc e ssing Store-and-Forward
IPS-1080-24V
EN 550 32, CISPR32, EN 61 000-3-2, EN 610 0 0-3-3, FCC Pa rt 15B class AEMI
EN 550 24 (IEC/EN 61000 - 4-2 (ESD), IEC/ E N 61000-4-3 (RS ) ,IEC/EN 61000 - 4-4 (EFT),
IEC/ E N 61000-4-5 (Su r ge), IEC/EN 610 0 0-4-6 (CS), IEC / EN 61000-4-8( P FMF),
IEC/ E N 61000-4-11 (D I P))
EMS
IEC6 0 068-2-27Shoc k
IEC6 0 068-2-31
IEC6 0 068-2-6Vibration
Free Fall
MTBF
7449 74hrs
UL 60 9 50-1, CSA C22. 2 N o. 60950-1- 0 7, EN 60950-1, IE C 6 0950-1Safe ty
Note : HW version 5.0
IPS-1080-24V
IPS-1080-24V Industrial Unmanaged PoE Switch
Sw i tch Latency <7us
Sw i tch Bandwidth 16Gb p s
Packet buffe r s ize 4 48K bits
DIP-Switch
DIP-Switch 1 Power-2 fail e d warning: (ON ) e nable, (OFF) di s able
DIP-Switch 2 Power-1 fail e d warning: (ON ) e nable, (OFF) di s able
PoE Power bu d get 60W at 1 2~24VDC, 120W a t 2 4~57VDC
CE EMC ( E N 55024, EN 55032 ), FCC Part 15 BEMC
Warranty
5 ye a rs
