Panasonic KX-TS105B User manual

ORDERNO. KM40212005C1
J01
Telephone Equipment
KX-TS105B
Integrated Telephone System
Black Version
(for U.S.A.)
SPECIFICATIONS
1

2003 PanasonicCommunications Co., Ltd. All rights reserved.
Unauthorized copying and distribution isaviolation of law.
2

1. LOCATION OF CONTROLS
3

2. CONNECTION
2.1. Connecting the Handset/Telephone Line Cord
Afterconnection, lift the handset tocheck fora dial tone.
4

-Use onlyaPanasonicHandset for the KX-TS105B.
2.2. Connecting aCommunication Device
If you connect a communication device (computer, modem, fax, answering machine, etc.) tothe
telephone line, you canconnect it through this unit using the DATA jack.
Afterconnecting the handset and telephone line cord, connect the communication device
telephone line cordtothe DATA jack.
5

-Make sure the communication device isnot inuse before using
thisunit(making calls, storing phone numbers inmemoryetc.)or
the communication device maynot operate properly.
3. SETTINGS
3.1. Dialing Mode
You canselect the dialing mode byprogramming. If you have touchtone service, set to"Tone".
If rotaryorpulse service is used, set to"Pulse". Yourphone comes fromthe factoryset to
"Tone".
Make sure that a call is not put on hold.
6

3.2. Ringer Volume
You canselect the ringervolume toHIGH, LOW orOFF. Yourphone comes fromthe factoryset
toHIGH.
4. SPECIAL FEATURES
4.1. FLASHButton
4.2. Selecting the Flash Time
The flashtime depends on yourtelephone exchange orhost PBX. You canselect the following
flashtimes: "80, 90, 100, 110, 200, 250, 300, 400, 600, 700 ms (milliseconds)". Yourphone comes
fromthe factoryset to"600 ms".
Make sure that a call is not put on hold.
7

-Ifyou are connected viaaPBX, alonger flash time maybe
necessaryto use PBXfunctions (transferring acall, etc.). Consult
your PBXinstaller for the correct setting.
4.3. PINCode
A 4-digit PIN Code (Personal Identification Number) prevents unauthorizedpersons fromusing
yourunit. The PIN Code is requiredforthe dial lock and call restriction tobe set orcanceled.
The factorypreset PIN code is "1111".
Make sure that a call is not put on hold.
8

4.4. Dial Lock
You canprevent others frommaking a call toanynumberexcept the one pre-programmedin
the memoryof the EMERGENCY button. Once you lockedthe dialing buttons, evenemergency
numbers cannot be dialed. Onlyincoming calls are accepteduntil the dial lock is canceled.
Before using this feature, we recommend storing anemergencynumberinthe memoryof the
EMERGENCY button. Evenif the dialing buttons are locked, the numberstoredinthe button can
be dialed.
9

-Ifyou choose not to program emergencynumbers, but plan to use
the dial lock, anynumber programmed into the EMERGENCY
button can be accessed.
4.4.1. To Set the Dial Lock
4.4.2. To Cancel the Dial Lock
Followsteps 1 through 3 above again.
4.4.3. To Release the Establishment of Dial Lock
10

Afterthis procedure, you will be able toestablisha newpassword.
Howtorelease the establishment of dial lock.
11

4.5. Call Restriction
You canprevent the unit fromdialing phone numbers beginning withspecifieddigit(s) (1 digit
or2 digits). Phone numbers withthe restrictedleading digits cannot be dialedout.
4.5.1. To Set the Call Restriction
Make sure that a call is not put on hold.
12

-Ifyour unitisconnected to aPBX, thisfunction maynot operate.
Contact your PBXsupplier for more information.
5. REPLACEMENT PARTS LIST
Ref. No. Part No. Part Name & Description Pcs/Set
Remarks
A1 PQJA10075Z CORD, TELEPHONE 1
A2 PQJA212V CORD, HANDSET 1
A3 PQJXC0301Z HANDSET 1
A4 PQKL10038Y3 STAND, WALL MOUNT 1
A5 PQQW12497Z QUICK GUIDE (forSpanish) 1
A6 PQQW12576Z LEAFLET 1
A7 PQQX13158Y INSTRUCTION BOOK 1
13

6. FOR SCHEMATIC DIAGRAM (SCHEMATIC
DIAGRAM)
1. DC voltage measurements are taken with electronicvoltmeter
from negative terminal.
(Add 40 mAto telephone line from the loop simulator.)
2. Thisschematicdiagram maybe modified at anytime with the
development of new technology.
Important SafetyNotice: / Components identifiedbymark have special
characteristics important forsafety. Whenreplacing anyof these
components, use onlythe manufacturer´s specifiedparts.
6.1. Memo
7. SCHEMATIC DIAGRAM
H.M/ KXTS105B
14

Speaker Phone Outgoing Signal
Speaker Phone Incoming SignalHandset & Headset Incoming Signal
Handset & Headset Outgoing Signal
The voltage during ON-Hook is indicated.
( ) shows the voltage during OFF-Hook.
KX-TS105B : SCHEMATIC DIAGRAM
Battery Low
3.8V
3.9V
(5.7V)
4.2V
(5.8V)
4.5V
(6.3V)
3.7V
(3.7V)
(6.3V)
R115
0
R185
0
390K100K
R100
180
VOUT VCC
3
R315
0
(1~4) (5) (6) (7~9) (11~13) (14~17) (21~24) (25~26) (28~29)(10) (18)(19) (20) (27) (30) (31) (32) (33)
IC201
IC1
IC304 IC302
IC303

DTMF
Hold Music
Beep
(5.8V)
3.7V
(3.7V)
(1~4) (5) (6) (7~9) (11~13) (14~17) (21~24) (25~26) (28~29)(10) (18)(19) (20) (27) (30) (31) (32) (33)
IC651
IC601
IC801
IC903

Speaker Phone Outgoing Signal
Speaker Phone Incoming SignalHandset & Headset Incoming Signal
Handset & Headset Outgoing Signal
The voltage during ON-Hook is indicated.
( ) shows the voltage during OFF-Hook.
KX-TS105B : SCHEMATIC DIAGRAM
Battery Low
3.8V
3.9V
(5.7V)
4.2V
(5.8V)
4.5V
(6.3V)
3.7V
(3.7V)
(6.3V)
R115
0
R185
0
390K100K
R100
180
VOUT VCC
3
R315
0
(1~4) (5) (6) (7~9) (11~13) (14~17) (21~24) (25~26) (28~29)(10) (18)(19) (20) (27) (30) (31) (32) (33)
IC201
IC1
IC304 IC302
IC303
