ParaBody 848 User manual

1
848 LAT OPTION
CLASSH
PART # 7080301
REV. B Revision: 07/10/01
USER’S GUIDE
WARNING:
Read and follow all directions
for each step to insure proper
assembly of this product.
Version: 848107

THERE IS A RISK ASSUMED BY INDIVIDUALS WHO USE THIS TYPE OF
EQUIPMENT. TO MINIMIZE RISK FOLLOW THESE RULES!
1. Before using, read all the warnings and instructions
on the use of this machine. Use only for intended
exercise. DO NOT modify the machine.
2. Obtain a medical exam before beginning any
exercise program.
3. Keep body and clothing free of all moving objects.
4. Inspect the machine before use. DO NOT use it if it
appears damaged. DO NOT attempt to fix a broken or
j
ammed machine. Notify your authorized ParaBody
dealer before use and have repairs made by an
authorized service technician.
5. Be certain that weight pin is completely inserted.
Use only the pin provided by the manufacturer. If
unsure, call your authorized ParaBody dealer.
6. Never pin the weights or prop plate into an elevated
position. DO NOT use the machine if found in this
condition. DO NOT attempt to fix. Notify your
authorized ParaBody dealer.
7. Inspect cables and their connections before using
machine. Pay particular attention to the cable ends.
DO NOT attempt to fix. Notify your authorized
ParaBody dealer before use and have repairs made by
an authorized service technician.
8. Make sure all spring loaded pull pins are fully
engaged in the adjustment position and fully tighten
thumbscrew before use.
9. Children must not be allowed near this machine.
Supervise teenagers.
.
IMPORTANT SAFETY INFORMATION
TABLE OF CONTENTS
Safety Statement.............2
General Notes..................3
Tools Required................3
NOTE: In a continual effort to improve our products, specifications are subject to change
2001 Life Fitness, a division of Brunswick Corporation. All rights reserved.
ParaBody is a trademark of Brunswick Corporation
www.parabody.com
2
Parts list..........................4
Assembly Instructions.....4-15
General Maintenance.......16
Warranty Statement..........17
Product Services..............18
Insert-Registration Card
©

IMPORTANT NOTES
Please note:
Tools Required forAssembly
* Thank you for purchasing the ParaBody 848 LAT OPTION. Please read these
instructions thoroughly and keep them for future reference. This product must be assembled
on a flat, level surface to assure its proper function.
* Rubber mallet or hammer
* 3/4” wrench
* 9/16” wrench
* Ratchet with 3/4” and 9/16” sockets
* Adjustable wrench
* Tape measure
3
NOTE:BOLTLENGTH IS MEASURED FROMTHEUNDERSIDE OFTHEHEADOFTHEBOLT.
BOLT LENGTH RULER:
* This product must be assembled on a flat, level surface to assure its proper function. DO NOT
securely tighten any frame connections until the entire frame has been assembled, unless
otherwise stated.
Bolt Length Ruler
0123456
1/2 1/2 1/2 1/2 1/2 1/2
BOLT LENGTH

4
0123456
1/2 1/2 1/2 1/2 1/2 1/2
PARTS LIST
PART #
6826608
6826908
6825408
6827208
6825502
6275302
6274402
6542402
6824801
3103102
3116201
6177001
6405201
6467001
6692601
6825101
KEY
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
QTY
1
1
1
1
1
1
1
2
2
4
6
2
4
2
3
1
PART #
3116001
6140701
3102501
3102802
3102502
3102801
3102933
3102903
3102922
3102935
3102910
3103801
3108102
6122703
6480301
6122701
DESCRIPTION
1-1/4” RUBBER BUMPER
1 X 1” GLIDE
3/8” WASHER
3/8” LOCK NUT
1/2” WASHER
1/2” LOCK NUT
3/8 X 2” BOLT
3/8 X 2-1/2” BOLT
3/8 X 2-3/4” BOLT
3/8 X 4-1/2” BOLT
1/2 X 3” BOLT
5/16” SNAP LINK
1/4” QUICK DISCONNECT LINK
3/8 X 3/8” SPACER
3/8” FLANGE SPACER
3/8 X 1” SPACER
QTY
1
8
12
11
2
1
2
2
6
1
1
2
1
2
6
1
DESCRIPTION
BASE
UPRIGHT
STAND
CROSSBRACE
CARRIAGE
LATBAR
LOW ROW BAR
3/16 X 1-3/4 X 5-1/4” PLATE
CABLE
1 X 8” GRIP
3-1/2” PULLEY
2-1/2 X 5-1/2” NON-SKID STRIP
2” SQ. END CAP
2” SQ COVER CAP
3 X 2” END CAP
17-1/2” FOAM STRIP
KEY
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32

FIGURE 1
STEP 1:
• SECURELY assemble the one 3/8 X 2-3/4” BOLT(25),two3/8”WASHERS (19), and one 3/8” LOCK NUT(20) to the STAND(3)as
shownin FIGURE 1.
• Assemble two 2” SQ. COVER CAPS (14) onto the ends of the STAND (3) as shown in FIGURE 1.
• Insert two 3 X 2” END CAP (15) into the ends of the BASE (1) as shown in FIGURE 2.
FIGURE 2
STEP2:
3/8X2-3/4” 25 19
14
15
20
1
3
13
• Assemble one 2” SQ. END CAP(13) into the end of the STAND (3) as shown in FIGURE 1.
5

6
FIGURE 4
STEP3:
• Assemble one 17-1/2” FOAM STRIP (16) to the underside of the CROSS BRACE (4) as shown in FIGURE 3.
• Assembletwo2-1/2 X 5-1/2” NON-SKID STRIPS (12)totheCROSS BRACE (4) as shown inFIGURE3.
FIGURE 3
STEP4:
• SECURELYattachone1-1/4” SQ.RUBBERBUMPER (17)tothe CARRIAGE (5)asshown inFIGURE4.
• Insert two 2” SQ. END CAPS (13) into the ends of the CROSS BRACE (4) as shown in FIGURE 3.
16
12
4
18
5
17
13
• Attach eight 1 X 1” GLIDES (18) to the ends the CARRIAGE (5) as shown in FIGURE 4 using the following steps:
• Thoroughly clean all surfaces where the 1 X 1” GLIDES (18) are to be attached.
• Remove the 1 X 1” GLIDES (18) from the paper backing and firmly apply them to all shown surfaces.
0123456
1/2 1/2 1/2 1/2 1/2 1/2

7
STEP5:
FIGURE 5
• SlidetheCARRIAGE(5)overthe UPRIGHT (2) as
shownin FIGURE 5.
• Assemble the STAND (3) to the UPRIGHT (2) as
shownin FIGURE 5.
1
3
5
2
• Assemble the BASE (1) to the UPRIGHT (2) as
shownin FIGURE 5.

STEP6:
FIGURE 6
• SECURELYassemble the BASE (1) to the UPRIGHT (2) using one 1/2 X 3” BOLT (27), two 1/2”WASHERS (21) (slide frontwasher
INSIDEoftube),andone1/2”LOCKNUT(22). SeeFIGURE 6.
• Insert one 3 X 2” END CAP (15) and one 2” SQ. END CAP (13) into the ends of the UPRIGHT (2) as shown in FIGURE 6.
• SECURELYassembletheCROSS BRACE(4) to theUPRIGHT(2)using two3/8X 2-3/4”BOLTS(25),two 3/8”WASHERS(19),and two
3/8”LOCKNUTS (20).SeeFIGURE6. 8
27 1/2 X 3”
3/8X 2-3/4” 25
21
20
19
22
21
1
15
13
4
2

9
STEP7:
FIGURE 7
• Route the CABLE (9) through the UPRIGHT (2) as shown in FIGURE 7.
• SECURELYassemblethree3-1/2” PULLEYS(11)intotheslotsoftheUPRIGHT(2)using three3/8 X2-3/4”BOLTS(25),six3/8”FLANGE
SPACERS(31),andthree 3/8” LOCK NUTS (20) asshowninFIGURE 7.(NOTE:Makesurethecableisroutedoverallthepulleys.)
3/8X 2-3/4” 25
2
9
31
20
11

10
STEP8:
FIGURE 8
23 3/8 X 2”
19
19
20
9
8
29
2
5
• Place one 3-1/2” PULLEY (11) into the loop of the CABLE (9) below the second and third PULLEY of the UPRIGHT (2) as shown in
FIGURE8.
• LOOSELY assembletwo 3/16 X 1-3/4 X 5-1/4” PLATES(8)toeachsideofthe3-1/2”PULLEY(11) using one 3/8 X 2” BOLT(23),
two3/8”WASHERS(19),andone 3/8” LOCKNUT(20).SeeFIGURE 8.
• AttachtheCABLE (9) from the UPRIGHT (2) totheCARRIAGE(5) using one 1/4” QUICK LINK (29)asshownin FIGURE 8. (IMPOR-
TANT!SecurelytightenQUICKLINK.)
11
SECURELY
TIGHTEN!
0123456
1/2 1/2 1/2 1/2 1/2 1/2

11
STEP9:
FIGURE 9
23 3/8 X 2”
19
19
20
9
11
2
• Route the end of the second CABLE (9) through the slot on the UPRIGHT (2) then SECURELYassemble one 3-1/2” PULLEY (11) to
theUPRIGHT(2)usingtwo3/8X2-1/2”BOLTS(24), two3/8X3/8”SPACERS(30),four3/8”WASHERS(19),andtwo3/8”LOCKNUTS
(20).(NOTE:TheCABLE(9)shouldberoutedbetweenthepulleyandtheretainingboltasshowninFIGURE9.)
• LooptheCABLE(9)around one 3-1/2” PULLEY (11) as shown in FIGURE 9.
• LOOSELYassemble the3-1/2” PULLEY(11)tothe3/16X1-3/4 X5-1/4” PLATES(8) usingone3/8X2”BOLT(23),two 3/8”WASHERS
(19),and one 3/8” LOCKNUT(20). SeeFIGURE9.
• SECURELYtightenthetwo3/8 X 2” BOLTS (23) ofthe3/16X 1-3/4 X 5-1/4” PLATES (8).
24 3/8 X 2-1/2”
20
19
30
11
8

12
STEP10:
FIGURE 10
• SECURELYassembletheCABLE(9) to theBASE(1)using one 3/8X4-1/2” BOLT(26),one3/8 X 1”SPACER(32),and one 3/8” LOCK
NUT(20)as shown inFIGURE10.
9
26 3/8X 4-1/2”
1
32
20
01234
1/2 1/2 1/2 1/2

13
STEP11:
FIGURE 11
• Attach the LAT BAR (6) to the ball end of the upper CABLE (9) using one 5/16” SNAPHOOK (28) as shown in FIGURE 11.
• Attach the LOW ROW BAR (7) to the ball end of the lower CABLE (9) using one 5/16” SNAP HOOK (28) as shown in FIGURE 11.
• Slidetwo 1 X 8” GRIPS(10) on the LOWROWBAR(7)andtwo 1 X 8” GRIPS (10) on the LATBAR (6) asshown in FIGURE11.
7
28
28
9
6
10
9
10

STEP12:
FIGURE 12
• Tilt the 848101 back and remove the STAND (3) as shown in FIGURE 12.
• Tousethe848101 LATOPTION:(NOTE:LATOPTIONMUSTBEUSEDWITHABENCH.LATOPTION CANNOTBE USED
WHILESTANDISATTACHED.STANDMUSTBEATTACHEDWITHTHEFEETOUTASSHOWN.)
14
3
0123456
1/2 1/2 1/2 1/2 1/2 1/2

Thankyouforpurchasingthe Parabody848LATOPTION.Ifunsureof properuseofequipment,callyour
localParabodydistributor or call the Parabodycustomerservice department at [phone].
BENCH
2
STEP13:
FIGURE 13
• Insert the UPRIGHT (2) of the 848 into the bench as shown in FIGURE 13.
15

MAINTENANCE
MODEL #________________________
SERIAL #_________________________
DATE OF PURCHASE: _____________
DEALERS NAME: _________________
DEALERS PHONE #_______________
16
* We recommend cleaning your product (pads and frame) on a regular basis, using warm soapy
water. Touch-up paint can be purchased from your ParaBody customer service representative
at [phone].
* Inspect equipment daily. Tighten all loose connections are replace worn parts immediately.
Failure to do so may result in serious injury
* Lubricate guide rods with a teflon based (or equivalent) lubricant on a regular basis
Thankyouforpurchasingthe ParaBodyXXX GymSystem.
Please note:
* PLEASE RECORD THE INFORMATION REQUESTED BELOW. IN THE EVENT
YOU MAY NEED SERVICE YOU WILLBEASKED FOR THIS INFORMATION.
REMEMBER TO FILL OUT YOUR WARRANTY REGISTRATION CARD AND
MAIL BACK.

17
NOTES:
LIMITED WARRANTY
ParaBodyextends the followingLIMITED WARRANTYto the original owner of the ParaBody products.The Warranty terms apply toIN HOMEUSE ONLY.
1. LIMITEDWARRANTYONFRAMEAND WELDS. Ifthe frameof theParaBody productor a weld should crack or break,it willbe repaired
or replaced by ParaBody. Terms: Lifetime – for so long as the Customer owns the ParaBody product.
2. LIMITEDWARRANTYON PARTS. Ifthe followingpartsaredefective inmaterial or workmanship,ParaBody willsupply replacementparts:
all bolts, nuts, washers, bearings, bushings, pulleys, thumbscrews, collars, cable retaining clips, adjustable pre-stretch slides, roller pad
shafts, allen head bolts, weight selector pin, weight stack shaft, set screws, protector caps, adjustment chain, cotter pin, plunger, spring
and knob. Terms: Lifetime – for so long as the Customer owns the ParaBody product.
3. LIMITED WARRANTY ON CABLES AND UPHOLSTERY. If the coated cables or upholstery are defective in material or workmanship,
ParaBody will repair or replace them, at its option. Terms: Three (3) years.
4. CONDITIONSAND EXCEPTIONS. Any product misuse, abuse or alteration, any attempt to repair by a person other than an authorized
ParaBody Service Center, any improper assembly, accident, or any other condition resulting from occurrences beyond the control of
ParaBody will void this Limited Warranty.
5. REPLACEMENTAND REPAIR EXPENSES. ParaBody will provide only replacement parts or repair under this warranty. The Owner is
responsiblefor allother costs. Suchcosts mayinclude, butare notlimited to: a. labor charges for service, removal,repair or reinstallation
ofthe ParaBody productor anycomponentpart; b.shipping, delivery,handling andadministrativecharges forreturningparts toParaBody;
and c. all necessary or incidental costs related to installation of the replacement parts.
6. SHIPPING. If shipping bythe Ownersis deemednecessary (insole discretionof ParaBody), partsshould beshipped intheir originalcarton
orequivalent packaging,fully insuredwith shippingcharges prepaid. ParaBodywill notassume anyresponsibility forany lossor damage
incurredin shipping.
7. CLAIM PROCEDURES. If service onyour ParaBodyproduct isrequired during the warranty period,please contactour CustomerService
Departmentat1-800-328-9714for instructionsregardingreturningor replacing parts. Pleasehaveavailablethe followinginformation: (i)the
dealer’s name; (ii) the date of purchase; (iii) the serial # (s) of your product (the serial number location is called out on the final assembly
drawingincluded with your assembly instruction);(iv) a description of thenature ofthe problem.
8. OWNER’S RIGHT. ThisLimited Warrantygivesyou specificlegal rights. You mayalsohave otherrights,which varydepending onlocallaw.
9. LIMITATION OF IMPLIED WARRANTIES. All implied warranties, except to the extent prohibited by applicable law, shall have no greater
duration than the warranty period set forth above. There are no warranties which extend beyond the description inthis Limited Warranty.
Because local laws do not allow limitations on how long an implied warranty lasts, the above limitations may not apply to you.
10. DISCLAIMER. No otherexpress warrantyhas been made or willbe madeon behalf of ParaBody withrespect toany ParaBody productor
the operation, repair or replacement of any ParaBody product. ParaBody shall not be responsible for injury, loss of use of the ParaBody
product,inconvenience, lossor damage to personal property,whether director indirect,and incidental or consequential damages,so the
above limitation or exclusion may not apply to you.

INTERNATIONALOFFICES
LifeFitnessAtlanticBV
AtlanticHeadquarters
Bijdorpplein 25-31
2992LBBarendrecht
The Netherlands
Phone: [phone]
Fax: [phone]
LifeFitness Japan
8/F, Nippon Brunswick Building
5-27-7Sendagaya
Shibuya-Ku, Tokyo 151-0051
Japan
Phone: [phone]
Fax:[phone]
LifeFitness(UK) Ltd.
QueenAdelaide
Ely,CambsCB74UB
United Kingdom
Phone CSS: [phone]
Fax CSS: [phone]
LifeFitnessBenelux N.V.
Bijdorpplein 25-31
2992LBBarendrecht
The Netherlands
Phone: [phone]
Fax: [phone]
LifeFitness
14150 Sunfish Lake Blvd. Ramsey Minnesota, 55303 U.S.A.
Tel: [phone] Fax: [phone]
800.328.9714 (Toll-free within the U.S. and Canada)
www.parabody.com
18
LifeFitnessEUROPE GmbH
Siemensstrasse 3
85716Unterschleissheim
Germany
Phone: [phone]
Fax: [phone]
LifeFitness Italia S.R.L.
Via Elvas 92
39042Bressanone
Italy
Phone: [phone]
Fax: [phone]
LifeFitnessAsiaPacific Limited
Room 2610, MiramarTower
132 Nathan Road,Tsimshatsui
Kowloon, Hong Kong
Phone: [phone]
Fax: [phone]
LifeFitnessDoBrazil
Al. Rio Negro, 433-Predio 2-Sala 2
3ºandar (Confab)
Aplhaville-Barueri-Sao Paulo
CEP: 06454-904
Brazil
Phone:[phone]
Fax:[phone]
