Panasonic KX-VC300 User manual

Operating Manual
HD Visual Communication Unit
Model No. KX-VC300/KX-VC600
Document Version: 2012-03
In this manual, the suffix of each model number (e.g., KX-VC600NA) is omitted unless necessary.
Thank you for purchasing this Panasonic product.
Please read this manual carefully before using this product and save this manual for future use.
KX-VC300/KX-VC600: Software File Version 2.40 or later

Introduction
Feature Highlights
DCE
*1
DCE
*1
Video camera
Display
Microphone
Router
Internet
Router
Microphone
Video camera
Display
*1 DCE: Data Circuit-terminating Equipment
Lifelike Visual Communication
You can experience lifelike visual communication*1 with smooth, high-quality video and clear stereo*2 sound.
*1 If you are using the KX-VC300, sending images in Full HD can only be done by purchasing an activation key card (KX-VCS401) to
activate this feature (Page 107).
*2 If using 2 or more Digital Boundary Microphones, stereo output can be enabled through system settings (Page 95). When using
Digital Boundary Microphones and an Analog Boundary Microphone together, stereo output may be unavailable depending on the
connection configuration (Page 25, Page 27).
Home Electronics-style Remote Control Operation and Simple, Easy to
Understand Graphical User Interface
You can make settings and perform operations using familiar remote control operations and a simple, easy to
understand interface.
Stabilized Communication Quality
In periods of network congestion, automatic packet transmission rate quality control prevents packet loss to
maintain a video conference call’s image and sound quality. This allows visual communication with stabilized
communication quality even over an Internet connection.
Remote Video Camera Operation via Remote Control
You can move your own video camera up, down, left, and right as well as zoom in and out (Page 59). You
can also register up to 9 preset patterns of video camera direction and zoom level which allows you to easily
2 Operating Manual Document Version 2012-03
Introduction

change the video camera’s direction and zoom level by selecting a preset (Page 61, Page 63). Additionally,
you can also use your remote control to control the other party’s video camera.*1
*1 To be able to control another party’s video camera, settings must be configured on the other party’s unit (Page 92).
Selectable Video Source
By connecting your computer or video camera to the unit, you can show your computer’s screen or video
camera image to video conference call participants (Page 69, Page 76).
Encrypted Communication
Packets sent for video conference calls can be encrypted to prevent packet leaks, tampering, or
eavesdropping.
KX-VC Series NAT Traversal Service
"KX-VC Series NAT Traversal Service" is a service that allows you to easily and affordably set up and operate
a communication environment for the HD Visual Communication Unit.*1*2 Also, complicated router configuration
is unnecessary, which allows even people who are not network administrators set up a communication
environment. Furthermore, you can assign the unit a unique number (Terminal ID), which allows the unit to be
called not by IP address, but with the unique 7-digit number. This means communication can be initiated as if
calling a telephone. Communication can also be encrypted, so that you can communicate over the Internet
safely and securely.
For details about KX-VC Series NAT Traversal Service, refer to the following web site:
http://panasonic.net/psn/products/hdvc/nat_traversal/index.html
*1 This service may be unavailable depending on the country/area of use. For details, contact your dealer.
*2 This service may be unavailable depending on your router’s type or your Internet connection environment. For details, contact your
dealer.
Making Video Conference Calls via SIP Server
By using a SIP server, you can establish video conference calls not just by IP address, but also by specifying
a SIP URI (SIP user name@SIP domain name) instead. If the other party uses the same SIP domain name
as you, you can make a video conference call by specifying only the SIP user name (Page 105). For information
about supported SIP servers, contact your dealer.
Enhanced Features through the Use of Activation Keys
By using an activation key (sold separately), you can upgrade the features of the KX-VC300 (Page 83). After
you upgrade the features, the KX-VC300 can initiate 3-party/4-party video conference calls and send images
in Full HD resolution. Features enabled through activation keys are available even after performing a system
initialization (Page 107). For details about the activation key, contact your dealer.
Connection to non-Panasonic Video Conference Systems
You can connect to a non-Panasonic video conference system and have a 2-party video conference call
(Page 48).*1
*1 For details about the types of non-Panasonic video conference systems you can connect to, contact your dealer. Communication
cannot be encrypted when you connect to a non-Panasonic video conference system. Instead, connect over an intranet or via a VPN
(Virtual Private Network).
Document Version 2012-03 Operating Manual 3
Introduction

MCU Connection
By connecting to an MCU (multipoint control unit), you can make multiple-party video conference calls with 5
or more parties, rather than the normal maximum of 4 parties (Page 49).*1
*1 For details about the types of MCUs you can connect to, contact your dealer. Communication cannot be encrypted when you connect
to an MCU. Instead, connect over an intranet or via a VPN (Virtual Private Network).
4 Operating Manual Document Version 2012-03
Introduction

Trademarks
•HDMI is a trademark or registered trademark of HDMI Licensing LLC in the United States and other
countries.
•Polycom® is a trademark owned by Polycom, Inc. in the US and other countries.
•All other trademarks identified herein are the property of their respective owners.
Licenses
•This product is licensed under the AVC Patent Portfolio License. This license permits the end user to
perform, for personal and non-commercial use, only the following actions:
–Encode video in compliance with the AVC Standard (below, "AVC Video").
–Decode AVC Video that was encoded by a consumer engaged in both personal and non-commercial
activity.
–Decode AVC Video obtained from a video provider licensed to provide AVC Video.
Additional information may be obtained from MPEG LA, LLC. See http://www.mpegla.com.
•This product incorporates G.722.1 and G.722.1 Annex C licensed by Polycom®.
Open Source Software
Parts of this product use Open Source Software supplied based on the conditions of the Free Software
Foundation’s GPLs and/or LGPLs and other conditions. Relevant conditions apply to this software. Therefore,
please read license information about GPLs and LGPLs, and information about other Open Source Software
in the included CD-ROM before using this product. Also, some software parts of this product are licensed under
the MOZILLA PUBLIC LICENSE (MPL). At least three (3) years from delivery of products, Panasonic will give
to any third party who contacts us at the contact information provided below, for a charge of no more than the
cost of physically distributing source code, a complete machine-readable copy of the corresponding source
code and the copyright notices covered under GPL, LGPL, and MPL. Please note that software licensed under
GPL, LGPL, and MPL is not under warranty.
Contact Information
http://www.panasonic.net/corporate/global_network/
Miscellaneous
About the Screen Shots and Illustrations in this Manual
The screen shots, illustrations and descriptions in this manual are based on using the KX-VC600. If you are
using the KX-VC300, please note that some displayed features will not be available for your model.
Document Version 2012-03 Operating Manual 5
Introduction

Precaution
Notice for users in California
This product contains a CR coin cell lithium battery that
contains perchlorate material—special handling may
apply.
See www.dtsc.ca.gov/hazardouswaste/perchlorate
Information on disposal in other countries outside the European
Union
These symbols are only valid in the European Union. If you wish to discard these items, please contact your
local authorities or dealer and ask for the correct method of disposal.
6 Operating Manual Document Version 2012-03
Introduction

Table of Contents
For Your Safety ......................................................................................10
For Your Safety ...............................................................................................................10
Before Operation ....................................................................................14
Notes about Operation ...................................................................................................14
Data Security ...................................................................................................................15
Privacy and Right of Publicity .......................................................................................15
Federal Communications Commission Requirements ................................................16
Preparation .............................................................................................17
Accessory Information ...................................................................................................17
Part Names and Usage ...................................................................................................18
Main Unit (Front) ............................................................................................................18
Main Unit (Back) .............................................................................................................19
Remote Control ..............................................................................................................21
Boundary Microphone (Optional Accessory) ..................................................................22
LED Patterns ..................................................................................................................23
Screen Standby ..............................................................................................................23
Connecting the Unit ........................................................................................................24
Turning the Power On/Off ..............................................................................................30
Screen Display ................................................................................................................31
Home Screen (Idle Screen) ............................................................................................31
Menu Screen (Idle Screen) ............................................................................................32
Video Conference Call Screen .......................................................................................34
Starting a Video Conference .................................................................36
Making a Video Conference Call ....................................................................................36
Calling Using Speed Dial (2-party Conference/3-party Conference/4-party
Conference) ....................................................................................................................36
Calling from the Contact List (2-party Conference/3-party Conference/4-party
Conference) ....................................................................................................................39
Calling by Entering an Address Directly .........................................................................41
Calling from the Call History ...........................................................................................44
Answering a Video Conference Call ..............................................................................47
Connecting to a Non-Panasonic Video Conference System ......................................48
Connecting to an MCU ....................................................................................................49
Changing the Screen Layout ................................................................51
Changing the Screen Layout during a 2-party Video Conference Call ......................51
Changing the Screen Layout during a 3-party Video Conference Call ......................53
Changing the Screen Layout during a 4-party Video Conference Call ......................56
Controlling a PTZ Camera .....................................................................59
Controlling a PTZ Camera ..............................................................................................59
Registering a Preset .......................................................................................................61
Recalling a Registered Preset ........................................................................................63
Adjusting the Volume and Tone ...........................................................64
Adjusting the Volume .....................................................................................................64
Muting the Microphone ...................................................................................................65
Reducing Microphone Noise (KX-VC600 only) .............................................................67
Adjusting the Tone ..........................................................................................................68
Document Version 2012-03 Operating Manual 7
Table of Contents

Displaying Other Video Sources ..........................................................69
Displaying a Computer’s Screen ...................................................................................69
Displaying the Sub Video Camera’s Image ..................................................................76
Displaying the Connection Status ........................................................80
Displaying the Connection Status .................................................................................80
Displaying Unit Information ...........................................................................................81
About Enhanced Features .....................................................................83
Activating Enhanced Features .......................................................................................83
Overview of Activation Keys ...........................................................................................83
Enabling Multiple-Party Video Conference Calls (KX-VC300 only) ................................83
Enabling the Sending of Images in Full HD Resolution (KX-VC300 only) ......................83
Contacts and Settings ...........................................................................84
Adding Contacts to the Contact List .............................................................................84
Registering a New Contact .............................................................................................84
Editing Contact Information ............................................................................................85
Deleting a Contact ..........................................................................................................86
Registering a Contact from the Call History ...................................................................86
Changing System Settings .............................................................................................88
Setting the Unit Name ....................................................................................................88
Setting the Date and Time ..............................................................................................89
Making Network Settings ................................................................................................89
Making Connection Settings ...........................................................................................90
Making Screen Standby Settings ...................................................................................93
Making Sound Settings ..................................................................................................93
Setting the MIC Position (KX-VC600 only) .....................................................................94
Making Remote Control Settings ....................................................................................96
Making Language Settings .............................................................................................98
Making Multicast Setting ................................................................................................98
Performing System Maintenance ..................................................................................99
Display Unit Information .................................................................................................99
Checking Enhanced Features ........................................................................................99
Performing a Network Test .............................................................................................99
Performing Self Diagnosis ............................................................................................100
Performing Remote Maintenance .................................................................................101
Making Administrator Menu Settings ..........................................................................102
Logging in to the Administrator Menu ...........................................................................102
Making Administrator Password Settings .....................................................................102
Making Encryption Settings ..........................................................................................103
Making Software Update Settings ................................................................................104
Making Connection Mode Setting ................................................................................105
Making SIP Settings .....................................................................................................105
Performing System Initialization ...................................................................................107
Activating Enhanced Features .....................................................................................107
Updating Software ........................................................................................................108
Making Audio Input Settings .........................................................................................109
Saving the Operation Log .............................................................................................110
Making HDMI Settings (for Checking Operation) .........................................................111
Making Local Site Settings ...........................................................................................111
Registering a Local Site ...............................................................................................111
Selecting a Local Site ...................................................................................................114
Editing Local Site Information .......................................................................................115
8 Operating Manual Document Version 2012-03
Table of Contents

Deleting Local Site Information ....................................................................................115
Input ......................................................................................................116
Inputting Letters and Numbers ....................................................................................116
Miscellaneous .......................................................................................121
Changing the Remote Control Batteries .....................................................................121
Cleaning the Unit ...........................................................................................................122
Additional Information .........................................................................123
Troubleshooting ............................................................................................................123
Basic Operation ............................................................................................................123
Audio ............................................................................................................................128
System Settings ...........................................................................................................129
If These Messages Appear ..........................................................................................130
Miscellaneous ...............................................................................................................137
Specifications .......................................................................................138
System Specifications ..................................................................................................138
Index............................................................................................................140
Document Version 2012-03 Operating Manual 9
Table of Contents

For Your Safety
To prevent personal injury and/or damage to property,
be sure to observe the following safety precautions.
The following symbols classify and describe the
level of hazard and injury caused when this unit is
operated or handled improperly.
WARNING
Denotes a potential hazard that could result in
serious injury or death.
CAUTION
Denotes a hazard that could result in minor injury or
damage to the unit or other equipment.
The following types of symbols are used to classify
and describe the type of instructions to be
observed. (The following symbols are examples.)
This symbol is used to alert users to a specific
operating procedure that must not be performed.
This symbol is used to alert users to a specific
operating procedure that must be followed in order
to operate the unit safely.
WARNING
General
Follow all warnings and instructions
marked on the unit.
Power
The power source voltage of this unit is
listed on the nameplate. Only plug the
unit into an AC outlet with the proper
voltage. If you use a cord with an
unspecified current rating, the unit or
plug may emit smoke or become hot to
the touch.
Do not connect the unit to the AC outlet,
AC extension cords, etc., in a way that
exceeds the power rating of, or does not
comply with the instructions provided
with, the AC outlet, AC extension cords,
etc.
Connect the AC adaptor firmly to the
power cord, and plug the power cord
firmly into an AC outlet. Otherwise, it can
cause fire or electric shock.
Do not pull, bend, rest objects on, or
chafe the power cord, plug, and AC
adaptor. Damage to the power cord or
plug can cause fire or electric shock.
To prevent fires, electric shock, injury, or
damage to the unit, be sure to follow
these guidelines when performing any
wiring or cabling:
a. Before performing any wiring or
cabling, unplug the unit’s power cord
from the outlet. After completing all
wiring and cabling, plug the power
cord back into the outlet.
b. Do not place any objects on top of
the cables connected to the unit.
c. When running cables along the floor,
use protectors to prevent the cables
from being stepped on.
d. Do not run any cables under
carpeting.
10 Operating Manual Document Version 2012-03
For Your Safety
For Your Safety

Do not attempt to repair the power cord,
plug, or AC adaptor. If the power cord or
plug is damaged or frayed, contact an
authorized service representative for a
replacement.
Ensure that the plug connection is free
of dust. In a damp environment, a
contaminated connector can draw a
significant amount of current that can
generate heat, and eventually cause fire
if left unattended over an extended
period of time.
Stop operation immediately if the unit
emits smoke, excessive heat, abnormal
smell or unusual noise. These conditions
can cause fire or electric shock.
Immediately turn the unit off, and unplug
the power cord, and contact your dealer
for service.
Never touch the plug or AC adaptor with
wet hands. Danger of electric shock
exists.
When disconnecting the unit, grasp the
plug instead of the cord. Pulling on a
cord forcibly can damage it, and cause
fire or electric shock.
During thunderstorms, do not touch the
unit, plug and AC adaptor. It may cause
an electric shock.
Operating Safeguards
Do not alter the AC adaptor or modify
any parts. Alteration or modification can
cause fire or electric shock.
If metal fragments or water gets into the
unit, turn the unit off and unplug the unit
immediately. Contact your dealer for
service. Operating the contaminated unit
can cause fire or electric shock.
Do not use a unit in the vicinity of a gas
leak to report the leak.
Do not place the remote control in
microwave ovens or on induction
cookware.
Clean the AC plug periodically with a
soft, dry cloth to remove dust and other
debris.
Do not use the supplied power cord with
any other device. It may cause fire or
electric shock.
Unplug the unit from the AC outlet and
have it serviced by qualified service
personnel in the following cases:
a. If the unit does not operate
according to the operating
instructions. Adjust only the controls
that are explained in the operating
instructions. Improper adjustment of
other controls may result in damage
and may require service by a
qualified technician to restore the
unit to normal operation.
b. If the unit has been dropped or the
cabinet has been damaged.
c. If unit performance deteriorates.
If damage to the unit exposes any
internal parts, disconnect the power cord
immediately and return the unit to your
dealer.
Do not use your headset at a high
volume. The use of excessive sound
volume through a headset may cause
hearing loss.
Installation
Do not install the unit in any other way
than described in relevant manuals.
Do not touch the unit, AC adaptor, AC
adaptor cord, or power cord during a
lightning storm.
Only connect the unit to the type of
electric power specified on the label
affixed to the unit. Confirm the type of
electric power supplied to the installation
site if necessary.
Document Version 2012-03 Operating Manual 11
For Your Safety

Battery
The battery contains diluted sulfuric
acid, a very toxic substance. If the
battery leaks and the liquid inside spills
on the skin or clothing, immediately
wash it off with plenty of clean water. If
the liquid splashes into eyes,
immediately flush the eyes with plenty of
clean water and consult a doctor.
Sulfuric acid in the eyes may cause loss
of eyesight and acid on the skin will
cause burns.
Do not charge, short, heat, break or
throw in a fire, as it may result in the
battery leaking, generating heat, or
bursting.
Do not connect the positive terminal and
the negative terminal of the battery to
each other with any metal object (such
as wire).
Do not carry or store the batteries
together with necklaces, hairpins, or
other metal objects.
Do not mix old and new batteries or
different types of batteries.
Batteries that seem worn down or
damaged should not be used. Using
worn down or damaged batteries may
result in leaking.
Do not use rechargeable batteries.
Take the depleted batteries out of the
remote control. Otherwise, the batteries
may leak.
CAUTION
Power
When the unit is not used over an
extended period of time, take the
batteries out of the remote control.
Otherwise, the batteries may leak. Do
not use the leaked batteries.
When the unit is not used over an
extended period of time, switch it off and
unplug it. If an unused unit is left
connected to a power source for a long
period, degraded insulation may cause
electric shock, current leakage, or fire.
The unit should be used only with the
power cord and AC adaptor enclosed
with the unit.
Installation
The unit should be kept free of dust,
moisture, high temperature (more than
40 °C [104 °F]) and vibration, and should
not be exposed to direct sunlight.
Place this unit on a flat surface. Serious
damage and/or injury may result if the
unit falls.
Allow 10 cm (4 in) clearance around the
unit for proper ventilation.
Do not place the unit in an area close to
fire. Doing so may cause fire.
Battery
Be sure to use the specified type of
batteries only.
Ensure that batteries are installed with
correct polarity. Incorrectly installed
batteries can burst or leak, resulting in
spillage or injuries.
12 Operating Manual Document Version 2012-03
For Your Safety

This product contains batteries. Replace
only with the same or equivalent type.
Improper use or replacement may cause
overheating, rupture or explosion
resulting in injury or fire. Dispose of used
batteries according to the instructions of
your local solid waste officials and local
regulations.
When replace the batteries for the
remote control, use AA/R6 type dry cell.
Do not install the battery backwards so
that the polarity is reversed.
Document Version 2012-03 Operating Manual 13
For Your Safety

Notes about Operation
Please pay attention to the following points when using
this device:
1. Please contact your dealer for installing,
upgrading, or repairing this device.
2. Do not forcefully hit or shake this device.
Dropping or bumping this device can damage or
break this device.
3. Do not place this device in a freezer or other
location where it is exposed to cold
temperatures.
Doing so may result in damage or malfunctions.
4. Place this device at least 2 m (6.5 ft) away from
radios, office equipment, microwave ovens, air
conditioning units, etc.
Noise from electronic devices can cause static and
interference in other devices.
5. Do not place this device in a location where it is
exposed to hydrogen sulfide, phosphorous,
ammonia, sulfur, carbon, acid, dirt, toxic gas,
etc.
Doing so may result in damage, and the usable
life-span of the device may decrease.
6. Do not apply insecticides or other volatile
liquids to the device, nor leave rubber bands or
vinyl objects on the device for extended periods
of time.
Doing so may result in alterations to the material or
paint peeling off the device.
7. Do not bring cards with magnetic strips, such
as credit cards and telephone cards, near the
microphone.
Cards might become unusable.
8. Do not bring the device near items that emit
electromagnetic waves or that are magnetized
(high-frequency sewing machines, electric
welders, magnets, etc.).
Doing so may result in static noise or damage.
9. Keep the device at least 10 cm (4 in) away from
all walls.
If placed against a wall, the device may not be able
to ventilate properly, which may lead to a system
malfunction due to overheating.
10. Avoid placing the device in areas with high
humidity, and exposing it to rain.
Neither the main unit nor the power plug is water
resistant.
11. The power outlet should be near the product
and easily accessible.
About the Operating Environment
This device includes a feature that automatically adjusts
voice transmissions to improve clarity. After beginning
a video conference call, adjustments to the call
environment may not complete immediately, and as a
result voices may cut out or echo. In such cases, at the
beginning of the video conference call, be sure to speak
in turn with other parties.
About Moving the Device
Do not move this device while cords are still connected.
Doing so may result in damage to the cords.
Other
•This device is a class A information technology
device. Using this device in a residential setting can
cause radio wave interference. In these cases, the
user may be responsible for taking appropriate
measures to prevent the interference.
•The unit may not operate in the event of a power
failure.
•After unpacking the product, dispose of the power
plug cap and packing materials appropriately.
•The illustrations and screenshots in this manual are
for reference only and may vary from the actual
product.
14 Operating Manual Document Version 2012-03
Before Operation
Before Operation

Data Security
We recommend observing the security precautions
described in this section, in order to prevent the
disclosure of sensitive information.
Panasonic is not responsible for any damages
caused by improper use of this device.
Preventing Data Loss
Keep a separate record of the encryption key and all
information stored in the contact list.
Preventing Data Disclosure
•Do not place this device in a location that can be
accessed or removed without authorization.
•If important information is saved on this device,
store it in an appropriate location.
•Do not store sensitive personal information in the
unit.
•In the following situations, make a record of the
encryption key and the information stored in the
contact list and return the unit to the state it was in
when purchased (Page 107).
–Before lending or disposing of the unit
–Before handing the unit over to a third party
–Before having the unit serviced
•Make sure the unit is serviced by only a certified
technician.
This device can register and store personal data (the
contact list, encryption key, connection history, etc.). In
order to prevent the disclosure of data stored on this
device, make sure to delete all data that is registered
and stored on this device prior to disposing of, lending,
or returning this device (Page 107).
Preventing Data Disclosure over the
Network
•To ensure the security of private conversations,
only connect the unit to a secure network.
•To prevent unauthorized access, only connect the
unit to a network that is properly managed.
•Make sure all computers connected to the unit
employ up-to-date security measures.
•To prevent illegal access from the Internet, activate
a Firewall.
Privacy and Right of
Publicity
By installing and using this device, you are responsible
for maintaining the privacy and usage rights of images
and other data (including sound picked up by the
microphone). Use this device accordingly.
•Privacy is generally said to be, "A legal guarantee
and right not to have the details of one’s personal
life unreasonably publicized, and the right to be able
to control information about oneself. In addition,
right of publicity is a right not to have a likeness of
one’s face or figure photographed and publicized
without consent".
•When the Automatic Answer feature is enabled,
transmission begins as soon as a video conference
call is received. The receiver of the video
conference call will begin transmitting as soon as
the video conference call is received at any time,
from any caller. Please be aware when the
Automatic Answer feature is enabled, there is a risk
that due to an unexpected, automatically answered
video conference call, privacy rights may be
violated or sensitive information may be transmitted
to unauthorized parties.
Document Version 2012-03 Operating Manual 15
Before Operation

Federal Communications Commission
Requirements
Federal Communications Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in accordance with the instructions
manual, may cause harmful interference to radio communications. Operation of this equipment in a residential
area is likely to cause harmful interference in which case the user will be required to correct the interference
at his own expense.
FCC Caution
To assure continued compliance, (example - use only shielded interface cables when connecting
to other devices). Any changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate this equipment.
16 Operating Manual Document Version 2012-03
Before Operation

Accessory Information
The following accessories are included:
Included Accessories
Accessories Quantity
AC adaptor (Part No.: PNLV6506) 1
Power cord 1
Remote control (Part No.: N2QAYB000674) 1
Batteries (AA dry cell) 2
CD-ROM (included manuals, etc.) 1
Note
•Product documentation may vary depending on the country/area of use.
Document Version 2012-03 Operating Manual 17
Preparation
Preparation

Part Names and Usage
Main Unit (Front)
AB
D E
C
Power LED
Shows the power status. The LED is green when the power is on and off when the power is off.
Remote Control Signal Receiver
Receives Remote Control signals. The maximum range of reception is approximately 8 m (26.2 ft) from
front of the unit, and approximately 3 m (9.8 ft) from 20° on each side, total 40°.
Headset Input-Output Terminal
Used to connect a headset to the unit (Page 28).
Note
•If a headset is connected, audio from the other party can be heard through the headset. Audio is
not played through the display or speakers.
•If a headset is connected, how audio is sent to the other party differs depending on the type of
devices connected as follows:
Connected Device Audio Sent to Other Party
Boundary Microphone Audio is picked up only by the headset microphone. Audio
is not picked up by the Boundary Microphones.
General-purpose microphone Both the general-purpose microphones and the headset
microphone pick up audio.
Boundary Microphone and
general-purpose microphone
Both the general-purpose microphones and the headset
microphone pick up audio. The Boundary Microphones do
not pick up audio.
Power button
Turns the power on and off (Page 30).
Status LED
Shows the operational status of the unit (Page 23).
18 Operating Manual Document Version 2012-03
Preparation

Main Unit (Back)
KX-VC600
A B C F GE
H I J OK L M N
D
KX-VC300
BD F GE
H I J OK L M N
Camera Control terminal (KX-VC600 only)
Not used.
RS-232C terminal
Not used.
MIC (Digital) jack (KX-VC600 only) (Page 24)
Used to connect the Digital Boundary Microphone (optional) (Page 22).
MIC (Analog) jack (Page 24)
Used to connect the Analog Boundary Microphone (optional) (Page 22).
Audio In L/R jack (Page 24)
Used to connect general-purpose microphones (not for the Boundary Microphone).
Audio Out L/R jack
Used to connect an amplifier or active speaker (Page 28). Also used to connect the speakers of a display
without an HDMI terminal for audio output (Page 29).
Functional Ground terminal
Used to connect a grounding wire for when there is a lot of noise over the connection.
LAN jack (Page 24)
Connect a LAN cable.
USB jack (Page 110)
Used to connect USB memory device for saving the operation log.
RGB terminal (Page 69)
Used to connect a computer for sending screens to participants.
Main Camera terminal (Page 24)
Connect the main video camera with an HDMI cable.
Sub Camera terminal (Page 76)
Used to connect a second, sub video camera with an HDMI cable for sharing video contents apart from
the main video camera.
Document Version 2012-03 Operating Manual 19
Preparation

HDMI terminal (Page 24)
Used to connect to the display with an HDMI cable.
Component terminal (Page 29)
Used to connect to the display with a component video cable.
DC IN (Page 25)
Connect the AC adaptor’s DC cord.
20 Operating Manual Document Version 2012-03
Preparation
