Getting to Know Your Switch
1.1 About the IPS-2042 SERIES P.O.E Lite-Managed
Industrial Switch
The IPS-2042 SERIES switch are cost-effect and powerful industrial switch with many
features. The switch can work under wide temperature and dusty environment and humid
condition. IPS-2042 SERIES support Power over Ethernet, a system to transmit electrical
power with data to remote devices over standard twisted-pair cable. The IPS-2042
SERIES switch has 4 X 10/100Base-T(X) P.S.E. (Power Sourcing Equipment) ports which
are fully compliant with IEEE 802.3af standard.
The IPS-2042 SERIES switch can be managed by WEB and a useful Window Utility we
called Open-Vision. Open-Vision is powerful network management software. With its
friendly and powerful interface, you can easily configure multiple switches at the same time,
and monitor switches’ status
1.2 Software Features
World’s fastest Redundant Ethernet Ring : O-Ring (Recovery time < 10ms over 250
units connection)
Supports O-Chain technology for multiple ring redundancy
Supports Ring Coupling, Dual Homing over O-Ring and standard STP/RSTP
Support fast recovery mode
Easy-to-configure: Web / Windows utility
Windows utility (Open-Vision) for network management
1.3 Hardware Features
Wide Operating Temperature: -40 to 70 oC
Storage Temperature: -40 to 85 oC
Operating Humidity: 5% to 95%, non-condensing
4 10/100Base-T(X) Ethernet port with P.S.E. provides up to 25 watts
2 100Base-FX SFP ports

IPS-2042 Series User’s Manual
ORing Industrial Networking Corp. 4
Hardware Installation
2.1 Installing Switch on DIN-Rail
Each switch has a DIN-Rail kit on rear panel. The DIN-Rail kit helps switch to fix on the
DIN-Rail. It is easy to install the switch on the DIN-Rail:
2.1.1 MountIPS-2042 SERIES on DIN-Rail
DIN-Rail Size

IPS-2042 Seris User’s Manual
ORing Industrial Networking Corp. 5
2.2 Wall Mounting Installation
Each switch has another installation method for users to fix the switch. A wall mount panel
can be found in the package. The following steps show how to mount the switch on the
wall:
Wall-Mounting size

IPS-2042 Series User’s Manual
ORing Industrial Networking Corp. 6
Hardware Overview
3.1 Front Panel
The following table describes the labels that stick on the IPS-2042 SERIES.
Port Description
10/100 RJ-45 fast
Ethernet ports
10/100Base-T(X) RJ-45 fast Ethernet ports support
auto-negotiation.
Default Setting :
Speed: auto
Duplex: auto
Flow control : disable
Fiber ports 100Base-FX SFP ports
P.O.E. Ports Port 1 ~ 4 contain P.S.E. function compliant with IEEE802.3af
P.O.E. specifications.
Reset Push reset button 2 to 3 seconds to reset the switch.
Push reset button 5 second to reset the switch into Factory
Default.

IPS-2042 Seris User’s Manual
ORing Industrial Networking Corp. 7
IPS-2042TX
1. LED for PWR1. When the PWR1 links, the green led will be light on.
2. LED for PWR2. When the PWR2 links, the green led will be light on.
3. LED for PWR3. When the PWR3 links, the green led will be light on.
4. LED for R.M (Ring master). When the LED light on, it means that the switch is the ring
master of O-Ring.
5. LED for Ring. When the led light on, it means the O-Ring is activated.
6. LED for Fault Relay. When the fault occurs, the amber LED will be light on.
7. Reset button. Push the button 3 seconds for reset; 5 seconds for factory default.
8. LED for P.O.E power supplied
9. 10/100Base-T(X) P.S.E. Ethernet ports..
10. LED for Ethernet ACT status
11. LED for Ethernet LINK status
12. LED for Ethernet ACT/LINK status
13. 10/100Base-T(X) Ethernet ports..

IPS-2042 Series User’s Manual
ORing Industrial Networking Corp. 8
IPS-2042FX
1. LED for PWR1. When the PWR1 links, the green led will be light on.
2. LED for PWR2. When the PWR2 links, the green led will be light on.
3. LED for PWR3. When the PWR3 links, the green led will be light on.
4. LED for R.M (Ring master). When the LED light on, it means that the switch is the ring
master of O-Ring.
5. LED for Ring. When the led light on, it means the O-Ring is activated.
6. LED for Fault Relay. When the fault occurs, the amber LED will be light on.
7. Reset button. Push the button 3 seconds for reset; 5 seconds for factory default.
8. LED for P.O.E power supplied
9. 10/100Base-T(X) P.S.E. Ethernet ports..
10. LED for Ethernet ACT status
11. LED for Ethernet LINK status
12. LED for Fiber ACT/LINK status
13. 100Base-FX Fiber ports..

IPS-2042 Seris User’s Manual
ORing Industrial Networking Corp. 9
IPS-2042P
1. LED for PWR1. When the PWR1 links, the green led will be light on.
2. LED for PWR2. When the PWR2 links, the green led will be light on.
3. LED for PWR3. When the PWR3 links, the green led will be light on.
4. LED for R.M (Ring master). When the LED light on, it means that the switch is the ring
master of O-Ring.
5. LED for Ring. When the led light on, it means the O-Ring is activated.
6. LED for Fault Relay. When the fault occurs, the amber LED will be light on.
7. Reset button. Push the button 3 seconds for reset; 5 seconds for factory default.
8. LED for P.O.E power supplied
9. 10/100Base-T(X) P.S.E. Ethernet ports..
10. LED for Ethernet ACT status
11. LED for Ethernet LINK status
12. LED for SFP ACT/LINK status
13. LED for SFP ports status.

IPS-2042 Series User’s Manual
ORing Industrial Networking Corp. 10
3.2 Front Panel LEDs
LED Color Status Description
PWR1 Green On DC power module 1 activated.
PWR2 Green On DC power module 2 activated.
PWR3 Green On Power jack activated.
R.M Green On O-Ring Master.
Ring Green
On O-Ring enabled.
Slowly blinking O-Ring topology has problem
Fast blinking O-Ring work normally.
Fault Amber On Fault relay. Power failure or Port
down/fail.
10/100Base-T(X) Fast Ethernet ports
LNK / ACT Green On Port link up.
Blinking Data transmitted.
Link Amber On Port works under Link.
P.O.E. Green On P.O.E. activated
100Base-FX SFP ports
ACT Green Blinking Data transmitted.
LNK Amber On Port link up.
3.3 Bottom Panel
The bottom panel components of IPS-2042 SERIES are showed as below:
1. Terminal block includes: PWR1, PWR2 (+48V DC) and Relay output (1A@24VDC).
2. Power jack for PWR3 (+48VDC).
.
IPS-2042 SERIES power connection

IPS-2042 Seris User’s Manual
ORing Industrial Networking Corp. 11
Cables
4.1 Ethernet Cables
The IPS-2042 SERIES switch has standard Ethernet ports. According to the link type, the
switch use CAT 3, 4, 5, 5e UTP cables to connect to any other network device (PCs, servers,
switches, routers, or hubs). Please refer to the following table for cable specifications.
Cable Types and Specifications
Cable Type Max. Length Connector
10BASE-T Cat. 3, 4, 5 100-ohm UTP 100 m (328 ft) RJ-45
100BASE-TX Cat. 5 100-ohm UTP UTP 100 m (328 ft) RJ-45
4.1.1 100BASE-TX/10BASE-T Pin Assignments
With 100BASE-TX/10BASE-T cable, pins 1 and 2 are used for transmitting data, and pins
3 and 6 are used for receiving data.
RJ-45 Pin Assignments
Pin Number Assignment
1 TD+
2 TD-
3 RD+
4 P.O.E. power input +
5 P.O.E. power input +
6 RD-
7 P.O.E. power input -
8 P.O.E. power input -
The IPS-2042 SERIES switch support auto MDI/MDI-X operation. You can use a
straight-through cable to connect PC and switch. The following table below shows the
10BASE-T/ 100BASE-TX MDI and MDI-X port pin outs.

IPS-2042 Series User’s Manual
ORing Industrial Networking Corp. 12
MDI/MDI-X pins assignment
Pin Number MDI port MDI-X port
1 TD+(transmit) RD+(receive)
2 TD-(transmit) RD-(receive)
3 RD+(receive) TD+(transmit)
4 P.O.E. power input + P.O.E. power input +
5 P.O.E. power input + P.O.E. power input +
6 RD-(receive) TD-(transmit)
7 P.O.E. power input - P.O.E. power input -
8 P.O.E. power input - P.O.E. power input -
Note: “+” and “-” signs represent the polarity of the wires that make up each wire pair.
4.2 Fibers
Only models “IPS-2042FX series” have fiber optical ports. The fiber optical ports are in
multi-mode and single-mode with SC connector. Please remember that the TX port of Switch
A should be connected to the RX port of Switch B.
Switch A
TX RX
RX TX
Switch B
Fiber cord

IPS-2042 Seris User’s Manual
ORing Industrial Networking Corp. 13
4.3 SFP
Only models “IPS-2042P” have fiber optical ports. has fiber optical ports with SFP
connectors. The fiber optical ports are in multi-mode and single-mode with LC connector.
Please remember that the TX port of Switch A should be connected to the RX port of Switch B.
SwitchA SwitchB
Fiber cord

IPS-2042 Series User’s Manual
ORing Industrial Networking Corp. 14
WEB Management
5.1 Configuration by Web Browser
This section introduces the configuration by Web browser.
5.1.1 About Web-based Management
An embedded HTML web site resides in flash memory on the CPU board. It contains
advanced management features and allows you to manage the switch from anywhere on
the network through a standard web browser such as Microsoft Internet Explorer.
The Web-Based Management function supports Internet Explorer 5.0 or later. It is based
on Java Applets with an aim to reduce network bandwidth consumption, enhance access
speed and present an easy viewing screen.
Note: By default, IE5.0 or later version does not allow Java Applets to open sockets. You need to explicitly
modify the browser setting in order to enable Java Applets to use network ports.
Preparing for Web Management
The default value is as below:
IP Address: 192.168.10.1
Subnet Mask: 255.255.255.0
Default Gateway: 192.168.10.254
User Name: admin
Password: admin
System Login
1. Launch the Internet Explorer.
2. Type http:// and the IP address of the switch. Press “Enter”.

IPS-2042 Seris User’s Manual
ORing Industrial Networking Corp. 15
3. The login screen appears.
4. Key in the username and password. The default username and password is
“admin”.
5. Click “Enter” or “OK” button, then the main interface of the Web-based management
appears.
Login screen
Main interface

IPS-2042 Series User’s Manual
ORing Industrial Networking Corp. 16
5.1.2 Basic Setting
5.1.2.1 Switch setting
Switch setting interface
The following table describes the labels in this screen.
Label Description
System Name Assign the name of switch. The maximum length is 64 bytes
System Description Display the description of switch.
System Location Assign the switch physical location. The maximum length is 64
bytes
System Contact Enter the name of contact person or organization
Firmware Version Display the switch’s firmware version
Kernel Version Display the kernel software version
MAC Address Display the unique hardware address assigned by manufacturer
(default)
5.1.2.2 Admin Password
Change web management login username and password for the management security
issue
Admin Password interface

IPS-2042 Seris User’s Manual
ORing Industrial Networking Corp. 17
The following table describes the labels in this screen.
Label Description
User name Key in the new username (The default is “admin”)
New Password Key in the new password (The default is “admin”)
Confirm password Re-type the new password.
Apply Click “Apply” to activate the configurations.
5.1.2.3 IP configuration
You can configure the IP Settings and DHCP client function through IP configuration.
IP Configuration interface
The following table describes the labels in this screen.
Label Description
DHCP Client To enable or disable the DHCP client function. When DHCP
client function is enabling, the switch will assign the IP address
from the network DHCP server. The default IP address will be
replaced by the IP address which the DHCP server has assigned.
After clicking “Apply” button, a popup dialog will show up to
inform you when the DHCP client is enabling. The current IP will
lose and you should find the new IP on the DHCP server.
IP Address Assign the IP address that the network is using. If DHCP client
function is enabling, you do not need to assign the IP address.

IPS-2042 Series User’s Manual
ORing Industrial Networking Corp. 18
The network DHCP server will assign the IP address for the
switch and it will be displayed in this column. The default IP is
192.168.10.1
Subnet Mask Assign the subnet mask for the IP address. If DHCP client
function is enabling, you do not need to assign the subnet mask.
Gateway Assign the network gateway for the switch. The default gateway
is 192.168.10.254
DNS1 Assign the primary DNS IP address
DNS2 Assign the secondary DNS IP address
Apply Click “Apply” to activate the configurations.
5.1.2.4 SNTP Configuration
The SNTP (Simple Network Time Protocol) settings allow you to synchronize switch
clocks in the Internet.
SNTP Configuration interface
The following table describes the labels in this screen.
Label Description
SNTP Client Enable or disable SNTP function to get the time from the SNTP
server.
Daylight Saving Time Enable or disable daylight saving time function. When daylight
saving time is enabling, you need to configure the daylight saving
time period.

IPS-2042 Seris User’s Manual
ORing Industrial Networking Corp. 19
UTC Time zone Set the switch location time zone. The following table lists the
different location time zone for your reference.
Local Time Zone Conversion from UTC Time at 12:00 UTC
November Time Zone - 1 hour 11 am
Oscar Time Zone -2 hours 10 am
ADT - Atlantic Daylight -3 hours 9 am
AST - Atlantic Standard
EDT - Eastern Daylight -4 hours 8 am
EST - Eastern Standard
CDT - Central Daylight -5 hours 7 am
CST - Central Standard
MDT - Mountain Daylight -6 hours 6 am
MST - Mountain Standard
PDT - Pacific Daylight -7 hours 5 am
PST - Pacific Standard
ADT - Alaskan Daylight -8 hours 4 am
ALA - Alaskan Standard -9 hours 3 am
HAW - Hawaiian Standard -10 hours 2 am
Nome, Alaska -11 hours 1 am
CET - Central European
FWT - French Winter
MET - Middle European
MEWT - Middle European Winter
SWT - Swedish Winter
+1 hour 1 pm
EET - Eastern European, USSR
Zone 1 +2 hours 2 pm
BT - Baghdad, USSR Zone 2 +3 hours 3 pm
ZP4 - USSR Zone 3 +4 hours 4 pm
