Orion KRF08A-B-04E User manual

Spec. No. KRF08A-B-04E
OrionTradeName DRY PUMP 
Orion Model  KRF08A-B-04 
 Date: May 22, 2009
APPD CKD DWN
F
Yamada N Takei S Miyazawa
ORION MACHINERY CO., LTD.

Spec. No. KRF08A-B-04E

−1−
1. Warranty
1-1. Warranty period
The product shall be warranted for a period of one year from the date of purchase, or for
5000 hours of operation, whichever comes first.
1-2. Items exempted from warranty
①Consumable parts and periodic replacement parts.
② Fault caused by careless handling or improper use and maintenance. (Operation not
following the specifications and the instruction manual. Operation under abnormal
environmental conditions.)
③ Fault caused by fire, flood, lightning stoke, abnormal voltage or unforeseen disasters.
④ Fault caused by repair or modification not performed by ORION or ORION authorized
service contractors.
⑤Change of appearance, such as damage or deterioration caused in general use.
⑥Secondary damages caused by the fault (Incidental damages such as loss, inconvenience,
and commercial loss resulting from the failed product).
(Note) In case of a fault or an accident, contact the dealer with the model name and
serial number.

Spec. No. KRF08A-B-04E

−2−
2.Consumable parts / Periodic replacement parts
(1) Consumable parts (Parts to be replaced depending on the state at the time of inspection)
Name of Parts Parts Number Qty/ unit Inspection
period Replacement criterion
Filter element
(Inlet side) 04000028010 1 1 week
Whendamaged,ordirtcannotberemoved
byblowingair.
Filter element
(exhaust side) 04000028010 1 1 week
Whendamaged,ordirtcannotberemoved
byblowingair.
O-ring(65) 35154544040 2 Replacement
of element Whendamagedorworn.
Gasket (B) 04009579010 1 Removal of
SD case Whendamagedorworn.
Washer 33000300020 2 Removal of
SD case Whendamagedorworn.
Gasket 04100818010 4
When the cap
or case
attachment is
removed.
Whendamagedorworn.
Spring shaft 04100817010 2
Replacement
of element Whendamagedorworn.
Spring tube 04039359010 1 Replacement
of element Whendamagedorworn.
Spider 0400139610 1 6 months Whenitbecomesdamagedorcrushed.
Liner *1 040000370□0 To be decided by actual
positioning
Whentheblade
isreplaced. Whenitbecomesdamaged.
*1 The second digit from the right is subject to thickness.
0.2t(white)→1, 0.1t(black)→2, 0.05t(yellow)→3,0.03t(red)→4
(2) Replacement parts (Parts to be replaced at regular time intervals)
Name of Parts Parts No. Qty
/ unit
Replacement time
Blower 60kPa operation Blower 70kPa operation
Vane 04101753010 4 12,000 9,500
Bearing 0A000227000 2 12,000 9,500
*When vanes are replaced, replace bearing at the same time. Use ORION specified bearings
that are lubricated with special grease.

Spec. No. KRF08A-B-04E

−3−
* Use the maintenance kit for replacement parts.
(3) Motor Maintenance Cycle (An estimated indication of when motor replacement might be
necessary. Actual motor lifetime will depend on specific operating conditions.)
Part Name Part Number Specifications Qty ※Maintenance Cycle
Motor 0A001958000 Three phase 0.2kW 4P 1 20,000h
* Indicates the time when the chance of failure due to wear increases. The motor doesnot
necessarily require replacement after this time; the actual replacement time willdepend on
the operating conditions and environment of the particular installation. Please have the motor
replaced when operation becomes abnormal.
(4)Maintenance of plastic parts affecting operational safety
Replace the following plastic parts affecting operational safety promptly upon detection of
breakage or deformation. Failure to do so may cause personal injury.
NameofParts PartsNo. Qty/unit
Coupling cover (A) 02100771010 1
Coupling cover (B) 02100772010 1
Main cover assembly 03102492010 1
※To order a main cover assembly, check the pump model type and manufacturing number
shown on the name plate of the pump in use and advise us of these particulars.
Name of Parts Parts number Items Pcs / kit
Maintenance kit
08 Assembly 04101221010
Vane 4
Bearing 2
Liner (white) 4
Liner (black) 4
Liner (yellow) 6
Liner (red) 8

Spec. No. KRF08A-B-04E

−4−
3. Specifications Model KRF08A-B-04
Frequency Hz 50 60
Designed capacity *1 L/min 135 155
Continuous
operative
vacuum
Recommended
range *2 kPa 60 or less
Maximum
value *3 kPa 70
Diameter of piping connection Rc3/4
Motor
Phase / output/ pole Three-phase / 0.2kW / 4P
Frame no. / heat
resisting class 63M / E
Frequency / Rated
voltage – current
50Hz / 380V – 0.62A
400V – 0.64A
415V – 0.65A
60Hz / 400V – 0.55A
440V – 0.57A
460V – 0.58A
Setting for thermal protection
*4 A
50Hz / 380V – 0.68A
400V – 0.70A
415V – 0.72A
60Hz / 400V – 0.61A
440V – 0.63A
460V – 0.64A
Mass Kg 14
Painting color Black (except motor)
Installation condition
(Suction air)
Installation site Indoor
Permissible ambient
temperature deg.C 0 to 40
Permissible ambient
humidity %RH 65 ±20 (JIS Z8703)
Conditions
Corrosive or explosive gas must not exist
in ambient atmosphere.
Clean air with less dirt and dust, free of
vapor and dew condensation.
Operation noise *5 dB 64 67
*1 Designed Pumping Capacity: Theoretical value calculated from volume. Refer to Performance
Data for actual flow rate.
*2 Recommended range: Vacuum/pressure range the pump can exert its optimal performance (life,
operation noise, etc.). In case high degree of vacuum/pressure is not required, operate at
recommended range.
*3 Maximum value: The maximum degree of vacuum/pressure pump can continuously run. Do not
operate pump continuously over this limit. Doing so will shorten pump life and can lead to
premature failure or accidents.
*4 Setting for thermal protection is only as a guide regardless of variations of product performance.
*5 Operating noise level is only an actually measured value under continuous operational vacuum
and continuous operational pressure, and not guaranteed.

Spec. No. KRF08A-B-04E

−5−
EC DECLARATION OF CONFORMITY

Spec. No. KRF08A-B-04E

−6−
4. Precautions
(1) Observe precautions, and operate the product within specifications.
(2) Read the instruction manual prior to installation, operation, maintenance and inspection of
the product. Especially pay attention to safety.
(3) The vanes may get damaged if the residual pressure reverses the rotation when the pump
stops. A check valve must be installed within 50 cm from the inlet port or exhaust port for
protection.
(4) Be sure to install the product horizontally on the flat surface.
(5) Operating the product in an enclosed space may cause malfunction due to heat generated
from the pump. Provide good ventilation around the product, so the ambient temperature
does not exceed the permissible level.
(6) Be sure to clean the filters periodically. Failure to do so may cause clogging and result in
trouble due to overload.
(7) Wiring work has to be performed by qualified personnel according to applicable laws and
in-house regulations.
(8) Be sure to install an overload protection such as a thermal relay in the electric circuit.
(9) Allowable intermittent power supply voltage fluctuation range is ±10% of the specified voltage;
allowable sustained supply voltage fluctuation range is ±5% of the specified voltage.
(10) Be sure to use the product 1,000m or below above sea level.
5. Accessories
D type compound gaugeφ60
1 piece
Pressure controllerPC321 piece
Bushing  3/4×3/8 1 piece

Spec. No. KRF08A-B-04E

−7−
6. Pressure-Flow rate diagram
KRF08A−B−04
Condition: under 1 atmospheric pressure
20 deg.C
50Hz
60Hz

−８−
210
186
3.2
50
6318.5
D:Rc3/4
A:Rc3/4
B:Rc3/4
(232) 4×φ9.2
24040
305
10
(405)
65.5
40
Spec. No. KRF08A-B-04E
7. Dimensional Outline Drawing
C:Rc3/4
Outlet port
Outlet port
can be attached to A,B,C and D.
※The pressure controller
However, the outlet port
can only be attached to A and C.
(238)
(194)
Suction air
Suction air
(265)
Detail of terminal box
E
UWV
Power terminal
FIxing screw 3×M4
Knockout bushφ23
（terminal box hall）
Ground terminal
Fixing screw M5
