Panasonic MX-GX1061WTN User manual

Panasonic Corporation © 2013 Unauthorized copy-
ing and distribution is a violation of law.
Order No. PMX1308005CE
Blender
Model No. MX-GX1061WTN
MX-GX1061WTZ
Chassis
Product Color White
Destination WTN: PGF,Qatar,Oman,Egypt
WTZ: Saudi,Kuwait,UAE,Nigeria
TABLE OF CONTENTS PAGE PAGE
1 Safety Precautions----------------------------------------------- 2
2 Specifications ----------------------------------------------------- 3
3 Location of Controls and Components ------------------- 4
4 Operating Instructions------------------------------------------ 5
5 Troubleshooting Guide----------------------------------------11
6 Disassembly and Assembly Instructions ---------------12
7 Wiring Connection Diagram ---------------------------------17
8 Exploded View and Replacement Parts List -----------19

2
1 Safety Precautions

3
2 Specifications
When the blender is used When the dry mill& wet mill are used
Power supply 220-240V ~ 50-60Hz
Power consumption 185-205W
Rated duration Continuous (Repetition 3 min. ON, 1 min. OFF) 90 seconds at a time
Container capacity Maximum 1,000mL Dry:Maximum 50g / Wet:Maximum 200mL
Container material Glass Glass
Dimensions (H x W x D) Approx. 36.6 x 16.0 x 20.6cm Approx. 26.8 x 15.1 x 20.6cm
Weight Approx. 2.7kg Approx. 1.9kg

4
3 Location of Controls and Components

5
4 Operating Instructions
4.1. How to Use Blender

6

7
4.2. How to Use Dry& Wet Mill

8

9
4.3. Safety

10
4.4. How to Clean

11
5 Troubleshooting Guide

12
6 Disassembly and Assembly Instructions
6.1. Juice Cup and Cutter Assy
1. Remove the cover, then turn the juice cup up-side-down.
2. Secure the juice cup and turn the cup base assy counter
clockwise. Then the packing can be removed.
3. The safety device lever from the cup base assy can be
removed after its three screws are loosened.

13
4. Turn the connector upper clockwise with long nose pliers.
Then the cutter assy and connector upper can be removed.
6.2. Mill Cup and Cutter Assy
1. Secure the mill cup and turn the cup base assy counter
clockwise. Then the mill packing can be removed.
2. The safety device lever from the cutter base assy can be
removed after its three screws are loosened. (Make not
lose a spring).

14
3. Turn the connector upper clockwise with long nose pliers.
Then the cutter assy and connector upper can be removed.
6.3. Bottom Plate
1. The bottom plate can be removed when its four screws
are ossened.

15
6.4. Connector (Lower)
1. Hold the part under the motor shaft by means of a
screws-driver, then turn the connector (lower) clockwise.
The connector (lower) can be removed.
• The connector (lower) can be relatively easily removed
by means of hitting its projecting section clockwise with
use of a screwdriver grip in a forceful manner.
6.5. Cord U
1. Pull out while the faston terminal with the part of the
cord U.

16
6.6. Motor Assy
1. Pull out while the faston terminal with the part of the lead
wire.
2. Takes out a motor from the body and it removes.
The brush can be exchanged by metal fittings coming
when bending fixation metal fittings.
6.7. Switch Assy
1. Pull out the switch assy in the direction of the arrow
shown in the figure to the right.
2. Remove the safety device and seal cap from the body.

17
7 Wiring Connection Diagram
7.1. Schematic Diagram

18
7.2. Basic Wiring Diagram

19
8 Exploded View and Replacement Parts List
8.1. Parts Location
32
33
34
35
35
35
36
36 36
37
32
31
30
29
28
26
27
25
38
38
39
42 40
41
43 43
43
9
11 11
44
45
11
46
1
7
8
5
12
13
3
4
6
14
15
16
17
18
20
21 21
23
24
19
2

20
8.2. Replacement Parts List
Notes:Important safety notice
• Components identified by mark have special characteristics important for safety.
• " When replacing any of these components use only manufacturer's specified parts."
MODEL No. MX-GX1061WTN/WTZ
Safety Ref. No. Part No. Part Name & Description Pcs/Set Remarks
WTN WTZ
<PARTS LIST>
1 X0190-470 Cup Assy(Juice-glass) 1 1
2 X0201-240 Cover 1 1
3 X0203-320 Juice Cup 1 1 glass
4 X0205-100 Packing 1 1
5 X0195-190 Cup Base Assy 1 1
6 X0224-180 Cutter Assy 1 1
7 X0217-010 Wave Washer 1 1
8 X0227-031 Main Shaft Washer 1 1
9 X0194-070 Cup Base U 1 1
11 X0925-010 Screw 3 3
12 X0227-060 Shaft washer 1 1
13 X0411-100R Connector (Upper) 1 1
14 X0190-460 Mill Cup Assy 1 1
15 X0203-390 Mill Cup 1 1 glass
16 X0205-070 Mill Packing 1 1
17 X0195-200 Mill Base Assy 1 1
18 X0224-100 Mill Cutter Assy 1 1
19 X0227-031 Main Shaft Washer 1 1
20 X0194-080 Mill Cup Base 1 1
21 VE18-200 Safety Device Lever Spring 3 3
23 X0227-060 Shaft Washer 1 1
24 X0411-030R Connector U (Upper) 1 1
25 VB99-184H0 Connector Lower 1 1
26 X0110-810 Body U 1 1
27 X0109-190 Body 1 1
28 X0175-240 Attention Sheet 1 1
29 X0104-010 Seal Cap 1 1
30 X0505-050 Safety Device Pin 1 1
31 X0501-480 Switch Assy 1 1 2key
32 X0103-020 Body Cover Gum 3 3
33 X0701-680 Motor Assy 1 1 thickness 20mm
34 X0130-200 Bottom Plate 1 1
35 X0133-020 Leg 3 3
36 XTN4T16BFJ Torx Screw 4 4
37 X0173-950 Name Plate 1
37 X0174-050 Name Plate 1
38 X0560-020 Cord U 1
38 X0560-030 Cord U 1
39 X0420-040 Scraper 1 1
40 X0213-110 Safety Device Lever(A) 1 1
41 X0213-120 Safety Device Lever(B) 1 1
42 X0213-130 Safety Device Lever(C) 1 1
43 X0925-010 Screw 3 3
44 X0213-080 Safety Device Lever(D) 1 1
45 X0213-090 Safety Device Lever(E) 1 1
46 X0213-100 Safety Device Lever(F) 1 1
<PACKING SPECIFICATIONS>
X0911-320 Protection A 1 1
X0912-320 Protection B 1 1
X0904-280 Carton Box 1 1
X0921-2102 Operation Book 1 1
X0917-020 Paper Plate 1 1
X0922-010 PE Bag 1 1 for cord
