Panasonic FP7 Series User manual

Introduction
Thank you for buying a Panasonic product. Before you use the product, please carefully read
the installation instructions and the user’s manual, and understand their contents in detail to
use the product properly.

Table of Contents
ii
Types of Manual
•There are different types of user’s manual for the FP7 series, as listed below. Please refer to
a relevant manual for the unit and purpose of your use.
•The manuals can be downloaded on our website:
https://industrial.panasonic.com/ac/e/dl_center/manual/
Unit name or purpose of use
Manual name
Manual code
FP7 Power Supply Unit
FP7 CPU Unit User’s Manual (Hardware) WUME-FP7CPUH
FP7 CPU Unit
FP7 CPU Unit Command Reference Manual WUME-FP7CPUPGR
FP7 CPU Unit User’s Manual
(Logging Trace Function) WUME-FP7CPULOG
FP7 CPU Unit User’s Manual (Security Function) WUME-FP7CPUSEC
Instructions for Built-in
LAN Port
FP7 CPU Unit User’s Manual
(LAN Port Communication) WUME-FP7LAN
FP7 CPU Unit User’s Manual
(Ethernet Expansion Function) WUME-FP7CPUETEX
FP7 CPU Unit User’s Manual
(EtherNet/IP Communication) See our web site.
FP7 Web Server Function Manual See our web site.
Instructions for Built-in
COM Port
FP7 series User’s Manual (SCU communication) WUME-FP7COM
FP7 Extension Cassette
(Communication)
(RS-232C/RS485 type)
FP7 Extension Cassette
(Communication)
(Ethernet type)
FP7 series User’s Manual (Communication
cassette Ethernet type) WUME-FP7CCET
FP7 Extension (Function)
Cassette
Analog Cassette
FP7 Analog Cassette User’s Manual WUME-FP7FCA
(Upcoming)
FP7 Digital Input/Output Unit FP7 Digital Input/Output Unit User’s Manual WUME-FP7DIO
FP7 Analog Input Unit FP7 Analog Input Unit User’s Manual WUME-FP7AIH
FP7 Analog Output Unit FP7 Analog Output Unit User’s Manual WUME-FP7AOH
Thermocouple Multi-analog
Input Unit Thermocouple multi-analog input unit
RTD input unit
User’s Manual
WUME-FP7TCRTD
RTD Input Unit
FP7 High-speed Counter Unit FP7 High-speed counter Unit User’s Manual WUME-FP7HSC
FP7 Pulse Output Unit FP7 Pulse Output Unit User’s Manual WUME-FP7PG
FP7 Positioning Unit FP7 Positioning Unit User’s Manual WUME-FP7POSP
FP7 Serial Communication
Unit FP7 series User’s Manual (SCU communication) WUME-FP7COM
FP7 Multi Input / Output Unit FP7 Multi Input / Output Unit User’s Manual WUME-FP7MXY
FP7 Motion Control Unit FP7 Motion Control Unit User’s Manual WUME-FP7MCEC
FP7 Multi-wire Link Unit FP7 Multi-wire Link Unit User’s Manual WUME-FP7MW
PHLS System PHLS System User’s Manual WUME-PHLS
Programming Software
FPWIN GR7 FPWIN GR7 Introduction Guidance WUME-FPWINGR7

Table of Contents
iii
Table of Contents
1. Add-ons Specifications ..................................................... 1-1
1.1 Ethernet Add-ons .................................................................................. 1-2
1.1.1 Overview of Add-ons ...............................................................................1-2
1.1.2 Using Add-ons.........................................................................................1-4
1.1.3 IP Address Setting Specifications ...........................................................1-6
1.1.4 Recommended Connection Settings.......................................................1-8
1.2 I/O Allocation ...................................................................................... 1-10
1.2.1 I/O Relay Related to Built-in ET-LAN Function .....................................1-10
1.2.2 +Built-in ET-LAN common occupied area.............................................1-10
1.2.3 I/O Relays of Extended Connections ....................................................1-12
1.2.4 Confiming and Setting I/O Map .............................................................1-14
2. Extension of the Number of Connections ........................ 2-1
2.1 Overview of Extension of the Number of Connections........................... 2-2
2.2 How to Use Add-on for the Number of Connections.............................. 2-3
2.2.1 Setting with Tool Software ......................................................................2-3
2.2.2 Instructions Used in Master Communication ..........................................2-4
3. Routing Setting .................................................................. 3-1
3.1 Overview of Routing Setting.................................................................. 3-2
3.2 How to Use Routing Setting .................................................................. 3-3
3.2.1 Setting with Tool Software ......................................................................3-3

Table of Contents
iv
4. FTP Client Function ........................................................... 4-1
4.1 Overview of FTP Client Function ...........................................................4-2
4.2 FTP Client Function Specifications ........................................................4-3
4.2.1 FTP Client Specifications ........................................................................4-3
4.2.2 Connection Method .................................................................................4-3
4.3 Details of FTP Client Function ...............................................................4-4
4.3.1 Basic Setup .............................................................................................4-4
4.3.2 File Transfer Setting ................................................................................4-4
4.3.3 Logging/Trace Transfer Settings .............................................................4-5
4.3.4 Overwrite Method and Rename Method .................................................4-6
4.4 How to Use File Transfer.......................................................................4-8
4.4.1 Setting with Tool Software.......................................................................4-8
4.4.1.1 Basic Setup ....................................................................................4-8
4.4.1.2 FTP File Transfer Settings (Sending and Overwriting File) .........4-10
4.4.1.3 FTP File Transfer Settings (Sending and Renaming File) ...........4-12
4.4.1.4 FTP File Transfer Settings (Getting File) .....................................4-14
4.4.1.5 FTP File Transfer Settings (Sending and Overwriting Device) ....4-16
4.4.1.6 FTP File Transfer Settings (Sending and Renaming Device)......4-18
4.4.1.7 FTP File Transfer Settings (Getting Device) ................................4-20
4.4.2 Setting with Instructions ........................................................................4-22
4.4.2.1 Destination Server Setting (FTPcSV) ..........................................4-23
4.4.2.2 Transfer Settings (FTPcSET).......................................................4-30
4.4.3 Executing File Transfer with Instructions ..............................................4-39
4.4.3.1 Requesting Transfer (FTPcREQ).................................................4-39
4.4.3.2 Transfer Control (FTPcCTL) ........................................................4-42
4.4.3.3 Information Acquisition of Ethernet Unit (ETSTAT) .....................4-45
4.5 How to Use Logging/Trace Transfer ....................................................4-54
4.5.1 Setting with Tool Software.....................................................................4-54
4.5.1.1 Basic Setup ..................................................................................4-54
4.5.1.2 Logging/Trace Transfer Settings (Send Overwrite) .....................4-54
4.5.1.3 Logging/Trace Transfer Settings (Send Rename) .......................4-56

Table of Contents
v
4.5.2 Settings with Instructions ......................................................................4-58
4.5.2.1 Logging/Trace Transfer Settings (FTPcLOG) ..............................4-58
4.5.2.2 Confirming the Execution of Transfer with Instruction .................4-61
4.6 Precautions When Using FTP Client ................................................... 4-62
4.6.1 Precautions for FTP Client Operation ...................................................4-62
4.6.2 Precautions When Setting FTP Client ..................................................4-62
4.6.3 Number of Transferable Data and Processing Time.............................4-63
5. HTTP Client Function......................................................... 5-1
5.1 Overview of HTTP Client Function ........................................................ 5-2
5.2 Details of HTTP Client Function ............................................................ 5-3
5.3 How to Use Transfer Settings ............................................................... 5-4
5.3.1 Setting with Tool Software ......................................................................5-4
5.3.1.1 Basic Setup .................................................................................... 5-4
5.3.1.2 HTTP Transfer Settings - Send (Upload).......................................5-6
5.3.1.3 HTTP Transfer Settings - Get (Download).....................................5-8
5.3.1.4 HTTP Transfer Settings - Send and Get (Upload and Download)5-10
5.3.2 Setting with Instructions ........................................................................5-12
5.3.2.1 Destination Server Setting (HTTPcSV)........................................5-12
5.3.2.2 Transfer Settings (HTTPcSET) ....................................................5-18
5.3.3 Executing Transfer with Instructions .....................................................5-24
5.3.3.1 Transfer Request (HTTPcREQ) ...................................................5-24
5.3.3.2 Transfer Control (HTTPcCTL)......................................................5-27
5.3.3.3 Status Acquisition of Ethernet Unit (ETSTAT) .............................5-30
5.4 Precautions When Using HTTP Client ................................................ 5-31
6. Mail Transmission Function .............................................. 6-1
6.1 Overview of Mail Transmission Function............................................... 6-2
6.2 Details of Mail Transmission Function................................................... 6-3
6.2.1 Basic Setup .............................................................................................6-3

Table of Contents
vi
6.2.2 Event Mail Setting ...................................................................................6-3
6.2.3 Logging/Trace Mail Setting......................................................................6-3
6.3 How to Use Event Mail Transmission ....................................................6-4
6.3.1 Setting with Tool Software.......................................................................6-4
6.3.2 Settings with Instructions.......................................................................6-11
6.3.2.1 Destination Server Setting (SMTPcSV) .......................................6-12
6.3.2.2 Destination Group Setting (SMTPcADD) .....................................6-19
6.3.2.3 Mail Transmission Settings (SMTPcSET)....................................6-23
6.3.2.4 Set Mail Text (SMTPcBDY)..........................................................6-34
6.3.2.5 Read Mail Text (SMTPcBRD) ......................................................6-37
6.3.2.6 Create Text (PRINT) ....................................................................6-40
6.3.3 Sending Mails with Instructions.............................................................6-51
6.3.3.1 Mail Send Request (SMTPcREQ)................................................6-51
6.3.3.2 Mail Send Control (SMTPcCTL)...................................................6-54
6.3.3.3 Information Acquisition of Ethernet Unit (ETSTAT) .....................6-57
6.4 How to Use Logging/Trace Mail Transmission.....................................6-58
6.4.1 Setting with Tool Software.....................................................................6-58
6.4.2 Setting with Instructions ........................................................................6-61
6.4.2.1 Logging/Trace Mail Setting (SMTPcLOG) ...................................6-61
6.4.2.2 Confirming the Execution of Transmission with Instruction .........6-65
6.5 Precautions When Using Mail Transmission Function .........................6-66
7. Instruction References ...................................................... 7-1
7.1 List of Instructions Added to CPU Ver.3.................................................7-2
7.2 IP Address and Connection Setting Instructions ....................................7-3
7.2.1 IPv4SET ..................................................................................................7-3
7.2.2 CONSET..................................................................................................7-8
7.2.3 OPEN ....................................................................................................7-15
7.2.4 CLOSE ..................................................................................................7-17
7.3 Communication Instruction ..................................................................7-19

Table of Contents
vii
7.3.1 General-purpose Communication Send Instruction Leading Edge
Execution (PGPSEND) .........................................................................7-19
7.3.2 PING Request Instruction (PINGREQ) .................................................7-23
7.4 Special Instruction............................................................................... 7-26
7.4.1 Obtaining Starting Word Number of Specified Slot (GETSTNO)..........7-26
7.5 Comparison Instruction ....................................................................... 7-27
7.5.1 Block Comparison (BCMP) ...................................................................7-27
8. Common Items ................................................................... 8-1
8.1 List of Common Items ........................................................................... 8-2
8.1.1 List of SD29 Detail Codes .......................................................................8-2
9. MC Protocol Communication Function ............................ 9-1
9.1 Overview of MC Protocol Communication Function .............................. 9-2
9.1.1 MC Protocol Communication ..................................................................9-2
9.1.2 Communication Specifications of MC Protocol .......................................9-3
9.1.3 I/O Relays Used for MC Protocol Communication..................................9-3
9.2 How to Use MC Protocol Communication ............................................. 9-4
9.2.1 Setting with Tool Software ......................................................................9-4
9.3 Communication Format......................................................................... 9-5
9.3.1 Format of Command Response ..............................................................9-5
9.3.2 Command and Subcommand .................................................................9-6
9.3.3 Format of Request Data Part and Response Data Part..........................9-7
9.3.4 Device Codes and Device Numbers .......................................................9-9
9.4 Bulk Read and Bulk Write ................................................................... 9-11
9.4.1 Example of Bulk Read...........................................................................9-11
9.4.2 Example of Bulk Write...........................................................................9-14
9.5 Exit Codes When Communication Error Occurs.................................. 9-16
9.6 MC Protocol Master Communication (RECV)...................................... 9-17

Table of Contents
viii
9.6.1 Reading Data From External Devices...................................................9-17
9.6.2 RECV Instruction (MC Protocol) ...........................................................9-19
9.7 MC Protocol Master Communication (SEND) ......................................9-21
9.7.1 Writing Data to External Devices ..........................................................9-21
9.7.2 SEND Instruction (MC Protocol) ...........................................................9-23

1
Add-ons Specifications

Add-ons Specifications
1-2
1.1 Ethernet Add-ons
1.1.1 Overview of Add-ons
Expansion of the number of connections
•The number of user connections has been expanded to the maximum of 216 so that the unit
can communicate with more devices.
(Note): As for the general-purpose communication, the maximum number of connections is 16.
Routing setting function
•When a partner device exist in a different network and that network is located in a place
through a router other than the default gateway, the routing setting should be required.
FTP client function
•Enables the transfer of files and data.
•Supports SSL transfer.
•Four FTP servers can be set.
•Sixteen transfer settings can be registered.
•Four transfer modes can be set.
PUT file / GET file / PUT data / GET data
•The logging trace done file can be transfered
HTTP client function
•Enables the communication with WEB servers.
•Supports SSL communication.
•Four WEB servers can be set.
•Sixteen transfer settings can be registered.
•Three transfer modes can be set.
Send (Upload) / Get (Download) / Send and get (Upload and download)
Mail send function
•Enables mail transmission.
•Supports SSL communication.
•One SMTP server can be set.
•Eight destination groups can be set.
•Sixteen transfer settings can be registered.
•The following five communication triggers can be set.
Bit device / Cycle / Time / Instruction / PLC status change
•Files can be transferred at the the time of completion of logging trace.

1.1 Ethernet Add-ons
1-3
Additional instructions
Classification Name Function
IP address and connection setting
instructions
IPv4SET IP address setting
CONSET User connection setting
OPEN Connection open
CLOSE Connection close
FTP client instructions
FTPcSV FTP client connected server setting
FTPcSET FTP client transfer setting
FTPcLOG FTP client logging/trace transfer setting
FTPcREQ FTP client transfer request
FTPcCTL FTP client transfer control
HTTP client instructions
HTTPcSV HTTP client connected server setting
HTTPcSET HTTP client transfer setting
HTTPcREQ HTTP client transfer request
HTTPcCTL HTTP client transfer control
Mail send (SMTP client)
instructions
SMTPcSV Mail send server and sender settings
SMTPcADD Destination group setting instruction
SMTPcSET Mail send setting instruction
SMTPcREQ Mail send request instruction
SMTPcLOG Logging/trace mail send setting instruction
SMTPcCTL
SMTPc transfer control
Communication instructions
ETSTAT Ethernet unit status read
PGPSEND General-purpose communication send instruction
leading edge execution
PINGREQ PING request instruction (Note)
Special instruction GETSTNO Starting word number acquisition of target slot
Data comparison instruction BCMP Matched blocks detection
(Note): The PINGREQ instruction is supported from the CPU unit version 3.2.

Add-ons Specifications
1-4
1.1.2 Using Add-ons
Activating Add-ons
•For using each function for extending the number of user connections, the routing setting,
FTP client, HTTP client and mail transmission (SMTP client), change "Add-on" to "Use" in
Built-in ET-LAN setting dialog box.
•When "Add-on" is set to "Not use", each communication task does not start.

1.1 Ethernet Add-ons
1-5
FTP client settings, HTP client settings and Mail settings
•When "Add-on" is set to "Use" in FP7 configuration, each communication task can be
activated.
•When setting in the setting windows of FPTc, HTTPc and mail settings, the functions are
automatically activated.
•When executing the server settings with the server setting instructions (FTPcSV, HTTPcSV,
SMTPcSV), the functions are activated at that point.
Check the box of "Use FTP client function" in FTP
client settings to activate the task of FTP client.
Check the box of "Use HTTP client function" in HTTP
client settings to activate the task of HTTP client.
Check the box of "Use Mail Transmission Function" in
Mail settings to activate the task of mail function.

Add-ons Specifications
1-6
1.1.3 IP Address Setting Specifications
List of usable IP addresses
Address range
Remarks
000.000.000.001 to 000.255.255.255 *1
001.000.000.000 to 126.255.255.255
128.000.000.000 to 223.255.255.255
*1: Although this range can be set, try not to use it as much as possible.
List of conditional IP addresses
○: Available, ×: Not available, △: Self IP address is not available. Default gateway is available.
Address range Setting with instruction Setting with tool software
E1 E2 E3 T1 T2 T3
000.000.000.000 △××△○×
127.000.000.000 to 127.255.255.255 ×○○×○○
224.000.000.000 to 224.255.255.255 ×○○×○○
：×○○×○○
239.000.000.001 to 239.255.255.255 ×○○×○○
240.000.000.001 to 240.255.255.255 ×○○×○○
：×○○×○○
247.000.000.001 to 240.255.255.255 ×○○×○○
248.000.000.001 to 248.255.255.255 ×○○×○○
： × ○ ○ × ○ ○
255.000.000.001 to 255.255.255.254 ×○○×○○
255.255.255.255 ×○××××
(Note 1): The marks E1 to E3 and T1 to T3 in the above list indicate the combinations in the following table.
Mark
Description
E1 Self IP address setting with IPv4SET instruction
E2 Destination address setting with CONSET instruction
E3 Server address setting with FTPcSV, HTTPcSV, SMTPcSV and IPv4SET instructions.
T1 Self IP address (IPv4) setting with tool software
T2 SNTP IP address (name), priority DNS server, alternative DNS server and router IP address
settings with tool software
T3 System connection IP addresses 1 to 4 and user connection IP addresses 1 to 16 (max. 216)
with tool software
(Note 2): When an IP address that cannot be set is specified with an instruction, an operation error will not occur and
the error flags of CY (SR9) and SD29 will be set.

1.1 Ethernet Add-ons
1-7
Netmask setting
Masked bits should be registered in ascending order. It is not possible to set bits as follows.
Input notation Binary notation
255.255.253.0 11111111.11111111.11111101.00000000
Default gateway setting
•It may not be set according to the combination of IP address and default gateway.
•When it is not used, specify 000.000.000.000.
•It cannot be set in the following case.
(IP address AND netmask) ≠(Default gateway address AND netmask)
Judgement using the combination of IP address and netmask
•The following combination is not possible.
•IP address AND (Inverse all bits of netmask: 1's complement) = 0
•IP address OR (netmask) = 255.255.255.255
•Only when the router IP address is other than 000.000.000.000, the above combination
judgement is performed for the routing setting.
*The above combination may occur when setting to omit masks with IPv4SET instruction.
Example) When the netmask is 255.255.0.0, set the IP address to 0.0.255.255 with IPv4SET.
The set values for IP addresses, netmask and default gateway are initialized when performing
the communication process with the above combination. The defaults are as follows.
•IP address =192.168.1.5, Netmask = 255.255.255.0, Default gateway = 192.168.1.1

Add-ons Specifications
1-8
1.1.4 Recommended Connection Settings
Settings for slave communication
Communication method
TCP
UDP
Open method (Server/Client) Server connection
(destination unit arbitrary) -
Open method (Automatic/Manual) Open automatically
Destination unit port No. - 0
Destination unit IP address - 0
Home unit port No. Specify Specify
For using TCP with slave communication, server connection (destination unit arbitrary) is recommended.
For using UDP with slave communication, it is recommended to set the destination unit port number to 0,
and the destination unit IP address to 0.
Recommended setting example (TCP/IP) Recommended setting example (UDP/IP)
Even for slave communication, select client connection for establishing the connection from the slave side.
•Connection setting on the slave side
Open method (Server/Client) Client connection
Destination unit port No. Specify
Destination unit IP address Specify
Home unit port No. 0
•Communication procedure
Slave side
Master side
Connect
Communication command
Response

1.1 Ethernet Add-ons
1-9
Settings for master communication
Communication method
TCP
UDP
Open method (Server/Client) Client connection Server connection
(destination unit arbitrary) -
Open method (Automatic/Manual) Open automatically
Destination unit port No. Specify - Specify
Destination unit IP address Specify - Specify
Home unit port No. 0 Specify 0
For using TCP (client) and UDP for master communication, it is recommended to set the home unit port number to 0.
Recommended setting example (TCP/IP)
Recommended setting example (UDP/IP)
Even for master communication, select server connection for establishing the connection from the slave side.
•Connection setting on the master side
Open method (Server/Client) Server connection
(destination unit arbitrary)
Destination unit port No. -
Destination unit IP address -
Home unit port No. Specify
•Communication procedure
Master side
Slave side
Connect
Communication command
Response

Add-ons Specifications
1-10
1.2 I/O Allocation
1.2.1 I/O Relay Related to Built-in ET-LAN Function
For using each function of the built-in ET-LAN, the following I/O areas are occupied.
List of the number of occupied words and I/O points
Unit type Application
No. of occupied words (No. of occupied
points)
Input
Output
CPU
unit
Built-in ET-
LAN
Common occupied area 1 word (16 points)
WX6 -
User connections 1 to 16 3 words (48 points)
WX7 to WX9
3 words (48 points)
WY7 to WY9
User connections 17 to 216
Max. 26 words (416
points)
WX11 to WX36
Max. 26 words (416
points)
WX7 to WX9
(Note 1): Input/output contacts of the CPU unit are allocated for using the functions of each cassette. Regardless of
use of such functions, input occupies 10 words (160 points, WX0 to WX9) and output occupies 10 words (160
points, WY0 to WY9).
(Note 2): Occupied area in the area of user connections 17 to 216 varies according to the number of used
connections.
(Note 3): The starting numbers of I/O contacts of each unit including the CPU unit can be changed by the setting of
the tool software.
1.2.2 +Built-in ET-LAN common occupied area
When using the Ethernet-related functions, flags for confirming the initialization, connection of
network and the completion of preparation are allocated.
Allocation of common occupied areas
Address Application
X60 Disconnection detection relay 1 = Disconnect 0 = Connect
X61 Ethernet initialization active 1 = During initialization 0 = Completed
X62
IP address establishment
1 = Establish
0 = Not establish
X63 Reserved for system
X64 FTP server preparation done 1 = Preparation done 0 = Unsable
X65 FTP client prepartion done 1 = Preparation done 0 = Unsable
X66 Reserved for system
X67 Reserved for system
X68 HTTP client preparation done 1 = Preparation done 0 = Unsable
X69 Mail send (SMTP client) preparation done 1 = Preparation done 0 = Unsable
X6A-X6F Reserved for system
