Ortovox Zoom+ User manual

S1+S1+S1+SMART-ANTENNA
BeSSer gefunden werden!
Automatische Umschaltung auf die optimale Sende-Antenne.
Be found eaSier!
Automatic switchover to the best transmission antenna.
etre retrouvé pluS facilement!
Connexion automatique à l‘antenne émettrice optimale.
Sarete trovati più facilmente!
Commutazione automatica alla migliore antenna trasmittente.
¡Se localiza máS fácilmente!
Conmutación automática a la antena emisora óptima.
zoom+
Made in Germany
ortovox.com
geBrauchSanleitung
Lawinen-Verschütteten-Suchgerät
manual
Avalanche Transceiver
mode d‘emploi
DVA
iStruzioni per i‘uSo
Localizzatore a.r.t.va.
inStruccioneS de uSo
Aparato de búsqeuda de victimas de avalanchas
OX-GAL-ZOOM-COVER-130524-vh.indd 1-3 29.05.13 15:56

S1+S1+S1+SMART-ANTENNA
BeSSer gefunden werden!
Automatische Umschaltung auf die optimale Sende-Antenne.
Be found eaSier!
Automatic switchover to the best transmission antenna.
etre retrouvé pluS facilement!
Connexion automatique à l‘antenne émettrice optimale.
Sarete trovati più facilmente!
Commutazione automatica alla migliore antenna trasmittente.
¡Se localiza máS fácilmente!
Conmutación automática a la antena emisora óptima.
zoom+
Made in Germany
ortovox.com
geBrauchSanleitung
Lawinen-Verschütteten-Suchgerät
manual
Avalanche Transceiver
mode d‘emploi
DVA
iStruzioni per i‘uSo
Localizzatore a.r.t.va.
inStruccioneS de uSo
Aparato de búsqeuda de victimas de avalanchas
OX-GAL-ZOOM-COVER-130524-vh.indd 1-3 29.05.13 15:56

S1+SMART-ANTENNA-TECHNOLOGIE
die ortovox-geräte haBen
3 antennen (x, y, z) an Board
Bei der Suche kommen alle  Antennen zum Einsatz. Für die Anzeige
der Entfernung und der Laufrichtung dienen die x- und y-Antenne. Die
z-Antenne wird ausschließlich für die Feinsuche benötigt.
Die ORTOVOX Geräte S1+, 3+und zoom+können als einzige Geräte
auf dem Markt die Position der Antennen analysieren mit der Smart-
Antenna-Technologie Sowohl üBer die x-alS auch üBer die
y-antenne Senden.
Dadurch erhöht sich die Sendereichweite des Verschüttenen
enorm (bis zu doppelt) und wird dadurch wesentlich besser gefunden
(verBeSSerte SichtBarkeit)
vertikale poSition ohne Smart-antenna
=Schlechte SichtBarkeit
Eine vertikal ausgerichtete Sendeantenne (x-Antenne) strahlt nur
vertikal aus und verursacht eine schlechte Sichtbarkeit durch minimale
Flächenabdeckung (Reichweite) im Suchbereich. Ein vertikaler Sender
ohne Smart-antenna ist daher Schwerer zu finden.
vertikale poSition mit Smart-antenna
=Sehr gute SichtBarkeit
Die patentierte Smart-antenna-technologie löst das Problem
der schlechten Sichtbarkeit der vertikalen Position. Der Lagesensor
analysiert die Position des Gerätes in der Lawine und Schaltet
automatiSch auf die y-antenne um. Dadurch sendet die Antenne
wieder horizontal und vergrößert die Flächenabdeckung annäherend
auf maximale Reichweite.
X
Y
Z
© ortovox / Änderungen und Fehler vorbehalten. concept Dieter Kotlaba, Volker Heuer deSign www.volkerheuer.com
photo Leonhard Habersetzer
SMART
ANTENNA
S1+
cover Leonhard Habersetzer
OX-GAL-ZOOM-COVER-130524-vh.indd 5-6 29.05.13 15:56

 EN
ZOOM+SMART-ANTENNA-TECHNOLOGY
THE ORTOVOX DEVICES HAVE
THREE ANTENNAS (X, Y, AND Z)
All three antennas are used during SEARCHES. The x and
y antennas are used to display the distance and the direction
of movement. The z antenna is solely used for the fine search.
The ORTOVOX device S+, +and ZOOM+are the only devices
on the market that can analyze the position of the antennas using
smart antenna technology and TRANSMIT VIA BOTH THE X AND
THE Y ANTENNA.
This vastly increases (UP TO DOUBLES) the victim’s transmission
range, making him or her far easier to find (IMPROVED VISIBILITY).
VERTICAL POSITION WITHOUT SMART-ANTENNA
=poor visibility
A vertically positioned transmitter antenna (x antenna) only emits a
signal vertically and results in poor visibility due to minimum area
coverage (range) in the search area. A vertical TRANSMITTER WITHOUT
A SMART ANTENNA is therefore MORE DIFFICULT TO LOCATE.
VERTICAL POSITION WITH SMART-ANTENNA
=very good visibility
The PATENTED SMART-ANTENNA-TECHNOLOGY resolves this
problem of poor visibility in the vertical position. The position sensor
analyzes the device’s position in the avalanche and AUTOMATICALLY
SWITCHES TOTHE Y-ANTENNA. As a result, the antenna once again
transmits horizontally and expands the area coverage to almost the
maximum range, making it easier to locate victims in less time.
OX-GAL-ZOOM+-BUCH-vh.indd 26 06.06.13 15:48

EN 
ZOOM+
GEBRAUCHSANLEITUNG - 
Lawinen-Verschütteten-Suchgerät
DEUTSCH
ENGLISH
MANUAL  - 
Avalanche Transceiver
MODE D‘EMPLOI  - 
DVA
FRANÇAIS
ISTRUZIONI PER I‘USO  - 
Localizzatore a.r.t.va.
ITALIANO
INSTRUCCIONES DE USO  - 
Aparato de búsqueda de victimas de avalanchas
ESPAÑOL
 - 
SERVICE
OX-GAL-ZOOM+-BUCH-vh.indd 27 06.06.13 15:48

 EN
ZOOM+
IT COULDN‘T BE EASIER!
The ZOOM+combines the SIMPLEST handling with
the LATEST technology and the MOST ADVANCED
design. Reduced to two functional buttons, the
ZOOM+concentrates on intuitive usability. The
focus on the clearly designed LED display is on the
on / o switches and the switch between transmit-
ting and searching. Distances, directional arrows
and information about multiple avalanche victims
guide you in the FASTEST way to the refined search
area, with the INTUITIVE search acoustics making
victims easier to locate. Equipped with the patented
SMART-ANTENNA-TECHNOLOGY™, avalanche
victims are found much better with the ZOOM+.
The device analyzes its position in the avalanche
and automatically switches to the BEST TRANS-
MISSION ANTENNA. The latest digital -antenna
technology is utilized at ORTOVOX just as much as
the automatic switchover in case of a follow-up
avalanche.
Valuable information on how to help companions,
accident prevention and the latest safety products
from ORTOVOX can be found at:
www.ortovox.com
You can reach us by e-mail at
[e-mail]
ORTOVOX hopes you have wonderful, safe trips!
MANUAL
ENGLISH
RECCO
REFLECTOR
INSIDE!
So professional
rescuers can quickly
find avalanche
victims! The backup
technology is used
by more than 
ski areas and rescue
teams around the
world.
ocial
supplier
OX-GAL-ZOOM+-BUCH-vh.indd 28 06.06.13 15:48

EN 
ZOOM+










OPERATING ELEMENTS
ON/OFF switch
Battery compartment
SEARCH GUIDANCE
- Signal search
- Coarse search
- Fine search
Sliding switch
“search mode”
Sliding switch
“transmission mode”
Direction arrow
Distance indicator
Multiple signal indicator
Loudspeaker
 Transmission
monitoring light
OX-GAL-ZOOM+-BUCH-vh.indd 29 06.06.13 15:48

 EN
ZOOM+REGISTRATION / INFO
If you desire, we will regularly
inform you about updates and
the latest news in relation to
our emergency equipment.
This keeps you up to date
at all times.
EXTENDED WARRANTY
Register your ZOOM+at:
www.ortovox.com/registration
In doing so, your warranty period
will extend from two to five years
from the date of purchase.
Avalanche transceivers are designed
to support the assistance oered
by companions in the event of
avalanche burial.
Your presence in areas where
avalanche hazards exist is fraught
with potential risk. The eective
use of an avalanche transceiver
requires appropriate training and
constant practice.
ORTOVOX strongly recommends
that you carefully read the operating
instructions provided with the
avalanche transceiver and take
the appropriate avalanche educa-
tion courses.
In addition, always take a shovel
and a probe when you go o-piste
in areas where avalanche hazards
exist, and never head out alone.
Plan your o-piste activities using
the current avalanche report at:
www.ortovox.com
Before you enter an area at risk of
an avalanche, you should make sure
that all avalanche transceivers are
working properly and all batteries
are in good condition.
The ZOOM+ fulfills the maximum
safety requirements and is charac-
terized by its simple operation!
OX-GAL-ZOOM+-BUCH-vh.indd 30 06.06.13 15:48

EN 
ZOOM+INSTRUCTIONS
HOW TO CARRY THE DEVICE
IMPORTANT NOTICE
People with pacemakers should wear the ZOOM+on the right
side of their body. It is essential to observe the pacemaker
manufacturer’s instructions!
The ZOOM+is carried close to your body in the
comfort carrier bag () and should always
be covered by at least one layer of clothing.
In warmer temperatures, the ZOOM+can also
be carried in a zippered pant pocket (not in
sewn-on pockets).
In TRANSMISSION MODE,
no electronic devices
(wireless devices, mobile
phones, other avalanche
transceivers) or other metal objects
should be located in the immediate
vicinity (within a few centimeters).
In SEARCH MODE other electronic
devices should be switched o
or carried at a distance of at least
 cm away.
Interference can also be caused
by approaching storms, lifts and
power systems.
AVOIDING INTERFERENCE

OX-GAL-ZOOM+-BUCH-vh.indd 31 06.06.13 15:48

 EN
ZOOM+INSTRUCTIONS


SWITCHING ON
Turn the ON/OFF switch () clockwise.
The rotary switch clicks into the position
“ON” and is now secured against being
unintentionally switched o.
SWITCHING OFF
Press in the ON-OFF switch () to unlock
it then turn it counter-clockwise to the
“OFF” position.
After switching on the ZOOM+,
the -digit serial number appears.
The automatic self-test begins
with the display check.
The transmitter, receiver, smart antenna,
and sensors are then tested.
The remaining battery capacity is also
displayed as a percentage (e.g. “”).
For further information about the battery, see p. 
The installed software version then follows (e.g. “.”)
INITIAL USE
SELF-TEST, TRANSMISSION MODE (device in transmission mode)
OX-GAL-ZOOM+-BUCH-vh.indd 32 06.06.13 15:48

EN 
ZOOM+

TRANSMISSION
Once the self-test has successfully concluded,
the ZOOM+will transmit and the transmission
lights flash ( ) on the screen.
After the self-test, the smart antenna
function is shown on the display for
 seconds.
If positioned horizontally, the
ZOOM+transmits on the X-antenna.
If positioned vertically, the
ZOOM+transmits on the Y-antenna.
SMART ANTENNA
X
Y
Z
INSTRUCTIONS
OX-GAL-ZOOM+-BUCH-vh.indd 33 06.06.13 15:48

ZOOM+
 EN
FAULT
INSTRUCTIONS
If a malfunction or fault is detected during
the self-test, “EE” appears on the screen.
A warning can be triggered in the immediate
vicinity of a transmitting avalanche transceiver,
mobile phone, wireless appliance, large metal
objects, or particularly strong magnetic fields.
If the malfunction warning is displayed during the self-test, repeat
the test while outside in interference-free surroundings.
When doing so, it is essential to make sure that no other transmitters
are nearby. SWITCH OFF ALL SOURCES OF INTERFERENCE (mobile
phones, wireless devices etc.) or move them well away.
If the warning is displayed again, the device must be sent to the ORTOVOX
service department.
For further information about the service, see p. .
During the partner check, the transmission
signal of the other participants’ avalanche
transceivers is checked.
•Switch on the ZOOM+ by turning
the ON/OFF switch () clockwise.
PARTNER CHECK

OX-GAL-ZOOM+-BUCH-vh.indd 34 06.06.13 15:48

ZOOM+
EN 
INSTRUCTIONS
•Switch the ZOOM+to locating.
Push the two sliding switches ()
outward simultaneously.
•If the partner device is transmitting,
the screen will display the distance
(e.g. “.”) from the transmitter.
•Only one transmission signal can ever
be tested at a time. The minimum distance
during the partner check is  m;
the distance to other transmitters
must be at least  m.
•If there are no transmitters within the
reception area of the ZOOM+, the dynamic
“signal search” symbol (“S”) appears on
the screen.

OX-GAL-ZOOM+-BUCH-vh.indd 35 06.06.13 15:48

ZOOM+
X
 EN
INSTRUCTIONS
Simultaneously press apart
both SLIDING SWITCHES ().
The TRANSMISSION SWITCH
OVER BUTTON () springs up.
The search situation is automatically
displayed on the screen.
SEARCHING - LOCATING - RESCUING 

PHOTO Klaus Fengler
SIGNAL SEARCH
Search the avalanche debris in
the indicated manner during the
signal search.
When using the ZOOM+, a search
strip width of  m (equates to
- steps) must not be exceeded.
The distance from the edge of
the avalanche must remain less
than  m.
At the same time, keep an eye
out for objects or partially buried
victims.
VICTIM’S POINT OF
DISAPPEARANCE KNOWN
If the point of disappearance is
known or objects are visible, the
search area is narrowed down to
below this point in the avalanche
flow direction.
This can save valuable time.
< m
< m
OX-GAL-ZOOM+-BUCH-vh.indd 36 06.06.13 15:48

ZOOM+INSTRUCTIONS


EN 
X
Y
Z
COARSE SEARCH
Hold the ZOOM+in a horizontal
position during the coarse search!
From a distance of approx.  m
to the avalanche victim, move the
direction pointer () and distance
indicator () along the field line to
the target point.
The distance indicator () goes
down and confirms that you are
getting closer.
INTUITIVE SEARCH ACOUSTICS
After the first signal, move
quickly during your search.
The intuitive search acoustics
confirm your approach.
At  m you should move slower
and get more precise in your
search. An acoustic change will
help you to do so. PHOTO Klaus Fengler
SEVERAL SEARCHERS
The searchers move across the search area in parallel.
The distance between the searchers must remain less than  m.
After first signal: QUICK
Under m: SLOW
Fine search: PRECISE
< m < m
< m
OX-GAL-ZOOM+-BUCH-vh.indd 37 06.06.13 15:48

 EN
ZOOM+


INSTRUCTIONS
FINE SEARCH
The fine search starts automatically
when you are . m away.
The direction arrow is switched o.
The closer you are to the victim,
the lower the distance displayed ()
and the faster the intuitive search
acoustic signal beeps ().
During the fine search,
determine the smallest
distance.
Move the device for-
ward and back once
and left and right once
in a cross shape.
Do not turn the ZOOM+
during this process!
The smallest distance
corresponds to the
burial depth.
PHOTO Klaus Fengler
OX-GAL-ZOOM+-BUCH-vh.indd 38 06.06.13 15:48

EN 
ZOOM+INSTRUCTIONS
PINPOINTING (PROBING)
Mark the point with the smallest
distance reading (using crossed
poles or a shovel).
To now determine the precise
location of the victim, probe in
the displayed  cm grid.
Insert the probe quickly and
deeply at a ° angle to the snow.
A clear decrease in the penetration
depth indicates a hit.
The probe remains in the ground
as a point of reference while you
dig out the victim.
DIGGING OUT
Read the burial depth ()
on the probe. Move this
distance down the slope
and start shoveling in a
V-shape.
If there are several res-
cuers, the person shove-
ling at the top should cut
out blocks. Those behind
should shovel and move
the snow away. The air
passages should be
exposed as quickly as
possible.
TIP Shovels with a CLEARING FUNCTION can save valuable time.
cm

PHOTO Klaus Fengler
OX-GAL-ZOOM+-BUCH-vh.indd 39 06.06.13 15:48

 EN
ZOOM+
m
m
m
m
INSTRUCTIONS
SEARCHING FOR MULTIPLE VICTIMS
Once the first victim has been located and rescued, the remaining
avalanche area is searched for additional victims. To this end, the ZOOM+
oers the useful multiple signal indicator ().
As soon as you get closer to the second victim, the search
indicator switches to this signal. The switchover is indicated by ALL
THE DIRECTION ARROWS FLASHING as well as acoustically.
The search for the second victim occurs.
If multiple victims (, ) are
located WITHIN the reception
area ( m), the multiple signal
indicator ILLUMINATES.
The close-range area is searched
using the three-circle method
or in micro search strips.
Once multiple victims (, )
are located in CLOSE PROXIMITY
(under  m), the multiple signal
indicator starts to FLASH.
The search is conducted
in  m search strips
(see figure on p. )
OX-GAL-ZOOM+-BUCH-vh.indd 40 06.06.13 15:48

EN 
ZOOM+

INSTRUCTIONS
SIGNAL OVERLAP
The transmission signals are measured and analyzed by the ZOOM+.
If several transmission signals are received that are transmitting
at the same time then a signal overlap occurs.
The signals overlap and can no
longer be technically distinguished.
In the worst cases, this can last
for several seconds.
A signal overlap is illustrated
without a direction arrow e.g. “”
and with the multiple signal
indicator () illuminated.
You must wait until the signal
overlap period has passed before
you continue your search.
 Sec
AUTOMATIC TRANSMISSION SWITCH OVER
In the event of a SECONDARY AVALANCHE
to which you fall victim (with your device
in search mode), the ZOOM+automatically
switches to transmission mode after  min-
utes of non-movement. This is indicated by
a -second warning tone.
This makes it possible for you to also
be found if buried in an avalanche while
searching.
OX-GAL-ZOOM+-BUCH-vh.indd 41 06.06.13 15:48

 EN
ZOOM+INSTRUCTIONS

CHANGING THE BATTERY
(when the device is switched o)
Remove the screw from the battery
compartment () and insert a new battery
(.V, alkaline, AA, mignon, LR ).
When changing the battery, make
sure the polarity is correct. See the
labeling in the battery compartment.
BATTERY
Remove the battery from the ZOOM+
during the summer months.
In the case of damage due to batteries that
have run out, the ORTOVOX warranty lapses.
ORTOVOX recommends that you change the battery when its remaining
capacity falls below %.
RECHARGEABLE BATTERIES
NEVER use rechargeable batteries (such as nickel-cadmium
batteries, lithium-ion batteries etc.).
Rechargeable batteries have a significantly lower operating voltage,
and thus a lower range and limited service life. In addition, defective
rechargeable batteries cannot be detected immediately.
After recharging they initially show the full operating voltage,
only to severely drop o again after a very short operating period
(THIS CAN BE VERY DANGEROUS).
OX-GAL-ZOOM+-BUCH-vh.indd 42 06.06.13 15:48
