INSTALLATION INSTRUCTIONS
© Panduit Corp. 2007
For Technical Assistance, Call: 800-777-3300
NET-ACCESS Overhead Cable Routing System
CRB6BL
1
¼-20x1 Hex Slotted
Panduit Part Numbers: CRB6BL, CRTB
2x
2x
2
FR38DR
Washer Head Machine
Screw
Typical: 4 Places
Typical: 4 Places
FR716DR
¼-20 Hex Washer
Lock Nut
NET-ACCESS Network Cabinet

INSTALLATION INSTRUCTIONS
For Technical Assistance, Call: 800-777-3300
2
3 4
1
CRTB

INSTALLATION INSTRUCTIONS
For Technical Assistance, Call: 800-777-3300
3
¼-20x1 Hex Slotted
FR38DR
Washer Head Machine
Screw
Typical: 4 Places
4
Typical: 4 Places
FR716DR
¼-20 Hex Washer
Lock Nut
¼-20x Hex Head Cap Screw
Typical: Both Sides
FR716DR ¼ Helical Spring Lockwasher
¼ SAE Flat Washer
58

17301 Ridgeland Avenue Fax: [phone]
Tinley Park, IL 60477-3901 Technical Support: 800-777-3300
Web Site: www.panduit.com E-mail: [e-mail]
WORLDWIDE SUBSIDIARIES AND SALES OFFICES
RACEWAY SYSTEMS DIVISION
INSTALLATION INSTRUCTIONS
Instruction Sheet RW230
FIBERRUNNER 4x4
FR716DR
-or-
FIBERRUNNER 6x4
-or-
FIBERRUNNER 12x4
CRTB
5 6
Ladder Rack
-or-
Cable Tray
-or-
Wire Basket
Typical Installation

INSTALLATION INSTRUCTIONS
For Technical Assistance, Call: 800-777-3300
Mounting Hole Location - Top*
6.00” (152.4mm) 12.75” (323.9mm)
0.38” - 0.50” (9.7mm - 12.7mm) dia
6.25” (158.8mm)
27.54” (699.5mm)
1.00” (25.4mm)
* If the NET-ACCESS Network Cabinet was supplied without the four (4) required pre-drilled mounting holes, the installer must drill four (4) 0.38” - 0.50” dia
Front
holes at the locations specified above.
